Xterra 16804936500US User manual

Owner’s Manual
Model No.
16804936500US
-Assembly
- Operation
- Adjustments
- Parts
- Warranty
CAUTION:
Read and
understand this
manual before
operating unit
Retain For Future Reference

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
2
TABLE OF CONTENTS
Before you Begin ….……………………………………………………………………………. 3
Safety Precautions ……………………………………………………………………………... 3
Safeguards ……………………………………………………………………………………… 5
Pre-Assembly ………………….……………………………………………………………….. 6
Assembly Instructions………………………………………………………………………….. 8
How to Fill and Empty the Tank ……………………………………………………………… 10
ERG650W Console Operation ………………..………….………………………………….. 13
Console Programs …………………………………………………………………………….. 15
General Maintenance ………………………………………………………………………..… 18
Troubleshooting ………………………………………………………………………………... 18
Diagram and Parts List.......................…………….……………………………………..…… 19
Manufacture’s Limited Warranty…………………………………………………………….... 23

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
3
BEFORE YOU BEGIN
Thank you for choosing the ERG650W Water Rowing Machine.We take great pride in
producing this quality product and hope it will provide many hours ofquality exercise to
make you feel better, look better, and enjoy life to its fullest. It's a proven fact that a regular
exercise program can improve your physical and mental health. Too often, our busy
lifestyles limit our time and opportunity toexercise. The ERG650W Water Rowing Machine
provides a convenient and simple method to begin your assault on getting your body in
shape and achieving a happier and healthier lifestyle.
Read this manual carefully before using the ERG650W Water Rowing Machine.Although
Dyaco Canada Inc. constructs its products with the finest materials and uses the highest
standards of manufacturing and quality control, there can sometimes be missing parts or
incorrectly sized parts. Ifyou have any questions or problems with the parts included with
your ERG650W Water Rowing Machine,please do not return the product. Contact us
FIRST! If apart is missing or defective call us toll free at 1-888-707-1880. Our Customer
Service Staff are available to assist you from 8:30 A.M. to 5:00 P.M. (Eastern Time) Monday
through Friday.Be sure to have the name, model and serial number of the product available
when you contact us.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
This chapter includes precautions and fitness safeguards for the installation and use of
the Water Rowing Machine manufactured by Xterra Fitness.Please read this chapter
carefully before installing or using your equipment.
USER SAFETY PRECAUTIONS
These safety notes are directed to you as the owner of the Water Rowing Machine
manufactured by Xterra Fitness. Please follow these safety instructions.
Do:
•Do encourage each of your users to discuss their health program or fitness regimen with a
healthcare professional a qualified service personnel.
•Do stop operating your rower if you feel dizzy or faint
•Do perform regular preventative maintenance
•Do exercises slowly until you reach a level of comfort.
DO NOT:
•Do not let unsupervised children operate the rower.
•Do not use without proper athletic shoes.
•Do not use in rainy weather outdoors, or in an enclosed pool environment
•Do not drop or insert any object, hands, or feet into from this equipment any opening or
within the area operation of the product.
•Do not attempt to remove any shrouds or modify the rower.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
4
WARNING
•Your Water Rowing Machine manufactured by Xterra Fitness isdesigned for
exercise in a residential environment.
•Please check with your physician prior to beginning any exercise program.
•Do not push yourself to excess. Stop if you are feeling faint, dizzy,or exhausted. Use
common sense when rowing.
•Read the owner’s manual in its entirety before operating the rower.
•Failure to obey this warning can result in injury or death.
WARNING LABELS AND COMMUNICATION STICKERS
The image below shows an example of Xterra Fitness warning labels and communication
stickers placed on the equipment as part of the manufacturing process. It is critical that
owners maintain the integrity and placement of these stickers. If you find any stickers missing
or damaged contact your local dealer or distributor for a replacement. NOTE: STICKERS
AND LABELS ARE NOT SHOWN TO SCALE.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
5
SAFEGUARDS
The following fitness safeguards and operating precautions are directed to purchasers
and users of the Water Rowing Machine. Failure to follow these safeguards may result in
injury or serious health risk.
•Do not use any equipment in any way other than designed or intended by the
manufacturer. It is imperative that equipment is used properly to avoid injury.
