AEG AHF18240 User manual

AHF18240
Original instructions

2
2
A
B
C
E
D
F
G
A - Adjustable head
B - Control knob
C - Hooks
D - Battery cover
E - Receptacle
F - Battery port
G - Carrying handle
A
B
C
A
B
C
A - Battery pack
B - Battery port
C - Battery cover
A - Control knob
B - Off (O)
C - To increase speed
D - To decrease speed
Fig. 1 Fig. 2 Fig. 3
A
B
C
D
A - Receptacle
B - Power cord
C - Battery cover
Important!
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
It is essential that you read the instructions in this manual before
operating this tool.
Subject to technical modifications.

33
A
B
C
E
D
F
G
A - Adjustable head
B - Control knob
C - Hooks
D - Battery cover
E - Receptacle
F - Battery port
G - Carrying handle
A
B
C
A
B
C
A - Battery pack
B - Battery port
C - Battery cover
A - Control knob
B - Off (O)
C - To increase speed
D - To decrease speed
Fig. 1 Fig. 2 Fig. 3
A
B
C
D
A - Receptacle
B - Power cord
C - Battery cover

4
4
A - Hooks
B - Key Hole
C - Adjustable head
Fig. 4 Fig. 9
Fig. 5 Fig. 7
Fig. 6 Fig. 8
Fig. 10
A
C
A
B
A - Tripod mounting hole
B - Pocket
C - Recess
B
C
A
WARNING! Read all safety warnings, instructions,
illustrations and specications provided with this power
tool. Failure to follow all instructions listed below may result in
electric shock, re and/or serious injury. Save all warnings and
instructions for future reference.
FAN SAFETY WARNINGS
Know your product. Read operator’s manual carefully. Learn
its applications and limitations, as well as the specic potential
hazards related to this tool. Following this rule will reduce the risk
of electric shock, re, or serious injury.
Do not disassemble the product.
Do not attempt to modify this product or create accessories
not recommended for use with this product. Any such alteration
or modication is misuse and could result in a hazardous condition
leading to possible serious personal injury.
Do not use this product if it is not completely assembled or if
any parts appear to be missing or damaged. Use of a product
that is not properly and completely assembled could result in serious
personal injury.
The product is not intended for use in kitchens, bathrooms or
other places where water may be present.
Do not use this product to exhaust hazardous or explosive
materials and vapors. It is intended for general ventilating use only.
Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition. Be
aware of possible hazards when not using your battery tool or
when changing accessories. Following this rule will reduce the
risk of electric shock, re, or serious personal injury.
Do not place battery tools or their batteries near re or heat.
Following this rule will reduce the risk of explosion and possibly
TECHNICAL DATA 18 V HYBRID PORTABLE FAN AHF18240
Rated voltage 18 V / 220 - 240 V 50 Hz
High speed 2100 min-1
Low speed 700 min-1
Switch Variable speed
Air velocity Max 340 m/min
Air volume Max 799m3/h
Weight - excluding battery pack 2.66 kg
BATTERY AND CHARGER
Compatible battery pack
(not included)
Compatible charger
(not included)
L1815R
L1820R
L1825R
L1830R
L1830R-X5
L1840R
L1850R
L1860R
L1860R-X5
L1890R
AL18G
BL1218
BLK1218
BL18DP2-X5
BL18DPS
Use AEG 18V battery and charger only

