Suncast ML200 User manual

OWNER'S MANUAL ML200
STORAGE TRENDS METAL STORAGE LOCKER
'Pt"'Pt"'Pt"' •'Pt"' •' •' •"I
.Aj Top Panel Bjj Left Side Panel Side Panel BRigh Back Panel pj Bottom Panel
0630189 1 PC 0630186 1 PC 0630187 1 PC 0630188 1 PC 0630190 1 PC
Door Panel
IShelf
:; Door Handle Magnet
sCaster
0630191 1 Pc 0630194 2 cs 0630192 1 PC 0630193 1 PC 0630181 4 PCS
Caster Bushing
(Comes installed in
Bottom Panel D)
Truss Head
M4. 2 l3mm-AB 5] Flat Head
Socket Cap
M6 x 1.0 x 25mm
Phillips Pan Head
M4 x 7 x 4mm N_j Truss Head
M2.9 x 1 x l3mmAB
0630182 4PCS 0630183 iocs 0630161 4PCS 0630196 2PCS 0630195 2PCS
0] 5/32 Wrench
© 2004 Suncast Corporation H Patents Pending 0660016
IMPORTANT:
Follow Instructions listed below in the proper sequence as
numbered to assure fast, easy and correct assembly. This product
contains parts that can be damaged if incorrectly assembled
Before assembling, please count your parts and hardware as
listed below.
Do not fully tighten screws until the product is fully assembled.
REPLACEMENT PARTS ORDERING INSTRUCTIONS:
Call Suncast for pricing information. Call 800-846-2345 or 630-879-
2050. Monday-Friday 8:OOam-4:30pm Central Time (except holidays).
Or see www.suncast.com
0630009 1 PC
For
Information on
icast products and
replacement parts see
www.suncast.com

1. Attach Side Panel (BR) to Bottom
Panel (D), by lining up Side Panel
(BR) tab with tab receptacle in
Bottom Panel (D) then connecting
with screws (L).
Attach Side Panel (BL) to Bottom
Panel (D) using screws (L).
2. Attach Top Panel (A) to Side Panels
(BL) & (BR) in front left corner and front
right corner using screws (K) K
0660016
A
3. Attach Back Panel (C) to Side Panels
(BL) & (BR), Top Panel (A), and Bottom
Panel (D) using screws (K).
C

4. Place locker on its top and push Casters
(I) into caster bushing holes in Bottom
Panel (D).
5. Insert Shelf (F) into locker at an angle,
then place one side on one set of shelf
brackets provided on Left Side Panel
(BL).
6. With Shelf (F) inside locker and resting
on one set of shelf brackets, lower
opposite side of shelf onto coresponding
shelf brackets.
Repeat steps 5 and 6 for second shelf.
Bushing Hole
0660016

7. Place Magnet (H) on Left Side
Panel (BL), and attach with Screw
(N).
8. Align Door Handle (G) with the
holes in Door Panel (E). Attach Door
Handle (G) with Screw (M).
9. Align top and bottom hinge of
Door (E) with top and bottom hinge
receptacles on unit. Slide Door
down to engage hinges.
M
