Technogym SKILLRUN UNITY 5000 User manual

SKILLRUN UNITY 5000
- SKILLRUN UNITY 7000
- SKILLRUN TX 500
(DJJ)
Pre-Installation Requirements
Rev: 2.0
Date: 2019-02-10

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 3 -
Index
1. GENERAL WARNINGS ........................................................................................7
2. NETWORK DESIGN – CONFIGURATION AND INSTALLATION........................9
2.1 NETWORK DESIGN AND INSTALLATION ...................................................................9
2.2 CONFIGURATION AND INSTALLATION ......................................................................9
3. DISPLAY ............................................................................................................. 11
3.1 SKILLRUN UNITY 5000 / 7000 ................................................................................... 11
3.2 SKILLRUN TX 500....................................................................................................... 11
4. ELECTRICAL AND TECHNICAL DATA / REQUIREMENTS .............................13
4.1 DATA & REQUIREMENTS...........................................................................................13
4.2 OVERALL DIMENSIONS OF EQUIPMENT ................................................................14
4.2.1 SKILLRUN UNITY 5000 / 7000...............................................................................14
4.2.2 SKILLRUN TX 500 ..................................................................................................15
4.3 ELECTRICAL CONNECTION......................................................................................15
4.4 CONNECTION TO ANOTHER DEVICE......................................................................16
4.5 POSITIONING OF POWER SUPPLY SOCKET AND LAYOUT OF CABLES .............17
4.6 POSITIONING OF POWER INLET .............................................................................20
5. NETWORK REQUIREMENTS ............................................................................21
5.1 INTRODUCTION .........................................................................................................21
5.2 FREEZING UNITY DUE TO A WRONG LAN NETWORK SETUP (ONLY FOR SKILL-
RUN UNITY 5000 / 7000) ............................................................................................21
5.3 ETHERNET CABLED NETWORK (ONLY FOR SKILLRUN UNITY 5000 / 7000).......21
5.4 WI-FI NETWORK REQUIREMENTS...........................................................................21
5.5 WIRELESS GUIDELINES ...........................................................................................22
5.6 MAXIMUM NUMBER OF EQUIPMENT CONNECTED TO ONE ACCESS POINT ....23
5.7 INTERNET CONNECTION BANDWIDTH REQUIREMENTS (ONLY FOR SKILL-
RUN UNITY 5000 / 7000) ............................................................................................23
5.8 INTERNET CONNECTION BANDWIDTH REQUIREMENTS (ONLY FOR SKILLRUN
TX 500) ........................................................................................................................25
5.9 FIREWALL / ROUTER RULES FOR ACCESS TO MYWELLNESS CLOUD SERVIC-
ES ................................................................................................................................27
5.10 PROXY (ONLY FOR SKILLRUN UNITY 5000 / 7000) ................................................28
6. STANDARD TV TECHNICAL SPECIFICATIONS (ONLY FOR SKILLRUN UNITY
5000 / 7000) ........................................................................................................29
6.1 INTRODUCTION .........................................................................................................29

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 4 -
6.2 VIRTUAL LAN..............................................................................................................30
6.3 LAN..............................................................................................................................30
6.4 UNITY 3.0 - VERSION (-T) STANDARD OPTIONS ....................................................31
6.4.1 RANGE OF FRAMERATE AND BITRATE OF DVB-T HD VIDEO STREAM ..........33
6.5 UNITY 3.0 - VERSION (-A) STANDARD OPTIONS - USA/CANADA..........................33
6.6 UNITY 3.0 - VERSION (-I) STANDARD OPTIONS - JAPAN.......................................36
7. SKILLRUN CLASS REQUIREMENTS (ONLY FOR SKILLRUN UNITY 5000 /
7000) ...................................................................................................................39
8. ACKNOWLEDGEMENT AND ACCEPTANCE ...................................................41
9. LIST OF CHANGES FOR MANUAL REVISION.................................................43
9.1 REVISION 2.0..............................................................................................................43

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 5 -
The information in this manual is intended for QUALIFIED TECHNICAL PERSONNEL - designated
by the customer - who are in charge of preparing the electrical and network line, to guarantee the
correct functioning of equipment.
NOTES: This document contains proprietary information that is covered by copyright. All-
rights reserved. No part of this document may be circulated, copied, reproduced or trans-
lated into another language without the prior written consent of Technogym.
Additional information may be included in the After Sales technical documents, available in
the ocial ‘After Sales documents repository’.
The information contained in this document may be changed without prior notication. For
updates, please refer to the ocial ‘After Sales documents repository’.
Technogym® is a trademark owned by Technogym S.p.A.

