Target windham WNSIDTBLRD User manual

>>
© 2019 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
windham
side table
assembly instructions
style # WNSIDTBLRD (red)
dpci # 249-16-0739
tcin # 14122477
style # WNSIDTBLGY (gray)
dpci # 249-16-0727
tcin # 14373267
style # WNSIDTBLWH (white)
dpci # 249-16-0718
tcin # 14372250
style # WNSIDTBLBL (teal)
dpci # 249-16-0729
tcin # 14373230

2
Congratulations on your latest Target purchase.
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck—though we’re condent you won’t need it.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Read through and review assembly steps.
4. Gather all tools prior to assembly.
tools needed

3
table of contents
introduction 2
hardware 4
parts list 5
how to use the cam lock system 6
assembly 7-12
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.

hardware
(H1) x 12
wooden dowel
(H2) x 14
cam bolt
(H3) x 14
cam
(H4) x 8
at head screw
(H5) x 1
knob bolt
(H6) x 1
knob

5
exploded diagram
ITEM DESCRIPTION QUANTITY
A top panel 1
B right side panel 1
C left side panel 1
D back panel 1
E shelf 1
F drawer face 1
G drawer bottom 1
H drawer back 1
I drawer right side 1
J drawer left side 1
K top trim 1
L bottom trim 1

how to use the cam lock system
1.
Screw cam bolt into panel
2.
Align cam bolt(s) with cam(s)
and insert all the way into
cross-bored hole(s)
3.
Push cam into panel - arrow feature
on cam top points to panel edge
4.
Rotate cam(s) clockwise 180° to
lock panels together
5.
Panels should be tight against each
other and connection should be rigid
6
1. 2. 3.
4. 5.

step 1: attach shelf/back panel/bottom trim/top trim to left side panel
(H1) x 4
wooden dowel
(H2) x 5
cam bolt
(H3) x 5
cam
1.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
1.2. Screw-In cam bolts must be screwed down ush.
1.3. Refer to page 6 for instructions on how to use the cam lock system.
1.4. Do not over tighten bolts.
7
Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.

step 2: attach right side panel
(H1) x 4
wooden dowel
(H2) x 5
cam bolt
(H3) x 5
cam
2.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
2.2. Screw-In cam bolts must be screwed down ush.
2.3. Refer to page 6 for instructions on how to use the cam lock system.
2.4. Do not over tighten bolts.
8
Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.

step 3: attach top panel
(H1) x 4
wooden dowel
(H2) x 4
cam bolt
(H3) x 4
cam
3.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
3.2. Screw-In cam bolts must be screwed down ush.
3.3. Refer to page 6 for instructions on how to use the cam lock system.
3.4. Do not over tighten bolts.
9

step 4: attach drawer left and right sides to drawer face
(H4) x 4
at head screw
4.1. Align screws with pre-drilled holes.
4.2. Do not over tighten screws.
10

11
step 5: attach drawer bottom, drawer back and knob
(H4) x 4
at head
screw
(H5) x 1
knob bolt
(H6) x 1
knob
5.1. Align screws and bolt with pre-drilled holes.
5.2. Do not over tighten screws and bolt.

12
step 6: install drawer

1. This unit has been designed for the weight shown. Exceeding this recommended weight could result in
excessive “sagging” of the top. Extreme overloading can cause failure of the top and possible injury.
2. Furniture Care Instructions: Dust with a clean, lint-free cloth. Use a spray furniture polish as needed.
13
30 lbs.
QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPCI number ready when calling.
