UFO MicroLED 100P Series Specification sheet

PRODUCT USER GUIDE
MicroLED 100P Illuminator
PLEASE READ THIS USER GUIDE BEFORE INSTALLING, OPERATING
OR PERFORMING MAINTENANCE ON THE ILLUMINATOR UNIT
E357731
Rev: C2

Thank you for purchasing this UFO illuminator.
To ensure that the illuminator is set up optimally and gives a long service life, please read this
user guide before installing, operating or performing any maintenance on the unit.
Please keep this user guide for future reference.
MODELS COVERED BY THIS USER GUIDE
UFO MIC 100P-3 [3000K white light]
UFO MIC 100P-4 [4000K white light]
UFO MIC 100P-6 [6000K white light]
INTRODUCTION
MICROLED 100PUSER GUIDE
2
IMPORTANT
This product must be installed in accordance with the applicable installation code, by a person
familiar with the construction and operation of the product, and the hazards involved.
These illuminators are not mains dimmable.
The LED array in this illuminator is not replaceable. When it reaches end of life the whole unit
must be replaced.
Type Y Attachment: If the external flexible cable or cord of this luminaire or associated
PSU/driver is damaged, it shall be exclusively replaced by the manufacturer or his service agent
or a similar qualified person to avoid a hazard.
Location: Do not locate this illuminator closer than 200mm from any flammable surface.
Clearance / Ventilation: It is imperative that a gap of 200mm is le around the unit. This is to
allow air to circulate and prevent overheating. The location must have free ventilation and must
not have an ambient temperature higher than that specified for the luminaire.
Mounting: This luminaire comes with an integral mounting plate for securing the unit to a
vertical or horizontal surface. Refer to the instruction sheet supplied with the plate.
Warning: Never look directly at the luminaire through the fiber port of the illuminator.
Warning: The luminaire should be positioned so that prolonged staring into the
luminaire at a distance closer than 2.7 metres is not expected.

This luminaire is powered by a 12V Power Supply Unit or 12V Constant Voltage Driver. Remove
the PSU/driver from its box.
POWER SUPPLY REQUIREMENTS
Plug the jack plug into the socket in the back, and the illuminator is now ready for connection.
INSTALLATION
3
UFO LIGHTING
This luminaire supplied with a separate mounting plate. If using the mounting plate refer to the
fitting instructions supplied with it.
MOUNTING PLATE

There are 2 connections required - the fiber port and the mains supply. The fiber port should be
connected first. Connect and secure the fiber optic connector into the front of the unit and
secure using the M5 locking screw.
Plug the mains plug into the electrical supply socket. Switch on the power, the LED indicator
will illuminate, and the illuminator will illuminate. If no light is produced consult the
troubleshooting section.
CONNECTION
This illuminator is a static white unit with no control options. Once set up as detailed in the con-
nection section of this manual the unit is ready for use.
OPERATION
INSTALLATION &OPERATION
MICROLED 100PUSER GUIDE
4

MAINTENANCE LOG
Date Maintenance Undertaken
MAINTENANCE
5
UFO LIGHTING

Problem Possible Cause(s) Remedy
Unit is dead LED
power
indicator is not
illuminated
Mains supply offCheck supply and reinstate
Loose mains plugs Check plugs
PSU failed Replace PSU
Unit is dead no
light output but LED
power
indicator is sll
illuminated
LED array failure Replace Light Source
Poor light
output on fiber
Unit needs cleaning
Carefully clean LED Lens
with dry cloth
Clean fiber common end
Fiber port connector not
plugged in correctly
Ensure plugged in correctly
and secured with locking
screw
TROUBLESHOOTING
MICROLED 100PUSER GUIDE
6
NOTES

TECHNICAL SPECIFICATION
7
UFO LIGHTING
Port connector size 30mm diameter
Fiber type Glass / PMMA
Material/Finish ABS (black, silver or white)
Dimensions (L x W x H) 132mm (5.2”) x 98mm (3.8”) x 67mm (2.6”)
Weight 0.3kg
Operang Environment Indoor use IP20
Min Ambient Temp. 10°C
Max Ambient Temp. +45°C
LED Array Type White light
LED Array Power 2W
LED Array Model Cree XLamp XRE
LED Array Life (L70, B10) > 54,400 hours @ 25°C
Warm White Opon 3000K \ 80CRI \ 120lm
Neutral White Opon 4000K \ 75CRI \ 126lm
Cool White Opon 5000K \ 75CRI \ 150lm
Supply Voltage 90264Vac
Mains Running Current 0.03A @ 240Vac
Mains Voltage VA rang 8VA
External PSU Type Power Pax, 12V, 2A, 24W



