ADF Web HD67663-A1 User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 1 of 24
User Manual
Revision 1.000
English
EtherNet/IP / Modbus TCP Slave - Converter
(Order Code: HD67663-A1)
For Website information:
www.adfweb.com? roduct=HD67663
For rice information:
www.adfweb.com? rice=HD67663-A1
Benefits and Main Features:
Very easy to configure
Electrical isolation
Two Ethernet ports (for Modbus TC / EtherNet/I )
Temperature range: -40°C/+85°C (-40°F/+185°F)
For other EtherNet/I products see also the following link:
Converter EtherNet/IP to
www.adfweb.com? roduct=HD67077 (M-Bus)
www.adfweb.com? roduct=HD67595 (C N)
www.adfweb.com? roduct=HD67597 (DeviceNet Master)
www.adfweb.com? roduct=HD67598 (DeviceNet Slave)
www.adfweb.com? roduct=HD67599 (J1939)
www.adfweb.com? roduct=HD67589 (NME 2000)
www.adfweb.com? roduct=HD67591 (Modbus Master RS232)
www.adfweb.com? roduct=HD67591 (Modbus Master RS485)
www.adfweb.com? roduct=HD67592 (Modbus Slave RS232)
www.adfweb.com? roduct=HD67592 (Modbus Slave RS485)
Do you have your customer protocol? Then go to:
www.adfweb.com? roduct=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 2 of 24
INDEX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
OWER SU LY 7
FUNCTION MODES 8
LEDS 9
ETHERNET/I / MODBUS TC 10
USE OF COM OSITOR SW67663 11
NEW ROJECT / O EN ROJECT 12
SOFTWARE O TIONS 13
SET COMMUNICATION 14
U DATE DEVICE 15
MECHANICAL DIMENSIONS 17
ORDERING INFORMATIONS 18
ACCESSORIES 18
LC CONFIGURATION 19
DISCLAIMER 23
OTHER REGULATIONS AND STANDARDS 23
WARRANTIES AND TECHNICAL SU ORT 24
RETURN OLICY 24
UPD TED DOCUMENT TION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
W RNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TR DEM RKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date uthor Chapter Description
1.000 17/06/2014 Ff All First Release

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 3 of 24
SECURITY LERT:
G ENER L I NFORM TION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q U LIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDU L R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 4 of 24
EX MPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 5 of 24
CONNECTION SCHEME:
Figure 1: Connection scheme for HD67663-A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 6 of 24
CH R CTERISTICS:
The HD67663-A1 is a EtherNet/I / Modbus TC Slave Converter.
It allows for the following characteristics:
Up to 500 bytes in reading and 500 bytes in writing;
Isolation between Modbus/EtherNet/I - ower Supply;
Two-directional information between Modbus TC bus and EtherNet/I bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGUR TION:
You need Compositor SW67663 software on your C in order to perform the following:
Define the parameters of EtherNet/I line;
Define the parameters of Modbus TC line;
Define the Modbus TC data that a master read and where to take these information in the EtherNet/I array;
Define the Modbus TC data that a master write and where to map these information in the EtherNet/I array;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 7 of 24
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
V C
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/V ]
HD67663-A1 3.5
HD67663
-
A1
Caution:
Do n
ot reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 8 of 24
FUNCTION MODES:
The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’:
The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for uploading the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.
Warning:
Dip1 of ‘Dip-Switch A’ must be at ON position to work even if the Ethernet cable is not inserted.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 9 of 24
LEDS:
The device has got four LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Modbus TC comm.
(green)
Blinks when receive Modbus TC
request from the Master
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: Ethernet1 Link (green) Blinks when transmits a frame in
Ethernet
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Ethernet2 Link (green) Blinks when transmits a frame in
Ethernet
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 10 of 24
ETHERNET/IP / MODBUS TCP:
The EtherNet/I and Modbus TC connection must be made using Connector3 and/or Connector4 of HD67663-A1 with at least a Category 5E
cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in
cat.5 up to 100 Mbps. To connect the device to a Hub/Switch the use of a straight cable is recommended. To connect the device to a
C/ LC/other the use of a cross cable is recommended.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 11 of 24
USE OF COMPOSITOR SW67663:
To configure the Converter, use the available software that runs with Windows called SW67663. It is downloadable on the site
www.adfweb.com and its operation is described in this document. ( his manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (X , Vista, Seven, 8; 32/64bit).
When launching the SW67663, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figu
re 2: Main window for SW67663