•Injuries may result if exercising improperly or excessively. It is recommended that all
individuals consult a physician prior to commencing an exercise program.
•If at any time during exercise you feel faint, dizzy or experience pain, stop exercising and
consult your physician.
•Keep body parts (hands, feet, hair, etc.), clothing and jewelry away from moving parts to
avoid injury.
•The maximum weight for individuals riding the rower should not exceed 350 lbs.
•Do not use or permit use of any equipment that is damaged and/or has worn or broken
parts. For all equipment use only replacement parts supplied by Dyaco Canada Inc.
•Cables and belts pose an extreme liability if used when frayed. Always replace any cable
or belt at first sign of wear (consult Dyaco Canada Inc. if uncertain).
•Preventative maintenance is the key to smooth operating equipment as well as to keep
your liability to a minimum. Equipment needs to be inspected at regular intervals.
•Ensure that any person(s) making adjustments or performing maintenance or repair of
any kind is qualified to do so.
•Do not attempt to use or repair any accessory approved for use with the Xterra Fitness
Equipment which appears to be damaged or worn.
• Check all belts, pulleys and bungee cords regularly for signs of wear, and replace if
needed.
•Check regularly and follow all instructions for maintenance as specified in this manual.
•Replace immediately any defective parts and do not operate unit until all repairs are
complete.
•Keep children away from the equipment. Parents or others supervising children must
provide close supervision of children if the equipment is used in the presence of children.
•Do not allow users to wear loose fitting clothing or jewelry while using equipment. It is
also recommended to have users’ secure long hair back and up to avoid contact with
moving parts.
•All bystanders must stay clear of all users, moving parts and attached accessories and
components while machine is in operation.
•We recommend an area no less than 2ft kept clear around the rower for easier access
and safety.
WARNING
Do not insert fingers into tank
After rowing exercise, please allow the unit to sit for 5 minutes before standing it up for
storage
Do not fill past the calibration mark as indicated on the tank level sticker or water
spillage can occur
Never operate this rower without feet properly secured in foot straps, or without the sliding
portion of the slider footplate locked into position
WARNING
1. WARNING – KEEP BATTERIES OUT OF REACH OF CHILDREN
2. Swallowing may lead to serious injury in as little as 2 hours or beath, due to chemical burns
and potential perforation of the esophagus.
3. If you suspect your child has swallowed or inserted a button battery, immediately seek urgent
medical assistance.
4. Examine devices and make sure the battery compartment is correctly secured. E.g. that the
screw or other mechanical fastener is tightened. Do not use if compartment is not secure.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
6
5. Dispose of used button batteries immediately and safely. Flat batteries can still be dangerous.
6. Tell others about the risk associated with button batteries and how to keep their children safe.
a) Always purchase the correct size and grade of battery most suitable for the intended use.
b) Replace all batteries of a set at the same time.
c) Clean the battery contacts and also those of the device prior to battery installation.
d) Ensure the batteries are installed correctly with regard to polarity (+ and -).
e) Remove batteries from equipment that is not to be used for an extended period of time.
f) Remove used batteries promptly.
Note: The console cannot operate if battery is inserted backwards.
Note: Rower isnot suitable for therapeutic purposes.
ERG650W PRE-ASSEMBLY
Use the following procedures to unpack and assemble your rower manufactured by
Dyaco Canada Inc.
Position the shipping carton so the heavy end is located at the bottom
Cut the straps then lift the box over the unit and unpack. Remove foam inserts and all
parts from the shipping carton, then use the parts list to verify that all parts are
included in your shipment.
 Locate the hardware package. The hardware is separated into steps. Remove the
tools first. Remove the hardware for each step as needed to avoid confusion. As you
read through the assembly instructions, any number that is in brackets [#] refers to the
item number from the corresponding assembling drawing
NOTE: All tools required to assemble the rower are included within the packaging.
NOTE: If you are missing any of the parts listed above, inspect the packing material and the
box for items that may have been overlooked.
If parts are missing, or if you have any operational questions, please call Dyaco Canada Inc.
customer service department. Have your serial number ready.