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 6 -
Blank page

1. GENERAL WARNINGS
This manual includes informative notes with specic meanings:
DANGER: Indicates an imminently hazardous situation which, if not avoided, will re-
sult in death or serious injury. This signal word is to be limited to the most extreme
situations.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may re-
sult in minor or moderate injury. It may also be used to alert against unsafe practices.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result in
death or serious injury.
ATTENTION: Regulation that may lead to damage to the equipment if not complied
with.
Detail regarding the operation in progress.
SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 7 -

Blank page
SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 8 -

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 9 -
2. NETWORK DESIGN – CONFIGURATION AND
INSTALLATION
2.1 NETWORK DESIGN AND INSTALLATION
During the network design and preparation phases, Technogym requests to be put in touch with the
technicians of the company performing the work, in order to obtain and provide technical informa-
tion, so that the network is installed and congured according to the required technical.
Technogym can not be held responsible for failures due to site preparation, assembly and instal-
lation not correct.
2.2 CONFIGURATION AND INSTALLATION
Before performing the installation the customer shall inform Technogym that all the required com-
ponents have been provided and installed and that they operate correctly.
 ATTENTION:Installationandcongurationofthenetworkinfrastructure(cables),of
thenetworkhardware(Switch,Router,rewall)andanywirelessnetworkareatthe
expenseofthecustomer.
 ATTENTION:Technogymwarnsthatthee󰀩ciencyandcorrectoperationoftheequip-
mentandofthemywellnessCloudservicesdependonthetechnicalcharacteristics
ofthehardwarethatisinstalled.
 ATTENTION:Technogymdoesnotguaranteethecorrectoperationofthemywellness
Cloudservicesintheeventoffailuretocomplywithallthetechnicalspecications
andwarningsindicated.

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 10 -
Blank page

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 11 -
3. DISPLAY
3.1 SKILLRUN UNITY 5000 / 7000
The SKILLRUN UNITY 5000 / 7000 is tted with UNITY 3.0 display.
Fig. 1 - UNITY 3.0 display
3.2 SKILLRUN TX 500
The Skillrun TX 500 is tted with TX display (10”).
Fig. 2 - TX display

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 12 -
Blank page

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 13 -
4. ELECTRICAL AND TECHNICAL DATA /
REQUIREMENTS
4.1 DATA & REQUIREMENTS
SKILLRUN (DJJ)
DJJ0E... - DJJAE... DJJ0A... - DJJAA...
Power Supply 200÷240Vac
50/60Hz
100÷240Vac
50/60Hz
Power Requirements “EU” version: 200÷240V
50/60Hz
(It is advisable 16A 250V
dedicated socket for each
machine)
“U” version: 100÷240V
50/60Hz
(It is advisable 20A
125V or 20A 250V
dedicated socket for
each machine)
Peak Motor Power 5800 W (8 Hp) 5800 W (8 Hp)
Maximum user weight in
walking mode
220 Kg (485 lb) 220 Kg (485 lb)
Maximum user weight in run-
ning mode
180 Kg (397 lb) 180 Kg (397 lb)
Speed 100 Vac power supply
maximum power input
-0.2 ÷ 25 Km/h
(0.1 ÷ 15.5 mph)
1800 VA
Speed 120 Vac power supply
maximum power input
-0.2 ÷ 30 Km/h
(0.1 ÷ 18.6 mph)
1800 VA
Speed 200 ÷ 240 Vac power
supply maximum power input
0.2 ÷ 30 Km/h
(0.1 ÷ 18.6 mph)
2000 VA
0.2 ÷ 30 Km/h
(0.1 ÷ 18.6 mph)
2000 VA
Gradient -3% ÷ 25% -3% ÷ 25%
Noise Level Less than 70 dB Less than 70 dB
Protection grade IP 20 IP 20
Operating Temperature from +5°C to +30°C
(from +41°F to +86°F)
from +5°C to +30°C
(from +41°F to +86°F)
Tab. 1
The peak power values refer to a user with a maximum weight of 100Kg.

