Z3 Technology DME-05 User manual

User Instructions
Rack-Mount HD Video Encoder
Model Name: DME-05
DOC-USR-0151-01
Manual Version 1.0
March 15, 2018
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2018 Z3 echnology, LLC. All rights reserved.
Z3 echnology and ZEUS are registered trademarks of Z3 echnology, LLC.
his document contains proprietary information of Z3 echnology, LLC ("Z3"). his document may not be used, reproduced, disclosed, or
disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at
any time and without notice. All product names, trademarks, trade names, service marks, or service names mentioned in this document are the
property of their respective owners.
Z3 echnology, LLC incorporates HDMI® technology. he terms of HDMI and HDMI High-Definition Multimedia Interface, and
the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
he Power of ZEUS
™

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
2
Revision History
Version
Date
Change Note
Author
1.0 03/14/2018 Initial Document SI

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
3
TABLE OF CONTENTS
1.0 GENERAL DESCRIP ION .................................................................................................. 7
2.0 QUICK S AR GUIDE ..................................................................................................... 8
2.1 If You Have Received a System from Z3 with the Software Preloaded ........................................ 8
2.2 If You Already have a System from Z3 and Need to Update the Firmware ................................... 8
3.0 PACKAGE CON EN S ..................................................................................................... 9
4.0 FEA URES ................................................................................................................ 10
4.1 Supported Input Resolutions ....................................................................................... 10
4.2 Supported Output Resolutions ..................................................................................... 10
5.0 OPERA ING CON ROLS ................................................................................................. 11
6.0 GE ING S AR ED WI H HE DME-05 ................................................................................ 12
6.1 Set up the SDI Video Source ........................................................................................ 12
6.2 Connect and Power up the DME-05 ................................................................................ 12
6.3 Find the Encoder Using ZFinder ................................................................................... 13
6.4 Configure Encoder for UDP Streaming ............................................................................ 14
6.5 View a UDP Stream in VLC .......................................................................................... 16
6.6 Configure Encoder for R P/R SP Streaming ..................................................................... 17
6.7 View an R SP Stream in VLC ....................................................................................... 18
6.8 Configure Encoder for R MP Streaming .......................................................................... 19
6.9 Configure Encoder for ASI Output ................................................................................. 25
6.10 Encoding an HDMI Video Source .................................................................................. 26
6.11 Changing the Bitrate and Frame Rate Dynamically ........................................................... 27
6.12 Adjusting the UDP S Rate ........................................................................................ 29
6.13 uning for Latency ................................................................................................. 31
6.14 Recording to USB ................................................................................................... 33
6.15 Simultaneous Streaming and Recording ......................................................................... 34
6.16 Using MP S to Combine Multiple Streams ...................................................................... 35
6.17 Encoding Closed Captioning ...................................................................................... 37
6.18 Encoding with Forward Error Correction ........................................................................ 38
7.0 RUNNING HE DECODER ............................................................................................... 39
7.1 Set to Decoder Mode ................................................................................................ 39
7.2 Decoding ASI Input ................................................................................................... 40
7.3 Decoding IP Streams ................................................................................................. 41
7.4 Decoding a .ts File ................................................................................................... 42
7.5 Output HDMI .......................................................................................................... 43
7.6 Output SDI ............................................................................................................ 44

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
4
7.7 Decoding with Forward Error Correction ......................................................................... 46
8.0 PERFORMING O HER OPERA IONS WI H HE DME-05 .............................................................. 47
Saving Current Settings ............................................................................................. 47
8.2 Using a Static IP Address ............................................................................................ 48
8.3 Advanced Settings Mode ............................................................................................ 51
8.4 Making a Firmware Update ......................................................................................... 53
8.5 Using the Password Feature ........................................................................................ 55
9.0 SUMMARY OF OP IONS ................................................................................................. 56
9.1 he System Setup ab ............................................................................................... 56
9.2 he User Presets ab ................................................................................................ 59
9.3 he Status ab........................................................................................................ 60
9.4 MP S ab* ............................................................................................................. 61
9.5 he CH1 ab (Encode) ............................................................................................... 62
9.6 he CH2 & CH3 abs (Encode) ..................................................................................... 70
9.7 he CH1 ab (Decode) .............................................................................................. 71
9.8 he CH2 ab (Decode) .............................................................................................. 72
9.9 Values Appearing at the Bottom of All abs ...................................................................... 73
APPENDIX A: Configuring the Wowza Server for R MP ................................................................. 74
APPENDIX B: roubleshooting .............................................................................................. 76

