ACME Spartan Hybrid User manual

User Manual
Please read the instrucon carefully before use
XP-20R BSW

CONTENTS
1. Safety Instructions..........................................................................................2
2. Technical Specifications..................................................................................3
3. Description.....................................................................................................5
3.1 Control Panel ..........................................................................................5
4.2 Light Source ............................................................................................7
5. How To Set The Unit.......................................................................................8
5.1 Main Function.........................................................................................8
5.2 Home Position Adjustment...................................................................17
5.3 Error Information..................................................................................21
6. Control By Universal DMX Controller ...........................................................22
6.1 Connection ...........................................................................................22
6.2 Address Setting.....................................................................................23
6.3 DMX 512 Configuration ........................................................................23
7. Troubleshooting ...........................................................................................43
8. Maintenance and Cleaning...........................................................................45
1F

1. Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer
will not accept liability for any resulting defects or problems.
Unpack and check carefully that there is no transportation damage before using the unit.
The unit is for indoor use only. Use only in a dry location.
DO install and operate by qualified operator.
DO NOT allow children to operate the fixture.
Use safety chain when fixing the unit. Handle the unit by carrying its base instead of head only.
The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces.
Be sure that no ventilation slots are blocked, otherwise the unit will be overheated.
Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
Ambient temperature TA: 0℃-40℃.
DO NOT connect the device to any dimmer pack.
During initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective, and it will decrease gradually within 15 minutes.
Make sure there are no flammable materials close to the unit while operating to avoid fire hazard.
Examine the power wires carefully; replace them immediately if there is any damage.
Unit’s surface temperature may reach up to 85℃. DO NOT touch the housing bare-handed during
its operation, and allow about 15 minutes for cooling the unit down before replacing bulb or
maintenance as it could be very hot.
Avoid any inflammable liquids, water or metal objects entering the unit. Once it happens, cut off
Please read the instruction carefully which includes important information about
the installation, usage and maintenance.
2F

the mains power immediately.
DO NOT operate in dirty or dusty environment, do clean fixtures regularly.
DO NOT touch any wire during operation as there might be a hazard of electric shock.
Avoid power wires together twist other cables.
The minimum distance between light output and the illuminated surface must be more than 18
meters.
Disconnect mains power before fuse/lamp replacement or servicing.
Replace fuse/lamp only with the same type.
In the event of serious operating problem, stop using the unit immediately.
Never turn on and off the unit time after time.
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
DO NOT open the unit as there are no user serviceable parts inside.
Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage
or malfunction. Please contact the nearest authorized technical assistance center if needed.
Disconnect the mains power if the fixture is has not been used for a long time.
DO use the original packing materials before transporting it again.
Cautions:
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
Hot lamp explosion hazard. DO NOT open the unit within 15 minutes after switching off.
DO replace the bulb once it is damaged, deformed or life-expired.
DO NOT look directly at the light while the bulb is on.
Never touch bulb with bare fingers, as it is very hot after using.
DO NOT start on the unit without bulb enclosure or when housing is damaged.
2. Technical Specifications
Power supply
- AC 100~240V 50/60Hz
Power Consumption
- 600W
Fuse
- T 10A
3F

Light Source
- PHILIPS MSD Platinum 20R
ColorTemperature
：
- 7800K
Battery backup display
- Setting DMX address or other functions without connecting to mains power.
- Battery for LCD display charges automatically when the fixtures connects to the mains power.
- No need to change battery.
Optical system
- High efficiency optical system, delivering extremely powerful output
- High quality dichroic lenses
Movement
- Pan: 540°
- Tilt: 270°
- Pan/Tilt moving speed adjustable.
- Automatic Pan/Tilt correction.
- Easy calibration and maintenance by magnetic home positioning.
- Pan/Tilt position lock for transporting protection.
Dimmer/Shutter
- Blackout, 0~100% smooth dimming, independent shutter and various strobe effect.
Color wheel
- Color wheel: 3 color wheels with 5 color plus white
- Rainbow effect in both directions.
Gobo wheel
- Gobo Wheel : 1 Fixed gobo wheel with 18 gobos plus open
1 Rotating gobo wheel with 7 gobos plus open
Prism
- Prism 1: 8 facet prism rotating in both directions
- Prism 2: 6 linear prism rotating in both directions
Focus
- Electronic focus effect
4F