55
A - Hooks
B - Key Hole
C - Adjustable head
Fig. 4 Fig. 9
Fig. 5 Fig. 7
Fig. 6 Fig. 8
Fig. 10
A
C
A
B
A - Tripod mounting hole
B - Pocket
C - Recess
B
C
A
WARNING! Read all safety warnings, instructions,
illustrations and specications provided with this power
tool. Failure to follow all instructions listed below may result in
electric shock, re and/or serious injury. Save all warnings and
instructions for future reference.
FAN SAFETY WARNINGS
Know your product. Read operator’s manual carefully. Learn
its applications and limitations, as well as the specic potential
hazards related to this tool. Following this rule will reduce the risk
of electric shock, re, or serious injury.
Do not disassemble the product.
Do not attempt to modify this product or create accessories
not recommended for use with this product. Any such alteration
or modication is misuse and could result in a hazardous condition
leading to possible serious personal injury.
Do not use this product if it is not completely assembled or if
any parts appear to be missing or damaged. Use of a product
that is not properly and completely assembled could result in serious
personal injury.
The product is not intended for use in kitchens, bathrooms or
other places where water may be present.
Do not use this product to exhaust hazardous or explosive
materials and vapors. It is intended for general ventilating use only.
Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition. Be
aware of possible hazards when not using your battery tool or
when changing accessories. Following this rule will reduce the
risk of electric shock, re, or serious personal injury.
Do not place battery tools or their batteries near re or heat.
Following this rule will reduce the risk of explosion and possibly
injury.
Never use a battery that has been dropped or received a sharp
blow. A damaged battery is subject to explosion. Properly dispose
of a dropped or damaged battery immediately.
Batteries can explode in the presence of a source of ignition,
such as a pilot light. To reduce the risk of serious personal injury,
never use any cordless product in the presence of open ame. An
exploded battery can propel debris and chemicals. If exposed, ush
with water immediately.
Do not charge battery tool in a damp or wet location. Following
this rule will reduce the risk of electric shock.
Do not expose the product to rain. Water entering the product will
increase the risk of electric shock or malfunction.
For best results, your battery tool should be charged in a
location where the temperature is more than 10°C (50°F) but
less than 38°C (100°F). Do not store outside or in vehicles.
Under extreme usage or temperature conditions, battery
leakage may occur. If liquid comes in contact with your skin,
wash immediately with soap and water, then neutralize with
lemon juice or vinegar. If liquid gets into your eyes, ush them
with clean water for at least 10 minutes, then seek immediate
medical attention. Following this rule will reduce the risk of serious
personal injury.
Keep the product dry, clean and free from oil and grease.
Always use a clean cloth when cleaning.
Do not incinerate the battery even if it is severely damaged.
The batteries can explode in a re.
To reduce the risk of re or electric shock, do not use this
portable fan with any solid-state speed control device.
Save these instructions. Refer to them frequently and use them to
instruct others who may use this tool. If you loan someone this tool,
loan them these instructions also to prevent misuse of the product
TECHNICAL DATA 18 V HYBRID PORTABLE FAN AHF18240
Rated voltage 18 V / 220 - 240 V 50 Hz
High speed 2100 min-1
Low speed 700 min-1
Switch Variable speed
Air velocity Max 340 m/min
Air volume Max 799m3/h
Weight - excluding battery pack 2.66 kg
BATTERY AND CHARGER
Compatible battery pack
(not included)
Compatible charger
(not included)
L1815R
L1820R
L1825R
L1830R
L1830R-X5
L1840R
L1850R
L1860R
L1860R-X5
L1890R
AL18G
BL1218
BLK1218
BL18DP2-X5
BL18DPS
Use AEG 18V battery and charger only