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
5
LIST OF FIGURES
Figure Package Contents for the DME-05 ............................................................................ 9
Figure 2 Front and Rear Views of the DME-05 ....................................................................... 11
Figure 3 DME-05 Rear Panel SDI Encode Connections .............................................................. 12
Figure 4: ZFinder with a Product Selected .............................................................................. 13
Figure 5 DME-05 User Interface System Setup Tab .................................................................. 14
Figure 6 Channel Tab – UDP ........................................................................................... 15
Figure 7 VLC Open Network Stream Screen for UDP ............................................................... 16
Figure 8 Example of Z3 Video Streaming to VLC (UDP) ............................................................ 16
Figure 9 Channel Tab – RTP/RTSP .................................................................................... 17
Figure 0 VLC Open Network Stream Screen for RTSP ............................................................. 18
Figure Example of Z3 Video Streaming to VLC (RTSP) .......................................................... 18
Figure 2 Channel Tab – RTMP Streaming to the Wowza Streaming Engine™ ................................ 20
Figure 3 Getting to the Wowza Test Player ......................................................................... 21
Figure 4 Viewing Content on Wowza ................................................................................. 22
Figure 5 YouTube Live Dashboard – Encoder Setup ................................................................ 23
Figure 6 Channel Tab – RTMP Streaming to YouTube Live ...................................................... 24
Figure 7 DME-05 Rear Panel ASI Output Connection .............................................................. 25
Figure 8 Channel Tab – ASI ........................................................................................... 25
Figure 9 DME-05 Rear Panel HDMI Encode Connections .......................................................... 26
Figure 20 Channel Tab - HDMI ........................................................................................ 26
Figure 2 Viewing Bitrate in VLC ....................................................................................... 27
Figure 22 Changing the Bitrate Dynamically ......................................................................... 27
Figure 23 Drop in Bitrate after Dynamic Bitrate Change ........................................................... 28
Figure 24 Status Page Output Showing Lower Bitrate .............................................................. 28
Figure 25 Changing TS Rate ............................................................................................. 29
Figure 26 TS Rate and Lower Bitrate Reflected in VLC ............................................................ 30
Figure 27 Tuning for Latency............................................................................................ 31
Figure 28 Enable TS Lowlat Mode ...................................................................................... 32
Figure 29 CH Tab Configuration – TSFILE ............................................................................ 33
Figure 30 Using the Aux TS File Enable Option ...................................................................... 34
Figure 3 Z3-MVE-250 Rear Panel Example Encode Connections ................................................ 35
Figure 32 MPTS Tab ....................................................................................................... 36
Figure 33 Opening VLC for MPTS Multicast Stream ................................................................. 36
Figure 34 Viewing Channel 2 in VLC ................................................................................... 36

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
6
Figure 35 Setting VLC to use the Extracted Closed Caption Data ................................................ 37
Figure 36 Enabling Pro-MPEG FEC Encode ............................................................................ 38
Figure 37 DME-05 Rear Panel Decode Setup Connections ......................................................... 39
Figure 38 Changing to Decoder Mode .................................................................................. 39
Figure 39 DME-05 Panel ASI Decode Connection .................................................................... 40
Figure 40 Channel Tab – ASI Decode ................................................................................. 40
Figure 4 Channel Tab – UDP Decode ................................................................................ 41
Figure 42 DME-05 Rear Panel USB Connection ....................................................................... 42
Figure 43 Channel Tab – .ts File Decode ............................................................................ 42
Figure 44 DME-05 HDMI Output Connection for Decode ........................................................... 43
Figure 45 Set Display for HDMI Output ................................................................................ 43
Figure 46 Set Audio for HDMI Output .................................................................................. 44
Figure 47 DME-05 SDI Output Connection for Decode .............................................................. 44
Figure 48 Set Display for SDI Output ................................................................................... 45
Figure 49 Set Audio for SDI Output .................................................................................... 45
Figure 50 Enabling Pro-MPEG FEC Decode for TSRTP Streams .................................................... 46
Figure 5 The User Presets Tab ......................................................................................... 47
Figure 52 Entering a User Preset Name ............................................................................... 47
Figure 53 Saving New Settings to a User Preset ..................................................................... 48
Figure 54 Setting DHCP within z3_config ........................................................................... 49
Figure 55 Reboot Reminder for Changing IP Settings ............................................................... 49
Figure 56 IP Address Shown in ZFinder ............................................................................... 50
Figure 57 User Interface Using DHCP Address ....................................................................... 50
Figure 58 Accessing Advanced Settings ............................................................................... 51
Figure 59 Default UDP Settings (Left) and Advanced UDP Settings (Right) ..................................... 52
Figure 60 Updating the Device Firmware from the User Interface .............................................. 53
Figure 6 Updater Screen ............................................................................................... 53
Figure 62 File Selection Screen ........................................................................................ 54
Figure 63 Changing the Password ...................................................................................... 55
Figure 64 Password Entry Screen....................................................................................... 55
Figure 65 Wowza Performance Settings ............................................................................... 74
Figure 66 Wowza Security Settings .................................................................................... 75

