1About this document
1.1Function
This operating instructions manual provides all the information you
need for mounting,connection and setup as well as important
instructions for maintenance and fault rectification.Please read this
information before putting the instrument into operation and keep this
manual accessible in the immediate vicinity of the device.
1.2Target group
This operating instructions manual is directed to trained qualified
personnel.The contents of this manual should be made available to
these personnel and put into practice by them.
1.3Symbolism used
Information,tip,note
This symbol indicates helpful additional information.
Caution:If this warning is ignored,faults or malfunctions can
result.
Warning:If this warning is ignored,injury to persons and/or serious
damage to the instrument can result.
Danger:If this warning is ignored,serious injury to persons and/or
destruction of the instrument can result.
Ex applications
This symbol indicates special instructions for Ex applications.
lList
The dot set in front indicates a list with no implied sequence.
àAction
This arrow indicates a single action.
1Sequence
Numbers set in front indicate successive steps in a procedure.
4Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
1About this document
31547-EN-081211

2For your safety
2.1Authorised personnel
Mount and set up the pressure transmitter only if you know the
applicable national regulations and have the appropriate qualification.
You must be aquainted with the regulations and instructions for
hazardous areas,measurement and control technology as well as
electrical circuits because the pressure transmitter is "electrical
equipment"according to EN 50178.Depending on the application
conditions,it is necessary that you have appropriate knowledge,e.g.
concerning corrosive products or high pressure.
2.2Appropriate use
IPT-1*Vers.4.0is a pressure transmitter for measurement of gauge
pressure,absolute pressure and vacuum.
You can find detailed information on the application range in chapter
"Product description".
Operational reliability is ensured only if the instrument is properly used
according to the specifications in the operating instructions manual as
well as possible supplementary instructions.
For safety and warranty reasons,any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer.Arbitrary
conversions or modifications are explicitly forbidden.
2.3Warning about misuse
Inappropriate or incorrect use of the instrument can give rise to
application-specific hazards,e.g.vessel overfill or damage to system
components through incorrect mounting or adjustment.
2.4General safety instructions
This is a high-tech instrument requiring the strict observance of
standard regulations and guidelines.The user must take note of the
safety instructions in this operating instructions manual,the country-
specific installation standards as well as all prevailing safety
regulations and accident prevention rules.
The instrument must only be operated in a technically flawless and
reliable condition.The operator is responsible for trouble-free
operation of the instrument.
During the entire duration of use,the user is obliged to determine the
compliance of the required occupational safety measures with the
current valid rules and regulations and also take note of new
regulations.
Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA 5
2For your safety
31547-EN-081211

2.5Safety approval markings and safety tips
The safety approval markings and safety tips on the device must be
observed.
2.6CE conformity
This device fulfills the legal requirements of the applicable EC
guidelines.By attaching the CE mark,VEGA provides a confirmation
of successful testing.
2.7Fulfillment of NAMUR recommendations
With respect to interference resistance and emitted interference,the
NAMUR recommendation NE 21 is fulfilled.
With respect to compatibility,the NAMUR recommendation NE 53 is
fulfilled.This applies also to the corresponding indicating and
adjustment components.WIKA instruments are generally upward and
downward compatible.
lSensor software for DTM IPT-1*Vers.4.0HART,PA or FF
lDTM IPT-1*Vers.4.0for adjustment software PACTware
lIndicating and adjustment module for sensor software
The parameter adjustment of the basic sensor functions is indepen-
dent of the software version.The range of available functions depends
on the respective software version of the individual components.
The software version of IPT-1*Vers.4.0can be determined as follows:
lvia PACTware
lon the type label of the electronics
lvia the indicating and adjustment module
2.8Safety instructions for Ex areas
Please note the Ex-specific safety information for installation and
operation in Ex areas.These safety instructions are part of the
operating instructions manual and come with the Ex-approved
instruments.
6Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
2For your safety
31547-EN-081211