6
6
and possible injury.
Ensure that the fan is switched off from the supply mains before
removing the guar.
WARNING
If unusual oscillating movement is observed, immediately stop
using the fan and contact the manufacturer, its service agent or
suitably qualied persons.
The replacement of parts of the safety suspension system device
shall be performed by the manufacturer, its service agent or suitably
qualied persons.
The xing means for attachment to the ceiling such as hooks or
other devices shall be xed with a sufcient strength to withstand 4
times the weight of the fan.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of re, personal injury, and
product damage due to a short circuit, never immerse your tool,
battery pack or charger in uid or allow a uid to ow inside them.
Corrosive or conductive uids, such as seawater, certain industrial
chemicals, and bleach or bleach containing products, etc., can
cause a short circuit.
ASSEMBLY
WARNING
Do not use this product if it is not completely assembled or if any
parts appear to be missing or damaged. Use of a product that
is not properly and completely assembled or with damaged or
missing parts could result in serious personal injury.
WARNING
Do not attempt to modify this product or create accessories or
attachments not recommended for use with this product. Any
such alteration or modication is misuse and could result in a
hazardous condition leading to possible serious personal injury.
OPERATION
WARNING
Do not allow familiarity with tools to make you careless.
Remember that a careless fraction of a second is sufcient to
inict serious injury.
WARNING
Do not use any attachments or accessories not recommended
by the manufacturer of this tool. The use of attachments or
accessories not recommended can result in serious personal
injury.
APPLICATIONS
You may use this tool for the purpose listed below:
■General ventilation of most household spaces.
This product is designed to be powered by either a 18V battery pack
(DC mode) or by electric power (AC mode). Either power source
can be used by installing an approved battery pack or power cord
into the product as described in this manual.
INSTALLING/REMOVING BATTERY PACK
See Figure 1.
■ Turn the control knob to the OFF (0) position.
■Open the battery cover.
■Insert the battery pack into the product as shown.
■Make sure the latches on each side of the battery pack snap
into place and the battery pack is secured before beginning
operation.
■Depress the latches to remove the battery pack.
■Close the battery cover.
WARNING
Always remove battery pack or unplug extension cord from your
product when you are assembling parts, making adjustments,
cleaning, or when not in use. Removing battery pack or
unplugging extension cord will prevent accidental starting that
could cause serious personal injury.
NOTE: The battery pack should be recharged after approximately
5 hours of use to reduce the possibility of damage. Repeated deep
discharge of the battery may decrease storage capacity and battery
life.
INSTALLING/REMOVING POWER CORD
See Figure 2.
■ Turn the control knob to the OFF (0) position.
■Open the battery cover.
■Insert the female end of the power cord into the product as
shown.
■Connect the male end of the power cord to the power source.
■Make sure the power cord is secured before beginning
operation.
STARTING/STOPPING THE PORTABLE FAN
See Figure 3.
■Connect the portable fan to a power cord or approved battery
pack.
■Turn the control knob clockwise to turn the portable fan ON and
to adjust fan speed.
■To stop the portable fan, turn the control knob counterclockwise
to the OFF (0) position.
WARNING
Hybrid tools are always in operating condition. Therefore, the
control knob should always be in the OFF (0) position when not
in use and the power source is removed.
CHANGING PORTABLE FAN SPEED
See Figure 3.
■For low speeds, rotate the control knob clockwise.
■For high speeds, rotate the control knob counterclockwise.
HANGING/MOUNTING PORTABLE FAN
See Figures 4 – 10.
Your portable fan has a variety of hanging options. Choose the
option that is best suited for your location.
NOTE: The portable fan can be hung in a vertical or horizontal
position. Be careful not to hang the fan in such a way that it prevents
normal fan operation or damages the cord.
Hanging the fan using the key hole:
■Place the wide portion of the key hole over the head of a screw.
■Slide the portable fan down until the screw is inside the narrow
portion of the key hole and the fan is secure.
Hanging the fan using the hooks:
■Pull the hooks completely out of their slots and rotate them as
needed.
NOTE: Hooks will not rotate until they are fully extended.
■ Hang the fan from a sturdy location.
Mounting the fan to 2x wood material using the hooks:
■Pull the hooks completely out of their slots and rotate them
upward 180 degrees.
NOTE: Hooks will not rotate until they are fully extended.
■Put the wider side of the 2x wood material on the clamping
surface of the fan legs. The edge of the wood should rest
against the front surface of the legs.
■ Rotate the hooks down 180 degrees to clamp the fan to the 2x
wood material.
■To remove the fan from the 2x wood material, rotate the hooks
180 degrees to the upward position.
Mounting the fan to rods using the rod pockets:
■The fan can be mounted to rods, tubes, or rebar using the
pockets on the base of the fan.
NOTE: The mounting posts must have a diameter between 13
and 22.6 mm.
Mounting the fan to a 2x4 using the 2x4 recess:
■Place the fan onto a 2x4. Make sure the wood is seated
completely inside the 2x4 recess.
■Secure the fan to the wood using bungee cords or tie downs.
ADJUSTING THE HEAD
See Figure 4.
The portable fan head can be rotated 240 degrees. To switch head
positions, adjust head to desired position.
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance
of the battery pack. Avoid extended exposure to heat or sunshine
(risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
• Store the battery pack where the temperature is below 27°C
and away from moisture.
• Store the battery packs in a 30% - 50% charged condition.
• Every six months of storage, charge the pack as normal.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
■The user can transport the batteries by road without further
requirements.
■ Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately.
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
■Ensure that battery contact terminals are protected and
insulated to prevent short circuit.
■Ensure that battery pack is secured against movement within
packaging.