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
7
.0 GENERAL DESCRIPTION
he ZEUS

DME-05 Multi-Format Video Encoder is a system capable of processing multi-format H.264 High
Profile video up to 1080p at 60 frames per second. he DME-05 is a cost-effective system suitable for
broadcast encoders and IP streaming. he DME-05 provides immediate access to multi-format HD video,
integrated system peripherals and production-qualified codecs.
he DME-05 features multiple I/O interfaces, including 3G-SDI, HDMI, ASI and Gigabit Ethernet. Multiple
interfaces allow customers to quickly integrate full H.264 1080p performance in their network without the
power consumption and physical space required of a PC-based platform.

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
8
2.0 QUICK START GUIDE
2. If You Have Received a System from Z3 with the Software Preloaded
o start working with the encoder, you can go straight to Section 6.0, “GE ING S AR ED WI H HE DME-
05,” on page 12. his section describes how to quickly generate a UDP, R P, R SP or R MP stream over IP
as well as how to generate an ASI stream. Information is also provided on how to change bitrate
dynamically, how to adjust the UDP S rate, tuning for latency, streaming in multiple resolutions,
recording to USB and utilizing various features including MP S, closed captioning and forward error
correction.
Details on configuring and running the DME-05 as a decoder can be found in Section 7.0, “RUNNING HE
DECODER”, on page 39.
2.2 If You Already have a System from Z3 and Need to Update the Firmware
You can update the firmware via the H P-based user interface by following the instructions in Section
8.4: “Making a Firmware Update”, on page 53.
*Note: Actual version numbers for your Z3 product may differ from those pictured in this document.

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
9
3.0 PACKAGE CONTENTS
DME-05
2V2.5A Power Adapter
BNC to BNC Cable
HDMI Cable
Serial Cable + Gender Changer
*Note: he serial cable is included for advanced troubleshooting purposes only and is not needed by the typical user.
Figure Package Contents for the DME-05

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
10
4.0 FEATURES
HD resolutions up to 1920x1080, including 1080p60/50, 1080i30/25, and 720p60/50
H.264 support
Support for extraction from up to four sub channels of audio from SDI
AAC-LC, AACH-HE v1, and AAC-HE v2 audio codecs
Ability to encode two different streams from the same source
Closed caption support (EIA-608, EIA-708)
Pro-MPEG Forward Error Correction support for encode and decode
Inputs: HDMI, 3G-SDI, ASI (Decode)
Outputs: HDMI, 3G-SDI, ASI (Encode)
Interfaces to 1Gb Ethernet, USB 2.0 (x2), RS-232
Outputs MPEG-2 ransport Stream, R P, R MP, SR P or S File
H P-based configuration software for user-friendly configuration and control
RS-232 serial port for technical configuration and control
Operating emperature and Humidity: 0 to 40ºC at 20-80% relative humidity (non-condensing)
Storage emperature and Humidity: -10 to 65ºC at 20-80% relative humidity (non-condensing)
Measurements: 142 x 130 x 34 mm (16.93 x 8.46 x 1.72 in)
Weight: 613 g (1.35 lb)
4. Supported Input Resolutions
SDI: 1080p60, 1080p50, 1080i30, 1080i29.97, 1080i25, 720p60, 720p59.94, 720p50, 576p50,
576i25, 480i30, and 480i29.97
HDMI: 1080p60, 1080p50, 1080i30, 1080i29.97, 1080i25, 720p60, 720p59.94, 720p50, 576p50,
576i25, 480p60, 480i30, and 480i29.97
4.2 Supported Output Resolutions
HDMI: 1080p60, 1080p59.94, 1080p50, 1080i30, 1080i29.97, 1080i25, 720p60, 720p59.94,
720p50

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
11
RS-232 Serial
3G-SDI/ASI Output
1
3G-SDI/ASI Input
12V Power
HDMI Input
2
HDMI Output
2x USB 2.0
GigE
5.0 OPERATING CONTROLS
Figure 2 Front and Rear Views of the DME-05