Zoom
- Motorized linear zoom system, zoom range : 2°- 7°.(BEAM Mode)
5°- 32°(SPOT Mode)
8°- 70°(WASH Mode)
Protocols
- DMX 512
- Date input/output: 3/5 Pin XLR socket
Weight
- 28.5Kg
Dimension
- 667× 335×393mm
Photometrics Diagram
Distance(m) 5 10 15 20
2 Lux ° 850000 450000 189000 150000
Diameter(m) 0.18
0.35 0.53 0.7
2 ° 70 °
32 Lux ° 26800 6400 2900 1500
Diameter(m) 2.9 5.7 8.6 11.5
70 Lux ° 1500 375 167 94
Diameter(m) 6.37 12.74 19.11 25.48
32 °
3. Description
3.1 Control Panel
Front view Rear view
393
667
335
5F

1. Function Display:
Shows the various menus and the selected functions.
2. Button:
MENU To enter into move backward or leave the menu
UP To go backward to move up in the menu
DOWN To go to move down in the menu
ENTER To perform the desired functions
3. Battery Display:
To show battery status.
4. DMX IN:
DMX 512 operation, use 5-pin XLR cable to link the unit and DMX controller.
5. DMX IN:
DMX 512 link, use 3-pin XLR cable to link the unit and DMX controller.
6. DMX OUT:
DMX 512 operation, use 5-pin XLR cable to link the next units.
7. DMX OUT:
DMX 512 operation, use 3-pin XLR cable to link the next units.
8. Power:
To connect to the mains supply.
9. Fuse (T 10A):
Protect the unit from damage of over current.
10. Power Switch: Turns On/Off the power.
6F

4. Gobo and Lamp
4.1 Gobos
CAUTION: Never unscrew the screws of the rotating gobo as the ball bearing will otherwise be
opened!
4.2 Light Source
PHILIPS MSD Platinum 20R
For non replacable lightsources:
"The light source of this luminaire is not replaceable; when the light source reaches its end of life
the whole luminaire shall be replaced".
Because of its high internal pressure, there might be a risk that the Discharge lamp would
explode during operation. The lamp emits intense UV radiation which is harmful to the
eyes and skin. The high luminance of the arc can cause severe damage to the retina if you
take a close look at the lamp.
To protect the lamp, always turn off the lamp first (via control panel or DMX controller)
DANGER!
Install the gobos with the device switched off only.
Unplug from mains before changing gobos!
7F

and let the unit run at least five minutes to cool down before switching off the mains
supply. Never handle the lamp or luminary when it is hot.
Do not touch the bulb with bare hands. If this happens, clean the lamp with denatured
alcohol and wipe it with a lint free cloth before installation.
The lamp generates UV radiation. Never operate the lamp without appropriate shielding.
When lighting up, the lamp operates at high pressure and there is a slight risk of arc tube
rupture. The risk increases with age, temperature and improper handling of the lamp. Do not
use the lamp longer than its lifespan.
Make sure the lamp is located in the center of the reflector for the best projection.
5. How To Set The Unit
5.1 Main Function
Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until the
required function is shown on the monitor. Select the function by the ENTER button. Use the
UP/DOWN button to choose the submenu, press the ENTER button to store and automatically return
to the last menu. Press the MENU button or let the unit idle one minute to exit menu mode.
In the event of disconnecting with mains power, press the UP button for one minute to enter into
menu mode. Press MENU button or let the unit idle one minute to exit.
The main functions are shown below（the grayed boxes are preset settings）:
8F

