3One data TNS5500D Series User manual

TNS5500D 12-Port Series
Layer 2 Wall Mounting
Industrial Ethernet Switch
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District,
Shenzhen
Website: www.3onedata.com
Tel: [phone]
Fax: [phone]
【Packag Checklist】
Please check the integrity of package and accessories while
first using the switch.
1.
Switch ×1
2.
Warranty card
3.
Certificate
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
This series of product is 12-port managed layer-2 wall-
mounted EN50155 industrial Ethernet switch Models as
follows:
Model I. TNS5500D-8P4GT-P24 (8 100M PoE M12 + 4
Gigabit M12, 24VDC).
Model II. TNS5500D-8P4GT-P110 (8 100M PoE M12 + 4
Gigabit M12, 110VDC).
Model III. TNS5500D-8T4GT-P24 (8 100M M12 + 4 Gigabit
M12, 24VDC).
Model IV. TNS5500D-8T4GT-P110 (8 100M M12 + 4
Gigabit M12, 110VDC).
Model V. TNS5500D-8GP4GT-P110 (8 Gigabit PoE M12 +
4 Gigabit M12, 110VDC).
Model VI. TNS5500D-12GT-P110 (12 Gigabit M12,
110VDC).
【Panel Design】
Model I, Model II Front View
Model III, Model IV Front View
Model V front view
Model VI Front View
Left view and right view
Bottom view and top view

1. Power supply indicator (P1-P2)
2. Alarm indicator (ALM)
3. Running indicator (RUN)
4. Relay alarm output interface
5. Grounding screw
6. CONSOLE port
7. Lugs
8. Power input interface (P1-P2)
9. Ethernet port indicator (E1-E8, G1-G4)
10. Gigabit Bypass M12 interface (Two groups of
Bypass: G1-G2 and G3-G4, or G9-G10 and G11-
G12)
11. 100M PoE indicator (E1-E8)
12. 100M PoE M12 interface (E1-E8)
13. Gigabit PoE indicator (G1-G8)
14. Gigabit PoE M12 interface (G1-G8)
【Mounting Dimension】
Unit: mm
Notice Before Mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【Wall-mounted Device Mounting】
On the wall of device mounting, place the device on
the wall for reference or refer to the mounting
dimension to mark two screw positions.
Hang the device on the labeled wall, align the bolt
to the labeled position, then fix them with a certain
gap.
Slide the device down to hang on the screw, then
tighten the screw, and the installation is finished.
【Wall-mounted Device Disassembling】
Power off the device.
Hold the device steadily and screw out the bolt in
the wall.
Take out the device, disassembling ends.
Notice before power on:
Power ON operation: First insert the power supply
terminal block into the device power supply interface,
then plug the power supply plug contact and power on.
Power OFF operation: First, remove the power plug, then
remove the wiring section of terminal block. Please pay
attention to the above operation sequence.
【Power Supply Connection】
Model I and Model III: 24VDC power supply
Supply supports non-polarity and redundant power
input.The power supply interface adopts M12 A-
Coded 4-Pin pin (male) connector. The pin
definitions are shown in the left figure. Power supply
input range:
-Model I: 24VDC (18~36VDC).
-Model III: 24VDC (9~36VDC).
model II, Model IV, Model V, Model VI: 110VDC
power supply
Supply supports non-polarity and redundant power
input. The power supply interface adopts M12 A-
Coded 4-Pin pin (male) connector. The pin
definitions are shown in the left figure. Power
supply input range: 110VDC (66~156VDC).
【Relay Connection】
This series device provides 1 M12 D-Coded 4-Pin
slot (female) that supports 1 relay alarm output. R1
and R2 are a set of normally open contacts of the
device alarm relay. They are open circuit in the state of normal
non alarm, closed when any alarm information occurs. For
example: the relay supports the output of network abnormality
alarm. It can be connected to alarm light or alarm buzzer or
other switching value collecting devices, which can timely
inform operators when the alarm occurs. The pin definitions of
relay are shown in the figure.
【Console Port Connection】
The series of device provides 1 program debugging
port based on RS232 serial port which can conduct
device CLI command management after
connecting to PC. The interface adopts M12 D-Coded 4-Pin
slot (female). The pin definitions of M12 are shown in the figure:
【Communication Interface Connection】
100M PoE M12 interface