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
12
6.0 GETTING STARTED WITH THE DME-05
his section gives step-by-step instructions on using the DME-05 to stream 1080p or 1080i video to the VLC
media player running on your PC. In addition to the DME-05, you will need a computer with VLC media
player downloaded, a 1080p60/1080i video source with SDI output, a BNC to BNC cable and at least one
Ethernet cable. Encoding with an HDMI source is described later in Section 6.10.
*Note: Actual version numbers for your Z3 product may differ from those pictured in this document.
6. Set up the SDI Video Source
(1) Select an HD source with SDI output.
(a) Power on the HD source.
(b) Connect the HD source via SDI to a monitor.
(c) Set the HD Source to 1080p60 or 1080i output.
(d) If you are using a media player rather than a video camera, select and begin playback of the
content you would like to stream.
6.2 Connect and Power up the DME-05
(1) Connect the SDI source to “SDI In” on the unit.
(2) Connect an Ethernet cable from “Ethernet” on the back of the unit to a switch, router or other DHCP
server on the same network as your Windows PC. You will use this PC to control the DME-05 and to
decode the output stream.
(3) Connect the AC power supply and turn on the power switch. It will take 45-60 seconds to boot.
Figure 3 DME-05 Rear Panel SDI Encode Connections
( ) Connect video
source to
“
SDI In
”
(2) Connect
Ethernet
(3) Connect Power
and Turn on
Switch

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
13
6.3 Find the Encoder Using ZFinder
ZFinder is a PC Utility that allows you to find any Z3 echnology product on your network. If you have
not downloaded this to your computer, you can find it on the USB drive provided with your system.
(1) Verify your PC is set to DHCP. If it is set to a static IP address, ZFinder will be unable to discover your
encoder, or it will appear in red and you will be unable to proceed further.
(2) Run the “ZFinder” PC Utility on your Windows PC. he ZFinder window appears. ZFinder then
completes a scan of the network and lists the location of all Z3 systems connected to the network.
In this case, the DME-05 appears.
(3) Click on the DME-05 entry in the window to select it. his will cause the “Edit Device”, “Open
Device” and “Flash LEDs” boxes to activate.
Figure 4: ZFinder with a Product Selected
*Note: Selecting “Edit Device” allows for manual changes to network settings. Selecting “Flash LED’s” is not
applicable to the DME-05 as there are no LEDs.
(4) Click on “Open Device.” An Internet browser window is opened (for best results, Firefox or Chrome
are recommended) and the H P-based graphical user interface (GUI) appears at the System Setup
tab.

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
14
6.4 Configure Encoder for UDP Streaming
(1) Click on the CH1 tab.
(2) Verify the “Video Source” is set to “HD-SDI” using the dropdown menu.
*Note: HD-SDI selection supports HD-SDI resolutions and 3G-SDI resolutions.
(3) Set the “Video Resolution” to “1920x1080” or “Follow Input”.
(4) Set “Output Format” to “UDP”.
(5) You can set the “Dest Address” to:
(a) the IP address of your PC that will be running the VLC media player (in the pictured
example, 192.168.0.6)
(b) or to a multicast address (An example multicast address would be “225.1.2.3”. If you are
on a shared network, check with your Network Administrator.)
(6) Make note of the value of “Dest Port” ( his will be “5004” by default).
Figure 5 DME-05 User Interface System Setup Tab

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
15
(7) If the encoder hasn’t already autostarted, click on “start” in the “Channel Controls” section near the
bottom of the screen. If the encoder is already running, click on “stop” and then “start” to confirm
the specified values are in effect.
*Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.3, “Advanced Settings Mode”, for more information on accessing additional settings.
Figure 6 Channel Tab – UDP
(4) Change to
“
UDP
”
(5) Change to PC IP
Address or
Multicast Address
(6) Note Value
(
) If necessary, click
“
Stop
”
(
7
) Click
“
Start
”
(2) Verify
Is “HD-SDI”
(3) Change to
“ 920x 080” or
“Follow input”

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
16
6.5 View a UDP Stream in VLC
(1) Run VLC media player on your PC (version used by Z3: 2.1.5)
(2) Select Media – Open Network Stream. In the box, type “udp://@192.168.0.6:5004”, where
“192.168.0.6” matches the values of the computer IP address or multicast address entered for
“Dest Address”, and 5004 is the value of “Dest Port” noted previously.
(3) Press “Enter.”
(4) You will now see video streaming to VLC.
Figure 8 Example of Z3 Video Streaming to VLC (UDP)
Figure 7 VLC Open Network Stream Screen for UDP

