ADLINK Technology Express-KL User manual

Leading EDGE COMPUTING
Express-KL
User’s Manual
COM Express Basic Size Type 6 Module with
Mobile 7th Gen Intel® Core™ and Xeon® E3-1500 v6 Processors
Manual Rev.: 1.0
Revision Date: July 3, 2017
Part Number: 50-1J086-1000

ii Preface
Preface
Copyright
Copyright 2017 ADLINK Technology, Inc. This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic, or other means in
any form without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior notice in order to improve reliability, design, and
function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer
be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use
the product or documentation, even if advised of the possibility of such damages.
Environmental Responsibility
ADLINK is committed to fulfill its social responsibility to global environmental preservation through compliance with
the European Union's Restriction of Hazardous Substances (RoHS) directive and Waste Electrical and Electronic
Equipment (WEEE) directive. Environmental protection is a top priority for ADLINK. We have enforced measures to
ensure that our products, manufacturing processes, components, and raw materials have as little impact on the
environment as possible. When products are at their end of life, our customers are encouraged to dispose of them
in accordance with the product disposal and/or recovery programs prescribed by their nation or company.
Trademarks
Product names mentioned herein are used for identification purposes only and may be trademarks and/or
registered trademarks of their respective companies.
Revision History
Revision Description Date By
1.0 Initial release 2017-07-03 JC

Express-KL
Preface iii
Table of Contents
Preface................................................................................................................................ii
List of Figures ....................................................................................................................v
List of Tables.....................................................................................................................vi
1. Introduction................................................................................................................1
2. Specifications............................................................................................................3
2.1. Core System ...................................................................................................................3
2.2. Expansion Busses...........................................................................................................3
2.3. Video...............................................................................................................................4
2.4. Audio...............................................................................................................................4
2.5. LAN ................................................................................................................................. 4
2.6. Multi I/O and Storage ......................................................................................................4
2.7. Serial I/O on Module .......................................................................................................5
2.8. Trusted Platform Module (TPM)......................................................................................5
2.9. SEMA Board Controller...................................................................................................5
2.10. Debug ............................................................................................................................. 5
2.11. Power Specifications.......................................................................................................6
2.12. Power Consumption........................................................................................................6
2.13. Operating Temperatures.................................................................................................6
2.14. Environmental .................................................................................................................6
2.15. Specification Compliance................................................................................................6
2.16. Operating Systems..........................................................................................................6
2.17. Functional Diagram.........................................................................................................7
2.18. Mechanical Drawing........................................................................................................8
3. Pinouts and Signal Descriptions..............................................................................9
3.1. AB/CD Pin Definitions .....................................................................................................9
3.2. Signal Description Terminology ....................................................................................12
3.3. AB Signal Descriptions..................................................................................................13
3.4. CD Signal Descriptions .................................................................................................22
4. Connector Pinouts on Module................................................................................29
4.1. Connector, Switch and LED Locations..........................................................................29
4.2. 40-pin Debug Connector...............................................................................................30
4.3. Status LEDs ..................................................................................................................31
4.4. Fan Connector ..............................................................................................................32
4.5. BIOS Setup Defaults Reset Button ...............................................................................33
4.6. Switch Settings .............................................................................................................34
4.7. PCIe x16-to-two-x8 Adapter Card .................................................................................36
5. Smart Embedded Management Agent (SEMA) .....................................................37
5.1. Board Specific SEMA Functions ...................................................................................38
6. System Resources ..................................................................................................41
6.1. System Memory Map ....................................................................................................41

iv Preface
6.2. Direct Memory Access Channels..................................................................................41
6.3. I/O Map .........................................................................................................................41
6.4. Interrupt Request (IRQ) Lines.......................................................................................43
6.5. PCI Configuration Space Map.......................................................................................44
6.6. PCI Interrupt Routing Map ............................................................................................45
6.7. SMBus Address Table ..................................................................................................45
7. BIOS Setup...............................................................................................................47
7.1. Menu Structure..............................................................................................................47
7.2. Main .............................................................................................................................. 48
7.3. Advanced ......................................................................................................................52
7.4. Boot...............................................................................................................................69
7.5. Security ......................................................................................................................... 70
7.6. Save & Exit ...................................................................................................................70
8. BIOS Checkpoints, Beep Codes.............................................................................71
8.1. Status Code Ranges.....................................................................................................72
8.2. Standard Status Codes.................................................................................................72
8.3. OEM-Reserved Checkpoint Ranges.............................................................................79
9. Mechanical Information...........................................................................................81
9.1. Board-to-Board Connectors ..........................................................................................81
9.2. Thermal Solution...........................................................................................................82
9.3. Mounting Methods.........................................................................................................85
9.4. Standoff Types..............................................................................................................86
Safety Instructions...........................................................................................................87
Getting Service.................................................................................................................88