9F

DMX Settings
To select DMX Settings press the ENTER button to confirm, use the UP/DOWN button to select DMX
Address, DMX Channel Mode , DMX Retransmit or View DMX Value.
DMX Address
To select DMX Address, press the ENTER button to confirm. Use the UP/DOWN button to adjust
the address from 001 to 512, press the ENTER button to store. Press the MENU button back to the
last menu or let the unit idle one minute to exit menu mode.
DMX Channel Mode
To select DMX Channel Mode, press the ENTER button to confirm. Use the UP/DOWN button to
select Mode1 (19) channels mode, press the ENTER button to store. Press the MENU button back
to the last menu or let the unit idle one minute to exit menu mode.
DMX Retransmit
To select DMX State, press the ENTER button to confirm. Use the UP/DOWN button to select No
or Yes, press the ENTER button to store. Press the MENU button back to the last menu or let the
10F

unit idle one minute to exit menu mode.
View DMX Value
To select View DMX Value, press the ENTER button to confirm. Use the UP/DOWN button to view
the DMX channel value. Press the MENU button back to the last menu or let the unit idle one
minute to exit menu mode.
Fixture Settings
To select Fixture Settings, press the ENTER button to confirm, use the UP/DOWN button to select Pan
Inverse, Tile Inverse, P/T Feedback, P/T Speed, Focus Compensate, BL.O. P/T Moving, BL.O. Color
Moving, BL.O. Gobo Moving, Dimmer Curve or Soft Filter.
Pan Inverse
To select Pan Inverse, press the ENTER button to confirm. Use the UP/DOWN button to select No
(normal) or Yes (pan inverse), press the ENTER button to store. Press the MENU button back to
the last menu or let the unit idle one minute to exit menu mode.
Tilt Inverse
To select Tilt Inverse, press the ENTER button to confirm. Use the UP/DOWN button to select No
(normal) or Yes (tilt inverse), press the ENTER button to store. Press the MENU button back to the
last menu or let the unit idle one minute to exit menu mode.
P/T Feedback
To select P/T Feedback, press the ENTER button to confirm. Use the UP/DOWN button to select
No (Pan or tilt’s position will not feedback while out of step) or Yes (Feedback while pan/tilt out of
step), press the ENTER button to store. Press the MENU button back to the last menu or let the
unit idle one minute to exit menu mode.
P/T Speed
To select P/T Speed, press the ENTER button to confirm. Use the UP/DOWN button to select Slow
or Fast, press the ENTER button to store. Press the MENU button back to the last menu or let the
unit idle one minute to exit menu mode.
11F

Focus Compensate
To select Focus Compensate, press the ENTER button to confirm. Use the UP/DOWN button to
select Disable, Near, Medium or Far, press the ENTER button to store. Press the MENU button
back to the last menu or let the unit idle one minute to exit menu mode.
BL.O. P/T Moving —Blackout while pan/tilt moving
To select BL.O. P/T Moving, press the ENTER button to confirm. Use the UP/DOWN button to
select No (normal while pan/tilt moving) or Yes (blackout while pan/tilt moving), press the ENTER
button to store. Press the MENU button back to the last menu or let the unit idle one minute to
exit menu mode.
BL.O.Color Moving —Blackout while Color moving
To select BL.O. Color Moving, press the ENTER button to confirm. Use the UP/DOWN button to
select No (normal while color moving) or Yes (blackout while color moving), press the ENTER
button to store. Press the MENU button back to the last menu or let the unit idle one minute to
exit menu mode.
BL.O.Gobo Moving —Blackout while Gobo moving
To select BL.O. Gobo Moving, press the ENTER button to confirm. Use the UP/DOWN button to
select No (normal while gobo moving) or Yes (blackout while gobo moving), press the ENTER
button to store. Press the MENU button back to the last menu or let the unit idle one minute to
exit menu mode.
Dimmer Curve
To select Dimmer Curve, press the ENTER button to show the DIMMER CURVE on the display. Use
the DOWN/UP button to select the Mode1 or Mode 2 or Mode 3 or Mode 4. Once the mode has
been selected, press the ENTER button to setup, to go back to the functions without any change
press the MENU button again. Press and hold the MENU button about one second or wait for one
minute to exit the menu mode.
12F