3Product description
3.1Configuration
The scope of delivery encompasses:
lIPT-1*Vers.4.0pressure transmitter
lDocumentation
-this operating instructions manual
-Operating instructions manual "Indicating and adjustment
module"(optional)
-Supplementary instructions manual "Plug connector for con-
tinuously measuring sensors"(optional)
-Ex-specific"Safety instructions"(with Ex-versions)
-if necessary,further certificates
IPT-1*Vers.4.0consists of the following components:
lProcess fitting with measuring cell
lHousing with electronics,optionally available with plug connector
lHousing cover,optionally available with indicating and adjustment
module
The components are available in different versions.
1
2
3
Fig.1:Example of a IPT-1*Vers.4.0with process fitting G1½Aand plastic
housing
1Housing cover with integrated indicating and adjustment module (optional)
2Housing with electronics
3Process fitting with measuring cell
The type label contains the most important data for identification and
use of the instrument:
lArticle number
lSerial number
lTechnical data
Scope of delivery
Components
Type label
Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA 7
3Product description
31547-EN-081211

3.2Principle of operation
IPT-1*Vers.4.0is a pressure transmitter for use in the paper,food
processing and pharmaceutical industries as well as in water/sewage
water plants.Depending on the version,it is used for level,gauge,
absolute pressure or vacuum measurement.Measured products are
gases,vapours and liquids,also those containing abrasive substan-
ces.
Ameasuring cell with front-flush,abrasion-resistant diaphragm is the
sensor element.The hydrostatic pressure of the product or the
process pressure effects a capacitance change in the measuring cell
via the diaphragm.This change is converted into a respective output
signal and outputted as measured value.
The ceramic measuring cell is also equipped with a temperature
sensor.The temperature value can be displayed via the indicating and
adjustment module or processed via the signal output.
Power supply via the Profibus DP/PA segment coupler.Atwo-wire
cable according to Profibus specification serves as carrier of both
power and digital data transmission for multiple sensors.The
instrument profile of IPT-1*Vers.4.0corresponds to profile specifi-
cation version 3.0.
The GSD (instrument master files)and bitmap files necessary for
planning your Profibus-DP-(PA)communication network are available
from the download section on the WIKA homepage www.wika.com
under "Service".There you can also find the appropriate certificates.In
aPDM environment,an EDD (Electronic Device Description)is also
required to enable the full range of sensor functions (also available as
a download).A CD with the appropriate files can be ordered via e-mail
under [e-mail] or by phone from one of the WIKA
agencies.
The backlight of the indicating and adjustment module is powered by
the sensor.Prerequisite is a certain level of operating voltage.
The data for power supply are specified in chapter "Technical data".
This function is available at a later date for instruments with StEx,
WHG or ship approval as well as country-specific approvals such as
those according to FM or CSA.
3.3Operation
IPT-1*Vers.4.0can be adjusted with different adjustment media:
lwith indicating and adjustment module
lthe Simatic adjustment program PDM
The entered parameters are generally saved in IPT-1*Vers.4.0,
optionally also in the indicating/adjustment module.
Application area
Functional principle
Power supply and bus
communication
GSD/EDD
8Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
3Product description
31547-EN-081211

3.4Packaging,transport and storage
Your instrument was protected by packaging during transport.Its
capacity to handle normal loads during transport is assured by a test
according to DIN EN 24180.
The packaging of standard instruments consists of environment-
friendly,recyclable cardboard.For special versions,PE foam or PE foil
is also used.Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out under consideration of the notes on the
transport packaging.Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt.Ascertained transit damage or
concealed defects must be appropriately dealt with.
Up to the time of installation,the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated,the packages must be stored only under
the following conditions:
lNot in the open
lDry and dust free
lNot exposed to corrosive media
lProtected against solar radiation
lAvoiding mechanical shock and vibration
lStorage and transport temperature see chapter "Supplement -
Technical data -Ambient conditions"
lRelative humidity 20 …85 %
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature
Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA 9
3Product description
31547-EN-081211

4Mounting
4.1General instructions
Make sure that all parts of the instrument in contact with the measured
product,especially the sensor element,process seal and process
fitting,are suitable for the existing process conditions such as process
pressure,process temperature as well as the chemical properties of
the medium.
You can find the specifications in chapter "Technical data"in the or on
the type label.
Select an installation position you can easily reach for mounting and
connecting as well as later retrofitting of an indicating and adjustment
module.The housing can be rotated by 330°without the use of any
tools.You can also install the indicating and adjustment module in four
different positions (each displaced by 90°).
Use the recommended cables (see chapter "Connecting to power
supply")and tighten the cable gland.
You can give your instrument additional protection against moisture
penetration by leading the connection cable downward in front of the
cable entry.Rain and condensation water can thus drain off.This
applies mainly to outdoor mounting as well as installation in areas
where high humidity is expected (e.g.through cleaning processes)or
on cooled or heated vessels.
Fig.2:Measures against moisture penetration
The ventilation of the measuring cell is realised by a filter element in
the socket of the electronics housing.The ventilation of the electronics
housing is realised via an additional filter element around the cable
glands.1)
1)With previous instrument versions,ventilation and pressure compensation
were carried out together via a filter element.
Suitability for process
conditions
Mounting position
Moisture
Ventilation and pressure
compensation
10 Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
4Mounting
31547-EN-081211

