3One data TNS5800D Series User manual

TNS5800D Series
Managed Wall-mounted Industrial
Ethernet Switch Quick Installation
Guide
3onedata Co., Ltd.
【Package Checklist】
Please check whether the package and accessories are intact
while using the switch for the first time.
1.
Industrial Ethernet switch
2.
CD
3.
Quick installation guide
4.
Certification
5.
Warranty card
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
The series of product is 100M/Gigabit layer 3 managed
Wall-mounted industrial Ethernet switch designed for rail
transit industry. The module is: TNS5800D-4GT-8T (4 Gigabit
copper ports + 8 100M copper ports)
【Panel Design】
Front view
Bottom view
Top view
Left view
Right view
1. Hanger
2. Relay alarm output terminal block
3. Console port
4. Indicator of power supply input status PWR
5. Relay alarm indicator ALARM
6. Indicator of device running status RUN
7. Grounding screw
8. Power input terminal block
9. 10/100/1000Base-T(X) Gigabit copper port
10. Gigabit copper port connection indicator
11. 100M copper port connection indicator
12. 10/100Base-T(X) 100M copper port
【Mounting Dimension】
Unit: mm
Address:
3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District,
Shenzhen
Website:
www.3onedata.com
Tel:
[phone]
Fax:
[phone]

Attention before mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【Wall-mounting the Device】
Put the device on the wall it will be mounted as
Step 1
reference or to refer to its mounting dimension, and
mark the locations of the 4 expansion screws.
Mount the screws on the wall and reserve 7mm
Step 2
void.
Hang the device on the 4 expansion screws and
Step 3
slide it down, then tighten the screws, mounting
ends.
【Disassembling the Device】
Step 1 Device powers off
Step 2 Unscrew the screws on the wall about 7mm.
Step 3 Lift the device then take it out, disassembling ends.
Note:
Power ON operation: first connect power line to the
connection terminal of device power supply, then power
on.
Power OFF operation: first unpin the power plug, then
remove the power line, please note the operation order
above.
【Power Supply Connection】
DC power supply
The series devices provide 1 power supply
input. The interface adopts M12 A-Coded 4-pin
needle (male) connector, which could be
connected to M12 A-Coded 4-pin slot (female).
Power supply range: 110VDC (70-160VDC).
The pin definitions of M12 (Male) are as follows:
No.
1
2
3
4
Definition
FG
V-
V+
NC
Description
Ground
Power
input
negative
Power
input
positive
reserved
【Relay Connection】
This device provides 1 M12 D-Coded 4-Pin slot
(female) for relay output. R1 and R2 is a pair of
normally open contacts of device alarm relay.
They are open circuit in normal non alarm state,
closed when any alarm information occurs.
Such as: it's closed when power off, and send out alarm. This
series switches support 1 channel relay alarm information
output, support DC power alarm information or network
abnormal alarm output, it can be connected to alerting lamp,
alarm buzzer, or other switching value collecting devices for
timely warning operating staffs when alarm information occurs.
The pin definitions of relay are as follows:
No.
1
2
3
4
Definiton
R1
R2
NC
NC
【Console Port Connection】
This device provides 1 program debugging port
based on RS232, which could be connected to
PC for device CLI command management. The
interface adopts M12 D-Coded 4-pin slot
(female). The pin definitions of M12 are as follows:
No.
1
2
3
4
Definition
TX
RX
NC
GND
Description
RS-232
sending
signal
RS-232
receiving
signal
Reserved
Ground
【Communication Interface Connection】
M12 100M Copper Port
This device provides 8 10/100Base-T(X) ports.
The interface type is M12 D-Coded 4-pin slot
(female). The pin definitions of M12 are as
follows:
No.
Definition
Description
1
TD+
100M Ethernet transmitted
signal Positive
2
TD-
100M Ethernet transmitted

signal Negative
3
RD+
100M Ethernet received
signal positive
4
RD-
100M Ethernet received
signal negative
M12 Gigabit Copper Port
This device provides 4
10/100/1000Base-T(X) interfaces. The
interface type is M12 A-Coded 8-Pin slot
(female) and its pin definitions are as follow:
No.
Definition
Description
1
D0+ (DA+)
The first group of bi-directional
data of Gigabit Ethernet
positive
2
D0- (DA-)
The first group of bi-directional
data of Gigabit Ethernet
negative
3
D1+ (DB+)
The second group of
bi-directional data of Gigabit
Ethernet positive
4
D1- (DB-)
The second group of
bi-directional data of Gigabit
Ethernet negative
5
D3+ (DD+)
The fourth group of
bi-directional data of Gigabit
Ethernet positive
6
D3- (DD-)
The fourth group of
bi-directional data of Gigabit
Ethernet negative
7
D2- (DC-)
The third group of
bi-directional data of Gigabit
Ethernet negative
8
D2+ (DC+)
The third group of
bi-directional data of Gigabit
Ethernet positive
【Checking LED Indicator】
This device provides LED indicators for monitoring the work
status of the device, which has simplified the troubleshooting
process comprehensively. The function of each LED is
described in the table as below:
LED
Status
Description
PWR
ON
PWR is connected and
running normally
OFF
PWR is disconnected and
running abnormally.
ALARM
ON
Power supply, port link alarm
OFF
Power supply, port link
without alarm
RUN
ON
The device is powered on or
the device is abnormal.
OFF
The device is powered off or
the device is abnormal.
Blinking
Blink 1 time/s, system is
running well.
Link/Act
(1-8/G1-G4)
ON
Ethernet port connection is
active.
Blinking
Data transmitted
OFF
Ethernet port connection is
inactive.
【Logging in to WEB Interface】
This device supports WEB management and configuration.
Computer can access the device via Ethernet interface. The
way of logging in to device’s configuration interface via IE
browser is shown as below:
Configure the IP addresses of computer and the
Step 1
device to the same network segment, and the
network between them can be mutually accessed.
Enter device’s IP address in the address bar of the
Step 2
computer browser.
Enter device’s username and password in the login
Step 3
window as shown below.
Click “OK”button to login to the WEB interface of
Step 4
the device.
Note:
The default IP address of the device is “192.168.1.254”.
The default username and password of the device is
“admin123”.
If the username or password is lost, user can restore it to
factory settings via device DIP switch or management
software; all modified configurations will be cleared
after restoring to factory settings, so please backup
configuration file in advance.
Please refer to user manual for specific configuration
method of logging in to WEB interface and other
configurations about network management function.
【Specification】
Panel
100M M12
10/100Base-T(X), M12
(Female), 4-Pin D-Coded,
automatic flow control, full/half
duplex mode, MDI/MDI-X
automatic detection

Gigabit M12
10/100/1000Base-T(X)，
M12(Female)，8-Pin A-Coded
automatic flow control, full/half
duplex mode, MDI/MDI-X
automatic detection; support
Bypass function
Console port
CLI command management
port, M12 D-coded port
Alarm interface
1 relay alarm information
output, M12 D-coded port
Indicator
Power indicator, run indicator,
interface indicator, alarm
indicator
Exchange attributes
Backplane bandwidth
128G
Packet buffer size
12Mbit
MAC table size
16K
Power supply
Input power supply
110VDC (70-160VDC)
M12 A-coded port
Consumption
No-load
14.30W@110VDC
Full-load
14.85W@110VDC
Working environment
Working temperature
-40～75℃
Storage temperature
-40～75℃
Working humidity
5%～95%(no condensation)
Protection grade
IP30 (metal shell)
