MicroLED 4000P Slave Illuminator
PLEASE READ THIS USER GUIDE BEFORE INSTALLING, OPERATING
OR PERFORMING MAINTENANCE ON THE ILLUMINATOR UNIT
E357731
Rev: C1

INTRODUCTION
MICROLED 4000PSLAVE USER GUIDE
2
Thank you for purchasing this UFO illuminator/luminaire.
To ensure that the illuminator is set up optimally and gives a long service life, please read this
user guide before installing, operating or performing any maintenance on the unit.
Please keep this User Guide for future reference. This User Guide is laid out in three sections
Installation -details on how to connect your luminaire
Operation - details how to programme and set up your luminaire
Maintenance - maintenance log, troubleshooting guide, technical specification
MODELS COVERED BY THIS USER GUIDE
UFO MIC4000SL
IMPORTANT
This product must be installed in accordance with the applicable installation code, by a person
familiar with the construction and operation of the product, and the hazards involved.
These illuminators are not mains dimmable.
The LED array in this illuminator is not replaceable. When it reaches end of life the whole unit
must be replaced.
Type Y Attachment: If the external flexible cable or cord of this luminaire or associated
PSU/driver is damaged, it shall be exclusively replaced by the manufacturer or his service agent
or a similar qualified person to avoid a hazard.
Location: Do not locate this illuminator closer than 200mm from any flammable surface.
Clearance / Ventilation: It is imperative that a gap of 200mm is le around the unit. This is to
allow air to circulate and prevent overheating. The location must have free ventilation and must
not have an ambient temperature higher than that specified for the luminaire.
Mounting: This luminaire comes with an integral mounting plate for securing the unit to a
vertical or horizontal surface. Refer to the instruction sheet supplied with the plate.
Warning: Never look directly at the luminaire through the fiber port of the illuminator.
Warning: The luminaire should be positioned so that prolonged staring into the
luminaire at a distance closer than 2.7 metres is not expected.

INSTALLATION
3
UFO LIGHTING
This luminaire is powered by a 12V Power Supply Unit or 12V Constant Voltage Driver. Remove
the PSU/driver from its box. Connect the jack plug into the socket in the back, and the illumina-
tor is now ready for connection.
POWER SUPPLY REQUIREMENTS
This luminaire supplied with a separate mounting plate. If using the mounting plate refer to the
fitting instructions supplied with it.
MOUNTING

There are 3 connections required - the fiber port, the mains supply and the DMX interlink cable.
The fiber port should be connected first. Connect and secure the fiber optic connector into the
front of the unit and secure using the M5 locking screw.
Plug the mains plug into the electrical supply socket. Switch on the power, the LED indicator
will illuminate, and the illuminator will start up automatically. If no light is produced consult the
troubleshooting section.
Finally, if DMX operation is required, connect the DMX interlink cable from the master illumina-
tor or the standalone DMX controller to the slave unit. The MicroLED 4000 SL unit has 2 RJ45
connectors on the rear of the unit - either can be used.
CONNECTION
Connect a DMX interlink cable between one of the RJ45 connectors on the master illuminator
and one of the RJ45 connectors on the slave unit.
The slave will now respond in exactly the same way as the master illuminator when commands
are issued via the master’s remote control unit.
Multiple slave units can be daisychained to a single master using RJ45 terminated cables.
SLAVE OPERATION WITH AMICROLED 4000 MASTER UNIT
INSTALLATION
OPERATION
MICROLED 4000PSLAVE USER GUIDE
4

To use the illuminator in manual standalone mode remove the DMX connector from the RJ45
socket at the rear of the Slave and it will now respond to manual commands from the 2 control
buttons as detailed below.
The illuminator has 2 color cycles, each with 3 dierent speed settings, the colors are
detailed in the table below:
STANDALONE OPERATION USING INBUILT BUTTONS
Cycle Color 1 Color 2 Color 3 Color 4 Color 5 Color 6 Color 7
1 White Red Orange Jade Green Cyan Blue
2Red Orange Jade Green Cyan Blue White
The illuminator is controlled using the 2 push buttons on the rear of the unit.
The lower button stops and starts the color cycle.
The upper button is used to select the cycle speed as follows:
Push the upper button repeatedly until the color white is displayed. The illuminator is now in
Cycle 1 Speed A as detailed in the table below. Each push reduces the speed. On the third push,
the color red will be displayed. The illuminator is now in Cycle 2 Speed A.
At any time the cycle can be stopped on a color and started again using the lower push
button.
Cycle Speed A Fastest Speed B Slower Speed C Slowest
1 (White Start) Push once Push once Push once
2 (Red Start) Push once Push once Push once
OPERATION
5
UFO LIGHTING

