Sunjoy Elworth L-GZ236PAL User manual

1
Our clear, easy to follow, step by step instructions will guide you through the project from
start to finish. Feel confident that this will be a fun and rewarding project. The final product
will be a quality piece that will go together smoothly and give years of enjoyment.
Item Identification: For ease of identification, all parts are labeled to correspond to the
Step number in which the part is used.
A hammer and a ladder (more than 2.5m) are needed.
Assembly Instructions
10’X12’ Elworth Gazebo
Item# L-GZ236PAL

2
Long décor beam (1) A 2
Long décor beam (2) B 2
Short décor beam (1) C 2
Short décor beam (2) D 2
Corner mandril connector (1) E1 2
Corner mandril connector (2) E2 2
Long top bar connector F 2
Short top bar connector G 2
Décor beam connector H 4
Long slanting bar I 4
Short top bar J 2
Long top bar K 2
Top connector L 1
Small top connector M 1
Small top pole N 4
Pothook O 1
Long netting track pole P 4
Short netting track pole Q 4
Post R 4
Post connector R1 4
Post base S 4
Connect piece U 4
Support bar U1 8
Parts List

3
AA M6X15 bolt
TBZ00306015HQ 24 PCS
BB M6 flat washer
TBZ10406HQ 40 PCS
CC M6X15 bolt
TBZ00106015HQ 16 PCS
W1 M6, M8 wrench 2 PCS
Hardware Pack 1
Mosquito net V 1
Small canopy W 1
Large canopy X 1
Wall Y 1
Parts List
Fig.1: Fix the netting track pole (P,Q) on décor beam (A,B,C,D) with bolt (AA) and flat washer (BB).
Fig.2: Insert décor beam D (B) into décor beam C (A), screw them with bolt (AA) and flat washer (BB) on
top. Fix the top bar connector G (F) on décor beam with bolt (CC) and flat washer (BB).
Fig.3: Connect décor beam A (C), D (B) and Corner mandril connector E1 (E2) with bolt (CC) and flat
washer (BB).

4
BB M6 flat washer
TBZ10406HQ 20 PCS
CC M6X15 bolt
TBZ00106015HQ 16 PCS
DD M6X35 bolt
TBZ00306035HQ 4 PCS
EE M6 nut
TBZ20106HQ 4 PCS
Hardware Pack 2
Fig.4: Install Pothook (O) on Top connector (L). Insert Long slanting bar (I), Short top bar (J) and Long top
bar (K) into Top connector (L). (Here need one person support the Top connector L).
Fig.5: Insert Long slanting bar (I) into Corner mandril connector E1 (E2).
Fig.6: Insert Short top bar (J) into Short top bar connector (G). Insert Long top bar (K) into Long top bar
connector
(
F
)
.
Fig.7: Insert Small top pole (N) into Small top connector (M).
Fig.8: Put Large canopy (X) on big top, do not spread. Install the assembled small top on Long slanting
bar (I) with bolt (DD), flat washer (BB) and nut (EE). Put the small canopy (W) on small top, and tighten it.
Fig.9: Install Décor beam connector (H) on 4 corners of décor beam with bolt (CC), flat washer (BB).

5
AA M6X15 bolt
TBZ00306015HQ 36 PCS
BB M6 flat washer
TBZ10406HQ 36 PCS
FF M8X50 bolt
TBZ00108050HQ 8 PCS
GG M8 nut
TBZ20108HQ 8 PCS
HH M8 flat washer
TBZ10408HQ 16 PCS
II Plastic hanger 112 PCS
JJ Φ6*180MM peg
TBZ10608260HQ 12 PCS
Hardware Pack 3

6
Now, your Gazebo is ready for use.
Fig.14 & Fig.14-1: Hang Wall (Y) on inside Netting track pole P (Q) with Plastic hanger (II). (Please noted
walls should wrap the support bars (U1) and posts.) Fix the wall ties on the frame corner as Fig.14-1.
Fig.15 & Fig.15-1: Hang Mosquito net (V) on outside Netting track pole P (Q) with Plastic hanger (II). Fix
the netting ties on the frame corner as Fig.15-1.
Hang the large canopy hooks into the hole on the corners of décor beam.
Fig.16: Fix the assembled gazebo with Peg (JJ).
Fig.10: Fix Post base (S) on the end of post (R) with bolt (AA) and flat washer (BB).
Fig.11: Fix Post connector (R1) on the top of post (R) with bolt (AA) and flat washer (BB).
Fig.11-1: Lift the whole top, put Décor beam connector (H) on Post connector (R1). Put Connect piece
(U) on décor beam connector (H), fix them with bolt (FF), flat washer (HH) and nut (GG).
Note: 4 people are needed for Fig.11-1.
Fig.12 & Fig.12-1: Fix the flat end of support bar (U1) on post (R) with bolt (AA) and flat washer (BB) as
Fig.12, fix another end of support bar (U1) on the inside décor beam as Fig.12-1.
Fig.13: Spread Large canopy (X), hang the hook (pre-assembled on the canopy) into the hole on décor
beam. (Do not hang the hooks at the four corners.)
Fig.14-1 (look down from roof) Fig.15-1 (look down from roof )

7
Important:
1. When assembling and using this product, basic safety precautions should always be followed to reduce the
risk of personal injury and damage to equipment. Please read all instructions before assembly and use.
2. Some parts may contain sharp edges, wear protective gloves if necessary. At least two or more people are
recommended for safe assembly.
3. Keep all children and pets away from assembly area.
4. At least 6 feet from any obstruction such as fence, garage, house, overhanging branches, laundry line or
electrical wires.
5. Do not use the unit during an electrical storm, as there is a remote chance of getting struck by lightening.
6. Do not leave the gazebo assembled when there is a risk of high wind, as possible damage will occur to the
structure. Remove fabric roof and secure screen & privacy panels to poles.
7. Install on level surface.
8. Never barbecue under this gazebo or use lanterns that have open flames.
9. This package contains small items and plastic bags that should be kept away from children.
10. Check all nuts and bolts for tightness before and during usage. Ensure that all connectors and poles are
firmly secured in position fully. It is important to do so before use so as to avoid a possible collapse or damage
to the item, which could also result in injury.
11. This gazebo is intended for decorative and sunshade purposes only and is not meant to withstand
extreme weather conditions including high winds, torrential rain and snow. Gazebo fabric is water resistant,
not water proof and may leak during exposure to precipitation.
Warnings:
1. Assembly Instructions must be followed.
2. Pegs and ropes supplied must be used to hold this gazebo in place when upright.
3. Warranty does not cover damage due to extreme weather conditions.
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC.
This tent meets the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact
with any flame source. The application of any foreign substance to the tent fabric may render the
flame-resistant properties ineffective.
This unit is heavy. Do not assemble this item alone.
Limited Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials and
workmanship of your item provided the item is maintained with care and used only for personal, residential
purposes.
The item is warranted to be free from defects in material or workmanship for a period of 6 months. If any
defect is found, please call our customer service department at 1-866-578-6569 for help. The manufacturer
will not cover transportation or delivery costs, or compensate the individual or any outside party for
assembling or disassembling the product. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Please do not return this product to the store. For technical assistance on assembly or
replacement parts call Sunjoy Industries at 1(866) 578-6569 from 8:30 AM to 5:30 PM EST or
Email [email protected] or fax your parts replacement order form together with your
purchase receipt to 1 [phone] for assistance.