CAUTION: Damage to the rower during assembly is not covered as part of the limited Xterra
Fitness warranty. Take care not to drop or lean the rower on its side. Carefully stand the
rower up in the normal upright position on a stable surface so it will not tip over during
assembly
Protect the environment by not disposing of this product with household waste. Check your
local authority or approved waste center for recycling advice and facilities

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: [email protected]
7
ERG650W ASSEMBLY PARTS CHECKLIST
Note: Above parts are all needed to assemble this
machine. Before you start to assemble, please
check the hardware packing to make sure they
are included
ERG650W Hardware Parts
Part No
Description
Q’ty
1
Main Frame
1
2
Rear Stabilizer
1
3R/3L
Slide Rail
1/1
38
Seat Assembly
1
54
Computer Assembly
1
52
Funnel
1
53
Pumping Siphon
1
User Manual
1
Hardware Parts
1

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
8
ASSEMBLY INSTRUCTIONS
1 SLIDE RAILS AND REAR STABILIZER
Turn over the Slide Rails (No.3) as below. Attach the Seat Rollers (No.39) to the slide Rails
making sure the plate touches the rollers. To secure the Slide Rails between the Rollers,
you’ll need to insert it at an angle and rotate as shown in the diagram.
Secure the Rear Stabilizer (No.2) to the Slide Rails (No.3) using 2 Bolts (No.63) and 2
Washers (No.74) on both sides. Use the Allen Wrench (No. 93) to secure.
# 63 M8*45 4pcs
#74 OD20*ID8.5*1.5 4pcs
3L
74
74
63
63
3R
38
#93 S 5
39
2 CONNECTING THE SLIDE RAIL TO THE MAIN BODY
This step can be made easier with the use of another person to assist you. Be careful of the
sliding Seat (No. 38) as it will move when placed upright.
Set the Main Frame (No. 1) in an upright position and connect the Slide Rails (No.3) using 4
Long Bolts (No. 99), 2 Small Bolts (No. 77), and 6 Screws (No. 65).
Use the Allen Wrench (No. 93) and Spanner (No. 94) to secure.
#93 S 5
99
99
#94 S13-17
# 99 M8*57 4pcs
1
38
3L 3R
65 65
77
77
# 77 M8*27 2pcs
# 65 M6*15 6pcs

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
9
3 ATTACHING THE CONSOLE
Place the 2 AA batteries into the back of the Computer (No. 54).
Turn the Main Frame (No.1) upright. Connect the Sensor Wire (No. 56) to the Connection
Wire (No. 96). Be careful not to pinch the wires. Feed any extra length of wire to lay in the
Main Frame.
Install the Decorative Cover (No. 26) into the Main Frame (No. 1).
Secure the Computer (No. 54) to the Main Frame using 4 Small Screws (No. 68).
Use the Allen Wrench (No. 93) to secure.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
10
How to Fill and Empty the Tank
Remove the Fill Plug (No. 50) from the Upper Tank (No. 24).
To fill the tank with water, refer to Fig. A. Insert the Funnel (No.52) into the tank, then use a
cup or the Siphon Pump (No.53) and a bucket to fill the tank. Use the water level gauge on
the side of the tank to measure the desired water level in the tank.
To empty the tank, refer to Fig. B. Place a bucket next to the rower and use the Siphon Pump
(No.53) to pump the water from the tank into the bucket.
Insert the Fill Plug (No.50) into the Upper Tank (No.24). Wipe the excess water off the frame.
Note:
Fill the tank only with tap water. Add 1 water-purification tablet (not included). Never use pool
chlorine or chlorine bleach. This will damage the tank and void the warranty.
Add water purification tablet every 6 month or as needed. If water remains cloudy, replace the
water in the tank.
Water from the tank is not suitable for consumption. Dispose of the water after pumping it out
of the tank.
WATER LEVEL:
See Fig. A. The water level gauge is on the side of the tank. The maximum fill level is 6.
Never fill it over the limit. Filling the tank over this limit will void the warranty.
The resistance depends on the water level in the tank. Water level 2 is the lowest resistance.
Level 6 is the highest resistance.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
11
Pedal strap Adjustment
The pedal strap is adjustable and can be personalized to fit the user’s foot size.