To use the Slave in DMX operation connect a DMX Cat5 cable between one of the RJ45 sockets
at the rear of the Slave Illuminator and the Master Illuminator or the DMX Controller- see RJ45
connection details and drawing below. To connect multiple Slave Illuminators connect link Cat5
cables between the spare RJ45 socket on the first Slave Illuminator and a RJ45 socket on the
next Slave Illuminator and so on.
RJ45 connection details are supplied below:
DMX OPERATION
Pin No. 1 2 3 4 5 6 7 8
Color White
Orange Orange White Green Blue White Blue Green White Brown Brown
Funcon DMX+
(Hot)
DMX
(Cold) Spare Spare Spare Spare GND GND
DMX XLR
Equivalent Pin 3 Pin 2     Pin 1 Pin 1
The illuminator is assigned to address 001, which cannot be changed, Each illuminator
occupies 4 DMX channels as detailed below:
Channel Funcon Value Descripon
1 Color Red 0255 From offat 0 to bright at 255
2 Color Green 0255 From offat 0 to bright at 255
3 Color Blue 0255 From offat 0 to bright at 255
4 Color White 0255 From offat 0 to bright at 255
OPERATION
MICROLED 4000PSLAVE USER GUIDE
6

MAINTENANCE LOG
Date Maintenance Undertaken
Note: A record of all maintenance MUST be kept in the table above, indicating what maintenance
was undertaken and when. This MUST be dated for warranty purposes.
MAINTENANCE
7
UFO LIGHTING

Problem Possible Cause(s) Remedy
Unit is dead LED
power
indicator is not
illuminated
Mains supply offCheck supply and reinstate
Loose mains plugs Check plugs
PSU failed Replace PSU
Unit is dead no
light output but LED
power
indicator is sll
illuminated
LED array failure Replace LED unit
Switched offvia remote control unit Recycle power to illuminator or switch on via re
mote control
Poor light
output on fiber
Unit needs cleaning
Carefully clean LED Lens
with dry cloth
Clean fiber common end
Fiber port connector not
plugged in correctly
Ensure plugged in correctly
and secured with locking
screw
Staonary on one
color
Lower buon has been
pressed Press lower buon once
LED driver has failed Replace LED unit
Color cycle cannot
be stopped LED driver has failed Replace LED unit
Slave illuminator
works on standalone
but does not
respond to DMX
DMX cable disconnected or faulty Check DMX link cable connecons 
repair or replace
Master illuminator not sending DMX signal Check master illuminator refer to the relevant
user guide troubleshoong secon
DMX controller not sending DMX signal Check DMX controller
TROUBLESHOOTING
MICROLED 4000PSLAVE USER GUIDE
8

TECHNICAL SPECIFICATION
9
UFO LIGHTING
Port connector size 30mm diameter
Fiber type Glass / PMMA
Material/Finish ABS (black, silver or white)
Dimensions (L x W x H) 137mm (5.4”) x 114mm (4.5”) x 73mm (2.9”)
Weight 0.4kg
Operang Environment Indoor use IP20
Min Ambient Temp. 10°C
Max Ambient Temp. +45°C
LED Array Type RGBW
LED Array Power 25W
LED Array Model Cree XLamp MCE
LED Array Life (L70, B10) > 50,000 hours @ 25°C
Wavelength and
Luminous Flux
Red: 625nm / 45lm
Green: 530nm / 93lm
Blue: 460nm / 12lm
White: 3500K / 120lm
Control Funconality Duplicates MicroLED 4000 Master unit
DMX Funconality Input from MicroLED 4000 Master unit
DMX Channels 1
Supply Voltage 90264Vac
Mains Running Current 0.06A @ 240Vac
Mains Voltage VA rang 14VA
External PSU Type Power Pax, 12V, 2A, 24W
