Wren Feature Robe User manual

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 1
7 Shelf Robe 5 Shelf Robe

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 2
BEFORE YOU START
THIS PRODUCT MUST BE SECURED TO THE WALL
INSTALLATION SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY.
THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED
NOT to be used with
CAM DOWEL &
CAM LOCK
8mm
Hex Key

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 3
1 x Back Panel
(A)
2 x End Panels
(B)
1 x Bottom
Fixed Shelf
(Cb)
Throughout this instruction the
full depth 7 shelf feature robe
will be used for reference only
1 x Top
Fixed Shelf
(Ct)
2 x Rails
(D)
Loose Shelf
Pack

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 4
x2
Anti Tipping
Bracket
x28
Loose Shelf Peg
(LL) x5
15mm Cover Cap
Robe
Legs
(F) x16
Wooden Dowel
(W) x12
Cam Dowel
(H) x12
Cam Lock
(L) x10
15mm Screw
(P) x6
45mm Screw
(K) x6
30mm Screw

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 5
Step 1.
Seat dowels (F) into holes in both end panels (B) as shown.

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 6
Step 2.
Seat cam dowels (W) into holes in both end panels (B) as shown.
Do not use power tools with cam dowels (W) or cam locks (H)

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 7
Step 3.
Attach panels (Ct), (Cb) & (D) to panel (B), using cam dowels (W), and also using wooden dowels (F) in
positions as shown.
All cam locks (H) are to be positioned facing the outside of the unit, for ease of tightening.

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 8
Step 4.
Slide back panel (A) into groove of end panel (B).
Ensure the back is in-line with top and bottom xed shelves.

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 9
Step 5.
Attach panel (B) to panels (Ct), (Cb) & (D), using cam dowels (W), and also using dowels (F) in positions
as shown.

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 10
Step 6.
Insert cam locks (H) and hand tighten, this will tighten the
unit together.
Do not use power tools with cam dowels (W)

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 11
Step 7.
Ensure the unit is square. Secure back panel (A) with 45mm screws (P) through the pre drilled holes in the
top and bottom of the back panel (A) into the xed shelves (Ct) and (Cb) as shown.
The number of screws required depends on the width of the unit.

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 12
Step 8.
Position the top section of the legs as shown. Ensure legs are rotated to
provide support to the end panels (B). Secure with 2 x 15mm screws (L) per
leg. Attach the bottom section of the legs and set all legs to the same height.
Step 9.
Lift the unit upright. Once in situ, level
accordingly using an 8mm hex key from inside
the unit.
Cover leg holes with 15mm cover caps (LL).
It is important to lift the unit onto its legs. Do not tilt as depicted in the image.

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 13
Step 10.
Ensure the unit is level and positioned correctly.
Wren recommends securing the robe to the wall using rails (D). Drill pilot holes through back panel (A)
and rails (D) into the wall. Screw through the pilot holes into the wall, place cover stickers on the heads
to conceal them. If unable to use the rails (D) to secure the robe to the wall use the anti-tipping brackets
provided. Attach the brackets to the top of the robe using 15mm screws (L) provided. Screw through the
brackets into the wall.
Step 11.
Screw into any adjacent units using 30mm screws (K) provided to secure the unit. Screw just to the rear
of the loose shelf peg hole at the top, middle and bottom on both sides. The loose shelf will conceal the
screw heads once in place.
Screws for xing to walls are not provided as these vary depending on your wall
material and construction. Ensure appropriate xings for wall constructions are used.

ROBE UNIT
Feature Robe Assembly Guide
For Internal Use: FI.WR.INS.138_WBIN0037_Feature_Robe_AssemblyGuide_Rev1 Page 14
Loose Shelves
Insert shelf pegs into holes on each end panel.
4 x shelf pegs are required per loose shelf.
Position loose shelf onto shelf pegs ensuring the shelf pegs locate in the holes on the
bottom of the loose shelf.
See customer-specic bedroom plan for position and number of loose shelves.