Express-KL
Preface v
List of Figures
Figure 1: Express-KL/KLE Functional Block Diagram..............................................................................7
Figure 2: Express-KL/KLE Mechanical Drawing ......................................................................................8
Figure 3: Express-KL/KLE Connector, Switch and LED Locations ....................................................... 29
Figure 4: Express-KL/KLE and the DB40 Debug Module ..................................................................... 29
Figure 5: cExpress Switch Locations .................................................................................................... 34
Figure 6: COM Express Mounting Methods ..........................................................................................85
Figure 7: COM Express Standoff Types................................................................................................ 86

vi Preface
List of Tables
Table 1: Express-KL/KLE AB/CD Pin Definitions.....................................................................................9
Table 2: 40-pin Debug Connector Pin Definition ................................................................................... 30
Table 3: Express-KL/KLE LED Descriptions ......................................................................................... 31
Table 4: Fan Connector Pin Definition .................................................................................................. 32
Table 5: PCI Express Configuration Switch Settings ............................................................................ 34
Table 6: BIOS Select and Mode Configuration Switch Settings............................................................ 35
Table 7: SEMA Onboard Voltage Monitor ............................................................................................. 38
Table 8: SEMA BMC Status .................................................................................................................. 38
Table 9: SEMA Exception Codes .......................................................................................................... 39
Table 10: SEMA BMC Flags.................................................................................................................. 39

Express-KL
Introduction 1
1. Introduction
The Express-KL/KLE is a COM Express® COM.0 R2.1 Basic Size Type 6 module supporting the 64-bit 7th
Generation Intel® Core™ and Xeon® processor E3 (codename “Kaby Lake-H”) with Mobile Intel® QM175, HM175,
CM238 Chipset. The Express-KL/KLE is specifically designed for customers who need excellent graphics
performance and high-level processing performance in a long product life solution.
The Express-KL/KLE features Intel® Hyper-Threading Technology (up to 4 cores, 8 threads) and DDR4 dual-
channel memory at 2133/2400 MHz with ECC/non-ECC support determined by CPU/chipset combination to
provide excellent overall performance. Intel® Flexible Display Interface and Direct Media Interface provide high
speed connectivity from the CPU to the Intel® QM175, HM175, CM238 Chipset.
Integrated Intel® Generation 9 Graphics includes features such as OpenGL 4.4/4.3/4.2, DirectX 11, Intel® Clear
Video HD Technology, Advanced Scheduler 2.0, 1.0, XPDM support, and DirectX Video Acceleration (DXVA)
support for full H.265/HEVC 10-bit, MPEG2 hardware codec. In addition, High Dynamic Range is supported for
enhanced picture color and quality and digital content protection has been upgraded to HDCP 2.2. Graphics
outputs include LVDS and three DDI ports supporting HDMI/DVI/DisplayPort and eDP as a build option. The
Express-KL/KLE is specifically designed for customers with high-performance processing graphics requirements
who want to outsource the custom core logic of their systems for reduced development time.
The Express-KL/KLE has dual stacked SODIMM sockets supporting up to 32 GB of DDR4 ECC/non-ECC memory.
In addition to the onboard integrated graphics, a multiplexed PCIe x16 graphics bus is available for discrete
graphics expansion. Input/output features include a single onboard Gigabit Ethernet port, eight PCIe x1 Gen3 lanes,
USB 3.0 ports and USB 2.0 ports, and SATA 6 Gb/s ports. Support is provided for SMBus and I2C. The module is
equipped with SPI AMI EFI BIOS with CMOS backup, supporting embedded features such as remote console,
hardware monitor, and watchdog timer.