This series of device provides 8
10/100Base-T(X) interfaces, the
interface type is M12 D-Coded
4-Pin slot (female). Single port
supports up to 30W PoE power
output, PoE power supply Pin 1
and 3 are positive, 2 and 4 are negative, and M12 pin is defined
as follows:
Pin No. Pin Definition Description
1 TD+ Positive send data of 100M
Ethernet
2 RD+ Positive receive data of
100M Ethernet
3 TD- Negative send data of
100M Ethernet
4 RD- Negative receive data of
100M Ethernet
Gigabit M12 interface
This series of device provides 4 10/100/1000Base-T(X)
interfaces, the interface type is M12 X-Coded 8-Pin slot
(female). Two groups of Bypass interfaces are supported, in
which G1 and G2 are a group and G3 and G4 are a group.
The pin definitions of M12 are shown as follows:
Pin No. Pin Definition Description
1 GE0+ Positive bi-directional
data of Gigabit Ethernet
group 1
Pin No. Pin Definition Description
2 GE0- Negative bi-directional
data of Gigabit Ethernet
group 1
3 GE1+ Positive bi-directional
data of Gigabit Ethernet
group 2
4 GE1- Negative bi-directional
data of Gigabit Ethernet
group 2
5 GE3+ Positive bi-directional
data of Gigabit Ethernet
group 4
6 GE3- Negative bi-directional
data of Gigabit Ethernet
group 4
7 GE2- Negative bi-directional
data of Gigabit Ethernet
group 3
8 GE2+ Positive bi-directional
data of Gigabit Ethernet
group 3
【Checking LED Indicator】
The series of devices provide LED indicators to monitor its
operating status, which has simplified the overall
troubleshooting process. The function of each LED is
described in the table below:
LED
Indicate
Description
P1/P2
ON P1/2 is connected and running
normally
OFF P1/2 is disconnected and
running abnormally
ALM
ON
Port link has alarm
OFF
Port link has no alarm
RUN
ON
The device is powering on or
the device is abnormal.
OFF The device is powered off or the
device is abnormal.
Blinking
Blinking 1 time per second,
system is running normally
LINK(E1-
E12, G1-
G12)
ON Ethernet port has established a
valid network connection
Blinking
Ethernet port is in an active
network status
OFF
Ethernet port has not
established valid network
connection
POE(E1-
E8, G1-G8)
ON POE port is powering other PD
devices normally
OFF POE port is not powering other
PD devices
【Logging in to WEB Interface】
This series of devices supports WEB management and
configuration, and computers can access devices through
Ethernet interfaces. The way of logging in to device’s
configuration interface via IE browser is shown as below:
Configure the IP addresses of computer and the
device to the same network segment, and the
network between them can be mutually accessed.
Enter device’s IP address in the address bar of the
computer browser.
Enter device’s username and password in the login
window as shown below.

Click “Login” button to login to the WEB interface of
the device.
Note:
The default IP address of the device is “192.168.1.254”.
The default user name and password of the device are
“admin”.
If the username or password is lost, user can restore it to
factory settings via management software; all modified
configurations will be cleared after restoring to factory
settings, so please backup configuration file in advance.
Please refer to user manual for specific configuration
method of logging in to WEB interface and other
configurations about network management function.
【Specification】
Panel
Gigabit M12
LAN Port
10/100/1000Base-T(X), M12(Female),
8-Pin X-Coded, Automatic Flow Control,
Full/half Duplex Mode, MDI/MDI-X
Autotunning; support two groups of
Bypass
Gigabit PoE
M12
10/100/1000Base-T(X), M12(Female),
8-Pin X-Coded, Automatic Flow Control,
Full/half Duplex Mode, MDI/MDI-X
Autotunning;
Single port supports up to 30W PoE
power output, PoE power supply Pin 1
and 3 are positive, 2 and 4 are negative
100M M12 10/100Base-T(X), M12(Female), 4-Pin
D-Coded, Automatic Flow Control,
Full/half Duplex Mode, MDI/MDI-X
Autotunning
100M PoE
M12
10/100base-T(X), M12 (Female), 4-Pin
D-Coded, automatic flow control,
full/half duplex mode, MDI/MDI-X
automatic detection; The single port
supports up to 30W PoE power supply
output. Pin 1 and 3 of PoE power
supply are positive, while pin 2 and 4
are negative
Console port CLI command line management port
(RS-232), M12(Female), 4-Pin D-Coded
Alarm
interface
M12 (Female), 4-Pin D-
Coded, support
1 relay alarm output, current load
capability is 1A@30VDC or
0.3A@125VAC
Indicator Power indicator, alarm indicator, running
indicator, interface indicator, PoE
indicator
Switch Property
Backplane
bandwidth
56G
Packet buffer
size
12Mbit
MAC Address
Table
16K
Power Supply
Model I M12(Male), 4-Pin A-Coded
24VDC(18~36VDC), support non-
polarity
Model III M12(Male), 4-Pin A-Coded
24VDC(9~36VDC), support non-polarity
Model II,
Model IV,
Model V,
Model VI
M12(male)，4-Pin A-Coded，
110VDC (66~156VDC), support reverse
connection protection
Power Consumption
Model II Full-
load(Without PoE):
15.8W@110VDC
Full-load(With PoE): 124.6W@110VDC
Working Environment
Working
temperature
-40~75℃
Storage
temperature
-40~85℃
Working
humidity
5%～95% (no condensation)
Protection
grade
IP67(metal shell)
【Disposal of Waste Electrical and Electronic
Equipment (WEEE 2012/19/EU)】
(Applicable in the EU-member states)
The crossed-out wheeled bin
symbol on the equipment or its
packaging indicates that the
product, at the end of its
service life, shall not be mixed
with unsorted municipal waste
but should be collected
separately, in accordance with
local laws and regulations.
A proper separate collection of
end-of-life equipment for the subsequent recycling, treatment
and environmentally compatible disposal, will help prevent
potential damage to the environment and human health,
facilitating the reuse, recycling and/or recovery of its
component materials.
Private users should contact their vendor or municipal waste
management service and ask for disposal information.
Professional users should contact their suppliers and check
the terms of their selling agreement.
This product must not be disposed of with other commercial
waste.

Users’ cooperation in the correct disposal of this product will
contribute to saving valuable resources and protecting the
environment.
