Whalen Kellum WMFP54EC-26GR User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2022-06-16 Rev. 0001-A
Kellum Fireplace TV Stand
Stock # WMFP54EC-26GR
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenstyle.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /

2
1. Please read the Assembly Instructions prior to assembling this product.
2. Remove all hardware from the box and sort by size.
3. Check to see that all hardware and parts are present BEFORE assembling.
4. Ask a friend to assist you with the assembly of this furniture.
5. To avoid damage, assemble the product on a sturdy, level and protective surface.
6. Please wait until all steps are completed before fully tightening bolts.
7. Make sure all bolts and screws are tightly fastened before the unit is used.
SPECIAL NOTE
Please read the instruction sheets completely before assembly. Examine all packaging material
before discarding carton. Remove any remaining staples from the carton before discarding.
Remove all parts from carton and separate into groups as indicated on part list. Please ensure
all parts are included prior to assembly. Use of power tools to complete assembly is not
recommended.
How to adjust the European adjustable hinges on doors
Shipping may cause doors to go out of alignment. If you find that the doors need to be adjusted slightly,
turn the appropriate screw, as illustrated.
1. TO ADJUST DOOR FORWARD OR BACKWARD.
2. TO ADJUST DOOR TO RIGHT OR TO LEFT.
3. TO ADJUST DOOR UP OR DOWN.
G E N E R
A L I NF O R M A T I O N , T I P S A N D T R I C K S
This product is sold with two sets of Tipping Restraint Hardware Kits
. You must install the Tipping Restraint
Hardware between the wall and the console to prevent any accidents or damages. When
properly installed,
this restraint can provide protection against the unexpected tipping of the unit due to small
tremors, bumps or
climbing. The restraint is only a deterrent and is not a substitute for proper adult supervision. Use of tip-
over
restraints may only reduce, but not eliminate, the risk of tip-over.
1
2

3
IMPORTANT
Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-
abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manuals.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED
OFF WITH DAMP CLOTH.
Insert the Dowel at least half-way by tapping lightly with a rubber mallet, IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw the Cam Bolt into the threaded inserts on the panel. Connect both panels together; making sure Cam
Bolt goes into the pre-drilled hole on the end of panel for Cam Lock.
2. Insert the Cam Lock into the pre-drilled large hole on the panel. Make sure the arrow on the face of Cam
Lock faces out and points towards Cam Bolt.
3. Take a Phillips screwdriver and rotate the Cam Lock clockwise to lock the Cam Bolt in place.
4. Plug the Cam Lock Cover into the cross slot of the Cam Lock to conceal the Cam.
You are now ready to assemble the fireplace.
FINAL
13

4
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Top Panel (Qty. 1) B- Upper Side Panel (Qty. 2) C- Upper Front Molding (Qty. 2)
D- Upper Partition Panel (Qty. 1) E- Media Shelf (Qty. 1) F- Left Lower Side Panel (Qty. 1)
G- Right Lower Side Panel H- Left Lower Partition Panel I- Right Lower Partition Panel
(Qty. 1) (Qty. 1) (Qty. 1)
J- Side Back Panel (Qty. 2) K- Middle Crossbar (Qty. 1) L- Middle Trim (Qty. 2)
M- Bottom Panel (Qty. 1) N- Bottom Back Stretcher (Qty. 1) O- Bottom Front Stretcher (Qty. 1)
P- Bottom Front Molding Q- Upper Back Panel R- Door S- Adjustable Shelf
(Qty. 1) (Qty. 1) (Qty. 2) (Qty. 2)

5
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
T- Stop Rail (Qty. 1) Fireplace Insert (Qty. 1) Remote Control with Battery (Qty. 1)
(1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel
(Qty. 43+2 extra) (Qty. 43+2 extra) (Qty. 44+2 extra)
(4) Mending Plate (5) M4 x 38 mm Flat Head Screw (6) M3.5 x 15 mm Flat Head Screw
(Qty. 2) (Qty. 12+1 extra) (Qty. 12+1 extra)
(7) M3.5 x 15 mm Washer Head Screw (8) Shelf Support (9) Cam Lock Cover
(Qty. 32+1 extra) (Qty. 8+1 extra) (Qty. 24+1 extra)
(10) Knob (Qty. 2) (11) Knob Bolt (Qty. 2) (12) Rubber Bumper (Qty. 4+1 extra)
(13) Triangle Metal Plate (Qty. 2) (14) Floor Leveler (Qty. 2) Glue (Qty. 2)
Touch-up Pen (Qty. 1) Tipping Restraint Hardware Kit (Qty. 2)
(Included in plastic bag)
Tools required: Phillips screwdriver and rubber mallet (not provided).