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 14 -
NOTE: We recommend a dedicated power supply line for each machine.
NOTE: ONLY UK: Recommended 3 x treadmills per ring main with 32amp Type C MCB.
4.2 OVERALL DIMENSIONS OF EQUIPMENT
4.2.1 SKILLRUN UNITY 5000 / 7000
Length 1851 mm - 73”
Width 876 mm - 34”
Height 1683 mm - 66”
Weight of equipment - SKILLRUN UNITY 5000 220 Kg (485 lb)
Weight of equipment - SKILLRUN UNITY 7000 232 Kg (511 lb)
Tab. 2
876 mm (34’’)
1851 mm (73’’)
1683 mm (66’’)
Fig. 3

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 15 -
4.2.2 SKILLRUN TX 500
Length 1835 mm - 72”
Width 876 mm - 34”
Height 1599 mm - 63”
Weight of equipment 216 Kg (476 lb)
Tab. 3
1835 mm (72’’) 876 mm (34’’)
1599 mm (63’’)
Fig. 4
4.3 ELECTRICAL CONNECTION
Before connecting the equipment to the mains power supply, ensure that the electrical system
specications comply with current regulations. Check the mains power supply specications on the
identication label.
WARNING: The wall socket must be located in a place where the plugging and unplugging
can be done easily and safely.
The excess cable must be arranged with specic cable ties / clips.

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 16 -
Fig. 5
The power supply socket must be grounded . If not, a ground connection must be in-
stalled by a qualied electrician before connecting the equipment to the electricity mains.
The product must be grounded.If the unit malfunctions or breaks down, earthing provides a mini-
mum resistance path for electric current thus reducing the risk of electric shock. The product is
equipped with a cable that includes an earth wire and an earthing plug. The plug must be con-
nected to an appropriate socket that is properly installed and earthed in accordance with all local
codes and ordinances.
Fig. 6
WARNING: Improper connection of the earth wire may result in risk of electrical shock. Check
with a qualied electrician or maintenance operator if you are in doubt as to whether the product is
properly earthed. Do not modify the plug provided with the product; if it does not t the socket, have
a suitable socket installed by a qualied electrician.
4.4 CONNECTION TO ANOTHER DEVICE
Use an RF coaxial cable for the connection with an F type of connector for the equipment.
The wall socket of the aerial cable must be positioned so that the plug can be easily inserted and
removed.
WARNING: The devices connected must comply with international standards.

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 17 -
4.5 POSITIONING OF POWER SUPPLY SOCKET AND
LAYOUT OF CABLES
In the SKILLRUN, It is mandatory to correctly arrange the cables (TV + LAN + power cord), pre-
venting the cables from being pinched when the belt is moving and the equipment moves with a
gradient. Moreover, the customer should position the power supply socket as detailed below.
WARNING: The rubbing of the cables with the running surface causes the wear of the plastic
/ insulation protection up to create a short circuit: a potentially dangerous condition for the user.
The following gure shows the compliant positioning of power supply socket with respect to the
equipment and the relative layout of cables (TV + LAN + power cord).
Fig. 7 - Position of power supply socket and cables layout

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 18 -
ATTENTION: It is not recommended to have the power supply socket located below
the Skillrun.
LAYOUT 1 / 4:
ATTENTION: The LAYOUT 1 is the recommended layout.
Fig. 8 - Layout 1 recommended
Layout 4: make sure that the cables are long enough.
LAYOUT 2 / 3:
It is recommended to use a sheath for cables (to be provided by the customer) that guides the
bending of cables. Hereafter an example:
Fig. 9 - Layout 2 / 3 OK

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 19 -
LAYOUT 5:
The following gure doesn’t show a sheath for cables but Its use is recommended (to be provided
by the customer). The cable must follow the following path. If this is not possible, it’s required to
reverse the socket (case of American plug) (to be provided by the customer).
Fig. 10 - Layout 5 OK but the use of a cable sheath is recommended
Fig. 11 - Layout 5 OK but the use of a cable sheath is recommended

SKILLRUN (DJJ) Pre-Installation Requirements
Rev. 2.0
- 20 -
4.6 POSITIONING OF POWER INLET
Fig. 12
