Zest 4 Leisure Deep Root Planter 1m User manual

Assembly Instructions
(WxDxH) 1.0m x 0.7m x 0.8m
Item Code: Deep Root Planter 1m
PLEASE KEEP THIS INSTRUCTION
Zest4Leisure
01352 752555 option 1 –[e-mail]

Deep Root Planter 1m Assembly Instructions
Requires 2 person assembly.All screw holes to be pre-drilled.
Tools required: Corded/Cordless Drill, Pozidrive Bit/Screwdriver, 3mm Drill Bit.
Deep Root Planter 1m Pack List
Item Description Quantity
A End Panel 2
B Side Panel 2
C Base Board Support Rail 2
D Baseboard 9
E Capping Trim 4
Fixings
45mm Screws 30
35mm Screws 8
www.zest4leisure.co.uk

Please take a few moments to check all pack contents listed on page 1 of the
Assembly Instructions.
Please contact “Zest4Leisure” directly if any of the pack contents are damaged
or missing. Contact telephone: [phone] option 1 or email:
[e-mail]
Assembly requires 2 persons. All screw holes to be pre-drilled.
Tools required: Corded/Cordless Drill, Pozidrive Bit/Screwdriver, 3mm Drill Bit.
The Deep Root Planter 1m is now complete.
1. Attach one End Panel (A) to Side Panels (B) using 6no 45mm screws per End
Panel, as shown in Figs 1a & 1b. Repeat process with the second End Panel (A)
as shown in Fig 1c. Position screws as shown in Fig 1d.
2. Attach Base Board Support Rails (C) to base of Side Panels using 8no 35mm
screws (4no per side) as shown in Figs 2a & 2b.
3. Loose fit ALL base boards (D) as shown in Figs 3a & 3b. A minimum of three
central boards to be screwed down to Base Board Support Rails using 6no 45mm
screws.
4. Set out the 4no Capping Trims (E) on top of the planter and attach using the 12no
45mm screws (3no screws per trim) as shown in Figs 4a & 4b.

www.zest4leisure.co.uk
1c
1a
2a 2b
1b
1d

www.zest4leisure.co.uk
4b4a
3a 3b
