C9 Meeting Tables + Accessories

2 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Surface(s)
Double Flip Power
Unit (Optional)
Cable Tray
(Optional)
T-Legs*
Support Rails*
*Included only with certain table sizes
Legs
Short Frame
Rails
C9 Meeting Table Basic Components
Long Frame
Rails
Support Rail
Brackets*

Hardware
Top Clip (0001156)#10 x 1/2” Philips
Screw (122815)
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
Tools
Thumbscrew (0000638)
Phillips Drill/Driver Bit 3mm Hex Drill/Driver
Bit
Additional tools such as a 90 Degree Bit and an 18” Extension are helpful for some steps
*No torque or ball bits should be used
Electric Drill
Rail Nut (0001120)

M6-1.0x12mm Low
Profile Cap Screw
(0001140)
4 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Attach Legs to Frame Rails
(A) Insert the legs into the short frame rail and (B) secure using
8 screws (0001140). Repeat this step for the other side.
Note: Start all screws before tightening.
Attach T-Legs to Frame Rails (for Multi-
Piece Tables Only)
(A) Insert the legs into the short frame rail and (B) secure using
8 screws (0001140). Repeat this step for the other side.
1.
a.
b.

M6-1.0x12mm Low
Profile Cap Screw
(0001140)
5 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Attach Leg Assemblies to Long Frame Rails
2.

M6-1.0x12mm Low Profile Cap
Screw (0001140)
6 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Hang the Cable Tray(s)
Loosely install the thumbscrews (0000638) on the outside
of the support rail(s). For multi-piece tops, make sure all the
thumbscrews installed in the support rails are on the same
side. Hang the Cable Tray(s) by inserting the tabs into the slots
in the opposite support rail. Swing the tray(s) up into place and
move sideways until the thumbscrews are fully seated in the
tray’s keyslots. Tighten the thumbscrews.
Position Support Rail Brackets and
Install Support Rails
Rotate the support rail brackets into place along the
frame rails. Position them such that the notch on the
brackets line up with the indicator holes in the rails.
Drop the support rails into place and secure them
from below with 2 screws (0001140) in each end.
Top View Shown
Thumbscrew (0000638)
4.
3.
a.
b.
c.

7 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Connect the Worksurface Pieces
(Multi-piece Tables Only)
Place the worksurfaces on the frame offset from the
center. Push the pieces together and ensure the plastic
spline sits in the grooves on the edge of the pieces.
Install the tite-joints (490006) and tighten them until
the worksurfaces are flush. After the tite-joints are in
place, center the worksurface assembly on the frame.
Attach the Worksurface(s)
Align the worksurface(s) on the frame and ensure
the spacing around the outside is consistent. Push
the top clip (0001156) into the frame rail channel
over one of the existing worksurface inserts. Attach
a screw (0001140) through the top clip into the
worksurface. Repeat for all clips.
Top Clip (0001156)
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
5.
6.

8 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Attach the Power Unit to the Top (Optional)
If a cable tray has been installed, lower it by loosening the
thumbscrews and sliding the tray left or right until it drops.
Raise the power unit up to the worksurface dado and drive
6 screws (122815) to secure the unit in place. If applicable,
connect an HDMI or CAT6 data cable to the female/female
adapters provided.
#10 x 1/2” Philips
Screw (122815)
7.

9 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Cable Channel Assembly (Optional)
Attach Cable Channel
Arrange cables inside the cable channel and make sure the
cords are contained in the “cable area”. Firmly press the cable
channel onto the table leg.
Note: Watson Cable Tower assembly instructions are in a separate
document
Cable Area
Clamping Area
1.

10 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Lock Plate
Tray Cross Bars
Alligator Clip
Mid Mount
Monitor Mount Basic Components
Monitor Mount
Hardware
Hardware Kit Envelope
(0000909)
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
Rail Nut (0001120)
M6-1.0 X 8MM Low
Profile Cap Screw
(0001259)

11 C9 ONE-PIECE MEETING TABLE ASSEMBLY INSTRUCTIONS
Attach Monitor Mount to Table
Align the Monitor Mount the with the holes in the rail nuts and
attach with (4) screws (0001140).
Position Rail Nuts
Rotate the rail nuts into place inside the frame rail channel.
Firmly push them together until the angled surfaces are
touching. Place two sets of rail nuts inside the rail.
Monitor Mount Assembly
M6-1.0 x 12mm Low Profile
Cap Screw (0001140)
Rail Nut (0001120)
2.
1.

12 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Attach Mid Mount and Cross Bars to TV
(A) Secure the Cross Bars to the back of the TV with the Monitor
Mounting hardware kit. Specific hardware and screw placement
will vary based upon TV brand.
(B) Next secure the Mid Mount to Cross Bars with (4) 0001140
M6 screws in the holes shown below.
Note: the ideal Monitor placement is 50mm gap from table
surface to bottom of Monitor.
Attach Tray
Align slotted holes in Tray with holes in Monitor Mount. Attach
with (2) 0001140 M6 x 12mm screws.
M6-1.0 x 12mm Low Profile
Cap Screw (0001140)
M6-1.0 x 12mm Low
Profile Cap Screw
(0001140)
3.
4.

13 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
M6-1.0 X 8MM Low Profile Cap Screw (0001259)
Install Alligator Clip
Using (1) 0001259 M6 x 8mm screw install Alligator Clip at the
bottom of the Monitor Mount
Mount and Secure TV
Route cables into Monitor Mount and out the bottom. Hang TV
on Monitor Mount approximatly 50mm above table surface.
Rotate Lock Plate into top of Monitor Mount. Align hole on lock
plate with hole on Monitor Mount lock tab and secure with (1)
0001259 M6 x 8mm screw.
M6-1.0 X 8MM Low Profile
Cap Screw (0001259)
6.
5.

14 C9 MEETING TABLE & ACCESSORIES ASSEMBLY INSTRUCTIONS
Additional Wiring
After the TV is mounted additional wiring can be routed into the
Monitor Mount by pivoting the TV out. Push the bottom of the
TV to rotate and route cables thru the Monitor Mount.
7.