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 12 of 24
NEW CONFIGUR TION / OPEN CONFIGUR TION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a rogrammable “EtherNet/I / Modbus TC Slave -
Converter” in order to configure another device in the same manner, it is necessary
to maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient
to duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 13 of 24
SOFTW RE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67663 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 14 of 24
SET COMMUNIC TION:
This section define the fundamental communication parameters of two buses, EtherNet/I and
Modbus TC .
By ressing the “Set Communication” button from the main window for SW67663 (Fig. 2) the
window “Set Communication” appears (Fig. 3).
The window is divided in two sections, one for the EtherNet/I and the other for the Modbus TC
Slave.
The means of the fields for “EtherNet/I ” are:
In the fields “IP DDRESS” insert the I address that you want to give to the Converter
(EtherNet/I side);
In the fields “SUBNET Mask” insert the SubNet Mask;
In the fields “G TEW Y” insert the default gateway that you want to use. This feature can
be enabled or disabled pressing the Check Box field. This feature is used for going out of the
net;
In the field “Port” the port used for EtherNet/I communication is defined. The port has a
fixed value of 44818;
In the fields “Number Byte IN” insert the number of input byte of the slave station;
In the fields “Number Byte Out” insert the number of output byte of the slave station.
The means of the fields for the “Modbus TC Master” section are:
In the fields “IP DDRESS” insert the I address that you want to give to the Converter
(Modbus TC side);
In the fields “SUBNET Mask” insert the SubNet Mask;
In the fields “G TEW Y” insert the default gateway that you want to use. This feature can
be enabled or disabled pressing the Check Box field. This feature is used for going out of the
net;
In the field “Port” the port used for Modbus TC communication is defined.
Figure
3
:
“Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 15 of 24
UPD TE DEVICE:
By pressing the “Update Device” button, it is possible to load the created Configuration into the
device; and also the Firmware, if necessary.
If you don’t know the actual I address of the device you have to use this procedure:
Turn off the Device;
ut Dip2 of ‘Dip-Switch A’ in ON position;
Turn on the device
Connect the Ethernet cable;
Insert the I “192.168.2.205”;
ress the “Ping” button, “Device Found! must appear”;
ress the “Next” button;
Select which operations you want to do;
ress the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn off the Device;
ut Dip2 of ‘Dip-Switch A’ in OFF position;
Turn on the device.
If you know the actual I address of the device, you have to use this procedure:
Turn on the Device with the Ethernet cable inserted;
Insert the actual I of the Converter;
ress the “Ping” button, must appear “Device Found!”;
ress the “Next” button;
Select which operations you want to do;
ress the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal
Mode.
At this point the configuration/firmware on the device is correctly update.
Figure 5: “Update device” windows

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 16 of 24
Figure
8
:
“
Protection
” window
Note:
When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67663
device.
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67663 device.
Warning:
If Fig. 6 appears when you try to do the Update try these points before seeking assistance:
Try to repeat the operations for the updating;
Try with another C;
Try to restart the C;
Check the LAN settings;
If you are using the program inside a Virtual Machine, try to use in the main Operating
System;
If you are using Windows Seven, Vista and 8 make sure that you have the
administrator privileges;
In case you have to program more than one device, you have to cancel the AR table
every time you connect a new device on Ethernet. For do this you have to launch the
"Command rompt" and write the command "arp -d". ay attention that with Windows
Vista, Seven, 8 you have to launch the "Command rompt" with Administrator
Rights;
ay attention at Firewall lock.
In the case of HD67663 you have to use the software “SW67663”: www.adfweb.com\download\filefold\SW67663.zip.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 17 of 24
MECH NIC L DIMENSIONS:
Figure
7
: Mechanical dimensions scheme
for HD6766
3
-
A1

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 18 of 24
ORDERING INFORM TIONS:
The ordering part number is formed by a valid combination of the following:
HD67663 – 1
Connectors Type
1: Removable 5mm Screw Terminal
Enclosure Type
A: 1M, 35mm DIN Rail mounting
Device Family
HD67663: EtherNet/I / Modbus TC Slave - Converter
Order Code: HD67663- 1 - EtherNet/I / Modbus TC Slave - Converter
CCESSORIES:
Order Code: C34001 - 35mm Rail DIN - ower Supply 220/240V AC 50/60Hz – 12 V AC
Order Code: C34002 - 35mm Rail DIN - ower Supply 110V AC 50/60Hz – 12 V AC

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 19 of 24
PLC CONFIGUR TION:
The configuration and commissioning of the EtherNet/I Converter as described on the following pages was accomplished with the help of
the “RSLogix 5000” software of Rockwell Automation. In case of using a control system from another supplier please attend to the
associated documentation.
These are the steps to follow:
1) Create a "Generic Ethernet Module" under the Ethernet section in the I/O Configuration tree.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EtherNet/IP / Modbus TCP Slave
Document code: MN67663_ENG Revision 1.000 age 20 of 24
2) Edit the settings of the new Generic Ethernet Module. As shown in the screen shot
below, the module was named “HD67663” and the I -address assigned is 192.168.0.5.
For the Comm Format “Data – SINT” shall be selected as the data type.
The HD67663-A1 can uses up to 496 bytes for input assembly instance 101 and 496
bytes for output assembly instance 100.
RSLogix 5000 requires a configuration assembly instance. Both modules do not provide a
configuration assembly instance. Therefore it is allowed to select an instance of 3 and to
set the value to zero.
3) The setting of 10msec for the “Requested acket Interval (R I)” is adequate but it
is possible to change this value as required. A lower value of 2ms shall not be selected.
Warning:
The field “Use Unicast Connection over EtherNet/I ” must be checked.