To adjust the pedal strap, remove the hook and loop end of the strap from the mesh side by
pulling it upward and over the side. Once removed, you may increase the opening of the
pedal strap by pulling the mesh end up and to the side.
To tighten, pull the hook and loop end of the pedal strap upward and down to secure it to the
mesh side of the strap.
Adjusting the Balance
Adjust the rear feet if the rower is out of balance
CAUTION
Moving parts, such as the seat, can crush and cut your fingers. Keep hands clear of the Slide
Rail during use.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
12
Storage
To move the rower, lift up the rear stabilizer until the transportation wheels on the front stand
are touching the ground. With the wheels on the ground, you can transport the rower to the
desired location with ease.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
13
ERG650W CONSOLE OPERATION
The full LCD display will be shown 2 seconds after installing 2 AA batteries. All fields will activate
briefly. The console will then prompt you to enter the Workout Intensity Level (this is determined
by how much water you’ve filled the tank with) from L1 to L6, using the Arrow Keys to
lower/raise the level. The default level is L6. Afterwards, press ENTER to confirm your Workout
Intensity Level. The console will then enter into Standby mode.
Button Functions
UP / DOWN: Press these two buttons to scroll through available selection. To adjust the function
value upward and downward.
ENTER: Press to confirm your selection. To access the different workout programs. During
training, press the button to cycle scan each display function.
START / STOP: To start and stop your selected workout program.
RESET: To return the computer back to the main menu. Press and hold to reset values.
RECOVERY: To activate the RECOVERY PROGRAM that will automatically evaluate your
fitness immediately after your work out.
This Class (B) digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may notcause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the device

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
14
Functions
TIME:Set a target time by pressing the UP and/or DOWN buttons (1min ~ 99 min), in 1 minute
increments.
TIME / 500M:Your average time to reach 500 meters isautomatically displayed.
SPM:Strokes per minute.
DISTANCE:Preset a target value by pressing the UP and/or DOWN buttons (0 ~ 99900 meters),
100 meters increments.
STROKES:Set a target value by pressing the UP and/or DOWN buttons (0~9990 strokes). 10
strokes increments.
TOTAL STROKES:Accumulates total strokes from 0 up to 9999.
CALORIES:Set a target value by pressing the UP and/or DOWN buttons (10~9990 Cal). 10
calorie increments.
PULSE: Wireless chest strap sensor - In Manual Mode, setthe target heart rate value by
pressing up/down (available range is 30 to 240 in 1 BPM increments). The computer will display
user’s heartrate during training. When you are out of range of the target value during exercise,
the computer will beep and PULSE will blink until target range is resumed or wireless chest strap
sensor is removed. The pulse measurement function is onlyusable with the optional wireless
chest strap sensor.
DRAG FORCE:Displays the current Drag Force.
WATT:Displays the current Watt output.
A+:Display the average function value of time, calories, watt and pulse.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
15
Programs
QUICK START:
Choose Quick Start then press START/STOP to start the training. Press ENTER to switch
between values during your workout. The program profile displays 16 columns, each equal to 100
meters.
STANDARD:
Choose Standard, then press ENTER to confirm and begin your desired training mode: 2000m,
5000m, 10000m, 30:00, 500m/1:00. Press START to begin the program. The preset value will
count down to 0, other values (calories, strokes, etc.) will count up. Pressing RESET will bring
you back to standby mode and all values will reset to 0.
TARGET SINGLE:
Choose Target Single then press ENTER to confirm and choose one of four values to target.
Single Time - Presets only a time value. Press Start to begin the workout.
Single Distance - Presets only a distance value. Press Start to begin the workout.
Single Calories - Presets only a Caloric value. Press Start to begin the workout.
Single THR - Presets only a Target Heart Rate. Ranges from 90 - 200 BPM. Press Start to begin
the workout. If you exceed the THR, a beeping sound will occur. Only usable with a Wireless
chest strap.
TARGET INTERVALS:
Choose Target Interval then press ENTER to confirm and choose one of three values to set an
Interval target for.
Interval Time - Using the Arrow Keys, set a training time. Press ENTER and set a rest time. Press
Start to begin the workout.
