ACME Ellipsoidal 10 DMX User manual

Features:
E-10D/E-40D is DMX Version, uniform light, sharp image edge, and
self-locking focus lens. The product takes advantage of the heat pipe heat
conduction and housing feature to dissipate heat without fan to prolong
LED life.
Specifications:
Power Voltage: AC 100~240V, 50/60Hz
Power Consumption: 15W (E-10D)
30W (E-40D)
Light Source:
E-10D CW DXX: LTAW1202-012-007-5500
E-10D WW DXX: LTAW1202-012-007-3150
E-40D CW DXX: C117C1206-036-001
E-40D WW DXX: C117W1206-036-001
Color temperature:5600±150K (E-10D/40D CW)
3200±150K (E-10D/40D WW)
Beam Angle: 19°/26°/36°/50°
CRI≥95
Dimension/Weight:
273 x 244 x 140 mm, 2kgs
10.7"x9.6"x5.5"in, 4.4lbs
244
273
140
1F

How To Change The Gobo
At first, put the gobo by hand as the arrow into the gobo gel splint, and
insert the gobo gel splint into the slot of the unit, please turn the hand
knob to left or right in order to take out gobo gel splint.
Note: The diameter of the inner and outer rings of the gobo, the size and
thickness of the gobo gel splint are shown in the following figure:
How To Change The Focus Lens
2F

At first, please push the screws on both side of the fixture by hand as the
arrow, and move away the focus lens silently by hand as the arrow.
Then insert the focus lens as the arrow silently, and insert the screws in
place by hand as the arrow, and fasten the lens.
Main Function
To select any of the given functions, press the MENU button up to when
the required one is showing on the display. Select the function by ENTER
button and the display will blink. Use the DOWN/UP button to change the
mode. Once the required mode has been selected, press the ENTER button
to setup, to go back to the functions without any change press the MENU
button again. Hold and press the MENU button about one second or wait
for one minute to exit the menu mode.
The main functions are showing below:
56
3F

DMX Address
Press the MENU button up to when the is shown on the display.
Press the ENTER button and the display will blink. Use the DOWN and UP
button to change the value from 1to 512. Once the mode has been
selected, press the ENTER button to setup, to go back to the functions
without any change press the MENU button again. Hold and press the
MENU button about one second or wait for one minute to exit the menu
mode.
MENU
DMX Address
Channel Mode
DMX State
Led
Display Inversion
Auto Test
Fixture Hours
Software Version
Dimmer Mode
Manual Mode
4F

Channel Mode
Press the MENU button to show on the display. Press the ENTER
button and the display will blink. Use the DOWN and UP button to select
1ch or 2ch. Once the mode has been selected, press the ENTER button to
setup, to go back to the functions without any change press the MENU
button again. Hold and press the MENU button about one second or wait
for one minute to exit the menu mode.
DMX State
Press the MENU button up to when the is shown on the display.
Press the ENTER button and the display will blink. Use the DOWN and UP
button to select the (blackout mode) or (last state).
Once the mode has been selected, press the ENTER button to setup, to go
back to the functions without any change press the MENU button again.
Hold and press the MENU button about one second or wait for one minute
to exit the menu mode.
Dimmer Mode
Press the MENU button up to when the is shown on the display.
Press the ENTER button and the display will blink.. Use the DOWN and UP
button to select the (dimmer 1), (dimmer 2),
(dimmer 3) or (dimmer 4). Once the mode has been selected,
5F

press the ENTER button to setup, to go back to the functions without any
change press the MENU button again. Hold and press the MENU button
about one second or wait for one minute to exit the menu mode.
Mode 1(Optically Linear):
The increase in light intensity appears to be linear as DMX value is
increased.
Mode 2(Square Law):
Light intensity control is finer at low levels and coarser at high levels.
Mode 3(Inverse Square Law):
Light intensity control is coarser at low levels and finger at high levels.
Mode 4(S-curve):
Light intensity control is finger at low levels and high levels and coarser at
medium levels.
LED
Press the MENU button up to when the is shown on the display.
Press the ENTER button and the display will blink. Use the DOWN and UP
button to select (On) or (Off), Once the mode has been
6F

selected, press the ENTER button to setup, to go back to the functions
without any change press the MENU button again. Hold and press the
MENU button about one second or wait for one minute to exit the menu
mode.
Display Inversion
Press the MENU button until is blinking on the display. Use the
DOWN and UP button to select (normal) or (inverse).
Once the mode has been selected, press the ENTER button to setup, to go
back to the functions without any change press the MENU button again.
Hold and press the MENU button about one second or wait for one minute
to exit the menu mode.
Manual Mode
Press the MENU button up to when the is shown on the display.
Press the ENTER button and the display will blink. Use the DOWN and UP
button to select (dimmer). Once the mode has been selected,
press the ENTER button to setup the value from 0to 255, to go back to the
functions without any change press the MENU button again. Hold and
press the MENU button about one second or wait for one minute to exit
the menu mode.
7F

Auto Test
Press the MENU button up to when the is blinking on the display.
Press the ENTER button and the unit will run the built-in programmer for
self-test. To go back to the functions press the MENU button.
Fixture Hours
Press the MENU button up to when the is blinking on the display.
Press the ENTER button and the display will show the using hours of the
unit. To go back to the functions press the MENU button.
Software Version
Press the MENU button up to when the is blinking on the display.
Press the ENTER button and the display will show the version of software
of the unit. To go back to the functions press the MENU button.
DMX Controller
By using a universal DMX controller to control the units, you will need to
set DMX address from 1 to 512 so that the units can receive DMX signal.
Press the MENU button up to when the DMX Address is showing on the
display. Pressing the ENTER button and the display will blink. Use the
DOWN/UP button to change the DMX512 address. Once the address has
been selected, press the ENTER button to setup, to go back to the
8F

functions without any change press the MENU button again. Hold and
press the MENU button about one second or wait for one minute to exit
the menu mode.
Please refer to the following diagram to address your DMX512 channel for
the first 4 units:
Channel mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
1 channels 1 2 3 4
2 channels 1 3 5 7
DMX512 Configuration
1 CH MODE (MODE 1):
CHANNEL VALUE FUNCTION
1
000-255
DIMMER
0%~100%
2 CH MODE (MODE 2):
CHANNEL VALUE FUNCTION
1
000-255
DIMMER
0%~100%
9F

1
000-255
DIMMER FINE
0%~100%
Troubleshooting
The fixture does not work, no light
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
Fixture Cleansing
The cleaning of internal and external optical lenses and/or mirrors must be
carried out periodically to optimize light output. Cleaning frequency
depends on the environment in which the fixture operates: damp, smoky
or particularly dirty surrounding can cause greater accumulation of dirt on
the unit’s optics.
Clean with soft cloth and use normal glass to clean liquid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal
optics at least every 30 days.
10F

Declaration of Conformity
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the provision
of the Electromagnetic Compatibility (EMC) Directive 2014/30/EU.
EN 55032: 2015; EN 61000-3-2: 2014;
EN 61000-3-3: 2013; EN 55103-2: 2009.
&
Harmonized Standard
EN 60598-2-17: 1989+A2: 1991; EN 60598-1: 2015; EN 62471: 2008;
EN 62493: 2015; EN 62031: 2008+A1: 2013+A2: 2015.
Safety of household and similar electrical appliances
Part 1: General requirements