2 Introduction
This page intentionally left blank.

Express-KL
Specifications 3
2. Specifications
2.1. Core System
CPU 7th Generation Intel® Core™ and and Xeon® E3-15xx v6 processor
(formerly “Kaby Lake-H”)
•Intel® Xeon® E3-1505M v6 3.0/4.0GHz (Turbo), 45W/35W(cTDP, 4C/GT2)
•Intel® Xeon® E3-1505L v6 2.2/3.0GHz (Turbo), 25W (4C/GT2)
•Intel® Core™ i7-7820EQ 3.0/3.7GHz (Turbo), 45W/35W(cTDP, 4C/GT2)
•Intel® Core™ i5-7440EQ 2.9/3.6GHz (Turbo), 45W/35W(cTDP, 4C/GT2)
•Intel® Core™ i5-7442EQ 2.1/2.9GHz (Turbo), 25W (4C/GT2)
•Intel® Core™ i3-7100E 2.9GHz, 35W (2C/GT2)
•Intel® Core™ i3-7102E 2.1GHz, 25W (2C/GT2)
Supporting: Intel® VT, Intel® TXT, Intel® SSE4.2, Intel® HT Technology, Intel® 64
Architecture, Execute Disable Bit, Intel® Turbo Boost Technology 2.0, Intel® AVX2, Intel®
AES-NI, PCLMULQDQ Instruction, Intel® Device Protection Technology with Intel®
Secure Key, Intel® TSXNI (availability of features may vary between processor SKUs)
Note: Power Limit option available in BIOS settings (see 7.3.1) to adjust TDP from 45W to
20-30W (45W SKUs only).
Cache 8MB for Xeon®/Core™ i7, 6MB for Core™ i5, 3MB for Core™ i3
Memory Dual channel ECC or non-ECC 2133/2400 MHz DDR4 memory up to 32GB in dual
stacked SODIMM sockets
Note: Only Xeon® and Core™ i3 processors paired with the CM238 Chipset can support
both of ECC and non-ECC memory. Other processor/chipset combinations support non-
ECC memory.
Chipset Mobile Intel® QM175, HM175 and CM238 Chipset (HM175 does not support Intel® AMT)
Embedded BIOS AMI EFI with CMOS backup in 16MB SPI BIOS with Intel® AMT 11 support
CPU and Chipset
Combinations Express-KL (non-ECC memory support)
•Core™ i7/i5 with QM175 Chipset
•Core™ i3 with HM175 Chipset
Express-KLE (ECC memory support and non-ECC memory support)
•Xeon® with CM238 Chipset
•Core™ i3 with CM238 Chipset (supported by project basis; please contact your ADLINK
representative)
Note: Combinations not listed above may be supported by project basis. Please contact
your ADLINK representative.
2.2. Expansion Busses
PCI Express PCI Express x16 Gen3 (can be configured to 1x16, 2 x8 or 1 x8 with 2 x4)
6 PCI Express x1 Gen3 (AB): Lanes 0/1/2/3/4/5
2 PCI Express x1 Gen3 (CD): Lane 6/7
Note: PCIe lanes 0/1/2/3 can also be configured to x2, x4 PCIe lanes 4/5/6/7 can also be
configured to x2, x4.
Other •LPC bus
•SMBus (system)
•I2C (user)

4 Specifications
2.3. Video
Integrated on Processor Intel® Generation 9 Graphics core architecture
GPU Feature Support •3 independent and simultaneous combinations of DisplayPort/HDMI/LVDS graphics
outputs (eDP optional in place of LVDS)
•Encode/transcode HD content
•Playback of high definition content including Blu-ray Disc
•Playback of Blu-ray Disc 3D content using HDMI (1.4a spec compliant with 3D)
•DirectX Video Acceleration (DXVA) support for accelerated video processing
•HEVC/H.265 10-bit, H.264, M/JPEG, MPEG2, VC1, WMV9, VP9 10-bit HW decode
•HEVC/H.265 10-bit, M/JPEG, MPEG2 HW encode
•Advanced Scheduler 2.0, 1.0, XPDM support
•DirectX 12, DirectX 11.3, DirectX 11, DirectX 10.1, DirectX 10, DirectX 9 support
•OpenGL up to 4.4, OpenCL up to 2.1 support
•High Dynamic Range (HDR) Rec. 2020 support
Note: Availability of features s dependent on operating system (Windows 10 64-bit, Linux
64-bit, VxWorks 7)
Display Interface Support •LVDS: single/dual channel 18/24-bit LVDS through eDP to LVDS, supports DE mode
and Hsync/Vsync mode
•eDP: eDP 1.4 up to 4 lane support, in place of LVDS (BOM option)
•Digital Display Ports x3: DDI1/2/3 support DisplayPort/HDMI/DVI
2.4. Audio
Integrated Intel® HD Audio integrated in QM175/HM175/CM238 Chipset
Codec Located on carrier Express-BASE6 (ALC886 standard support)
2.5. LAN
Integrated MAC integrated in QM175/HM175/CM238 Chipset
Intel PHY Intel® Ethernet Controller I219-LM or I219-V
Interface 10/100/1000 Mbit/s connection
2.6. Multi I/O and Storage
Integrated Intel® QM175/HM175/CM238 Chipset
USB 4x USB 3.0 (USB 0,1,2,3), 4x USB 2.0 (USB 4,5,6,7)
SATA* 4x SATA 6Gb/s (SATA 0,1,2,3)
GPIO 4 GPO and 4 GPI
*Note: For SATA 6Gb/s compatibility, it is strongly recommended to use a SATA redriver on the carrier board.

