Agilent Technologies RV Series User manual

Agilent Technology EM Pumps 1
P600-20-300
Issue D
Amendment for
A652-01-880
RV ROTARY VANE PUMPS FOR AGILENT TECHNOLOGY
1INTRODUCTION
1.1 Scope of this amendment
This amendment describes the installation, operation and maintenance for the RV
rotary vane pumps for Agilent Technology (referred to as Agilent RV pumps in the
rest of this amendment). Unless specified in this amendment, all information in the
instruction manual also applies to the Agilent RV pumps. Read this amendment
before you use the pump.
The Item Numbers for the Agilent RV pumps are as follows:
Pump Item Number
Agilent RV3 Rotary Vane Pump, 110-120/220-240 V,
50/60 Hz, single-phase A652-02-903 or -906
Agilent RV5 Rotary Vane Pump, 110-120/220-240 V,
50/60 Hz, single-phase A653-02-903 or -906
Agilent RV8 Rotary Vane Pump, 110-120/220-240 V,
50/60 Hz, single-phase A654-02-903 or -906
Agilent RV12 Rotary Vane Pump, 110-120/220-240 V,
50/60 Hz, single-phase A655-02-903 or -906
Agilent RV3 Rotary Vane Pump, 100/200 V, 50/60 Hz, single-phase A652-02-904
Agilent RV5 Rotary Vane Pump, 100/200 V, 50/60 Hz, single-phase A653-02-904
Agilent RV8 Rotary Vane Pump, 100/200 V, 50/60 Hz, single-phase A654-02/22-904
Agilent RV8 Rotary Vane Pump, 110-120/220-240 V, 50/60 Hz, single phase A654-22-903
Agilent RV12 Rotary Vane Pump, 100/200 V, 50/60 Hz, single-phase A655-02-904
Note that the Declaration of Conformity for the Agilent RV pumps is shown on page
7 of this amendment.
1.2 Description
The Agilent RV pumps differ from the standard RV pumps as follows:
The Agilent RV pumps are supplied with single-phase motors only, not with
three-phase motors.
The Agilent RV pumps are supplied with the pump configured for a specific
electrical supply voltage. A label over the electrical inlet-connector identifies this
voltage.
The Agilent RV pumps are filled with Edwards 45 oil and have a label next to the
oil filler-plugs which states that you should only use Edwards 45 oil in the pump.

2 Agilent Technology EM Pumps
The Agilent RV pumps are supplied with an oil-drain extension fitted to the oil
drain-port.
The Agilent RV pumps may be supplied with a transit-plug fitted to the outlet-
port of the pump to prevent the spillage of oil during transit. You will remove
the transit-plug and fit a nozzle (supplied) to the outlet-port.
The Agilent RV8 and RV12 pumps are fitted with a special lifting bracket (see
Figure 2).
The Agilent RV pump is supplied with the mode selector set to the High Vacuum
position.
The pump shown in Figure 1 of the instruction manual is therefore incorrect; the
correct Figure 1 is shown below.
1. Electrical inlet-connector 6. Oil-filler plug 11. Rubber feet (4 off)
2. Voltage indicator 7. Identification plate* 12. Mode selector
3. Lifting handle (lifting bracket 8. Outlet-nozzle 13. On/off switch
on Agilent RV8 & RV12 pumps) 9. Oil-level sight-glass 14. Motor fan-cover
4. NW25 inlet-port 10. Oil drain-plug 15. Correct direction of rotation
5. Gas-ballast control
* The plate shows the Agilent and Edwards part numbers
Figure 1 – The Agilent RV Pump (Agilent RV3 or Agilent RV5 shown)

Agilent Technology EM Pumps 3
2TECHNICAL DATA
The Agilent RV pumps have only single-phase motors; ignore all of the data
which applies to three-phase motors and electrical supplies in Section 2 of the
instruction manual.
You must use Edwards 45 oil and not Edwards Ultragrade 19 as recommended in
Section 2.6 of the instruction manual.
Figure 3 in the instruction manual is now incorrect. Figure 2 of this amendment
shows the correct dimensions for the Agilent RV pumps.
3INSTALLATION
3.1 Introduction
Unless otherwise specified in the following sections of this amendment, you must use
the procedures in Section 3 of the instruction manual to install the Agilent RV pump.
Ignore all of the procedures in Section 3 which apply to three-phase pumps.
3.2 Unpack and Inspect
When you unpack and inspect the Agilent RV pump, take note of the following:
There is no protective cover on the outlet-port. The pump may be supplied with
a red transit-plug fitted to the outlet-port (refer to Section 3.6 of this amendment).
An outlet nozzle is suppled separately.
3.3 Locate the Pump
WARNING
Use suitable lifting equipment to move the
Agilent RV8 or Agilent RV12 pump.
The mass of the Agilent RV8 and
Agilent RV12 pumps is approximately 26 kg.
Locate the pump as described in Section 3.4 of the instruction manual. Note however
that the Agilent RV8 and Agilent RV12 pumps have a special lifting bracket, suitable
for use with your lifting equipment.
3.4 Fill the Pump With Oil
You will need to fill the pump with Edwards 45 oil, using the funnel provided. Then
follow the instructions as described in Section 3.5 of the instruction manual.

4 Agilent Technology EM Pumps
1. On/off switch A Top view
2. Lifting bracket (Agilent RV8 and RV12 pumps only) B Side view
C Front view
Pump A B C D E F G H I J
Agilent RV3 429 127 57 37 32 225 78 230 120 158
Agilent RV5 429 127 57 37 32 225 78 230 120 158
Agilent RV8 469 161 63 37 32 225 78 230 120 158
Agilent RV12 489 181 63 37 32 225 78 230 120 158
Figure 2 – Dimensions (mm)

Agilent Technology EM Pumps 5
3.5 Check and Configure The Motor
The Agilent RV pump is supplied with a label fixed over the electrical inlet-connector
on the pump motor; this label specifies which electrical supply voltage the pump is
configured for.
1. Before you remove the label, check that the voltage specified on the label is
suitable for use with your electrical supply.
2. If the voltage is not suitable for use with your electrical supply, reconfigure the
motor as described in Section 3.6.1 of the instruction manual.
3. Remove the label before you connect the pump to your electrical supply.
3.6 Fit the outlet nozzle
CAUTION
You must remove the red transit-plug before you operate the pump. If you do not,
the oil box will become pressurised and may fracture.
Note: The red transit-plug fitted to the outlet-port has a label attached. The label (shown in
Figure 3 of this amendment) reminds you that you must remove the transit-plug and
fit the outlet nozzle before you switch on and use the pump.
The pump may be supplied with a red transit-plug fitted to the outlet-port of the
pump. Before you operate the pump, unscrew the transit-plug from the 3/4 inch BSP
threaded outlet-port and screw the outlet nozzle (supplied) into the outlet-port.
3.7 Outlet Connection
You cannot use NW25 fittings to connect to the outlet, as described in Section 3.8 of
the instruction manual. The outlet nozzle supplied is suitable for use with 10 mm
bore vacuum hose or 12 mm bore plastic hose.
4OPERATION
Operate the pump as described in Section 4 of the instruction manual. Note that the
Agilent RV pump is supplied with the mode selector (Figure 1, item 12) in the High
Vacuum mode position.
5MAINTENANCE
You must only use Edwards 45 oil:
When you check the oil-level and need to add more oil (Section 5.3 of the
instruction manual).
When you replace the oil in the pump (Section 5.4 of the instruction manual).

6 Agilent Technology EM Pumps
Figure 3 – Label attached to the transit-plug in the outlet port.

Intentionally left blank
