3One data IES2010 Series User manual

IES2010 Series
Unmanaged Industrial Ethernet
Switch Quick Installation Guide
3onedata Co., Ltd.
Address:
3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District,
Shenzhen
Website:
www.3onedata.com
Tel:
[phone]
Fax:
[phone]
【Package checklist】
Please check whether the package and accessories are intact
while using the switch for the first time.
1.
Industrial Ethernet switch
2.
Certification
3.
Quick installation guide
4.
Warranty card
5.
DIN-Rail mounting attachment
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
This series are 100M/Gigabit unmanaged DIN-Rail industrial
Ethernet switch. Models as follows:
Model I. IES2010-2GS (2 Gigabit SFP + 8 100M copper
ports)
Model II. IES2010-2GS-4F (2 Gigabit SFP + 4 100M fiber
ports + 4 100M copper ports)
【Panel design】
Rear view, Top view and Bottom view
Front view
1. DIN-Rail mounting kit
2. Grounding screw
3. Power supply input terminal block
4. Power supply input status indicator PWR
5. Port connection indicator
6. 100Base-FX Ethernet fiber port
7. 1000Base-SFP Ethernet SFP slot
8. 10/100Base-T(X) Ethernet copper port (including
indicator)
9. 10/100Base-T(X) Ethernet copper port
【Mounting Dimension】
Unit: mm
Attention before mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【DIN-Rail Mounting】
For convenient usage in industrial environments, the product
adopts 35mm DIN-Rail mounting, mounting steps as below:
Check whether the DIN-Rail mounting kit thatStep 1 comes with the device is installed firmly.
Insert the bottom of DIN-Rail mounting kit (one sideStep 2 with spring support) into DIN-Rail, and then insert
the top into DIN-Rail.
Tips:

Insert a little to the bottom, lift upward and then insert
to the top.
Check and confirm the product is firmly installed onStep 3 DIN-Rail, and then mounting ends.
【Disassembling DIN-Rail】
Power off the device.Step 1 After lift the device upward slightly, first shift out theStep 2 top of DIN-Rail mounting kit, and then shift out the
bottom of DIN-Rail, disassembling ends.
Attention before powering on:
Power ON operation: first connect power line to the
connection terminal of device power supply, and then
power on.
Power OFF operation: first unpin the power plug, and
then remove the power line, please note the operation
order above.
【Power Supply Connection】
DC power supply
This series provide 4 pins power input
terminal blocks and two independent DC
power supply systems of PWR1 and PWR2.
Power supply range: 12~48VDC
【Checking LED Indicator】
The function of each LED is described in the table as below:
LED
Status
Description
PWR
ON
Power supply is connected and
running normally
OFF
Power supply is disconnected
and running abnormally.
Link/ACT
(1-10)
ON
Ethernet port connection is
active.
Blinking
Data transmitted
OFF
Ethernet port connection is
inactive.
10M/100M
(only suit for
ON
100M operating mode
(100Base-TX)
100M
copper port
of model II)
OFF
10M operating mode
(10Base-T)
【Specification】
Panel
Gigabit SFP
1000Base-SFP, SFP slot
100M copper port
10/100Base-T(X) self-adapting
RJ45 port, full/half duplex
self-adaption, support
MDI/MDI-X self-adaption
100M fiber port
100Base-FX, optional SC/ST/FC
port
Indicator
Power indicator, interface
indicator and operating mode
indicator
Exchange attributes
Backplane bandwidth
7.6G
Packet buffer size
1Mbit
MAC table size
8K
Power supply
Input power supply
12~48VDC
Access terminal
4 pins 7.62mm pitch terminal
blocks
Support dual power supply
redundancy and anti-reverse
connection
Consumption
No-load
≤5.9W@24VDC
Full-load
≤7.3W@24VDC
Environmental Limits
Working temperature
-40~75℃
Storage temperature
-40~85℃
Working humidity
5%~95% (no condensation)
Protection grade
IP30 (metal shell)