Mode 1(Optically Linear):
The increase in light intensity appears to be linear as DMX value is increased.
Mode 2(Square Law):
Light intensity control is finer at low levels and coarser at high levels.
Mode 3(Inverse Square Law):
Light intensity control is coarser at low levels and finger at high levels.
Mode 4(S-cure):
Light intensity control is finger at low levels and high levels and coarser at medium levels.
Soft Filter
To select Soft Filter, press the ENTER button to confirm. Use the UP/DOWN button to select Auto,
Disable or Enable, press the ENTER button to store. Press the MENU button back to the last menu
or let the unit idle one minute to exit menu mode.
Lamp Settings
To select Fixture Settings, press the ENTER button to confirm, use the UP/DOWN button to select
Lamp On/Off, or State/Power on..
Lamp On/Off —Turn on/off the lamp
To select Lamp On/Off, press the ENTER button to confirm. Use the UP/DOWN button to select
On (lamp on) or Off (lamp off), press the ENTER button to store. Press the MENU button back to
the last menu or let the unit idle one minute to exit menu mode.
State/Power On — Lamp state while power on
To select State/Power On, press the ENTER button to confirm. Use the UP/DOWN button to select
13F

On (Lamp on while power on) or Off (Lamp off while power on), press the ENTER button to store.
Press the MENU button back to the last menu or let the unit idle one minute to exit menu mode.
Display Settings
Enter menu mode, select Display Setting, press the ENTER button to confirm, use the UP/DOWN
button to select Display Inverse, Backlight Intensity, Temperature Unit or Language.
Display Inverse
Select Display Inverse, press the ENTER button to confirm, present mode will blink on the display,
use the UP/DOWN button to select No (normal display) or Yes (inverse display), press the ENTER
button to store. Press the MENU button back to the last menu or let the unit idle one minute to
exit menu mode.
Backlight Intensity
Select Backlight Intensity, press the ENTER button to confirm, present mode will blink on the
display, use the UP/DOWN button to adjust backlight intensity from 1 (dark) to 10 (bright), press
the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one
minute to exit menu mode.
Temperature Unit
Select Temperature Unit, press the ENTER button to confirm, present mode will blink on the
display, use the UP/DOWN button to select
℃
or
℉
, press the ENTER button to store. Press the
MENU button back to the last menu or let the unit idle one minute to exit menu mode.
Language
Select Language, press the ENTER button to confirm, present mode will blink on the display, use
the UP/DOWN button to select English or Chinese. Press the MENU button back to the last menu
or let the unit idle one minute to exit menu mode.
F ixture Test
Enter menu mode, select Fixture Test, press the ENTER button to confirm, use the UP/DOWN
14F

button to select Auto Test or Manual Test
Auto Test
Select Auto Test, press the ENTER button to confirm, the unit will run built-in programs to
automatically test pan, tilt, shutter, color, CMY, gobo, gobo rotation, prism, prism rotation, iris,
frost, zoom, focus, dimmer and lamp on/off. Press the MENU button back to the last menu or exit
menu mode after auto test.
Manual Test
Select Manual Test, press the ENTER button to confirm, the present channel will show on the
display, use the UP/DOWN button to select channel, press the ENTER button to confirm, then use
the UP and DOWN button to adjust the value, press the ENTER button to store, the fixture will run
as the channel value indicates. Press the MENU button back to the last menu or exit menu mode
idling one minute.
(All channels value will become 0 after exiting Manual Test menu)
Fixture Information
Enter menu mode, select Fixture Information, press the ENTER button to confirm, use the
UP/DOWN button to select Fixture use hour, Light use hour,Temperature,Lamp State,Fan State
or Firmware Version.
Fixture use hour
Select Fixture use hour, press the ENTERbutton to confirm, fixture use time will show on the
display, press the MENU button to exit.
Light use hour
Select Light use hour, press the ENTER button to confirm, light use time will show on the display,
press the ENTER button to confirm, use the UP/DOWN button to select Exit or Reset Time, press
the ENTER button to confirm. Press the MENU button back to the last menu or exit menu mode
idling one minute.
15F