1
2
Fig.3:Position of the filter elements
1Filter element for ventilation of the measuring cell
2Filter element for ventilation of the electronics housing
Information:
Make sure that the filter elements are always free of buildup during
operation.Apressure washer must not be used for cleaning.
Higher process temperatures mean often also higher ambient
temperatures.
1
2
Fig.4:Temperature ranges
1Process temperature
2Ambient temperature
Make sure that the upper temperature limits for the environment of
electronics housing and connection cable specified in chapter
"Technical data"are not exceeded.
4.2Mounting steps
To mount IPT-1*Vers.4.0,a welded socket is necessary.Use
components from the line of WIKA mounting accessories:
àNote the applicable welding standards (segment welding proce-
dure)when welding the socket.
Temperature limits
Welding the socket
Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA 11
4Mounting
31547-EN-081211

Use the seal corresponding to the process fitting.Sealing/Screwing in hy-
gienic fittings
12 Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
4Mounting
31547-EN-081211

5Connecting to power supply
5.1Preparing the connection
Always keep in mind the following safety instructions:
lConnect only in the complete absence of line voltage
lIf overvoltage surges are expected,overvoltage arresters should
be installed according to Profibus specifications
In hazardous areas you should take note of the appropriate
regulations,conformity and type approval certificates of the sensors
and power supply units.
Power is supplied via a Profibus DP/PA segment coupler.The power
supply range can differ depending on the instrument version.The
exact range is stated in the "Technical data".
IPT-1*Vers.4.0is connected with screened cable according to the
Profibus specification.Power supply and digital bus signal are carried
over the same two-wire connection cable.
Use cable with round cross-section.Acable outer diameter of 5…9mm
(0.2…0.35 in)ensures the seal effect of the cable gland.If you are
using cable with a different diameter or cross-section,exchange the
seal or use a suitable cable gland.
Please make sure that your installation is carried out according to the
Profibus specification.In particular,make sure that the termination of
the bus is done with appropriate terminating resistors.
In systems with potential equalisation,connect the cable screen
directly to ground potential at the power supply unit,in the connection
box and at the sensor.The screen in the sensor must be connected
directly to the internal ground terminal.The ground terminal outside on
the housing must be connected to the potential equalisation (low
impedance).
In systems without potential equalisation,connect the cable screen
directly to ground potential at the power supply unit and at the sensor.
In the connection box or T-distributor,the screen of the short stub to
the sensor must not be connected to ground potential or to another
cable screen.The cable screens to the power supply unit and to the
next distributor must be connected to each other and also connected
to ground potential via a ceramic capacitor (e.g.1nF,1500 V). The low
frequency potential equalisation currents are thus suppressed,but the
protective effect against high frequency interference signals remains.
The total capacitance of the cable and of all capacitors must not exceed
10 nFin Ex applications.
Note safety instructions
Take note of
safety instruc-
tions for Ex ap-
plications
Select power supply
Selecting connection
cable
Cable screening and
grounding
Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA 13
5Connecting to power supply
31547-EN-081211

Take note of the corresponding installation regulations for Ex
applications.In particular,make sure that no potential equalisation
currents flow over the cable screen.In case of grounding on both sides
this can be achieved by the use of a capacitor or a separate potential
equalisation.
5.2Connection procedure
Proceed as follows:
1Unscrew the housing cover
2If an indicating and adjustment module is installed,remove it by
turning it slightly to the left.
3Loosen compression nut of the cable entry
4Remove approx.10 cm (4in)of the cable mantle,strip approx.
1cm (0.4in)insulation from the ends of the individual wires
5Insert the cable through the cable gland into the sensor
6Lift the opening levers of the terminals with a screwdriver (see
following illustration)
7Insert the wire ends into the open terminals according to the wiring
plan
Fig.5:Connection steps 6and 7
8Press down the opening levers of the terminals,you will hear the
terminal spring closing
Select connec-
tion cable for Ex
applications
14 Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
5Connecting to power supply
31547-EN-081211