Express-KL
Specifications 5
2.7. Serial I/O on Module
zChipset: Nuvoton NCT5104D
zPorts: 2x UARTs Rx/Tx only
zConsole Redirection: COM 1 or COM 2 selectable in BIOS
COM Port Description IRQ Address Console redirection support
COM 1 Supported by module (SER0, A98/A99), via NCT5104D 10 0x240 Yes
COM 2 Supported by module (SER1, A101/A102), via NCT5104D 11 0x248 Yes
COM 3 Supported by Super I/O (W83627DHG) on carrier board 4 0x3F8 Yes
COM 4 Supported by Super I/O (W83627DHG) on carrier board 3 0x2F8 Yes
2.8. Trusted Platform Module (TPM)
zChipset: Infineon SLB 9665XT2.0 FW5.51
zType: TPM 2.0 (TPM 1.2 by BOM option, support by project basis)
2.9. SEMA Board Controller
zType: ADLINK Smart Embedded Management Agent (SEMA)
zFunctions:
•Voltage/Current monitoring
•Power sequence debug support
•AT/ATX mode control
•Logistics and forensic information
•Flat panel control
•General purpose I2C
•Failsafe BIOS (dual BIOS )
•Watchdog timer and fan control
2.10. Debug
z40-pin flat cable connector to be used with DB-40 debug module
Supports: BIOS POST code LED, BMC access, SPI BIOS flashing, power testpoints, debug LEDs
z60-pin XDP header for ICE debug of CPU/chipset

6 Specifications
2.11. Power Specifications
Power Modes AT and ATX mode (AT mode startup controlled by SEMA Board Controller)
Standard Voltage Input ATX: 12V±5% / 5Vsb ±5% or AT = 12V±5%
Wide Voltage Input ATX: 8.5-20V, 5Vsb ±5% or AT @ 8.5-20V
Power Management ACPI 5.0 compliant, Smart Battery support
Power States Supports C1-C6, S0, S3, S4, S5 (Wake-on-USB S3/S4, WoL S3/S4/S5)
ECO Mode Supports deep S5 for 5Vsb power saving
2.12. Power Consumption
Please contact your ADLINK representative for the document “COM Express Module Power Consumption”.
2.13. Operating Temperatures
Standard Operating
Temperature 0°C to +60°C (Wide Voltage Input)
Storage: -20°C to +70°C
Extreme Rugged Operating
Temperature (optional) -40°C to +85°C (Standard Voltage Input)
Storage: -40°C to +85°C
2.14. Environmental
Humidity Operating: 5-90% RH, non-condensing
Storage: 5-95% RH (and operating with conformal coating)
Shock and Vibration IEC 60068-2-64 and IEC-60068-2-27
MIL-STD-202F, Method 213B, Table 213-I, Condition A and Method 214A, Table 214-I,
Condition D
HALT Thermal Stress, Vibration Stress, Thermal Shock and Combined Test
2.15. Specification Compliance
zPICMG COM.0: Rev 2.1 Type 6, Basic size 125 x 95 mm
2.16. Operating Systems
Standard Support •Windows 10 (64-bit)
•Windows 10 IOT Enterprise (64-bit)
•Linux (64-bit)
•VxWorks
Extended Support (BSP) •Linux (64-bit)
•VxWorks

Express-KL
Specifications 7
2.17. Functional Diagram
Mobile 7th Gen
Intel® Core™
i7/i5/i3 Processor
Intel® Xeon® Processor
(formerly “Kaby Lake-H”)
LM73
Sensor
eDP - LVDS
TPM
Mobile Intel®
QM175/HM175/
CM238
Chipset
LAN
I219
GPIO
AB
GP I2C
CD
SPI 0
BIOS
LPC bus
SODIMM 1
2133/2400 MHz
4-16 GB DDR4
PCIe x16 (Gen3)
2 x8 or 1 x8 + 2 x4
SPI
UMI
Debug
header
PCIe x1
HD Audio
4x SATA 6Gb/s
(port 0/1/2/3)
8x USB 2.0
4x USB 3.0 (port 0/1/2/3)
UART0/1
SPI 1
BIOS
DDC I2C
SODIMM 2
2133/2400 MHz
4-16 GB DDR4
2x PCIe x1 (Gen3)
(port 6/7)
SPI_CS#
DDI1
DP/HDMI/DVI
DDI 2
DP/HDMI/DVI
DDI 3
DP/HDMI/DVI
single/dual
18/24 bit LVDS
6x PCIex1 (Gen3)
(port 0-5)
New
SEMA
BMC
eDP x4 lanes (optional)
XDP
60
SMBus
4x GPO, 4x GPI
SMBus
LPC to
UART
Figure 1: Express-KL/KLE Functional Block Diagram