Temperature
Select Temperature, press the ENTERbutton to confirm, fixture temperature will show on the
display, press the MENU button to exit.
lamp State
Select Lamp State, press the ENTERbutton to confirm, fixture lamp state will show on the display,
press the MENU button to exit.
Fan State
Select Fan State, press the ENTERbutton to confirm, fixture fan state will show on the display,
press the MENU button to exit.
Firmware Version
Select Firmware Version, press the ENTER button to confirm, firmware version will show on the
display, press the MENU button back to exit.
Reset Functions
Enter menu mode, select Reset Function, press the ENTER button to confirm, use the UP/DOWN
button to select Pan/Tilt, Effect or All.
Pan
﹠
Tilt —Reset Pan/Tilt
Select Pan
﹠
Tilt, press the ENTER button to confirm, use the UP/DOWN button to select Yes (the
unit will run built-in program to reset pan and tilt to their home positions) or No(normal), press
the ENTER button to store. Press the MENU button back to the last menu or let the unit idle one
minute to exit menu mode.
Effect —Reset Effect
Select Effect, press the ENTER button to confirm, use the UP/DOWN button to select Yes (the unit
will run built-in program to reset effect to their home positions) or No, press the ENTER button to
store. Press the MENU button back to the last menu or let the unit idle one minute to exit menu
mode.
16F

All — Reset All
Select All, press the ENTER button to confirm, use the UP/DOWN button to select Yes (the unit
will run built-in program to reset all motors to their home positions) or No, press ENTER button to
store. Press the MENU button to exit.
Special Functions
Factory Settings
Select Factory Settings,press the ENTER button to confirm, use the UP/DOWN button to select
Yes (the fixture will reset to factory settings)or No (normal), press ENTER button to store. Press
the MENU button to exit.
5.2 Home Position Adjustment
Press the MENU button into menu mode, then press the ENTER button for about 3 seconds into offset
mode to adjust the home position. Select the function by the ENTER button. Use the UP/DOWN
button to choose the submenu, press the ENTER button to store and automatically return to the last
menu. Press MENU button to exit.
17F

Pan
Tilt
Shu er
Color 1
Color 2
Color 3
Rota ng Gobo
R-Gobo
Sta c Gobo
Prism 1
RPrism 1
Prism 2
RPrism 2
Frost
Focus
Zoom
Anima on
-128
127
Pan—pan home position adjustment
Enter offset mode, Select Pan, press the ENTER button to confirm, the present position will blink on
the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button to
store. Press the MENU button to exit.
Tilt—Tilt home position adjustment
Enter offset mode, Select Tilt, press the ENTER button to confirm, the present position will blink on
the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button to
store. Press the MENU button to exit.
Shutter—Shutter home position adjustment
18F

Enter offset mode, Select Shutter, press the ENTER button to confirm, the present position will blink
on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button
to store. Press the MENU button to exit.
Color 1—Color 1 home position adjustment
Enter offset mode, Select Color 1, press the ENTER button to confirm, the present position will blink
on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button
to store. Press the MENU button to exit.
Color 2—Color 2 home position adjustment
Enter offset mode, Select Color 2, press the ENTER button to confirm, the present position will blink
on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button
to store. Press the MENU button to exit.
Color 3—Color 3 home position adjustment
Enter offset mode, Select Color 3, press the ENTER button to confirm, the present position will blink
on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button
to store. Press the MENU button to exit.
Rotating Gobo—Rotating Gobo home position adjustment
Enter offset mode, Select Rotating Gobo, press the ENTER button to confirm, the present position will
blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER
button to store. Press the MENU button to exit.
R-Gobo—Gobo rotation home position adjustment
Enter offset mode, Select R-Gobo, press the ENTER button to confirm, the present position will blink
on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button
to store. Press the MENU button to exit.
Static Gobo—Static Gobo home position adjustment
Enter offset mode, Select Static Gobo, press the ENTER button to confirm, the present position will
blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER
button to store. Press the MENU button to exit.
Prism 1—Prism 1 home position adjustment
Enter offset mode, Select Prism 1, press the ENTER button to confirm, the present position will blink
19F