77
■Insert the battery pack into the product as shown.
■Make sure the latches on each side of the battery pack snap
into place and the battery pack is secured before beginning
operation.
■Depress the latches to remove the battery pack.
■Close the battery cover.
WARNING
Always remove battery pack or unplug extension cord from your
product when you are assembling parts, making adjustments,
cleaning, or when not in use. Removing battery pack or
unplugging extension cord will prevent accidental starting that
could cause serious personal injury.
NOTE: The battery pack should be recharged after approximately
5 hours of use to reduce the possibility of damage. Repeated deep
discharge of the battery may decrease storage capacity and battery
life.
INSTALLING/REMOVING POWER CORD
See Figure 2.
■ Turn the control knob to the OFF (0) position.
■Open the battery cover.
■Insert the female end of the power cord into the product as
shown.
■Connect the male end of the power cord to the power source.
■Make sure the power cord is secured before beginning
operation.
STARTING/STOPPING THE PORTABLE FAN
See Figure 3.
■Connect the portable fan to a power cord or approved battery
pack.
■Turn the control knob clockwise to turn the portable fan ON and
to adjust fan speed.
■To stop the portable fan, turn the control knob counterclockwise
to the OFF (0) position.
WARNING
Hybrid tools are always in operating condition. Therefore, the
control knob should always be in the OFF (0) position when not
in use and the power source is removed.
CHANGING PORTABLE FAN SPEED
See Figure 3.
■For low speeds, rotate the control knob clockwise.
■For high speeds, rotate the control knob counterclockwise.
HANGING/MOUNTING PORTABLE FAN
See Figures 4 – 10.
Your portable fan has a variety of hanging options. Choose the
option that is best suited for your location.
NOTE: The portable fan can be hung in a vertical or horizontal
position. Be careful not to hang the fan in such a way that it prevents
normal fan operation or damages the cord.
Hanging the fan using the key hole:
■Place the wide portion of the key hole over the head of a screw.
■Slide the portable fan down until the screw is inside the narrow
portion of the key hole and the fan is secure.
Hanging the fan using the hooks:
■Pull the hooks completely out of their slots and rotate them as
needed.
NOTE: Hooks will not rotate until they are fully extended.
■ Hang the fan from a sturdy location.
Mounting the fan to 2x wood material using the hooks:
■Pull the hooks completely out of their slots and rotate them
upward 180 degrees.
NOTE: Hooks will not rotate until they are fully extended.
■Put the wider side of the 2x wood material on the clamping
surface of the fan legs. The edge of the wood should rest
against the front surface of the legs.
■ Rotate the hooks down 180 degrees to clamp the fan to the 2x
wood material.
■To remove the fan from the 2x wood material, rotate the hooks
180 degrees to the upward position.
Mounting the fan to rods using the rod pockets:
■The fan can be mounted to rods, tubes, or rebar using the
pockets on the base of the fan.
NOTE: The mounting posts must have a diameter between 13
and 22.6 mm.
Mounting the fan to a 2x4 using the 2x4 recess:
■Place the fan onto a 2x4. Make sure the wood is seated
completely inside the 2x4 recess.
■Secure the fan to the wood using bungee cords or tie downs.
ADJUSTING THE HEAD
See Figure 4.
The portable fan head can be rotated 240 degrees. To switch head
positions, adjust head to desired position.
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance
of the battery pack. Avoid extended exposure to heat or sunshine
(risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
• Store the battery pack where the temperature is below 27°C
and away from moisture.
• Store the battery packs in a 30% - 50% charged condition.
• Every six months of storage, charge the pack as normal.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
■The user can transport the batteries by road without further
requirements.
■ Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately.
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
■Ensure that battery contact terminals are protected and
insulated to prevent short circuit.
■Ensure that battery pack is secured against movement within
packaging.
■Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice
BATTERY PACK PROTECTION
The battery pack has overload protection that protects it from being
overloaded and helps to ensure long life. Under extreme stress the
battery electronics switch off the machine automatically. To restart,
switch the machine off and then on again. If the machine does not
start up again, the battery pack may have discharged completely. In
this case it must be recharged in the battery charger.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should
components need to be replaced which have not been described,
please contact one of our AEG service agents (see our list of
guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label and
order the drawing at your local service agents or directly at:
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797(0800 AEGPWR)
New Zealand
SYMBOLS
Safety alert
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Please read the instructions carefully before
starting the machine.
The product can be used in a tropical climate.
Class II, double insulated
For indoor use only.
Do not dispose of electric tools together with
household waste material. Electric tools and
electronic equipment that have reached the end of
their life must be collected separately and returned
to an environmentally compatible recycling facility.

Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley,
VIC, 3149, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
AEG is a registered trade mark used under
license from AB Electrolux (publ)
© 2016-20 Techtronic Cordless GP.20200316v3