8 Specifications
2.18. Mechanical Drawing
Top View
Side View
00
00
44
66
1188
2277..994444
7733..4411
9911
9955
44
1166..55
3399..99113399..9911
6699..888822
112255
7744..22
8800
112211
88
22
44
ccoonnnneeccttoorroonnbboottttoommssiiddee
6
2.7
All are dimensions shown in millimeters.
Tolerances should be ± 0.25mm, unless otherwise noted. The tolerances of the module
connector locating peg holes (dimensions [16.50, 6.00] and [16.50, 18.00]) should be ±0.10mm.
Figure 2: Express-KL/KLE Mechanical Drawing

Express-KL
Pinouts and Signal Descriptions 9
3. Pinouts and Signal Descriptions
3.1. AB/CD Pin Definitions
The Express-KL/KLE is a Type 6 module supporting USB 3.0 upgrade signals and DDI channels on the CD
connector. All pins in the COM Express specification are described, including those not supported on the Express-
KL/KLE. Those not supported on the Express-KL/KLE module are crossed out.
Table 1: Express-KL/KLE AB/CD Pin Definitions
Row A Row B Row C Row D
Pin Name Pin Name Pin Name Pin Name
A1 GND (fixed) B1 GND (fixed) C1 GND (fixed) D1 GND (fixed)
A2 GBE0_MDI3- B2 GBE0_ACT# C2 GND D2 GND
A3 GBE0_MDI3+ B3 LPC_FRAME# C3 USB_SSRX0- D3 USB_SSTX0-
A4 GBE0_LINK100# B4 LPC_AD0 C4 USB_SSRX0+ D4 USB_SSTX0+
A5 GBE0_LINK1000# B5 LPC_AD1 C5 GND D5 GND
A6 GBE0_MDI2- B6 LPC_AD2 C6 USB_SSRX1- D6 USB_SSTX1-
A7 GBE0_MDI2+ B7 LPC_AD3 C7 USB_SSRX1+ D7 USB_SSTX1+
A8 GBE0_LINK# B8 LPC_DRQ0# C8 GND D8 GND
A9 GBE0_MDI1- B9 LPC_DRQ1# C9 USB_SSRX2- D9 USB_SSTX2-
A10 GBE0_MDI1+ B10 LPC_CLK C10 USB_SSRX2+ D10 USB_SSTX2+
A11 GND (fixed) B11 GND (fixed) C11 GND (fixed) D11 GND (fixed)
A12 GBE0_MDI0- B12 PWRBTN# C12 USB_SSRX3- D12 USB_SSTX3-
A13 GBE0_MDI0+ B13 SMB_CK C13 USB_SSRX3+ D13 USB_SSTX3+
A14 GBE0_CTREF B14 SMB_DAT C14 GND D14 GND
A15 SUS_S3# B15 SMB_ALERT# C15 DDI1_PAIR6+ D15 DDI1_CTRLCLK_AUX+
A16 SATA0_TX+ B16 SATA1_TX+ C16 DDI1_PAIR6- D16 DDI1_CTRLDATA_AUX
A17 SATA0_TX- B17 SATA1_TX- C17 RSVD D17 RSVD
A18 SUS_S4# B18 SUS_STAT# C18 RSVD D18 RSVD
A19 SATA0_RX+ B19 SATA1_RX+ C19 PCIE_RX6+ D19 PCIE_TX6+
A20 SATA0_RX- B20 SATA1_RX- C20 PCIE_RX6- D20 PCIE_TX6-
A21 GND (fixed) B21 GND (fixed) C21 GND (fixed) D21 GND (fixed)
A22 SATA2_TX+ B22 SATA3_TX+ C22 PCIE_RX7+ D22 PCIE_TX7+
A23 SATA2_TX- B23 SATA3_TX- C23 PCIE_RX7- D23 PCIE_TX7-
A24 SUS_S5# B24 PWR_OK C24 DDI1_HPD D24 RSVD
A25 SATA2_RX+ B25 SATA3_RX+ C25 DDI1_PAIR4+ D25 RSVD
A26 SATA2_RX- B26 SATA3_RX- C26 DDI1_PAIR4- D26 DDI1_PAIR0+
A27 BATLOW# B27 WDT C27 RSVD D27 DDI1_PAIR0-
A28 (S)ATA_ACT# B28 AC/HDA_SDIN2 C28 RSVD D28 RSVD
A29 AC/HDA_SYNC B29 AC/HDA_SDIN1 C29 DDI1_PAIR5+ D29 DDI1_PAIR1+
A30 AC/HDA_RST# B30 AC/HDA_SDIN0 C30 DDI1_PAIR5- D30 DDI1_PAIR1-
A31 GND (fixed) B31 GND (fixed) C31 GND (fixed) D31 GND (fixed)
A32 AC/HDA_BITCLK B32 SPKR C32 DDI2_CTRLCLK_AUX+ D32 DDI1_PAIR2+
A33 AC/HDA_SDOUT B33 I2C_CK C33 DDI2_CTRLDATA_AUX- D33 DDI1_PAIR2-
A34 BIOS_DIS0# B34 I2C_DAT C34 DDI2_DDC_AUX_SEL D34 DDI1_DDC_AUX_SEL
A35 THRMTRIP# B35 THRM# C35 RSVD D35 RSVD