Interval Distance - Using the Arrow Keys, set a training distance. Press ENTER and set a rest
time. Press Start to begin the workout.
Interval Variable - Using the Arrow Keys, set a training time, then press ENTER to confirm and
set a training distance. Press ENTER and set a rest time. Press Start to begin the workout.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
16
Programs
CUSTOM:
Choose Custom, then press ENTER to confirm and choose one of four custom modes:
V: 30/:30R - Training 30 seconds, Rest 30 seconds
V1:00/1:00R...7 - Training 1 minute, Rest 1 Minute, Repeat 7 times.
V2000m/3:00R...4 - Training 2000m, Rest 3 Minute, Repeat 4 times.
V1:40/:20R...9 - Training 1:40 minutes, Rest 20 seconds, Repeat 9 times.
RACE:
Choose Race then press ENTER to confirm. Select L1 - L5 using the Arrow Keys. Press ENTER
to confirm and enter a distance setting. Press Start to begin the Race.
Adot-matix will appear that displays you versus the PC graphic to race.
The program will end at the end of the race.
Pressing ENTER you can switch between seeing the different values and their averages.
The dot-matrix will show PC WIN or USER WIN.
Note: In the Race you can only set Distance, TIME/500M is Fixed, TIME/500M for L1-L15 is as
below:
RACE MODE
DISTANCE SET
START

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
17
Using AHeart Rate Transmitter
This ISM device complies with Canadian ICES-001.
How to wear your wireless chest strap transmitter:
1. Attach the transmitter to the elastic strap using the locking parts.
2. Adjust the strap as tightly as possible as long as the strap is not too
tight to remain comfortable.
3. Position the transmitter with the logo centered in the middle of your
body facing away from your chest (some people must position the
transmitter slightly left of center). Attach the final end of the elastic
strap by inserting the round end and, using the locking parts,
secure the transmitter and strap around your chest.
4. Position the transmitter immediately below the pectoral muscles.
5. Sweat is the best conductor to measure very minute heart beat
electrical signals. However, plain water can also be used to pre-wet the electrodes (2
ribbed oval areas on the reverse side of the belt and both sides of the transmitter). It’s
also recommended that you wear the transmitter strap a few minutes before your work
out. Some users, because of body chemistry, have a more difficult time in achieving a
strong, steady signal at the beginning. After “warming up”, this problem lessens. As
noted, wearing clothing over the transmitter/strap doesn’t affect performance.
6. Your workout must be within range - distance between transmitter/receiver – to achieve a
strong steady signal. The length of range may vary somewhat but generally stay close
enough to the console to maintain good, strong, reliable readings. Wearing the
transmitter immediately against bare skin assures you of proper operation. If you wish,
you may wear the transmitter over a shirt. To do so, moisten the areas of the shirt that
the electrodes will rest upon.
Note: The transmitter is automatically activated when it detects activity from the user’s heart.
Additionally, it automatically deactivates when it does not receive any activity. Although the
transmitter is water resistant, moisture can have the effect of creating false signals, so you
should take precautions to completely dry the transmitter after use to prolong battery life
(estimated transmitter battery life is 2500 hours). The replacement battery is Panasonic
CR2032.
Erratic Operation
Caution! Do not use this elliptical for Heart Rate Control unless a steady, solid Actual Heart
Rate value is being displayed. High, wild, random numbers being displayed indicate a
problem.
Areas to look for interference which may cause erratic heart rate:
1. Microwave ovens, TV’s, small appliances, etc.
2. Fluorescent lights.
3. Some household security systems.
4. Perimeter fence for a pet.
5. Some people have problems with the transmitter picking up a signal from their skin. If
you have problems, try wearing the transmitter upside down. Normally the transmitter will
be oriented so the logo is right side up.
6. The antenna that picks up your heart rate is very sensitive. If there is an outside noise
source, turning the whole machine 90 degrees may de-tune the interference.
7. Another Individual wearing a transmitter within 3’ of your machine’s console.
If you continue to experience problems, contact your dealer.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
18
GENERAL MAINTENANCE
A regular preventative maintenance schedule with your fitness equipment ensures that
products are working at an optimal condition without affecting your exercise experience. To
assist in the maintenance regimen, it is recommended to break service into daily, weekly, &
monthly activities.
