Witter KA26U-FIT User manual

µW0001KA26U-FIT$12090020000'Ä
W0001KA26U-FIT$12090020000
Fitting
Instructions
TOWBAR
For KIA RIO 2010-
KA26U-FIT
For KA26
&
KA26Q
MATERIALS
A 1 Cross Bar with Europea faci g to 94/20/EC A50-1
D 1 Right ha d cleat
E 4 M12 x 40 x 1.25 Bolts, Lock Washers a d 30mm O.D. Flat Washers
F 1 Safety Chai Plate
G 2 M10 x 40 x 1.5mm Bolts (10.9 Grade), Flat Washers, Lock Washers, a d Special Nut Retai ers with
Square Nuts
Z 1 Electrical Plate (ZEP 2)
For use with either
KA26 Flange nec option – ZF2030. Note: This towbar must be used with either a Witter Towball (part umber Z11) or Class
A50-1 or A50-X towball, which dime sio ally co forms to A50-1 with a ‘D’ a d 'S' value greater tha or equal to that of the towbar.
KA26Q Detachable nec option – ZQ2030. Please refer to ZQ fitti g i structio s for i stallatio
FITTING
1. Release reamost exhaust ha ger to lower exhaust, remove clips alo g bottom edge of bumper.
2. Assemble Special Cage Nuts as show (PAGE 2) a d i sert i to special holes of Cleat (D) as show below,
Loosely attach to existi g captive uts i chassis usi g Bolts (E) with flat washers.
3. I sert Crossbar (A) i side lower edge of bumper a d loosely secure usi g (Bolts (E) a d Bolts (G)
4. Fully Tighe Bolts a d secure exhaust a d bumper.
5. Attach eck optio a d fit electrical plate (Z) a d Safety Chai Plate (F) .
Recommended torque settings: Grade 8.8 bolts: M8 - 24Nm, M10 - 52 Nm, M12 - 80 Nm, M14 - 130 Nm, M16 - 200
Nm Grade 10.9: M12 – 120Nm, M10 – 70Nm M8- 35Nm