10 Pinouts and Signal Descriptions
Row A Row B Row C Row D
Pin Name Pin Name Pin Name Pin Name
A36 USB6- B36 USB7- C36 DDI3_CTRLCLK_AUX+ D36 DDI1_PAIR3+
A37 USB6+ B37 USB7+ C37 DDI3_CTRLDATA_AUX- D37 DDI1_PAIR3-
A38 USB_6_7_OC# B38 USB_4_5_OC# C38 DDI3_DDC_AUX_SEL D38 RSVD
A39 USB4- B39 USB5- C39 DDI3_PAIR0+ D39 DDI2_PAIR0+
A40 USB4+ B40 USB5+ C40 DDI3_PAIR0- D40 DDI2_PAIR0-
A41 GND (fixed) B41 GND (fixed) C41 GND (fixed) D41 GND (fixed)
A42 USB2- B42 USB3- C42 DDI3_PAIR1+ D42 DDI2_PAIR1+
A43 USB2+ B43 USB3+ C43 DDI3_PAIR1- D43 DDI2_PAIR1-
A44 USB_2_3_OC# B44 USB_0_1_OC# C44 DDI3_HPD D44 DDI2_HPD
A45 USB0- B45 USB1- C45 RSVD D45 RSVD
A46 USB0+ B46 USB1+ C46 DDI3_PAIR2+ D46 DDI2_PAIR2+
A47 VCC_RTC B47 EXCD1_PERST# C47 DDI3_PAIR2- D47 DDI2_PAIR2-
A48 EXCD0_PERST# B48 EXCD1_CPPE# C48 RSVD D48 RSVD
A49 EXCD0_CPPE# B49 SYS_RESET# C49 DDI3_PAIR3+ D49 DDI2_PAIR3+
A50 LPC_SERIRQ B50 CB_RESET# C50 DDI3_PAIR3- D50 DDI2_PAIR3-
A51 GND (fixed) B51 GND (fixed) C51 GND (fixed) D51 GND (fixed)
A52 PCIE_TX5+ B52 PCIE_RX5+ C52 PEG_RX0+ D52 PEG_TX0+
A53 PCIE_TX5- B53 PCIE_RX5- C53 PEG_RX0- D53 PEG_TX0-
A54 GPI0 B54 GPO1 C54 TYPE0# D54 PEG_LANE_RV#
A55 PCIE_TX4+ B55 PCIE_RX4+ C55 PEG_RX1+ D55 PEG_TX1+
A56 PCIE_TX4- B56 PCIE_RX4- C56 PEG_RX1- D56 PEG_TX1-
A57 GND B57 GPO2 C57 TYPE1# D57 TYPE2#
A58 PCIE_TX3+ B58 PCIE_RX3+ C58 PEG_RX2+ D58 PEG_TX2+
A59 PCIE_TX3- B59 PCIE_RX3- C59 PEG_RX2- D59 PEG_TX2-
A60 GND (fixed) B60 GND (fixed) C60 GND (fixed) D60 GND (fixed)
A61 PCIE_TX2+ B61 PCIE_RX2+ C61 PEG_RX3+ D61 PEG_TX3+
A62 PCIE_TX2- B62 PCIE_RX2- C62 PEG_RX3- D62 PEG_TX3-
A63 GPI1 B63 GPO3 C63 RSVD D63 RSVD
A64 PCIE_TX1+ B64 PCIE_RX1+ C64 RSVD D64 RSVD
A65 PCIE_TX1- B65 PCIE_RX1- C65 PEG_RX4+ D65 PEG_TX4+
A66 GND B66 WAKE0# C66 PEG_RX4- D66 PEG_TX4-
A67 GPI2 B67 WAKE1# C67 RSVD D67 GND
A68 PCIE_TX0+ B68 PCIE_RX0+ C68 PEG_RX5+ D68 PEG_TX5+
A69 PCIE_TX0- B69 PCIE_RX0- C69 PEG_RX5- D69 PEG_TX5-
A70 GND (fixed) B70 GND (fixed) C70 GND (fixed) D70 GND (fixed)
A71 LVDS_A0+ B71 LVDS_B0+ C71 PEG_RX6+ D71 PEG_TX6+
A72 LVDS_A0- B72 LVDS_B0- C72 PEG_RX6- D72 PEG_TX6-
A73 LVDS_A1+ B73 LVDS_B1+ C73 GND D73 GND
A74 LVDS_A1- B74 LVDS_B1- C74 PEG_RX7+ D74 PEG_TX7+
A75 LVDS_A2+ B75 LVDS_B2+ C75 PEG_RX7- D75 PEG_TX7-
A76 LVDS_A2- B76 LVDS_B2- C76 GND D76 GND
A77 LVDS_VDD_EN B77 LVDS_B3+ C77 RSVD D77 RSVD
A78 LVDS_A3+ B78 LVDS_B3- C78 PEG_RX8+ D78 PEG_TX8+
A79 LVDS_A3- B79 LVDS_BKLT_EN C79 PEG_RX8- D79 PEG_TX8-

