WATSON C9 Height Adjustable Desk User manual

ASSEMBLY
V.1.00 08/2020 360.394.1300 watsonfurniture.com
C9 Occasional Table

2 C9 OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Surface
Legs
C9 Occasional Table Basic Components
Frame Rails

Hardware
Top Clip (0001156)
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
Tools
3mm Hex Drill/Driver
Bit
Additional tools such as a 90 Degree Bit and an 18” Extension are helpful for some steps
*No torque or ball bits should be used
Electric Drill

M6-1.0x12mm Low
Profile Cap Screw
(0001140)
M6-1.0x12mm Low Profile
Cap Screw (0001140)
4 C9 OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Attach Legs to Frame Rails
Insert 2 legs into a frame rail and secure them using 8 screws
(0001140). Repeat this step for the other side.
Attach Leg Assembly to Remaining
Frame Rails
Slide the remaining frame rails onto one of the leg
assemblies and secure them with 8 screws (0001140).
Repeat this step for the other leg assembly.
1.
a.
b.
2.

5 C9 OCCASIONAL TABLE ASSEMBLY INSTRUCTIONS
Attach Frame to Top
Place the Top upside down on a soft surface. Place the
frame upside down on the worksurface and align such that
the edges are flush all the way around. Clip the top clips
into the frame rail channel and drive a screw (0001140)
until tight. Repeat for the remaining clips. When complete,
flip the table over.
Top Clip (0001156)
M6-1.0x12mm Low
Profile Cap Screw
(0001140)
3.
