Zest 4 Leisure Caroline Bench with Storage Box User manual

Assembly Instructions
(W x D x H): 1.20m x 0.50m x 0.80m
Product Name: Caroline Bench with Storage Box
Pressure Treated products should not be treated with any other products for the first month.
PLEASE KEEP THIS INSTRUCTION
Zest4Leisure
01352 752555 option 1 –[e-mail]
V2-12.16

Caroline Bench with Storage Box Assembly
Instructions
Requires 2 person assembly.
Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit
required in order for you to drill all screw holes before construction.
The colour version of this document can be downloaded from:
www.zest4leisure.co.uk/downloads/category/C1
Caroline Bench with Storage Box Pack List
Item Description Quantity
A Seat Assembly 1
B Side Assembly 2
C Back Assembly 1
D Box Panel (Front & Back) 2
E Box Base Panel 1
F Seat Infill 1
Fixings
60mm screws 6
90mm screws 16
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed.
Assembly requires 2 persons.
Tools required: Corded/Cordless Drill, Pozi-drive Bit/Screwdriver, 3mm Drill Bit
required in order for you to drill all screw holes before construction.
Caroline Bench with Storage Box is now complete.
1. Position Seat Assembly A between Side Assemblies B and attach using 4no
90mm Screws (2no per side). (See Fig.1)
2. Position Back Assembly C between SideAssemblies B and attach using 4no
90mm Screws (2no per side). (See Figs. 2a & 2b)
3. Position 1no Box Panel D to the front of seat assembly, beneath seat and
between legs and attach through legs using 4no 90mm screws (2no per leg).
(See Fig. 3a)
Repeat procedure on back of seat assembly, ensuring panel follows angle of
back legs. (See Fig. 3b)
4. Insert Box Base Panel E between box panels and fix using 6no 60mm screws
(3no per front & back). (See Figs. 4a & 4b)
5. Place Seat Infill F into Seat Assembly A. (See Fig. 5)

www.zest4leisure.co.uk
2a
1
2b 3a
3b 4a
4b 5