Express-KL
Pinouts and Signal Descriptions 11
Row A Row B Row C Row D
Pin Name Pin Name Pin Name Pin Name
A80 GND (FIXED) B80 GND (FIXED) C80 GND (FIXED) D80 GND (FIXED)
A81 LVDS_A_CK+ B81 LVDS_B_CK+ C81 PEG_RX9+ D81 PEG_TX9+
A82 LVDS_A_CK- B82 LVDS_B_CK- C82 PEG_RX9- D82 PEG_TX9-
A83 LVDS_I2C_CK B83 LVDS_BKLT_CTRL C83 RSVD D83 RSVD
A84 LVDS_I2C_DAT B84 VCC_5V_SBY C84 GND D84 GND
A85 GPI3 B85 VCC_5V_SBY C85 PEG_RX10+ D85 PEG_TX10+
A86 RSVD B86 VCC_5V_SBY C86 PEG_RX10- D86 PEG_TX10-
A87 RSVD B87 VCC_5V_SBY C87 GND D87 GND
A88 PCIE0_CK_REF+ B88 BIOS_DIS1# C88 PEG_RX11+ D88 PEG_TX11+
A89 PCIE0_CK_REF- B89 VGA_RED C89 PEG_RX11- D89 PEG_TX11-
A90 GND (fixed) B90 GND (fixed) C90 GND (fixed) D90 GND (fixed)
A91 SPI_POWER B91 VGA_GRN C91 PEG_RX12+ D91 PEG_TX12+
A92 SPI_MISO B92 VGA_BLU C92 PEG_RX12- D92 PEG_TX12-
A93 GPO0 B93 VGA_HSYNC C93 GND D93 GND
A94 SPI_CLK B94 VGA_VSYNC C94 PEG_RX13+ D94 PEG_TX13+
A95 SPI_MOSI B95 VGA_I2C_CK C95 PEG_RX13- D95 PEG_TX13-
A96 TPM_PP B96 VGA_I2C_DAT C96 GND D96 GND
A97 TYPE10# B97 SPI_CS# C97 RSVD D97 RSVD
A98 SER0_TX / CAN_TX B98 RSVD C98 PEG_RX14+ D98 PEG_TX14+
A99 SER0_RX / CAN_RX B99 RSVD C99 PEG_RX14- D99 PEG_TX14-
A100 GND (fixed) B100 GND (fixed) C100 GND (fixed) D100 GND (fixed)
A101 SER1_TX B101 FAN_PWMOUT C101 PEG_RX15+ D101 PEG_TX15+
A102 SER1_RX B102 FAN_TACHIN C102 PEG_RX15- D102 PEG_TX15-
A103 LID# ** B103 SLEEP# ** C103 GND D103 GND
A104 VCC_12V B104 VCC_12V C104 VCC_12V D104 VCC_12V
A105 VCC_12V B105 VCC_12V C105 VCC_12V D105 VCC_12V
A106 VCC_12V B106 VCC_12V C106 VCC_12V D106 VCC_12V
A107 VCC_12V B107 VCC_12V C107 VCC_12V D107 VCC_12V
A108 VCC_12V B108 VCC_12V C108 VCC_12V D108 VCC_12V
A109 VCC_12V B109 VCC_12V C109 VCC_12V D109 VCC_12V
A110 GND (fixed) B110 GND (fixed) C110 GND (fixed) D110 GND (fixed)
Note: 4-lane eDP is available as BOM option in place of LVDS.

12 Pinouts and Signal Descriptions
3.2. Signal Description Terminology
The following terms are used in the COM Express AB/CD Signal Descriptions below.
I Input to the Module
O Output from the Module
I/O Bi-directional input/output signal
OD Open drain output
I 3.3V Input 3.3V tolerant
I 5V Input 5V tolerant
O 3.3V Output 3.3V signal level
O 5V Output 5V signal level
I/O 3.3V Bi-directional signal 3.3V tolerant
I/O 5V Bi-directional signal 5V tolerant
I/O 3.3Vsb Input 3.3V tolerant active in standby state
P Power Input/Output
REF Reference voltage output that may be sourced from a module power plane.
PDS Pull-down strap. This is an output pin on the module that is either tied to GND or not connected.
The signal is used to indicate the PICMG module type to the Carrier Board.
PU ADLINK implemented pull-up resistor on module
PD ADLINK implemented pull-down resistor on module