6
Assembly Instructions
NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back
and fully tighten all bolts. This will make it easier during assembly of unit.
1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the designated small holes on the Media Shelf (E), Lower Side
Panels (F and G), Lower Partition Panels (H and I) and Bottom Panel (M) using a Phillips screwdriver.
E
F
G
H
I
2
M
② x 27

7
Assembly Instructions
3. Glue the wood dowels (3) into the designated holes on the Bottom Panel (M), Bottom Stretchers (N and
O) and Bottom Front Molding (P) as shown.
NOTE: It is very important to use a small amount of glue on both ends of dowels and wipe off the
excess glue immediately with a damp cloth.
③ x 14
M
3
P
3
N
O
3
3

8
Assembly Instructions
4. Orient and attach the Bottom Front Stretcher (O) to the Bottom Front Molding (P) using eight 38 mm
Flat Head Screws (5).
O
P
5
5
5
5
⑤ x 8

9
Assembly Instructions
5. Align and attach the Bottom Stretchers (N and O) to the Bottom Panel (M) with six Cam Locks (1).
(Refer to page 3 on Cam Lock system operation supplement).
M
N
OP
1
N
M
① x 6

10
Assembly Instructions
6. Glue the wood dowels (3) into the designated holes on the Lower Side Panels (F and G), Lower
Partition Panels (H and I), Middle Crossbar (K) and Middle Trims (L) as shown.
③ x 18
FG
HI
KLL
3
3
3
3
333

11
Assembly Instructions
7. Orient and attach the Middle Crossbar (K) to the Media Shelf (E) by engaging three Cam Locks (1).
E
K1
① x 3

12
Assembly Instructions
8. Attach one Middle Trim (L) to each Lower Partition Panel (H and I) by engaging two Cam Locks (1).
H
I
L
L
1
1
1
1
x 4

13
Assembly Instructions
9. Using the wood dowels as a guide, firmly press the assembled Lower Partition Panels (H and I) to the
Bottom Panel (M) and fasten them in place with four 38 mm Flat Head Screws (5).
Exercise caution when assembling parts to the base. DO NOT lift the bottom
stretchers (N and P) to prevent any damage or injury to persons.
⑤ x 4
H
I
M
5
55
5
N
P

14
Assembly Instructions
10. Align and attach the Left Lower Side Panel (F) to previous assembly by engaging three Cam Locks (1).
11. Repeat the same procedure with the Right Lower Side Panel (G) at the opposite end.
F
G
N
M
1
1
G
M
N
x 6

15
Assembly Instructions
12. Place the Media Shelf (E) over the inserted Wood Dowels (3) on the vertical panels (F, G, H and I)
properly and fasten them into place by engaging eight Cam Locks (1).
x 8
E
F
H
I
G
1

16
Assembly Instructions
13. Ask for assistance to lift the previous assembly upright.
14. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), Upper Front
Moldings (C) and the top surface of Media Shelf (E) using a Phillips screwdriver.
C
C
E
A
2
② x 16

17
Assembly Instructions
15. Glue the Wood Dowels (3) into the inner holes on the Upper Side Panels (B) and Upper Partition Panel
(D) as shown.
B
D
B
3
3
3
③ x 12

18
Assembly Instructions
16. Orient and attach one Upper Front Molding (C) to one Upper Side Panel (B) by engaging two Cam
Locks (1).
17. Complete this step two times to assemble two Upper Side Panels (B).
C
B
1
x
2
① x 4

19
Assembly Instructions
18. Orient and attach the assembled Upper Side Panels (B) and Upper Partition Panel (D) to the Media
Shelf (E) by engaging six Cam Locks (1).
G
B
B
D
E
1
① x 6

20
Assembly Instructions
19. Align and attach the Top Panel (A) onto both Upper Side Panels (B) and Upper Partition Panel (D) and
fasten them in place by engaging six Cam Locks (1).
G
B
B
D
A
1
① x 6