9Check the hold of the wires in the terminals by lightly pulling on
them
10 Connect the screen to the internal ground terminal,connect the
outer ground terminal with potential equalisation
11 Tighten the compression nut of the cable entry.The seal ring must
completely encircle the cable
12 Screw the housing cover on
The electrical connection is finished.
5.3Wiring plan,single chamber housing
The following illustrations apply to the non-Ex as well as to the Ex-ia
version.
1 2 3
5
4
55
44
Fig.6:Material versions,single chamber housing
1Plastic
2Aluminium
3Stainless steel
Housing overview
Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA 15
5Connecting to power supply
31547-EN-081211

I²C
Display
1 2 5 6 7 8
3
4
1
2
Fig.7:Electronics and connection compartment,single chamber housing
1Plug connector for service
2Spring-loaded terminals for connection of the external indicating and
adjustment module
3Ground terminal for connection of the cable screen
4Spring-loaded terminals for voltage supply
I2C
Display
1
1 2 5 6 7 8
Fig.8:Wiring plan,single chamber housing
1Voltage supply/Signal output
5.4Wiring plan,double chamber housing
The following illustrations apply to the non-Ex as well as to the Ex-ia
version.
Electronics and connec-
tion compartment
Wiring plan
16 Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
5Connecting to power supply
31547-EN-081211

1 2 3
45
Fig.9:Double chamber housing
1Housing cover,connection compartment
2Blind stopper or plug M12 x1for the external indicating and adjustment
module (optional)
3Housing cover,electronics compartment
4Filter element for air pressure compensation
5Cable entry or plug
1
32
Display
1 2 5 6 7 8
I²C
Fig.10:Electronics compartment,double chamber housing
1Plug connector for service
2Internal connection cable to the connection compartment
3Terminals for the external indicating and adjustment module
Housing overview
Electronics compart-
ment
Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA 17
5Connecting to power supply
31547-EN-081211

3
1
2
Display
1 2 I²C
Fig.11:Connection compartment,double chamber housing
1Plug connector for service
2Ground terminal for connection of the cable screen
3Spring-loaded terminals for voltage supply
I2C
1
1 2
Fig.12:Wiring plan,double chamber housing
1Voltage supply/Signal output
5.5Switch on phase
After IPT-1*Vers.4.0is connected to voltage supply or after voltage
recurrence,the instrument carries out a self-check for approx.30
seconds.The following steps are carried out:
lInternal check of the electronics
lIndication of the instrument type,the firmware as well as the
sensor TAGs(sensor designation)
lStatus byte goes briefly to fault value
Connection compart-
ment
Wiring plan
Switch on phase
18 Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
5Connecting to power supply
31547-EN-081211

Then the current measured value will be displayed and the corre-
sponding digital output signal will be outputted to the cable.2)
2)The values correspond to the actual measured level as well as to the set-
tings already carried out,e.g.default setting.
Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA 19
5Connecting to power supply
31547-EN-081211

6Set up with the indicating and adjustment
module
6.1Short description
The indicating and adjustment module is used for measured value
display,adjustment and diagnosis.It can be mounted in the following
housing versions and instruments:
lAll sensors of the IPT-1*instrument family,in the single as well as
double chamber housing (optionally in the electronics or connec-
tion compartment)
lExternal indicating and adjustment unit
Note:
You can find detailed information on adjustment in the operating
instructions manual "Indicating and adjustment module".
6.2Insert indicating and adjustment module
The indicating and adjustment module can be inserted and removed at
any time.It is not necessary to interrupt the voltage supply.
For mounting,proceed as follows:
1Unscrew the housing cover
2Place the indicating and adjustment module in the desired position
on the electronics (you can choose any one of four different
positions -each displaced by 90°)
3Press the indicating and adjustment module onto the electronics
and turn it to the right until it snaps in.
4Screw housing cover with inspection window tightly back on
Removal is carried out in reverse order.
The indicating and adjustment module is powered by the sensor,an
additional connection is not necessary.
Function/Configuration
Mount/Dismount indicat-
ing and adjustment
module
20 Process pressure transmitter IPT-11 Vers.4.0-ceramic sensor •Profibus PA
6Set up with the indicating and adjustment module
31547-EN-081211