All preventive maintenance activities must be performed on a regular basis. Performing
routine preventive maintenance actions can aid in providing safe, trouble-free operation of
the Xterra equipment. Dyaco is not responsible for performing regular inspection and
maintenance for your machines.
Item
Time Frame
Instructions
Notes
Seat and Seat
Rails
Weekly
Wipe down seat rails with lint free
cloth
Frame
Weekly
Wipe down frame with lint free cloth
Tank and Water
Treatment
12m to 2years
Follow instructions as specified on
page 10. of the manual.
TROUBLESHOOTING
Issue
Possible Cause
Instructions
Water changes color
or becomes cloudy
Rower is in direct sunlight or has
not had water treatment
Local tap water is of poor quality
Change rower location to
reduce direct exposure to
sunlight. Add water treatment
or change tank water as
directed on page 10 of this
manual. Consider using
distilled water to refill tank.
Monitor does not display
Batteries not Installed
Computer Wires not connected
Install Batteries
Ensure the computer wires are
connected properly at the upright
and computer
No count or distance
displays on the monitor
Sensor wire not connected
Sensor wire not working properly
Monitor not working properly
Ensure the computer wires are
connected properly at the upright
and the computer
Replace sensor wire
Replace monitor
Please contact your Dyaco Canada Customer Service if any assistance is required.

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
19
EXPLODED DIAGRAM
1
2
4
5
6
7
8
9
10
12
13
14
15
16
16 17
17
18
18
21
21
25
24
26R
27
28
30
31
32
33
34
35
36
38
42
42
42
42
42
42
43
44
45
45
45
46
47
48
49
50 51
51
52
53
56
59
61
61
62
62
62
62
63
63
64
64
65
65
65
65
65 65
87
67
67
68 68
65
73
74
74
89
74
78
78
76
90
98
98
79
79
81
81
101
83
83
84
84
84
84
85
85
86
88
88
92
93
94
69
95
26F
3L
3R
19
19
21
21
21
28
29
29
37
37
39
39
40
40
40
40
42
42
42
42
60
55
55
58
58
63
74
63
74
67
67
69
69
69
69
20
20
22
22
71
71
72
72
72
72
70
70
75
75
100
75
75
100
79
82
82
99
99
90
90
23
23
41
41
57
57
96
67
100
67
100
65
97
97
80
80
80
80
90
65
65
77
77 89 89
89
91
74
102
103
11
54
66
74
98 67
67
97

Customer Service 1-888-707-1880 Dyaco Canada Inc
Email: customerser[email protected]
20
PARTS LIST
NO.
PART NO.
DESCRIPTION
Q'TY
1 0365001 Main Frame 1
2 0365002 Rear Stabilizer 1
3 0365003 Slide Rail R/L 2
4 0365004 Handlebar 1
5 0365005 Spring Fixed Plate 1
6 0365006 Seat Carriage 1
7 0365007 Sensor Stand L 1
8 0365008 Sensor Stand R 1
9 0365009 Support for Computer 1
10 0365010 Tank Plate 1
11 0365011 Support Plate 1
12 0365012 Impeller 1
13 0365013 Impeller Shaft 1
14 0365014 Mesh Belt Wheel Shaft 1
15 0365015 Belt Wheel 1
16 0365016 Guide Roller 2
17 0365017 Spacer for Guide Roller 2
18 0365018 Moving Wheel 2
19 0365019 Adjustable Knob 2
20 0365020 Aluminum Plate 2
21 0365021 Oval End cap 6
22 0365022 Cover for Roller 4
23 0365023 Lower Roller for Rail 2
24 0365024 Upper Tank 1
25 0365025 Lower Tank 1
26 0365026 Decorate Cover F/R 1
27 0365027 Handlebar Seat 1
28 0365028 Upper Pedal 2
29 0365029 Lower Pedal 2
30 0365030 Bearing Seat 1
31
0365031
Mesh Belt Wheel
1
32 0365032 Axle for Volute Spring 1
33 0365033 Base of Volute Spring 1
34 0365034 PC Board 1
35 0365035 Outer PC Board 1
36 0365036 Spacer for mesh belt wheel 1
