Wren 1000 Tall User manual

WALL UNIT
1000 Tall 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd
1000 Tall

WALL UNIT
1000 Tall 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd
Page 1
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED
Panel A
x1 Back Panel
HANGING BRACKET
x2 Inc Screws
(F) x8
Wooden Dowel
REQUIRED TOOLS
NOT to be used
with CAM DOWEL
& CAM LOCK
(G) x8
Cam Dowel
(Expanding)
(H) x8
Cam Lock
(K) x4
30mm
Screw
(P) x4
45mm
Screw
(L) x8
15mm
Screw
(S) x4
20mm
Screw
(M) x4
Cover Cap
(N) x2
Door
Buer
(Z) x10
Shelf Peg
Plastic
(T) x12
Back Panel
Support Clip
HANGING BRACKET PLATE
x2 (Screws NOT included)
HINGE MOUNTING PLATE
x4 Inc Screws
HINGE
x4 Inc Screws
CORNER
GUSSET
x2
HANGING BRACKET
COVER CAP
x2
Panel B
x2 End Panel
Panel C
x2 Base Panel
Frontal
(packed separately)
x2
Muntin D
x1
Loose Shelf
x3

WALL UNIT
1000 Tall 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd
Page 2
Step 1.
Seat dowel (F) into holes in
end panel (B) as shown.
Step 2.
Seat cam dowel (G)
into holes in end panel
(B) as shown.
Step 3.
Attach panels x2 (C) to panel
(B), using cam dowels (G)
& cam locks (H) (in blue),
and also using dowels (F)
(in orange) in positions as
shown.
Step 4.
Slide panel (A) into the
groove of panels (B) and
x 2 (C).
NB. All Cam Locks (H) are to be positioned facing the
outside of the unit carcass, for ease of tightening.
Do not use power tools with
cam dowel (G) or cam lock (H)
B
A
C
Dowel (F)
& Cam Dowel (G)
location detail
Seat (G)
cam dowel
into hole as
shown.
View from underside
B
CC
H
H
G
G
View from underside
G
G
F
F
F
F
G
G
B
Step 5.
Insert cam lock (H).
Hand tighten all cam locks
(H), this will expand the
cam dowels (G) and tighten
the unit together.
C
C
A
B

WALL UNIT
1000 Tall 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd
Page 3
Step 6.
Seat dowel (F)
into holes in
both panels (B)
as shown.
Step 7.
Seat cam dowel (G)
into holes in
both end panels (B)
as shown.
Step 8.
Attach panel (B) to panels
(C) using cam dowels (G)
& cam lock (H) (in blue)
and also using dowels (F)
(in orange) in positions as
shown. Ensure panel (A) is
seated into the groove of
panel (B).
Step 9.
Insert cam lock (H).
Hand tighten all cam locks
(H), this will expand the
cam dowels (G) and tighten
the unit together.
NB. All Cam Locks (H) are to be positioned facing the
outside of the unit carcass, for ease of tightening.
B
B
A
C
C
Dowel (F)
& Cam Dowel (G)
location detail
Do not use power tools with
cam dowel (G) or cam lock (H)
Seat (G)
cam dowel
into hole as
shown.
View from underside
B
CC
H
H
G
G
View from underside
G
G
F
F
F
F
G
G
B

WALL UNIT
1000 Tall 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd
Page 4
BA
B
B
C
C
P
P
Step 10.
Ensure carcass is square.
Step 10.
Join muntin panel (D), Both
panels (C) using 4 x 45mm
screws (P) as shown.
C
126mm
126mm
94mm
94mm
B
L
L
from base
from top
T
T
T
T
T
TT
TT
TT
Step 13.
Attach hinge mounting plates onto end
panels (B) in locations shown
using 4 x screws (L)
Hinge side to be mounted in
accordance to customer kitchen plan.
Step 11.
Slide the back panel clips (T)
into the groove of both panels (B) & (A).
The back panel clips (T) should be evenly
spaced as shown and positioned to allow
the hanging bracket and corner gussets
to be tted. Once in place, tighten screw.
Step 12.
Join muntin
panel (D), to
both panels (C)
using 4 x 45mm
screws (P) as
shown.
B
A
T
T
A
B
T

WALL UNIT
1000 Tall 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd
Page 5
Step a
Insert Hanging
Bracket into pre-drilled holes
Step 14.
Hanging Brackets steps a,b & c to be carried out on both sides as shown
Step c
Secure with provided
2 x 20mm screws (S) per bracket
Step b
Rotate locking
lever 180 degrees
S
S
Detail A Detail A Detail A
Step 15.
Secure Corner Gussets
to the bottom left and
right hand side of the
wall unit using
4 x 15mm screws (L)
per plate.
L
L
L
L
Detail B
Step 16.
Drill a small pilot hole through the centre of the Corner Gussets.
Use this hole at the end of the process to screw through and
into the wall. Cover the screw heads using the cover caps (M)
provided.
Screws for xing to walls are not provided as these vary
depending on your wall material and construction. Ensure
appropriate xings for wall constructions are used.
Pilot
hole
M
Detail B
View through
back paanel
A
B

WALL UNIT
1000 Tall 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd
Page 6
Step 17.
Measure appropriately and attach the 2 x hanging bracket plates onto the
wall screwing through the provided holes into your wall.
Screws for xing to walls are not provided as these vary depending
on your wall material and construction. Ensure appropriate xings for
wall construction are used.
Step 18.
Hang the cabinet using
the brackets to hook
onto the plate as shown
Hanging Bracket
Plate
Step 19.
Using points a, b & c adjust the Cabinet to suit.
Step a.
Rotate the screw clockwise
to move the cabinet up.
Anti-clockwise for down.
Step b.
Adjust the depth
using centre
screw.
Step c.
Screw the red screw until it
touches the plate to lock
in position.
Hanging
Bracket
viewed though
Back Panel
b
C c
a
a
b
K
Step 20.
Screw into any side units using the
provided 2x 30mm screws (K) to
secure the unit. Screw just to the
rear of the hinge plate then place a
cover cap on the head to conceal it.

WALL UNIT
1000 Tall 2 Door
Assembly Guide
For Internal Use: FI.WR.INS.047_WKIN00132_WALL_1000_2Dr_Tall_Rev3.indd
Page 7
Step 20.
Insert hinge in top & bottom
holes as shown.
Step 21.
Secure hinges by tightening
2 x screws with hinge dowels
attached. These are already
positioned within the hinges.
Step 22.
Attach the door to unit
where required.
To attach door
clip hinge onto hinge
plate and click to secure.
Hinge Cover Caps
Step 24.
Fit cover caps to hinge.
Adjust Softclose to suit.
Step 23.
Adjust hinge to suit. As shown below.
Hinge Plates
View from Inside of Carcass
To adjust hinge using a screw
driver, tighten or loosen as
required at points 1& 2.
Point 1- In - Out
Point 2- side - side
12
FRONTAL HINGE
ADJUSTMENT
To Release door
Pull catch as shown,
to release hinge
from the hinge
plate.
The top and bottom
hinges MUST be
adjusted to the SAME
STRENGTH.