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
17
6.6 Configure Encoder for RTP/RTSP Streaming
Once you have UDP streaming, it is relatively simple to change to R P or R SP streaming. All that is
needed is one parameter change. o stream using R P or R SP, complete the following steps:
(1) In the CH1 configuration tab, click on “stop” to stop the current encoding session.
(2) Change “Output Format” from “UDP” to “R P/R SP”.
When R P/R SP is selected, the encoder will send an R P stream using the Dest Address and Dest Port
listed in the user interface. If R SP will be used exclusively, the Dest Address field can be set to
“127.0.0.1” to prevent the R P stream from being sent.
*Note: As R SP operates through port 554, it is advised never to set the “Dest Port” field to “554” when
R P/R SP is selected.
(3) Click on “start” to start the R P/R SP encoding session.
*Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.3, “Advanced Settings Mode”, for more information on accessing additional settings.
Change to
“
RTP/RTSP
”
Figure 9 Channel Tab – RTP/RTSP

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
18
6.7 View an RTSP Stream in VLC
(1) Run VLC on your PC (version used by Z3: 2.1.5)
(2) In the “Open Media” box, enter “rtsp://{IP Address}/z3-{ch #}{m}.mp4” for the network URL.
(a) {IP Address} will be the IP address of your encoder. If your encoder is set to DHCP ( his is the
default setting when you first receive your encoder.), you can find this in ZFinder or the web
browser with the user interface open. If you have set your encoder to a static IP address, this
should match the “Local IP Address” field in the System Setup tab. In the example pictured, the
encoder was assigned 192.168.1.102 at start up.
(b) {ch #} corresponds to the number of the channel tab of the user interface. For example if the
CH1 tab is used, “1” is entered.
(c) {m} is added if a multicast address is being used. (For example, rtsp://{IP_Address}/z3-1m.mp4)
If you are using a unicast address, as we are in the example pictured, omit the letter m after “z3-
1” in the address.
(d) In this example, the full network URL would be “rtsp://192.168.1.102/z3-1.mp4”.
*Note: VLC version 2.1.5 or later is needed for R SP support.
(3) You will then see R SP video streaming on VLC.
Figure 0 VLC Open Network Stream Screen for RTSP
Figure Example of Z3 Video Streaming to VLC (RTSP)

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
19
6.8 Configure Encoder for RTMP Streaming
he DME-05 supports R MP streaming accepted by a variety of CDN’s (Content Delivery Networks) and
social media platforms for wide content distribution and live streaming.
*Note: VLC does not support R MP. he test player within Wowza Streaming Engine™ is recommended.
6.8. Stream RTMP to the Wowza Streaming Engine™
Z3 echnology is a member of the Wowza Media Systems™ echnology Alliance partner program, and
the Wowza Streaming Engine™ is used here as an example server for R MP streaming.
(1) In the CH1 configuration tab, click on “stop” to stop the current encoding session.
(2) Set “Output Format” to “R MP”.
(3) For “Dest Address”, type “{IP_Address}:{port}/{app}/{stream_name}”,
(a) {IP_Address} will be the IP address of the PC with the Wowza server installed. In the example
pictured, “192.168.0.4” is used.
(b) {port} will be the port used on the PC with the Wowza server. In the example pictured, “1935” is
used.
(c) {app} will need to match the application used in Wowza. In the example pictured, “live” is used.
(d) {stream_name} can be name of your choosing. In the example pictured, “1080” is used.
(e) In this example, the full “Dest Address” would be “192.168.0.4:1935/live/1080”.
(4) If necessary, set “Authentication” to “Enable” and enter your valid Wowza login credentials.
*Note: By default a limited selection of video encoding settings are available in the user interface. See Section
8.3, “Advanced Settings Mode”, for more information on accessing additional settings.
(5) Click the “start” button.

DOC-USR-0 5 -0
___________________________________________________________________________________________
Z3 echnology, LLC ♦ 100 N 8
th
S , S E 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
20
(6) If you have not already done so, install the Wowza Streaming Engine™ server on a PC on your network
(for details on configuring Wowza, please see APPENDIX A: Configuring the Wowza Server for R MP).
(7) Go to a PC that is on the same network as the Wowza server and open a web browser (in this
example, FireFox is used). ype in the URL of the Wowza server with the port 8088 (in this example,
“192.168.0.4:8088”). his will bring up the Wowza home page. Log in with your valid user name and
password.
(8) At the top you will see four options: Home, Server, Applications, and Help. Click on “Applications”
(9) hen select “live”.
(10) Click on “ est Players” in the top right hand corner.
Figure 2 Channel Tab – RTMP Streaming to the Wowza Streaming Engine™
(2) Change
to “RTMP”
(
) If necessary, click
“
Stop
”
(
5
) Click
“
Start
”
(3) Set to
“ 92. 68.0.4: 935/live/ 080”
(4) If necessary, set to
“Enable”