Express-KL
Pinouts and Signal Descriptions 13
3.3. AB Signal Descriptions
3.3.1. Audio Signals
Signal Pin # Description I/O PU/PD Comment
AC_RST# /
HDA_RST#
A30 Reset output to CODEC, active low. O 3.3VSB
AC_SYNC /
HDA_SYNC
A29 Sample-synchronization signal to the
CODEC(s).
O 3.3VSB
AC_BITCLK /
HDA_BITCLK
A32 Serial data clock generated by the
external CODEC(s).
I/O
3.3VSB
AC _SDOUT /
HDA_SDOUT
A33 Serial TDM data output to the CODEC. O 3.3VSB Boot strap pin, no external
pull-up or pull-down resistor
on carrier board is
recommended to avoid
change the configuration of
this signal
AC _SDIN[2:0]
HDA_SDIN[2:0]
B28
B29
B30
Serial TDM data inputs from up to 3
CODECs.
I 3.3VSB AC_SDIN0: supported
AC_SDIN1: supported
AC_SDIN2: not supported
3.3.2. Analog VGA
Note: No VGA support on this product.
Signal Pin
# Description I/O PU/PD Comment
VGA_RED B89
Red for monitor.
Analog DAC output, designed to
drive a 37.5-Ohm equivalent load.
O Analog PD 150R shall also be terminated on
the carrier with 150Ω
resistor to ground close to
VGA connector
VGA_GRN B91
Green for monitor
Analog DAC output, designed to
drive a 37.5-Ohm equivalent load.
O Analog PD 150R shall also be terminated on
the carrier with 150Ω
resistor to ground close to
VGA connector
VGA_BLU B92
Blue for monitor.
Analog DAC output, designed to
drive a 37.5-Ohm equivalent load.
O Analog PD 150R shall also be terminated on
the carrier with 150Ω
resistor to ground close to
VGA connector
VGA_HSYNC B93 Horizontal sync output to VGA
monitor
O 5V
VGA_VSYNC B94 Vertical sync output to VGA monitor O 5V
VGA_I2C_CK B95 DDC clock line (I²C port dedicated
to identify VGA monitor capabilities)
I/O OD 3.3V PU 2k2
3.3V
VGA_I2C_DAT B96 DDC data line. I/O OD 3.3V PU 2k2
3.3V

14 Pinouts and Signal Descriptions
3.3.3. LVDS
Signal Pin # Description I/O PU/PD Comment
LVDS_A0+ /
eDP_TX2+
LVDS_A0- /
eDP_TX2-
LVDS_A1+ /
eDP_TX1+
LVDS_A1- /
eDP_TX1-
LVDS_A2+ /
eDP_TX0+
LVDS_A2- /
eDP_TX0-
LVDS_A3+
LVDS_A3-
A71
A72
A73
A74
A75
A76
A78
A79
LVDS Channel A differential pairs O LVDS
LVDS_A_CK+ /
eDP_TX3+
LVDS_A_CK- /
eDP_TX3-
A81
A82
LVDS Channel A differential clock O LVDS
LVDS_B0+
LVDS_B0-
LVDS_B1+
LVDS_B1-
LVDS_B2+
LVDS_B2-
LVDS_B3+
LVDS_B3-
B71
B72
B73
B74
B75
B76
B77
B78
LVDS Channel B differential pairs O LVDS
LVDS_B_CK+
LVDS_B_CK-
B81
B82
LVDS Channel B differential clock O LVDS
LVDS is default
support
LVDS_VDD_EN A77 LVDS panel power enable O 3.3V PD 10K
LVDS_BKLT_EN B79 LVDS panel backlight enable O 3.3V PD 10K
LVDS_BKLT_CTRL B83 LVDS panel backlight brightness
control
O 3.3V PD 100K
LVDS_I2C_CK A83
DDC lines used for flat panel detection
and control.
I/O OD
3.3V
PU 2k2 3.3V
LVDS_I2C_DAT A84
DDC lines used for flat panel detection
and control.
I/O OD
3.3V
PU 2k2 3.3V
3.3.4. eDP
Note: eDP is a BOM option, in place of LVDS.
Signal Pin # Description I/O PU/PD Comment
eDP_TX2+
eDP_TX2-
eDP_TX1+
eDP_TX1-
eDP_TX0+
eDP_TX0--
A71
A72
A73
A74
A75
A76
eDP differential pairs O PCIE AC coupled off
module
eDP_TX3+
eDP_TX3--
A81
A82
eDP differential pairs O PCIE AC coupled off
module
eDP_VDD_EN A77 eDP power enable O 3.3V PD 10K
