Agilent Technologies VacIon Plus 500 User manual

V
acIon Plus 500 pumps
Models
919-1710/1720/1740
919-1711/1721/1741
919-1712/1722/1742
919-1750/1760/1780
919-1751/1761/1781
919-1752/1762/1782
Manuale di Istruzioni
Bedienungshandbuch
Notice de Mode D’Emploi
User Manual
87-900-104-01 (F)
05/2011

Notices
© Agilent Technologies, Inc. 2011
No part of this manual may be
reproduced in any form or by any
means (including electronic storage
and retrieval or translation into a
foreign language) without prior
agreement and written consent from
Agilent Technologies, Inc. as governed
by United States and international
copyright laws.
Manual Part Number
Publication Number: 87-900-104-01 (F)
Edition
Edition 05/2011
Printed in ITALY
Agilent Technologies Italia S.p.A.
Vacuum Products Division
Via F.lli Varian, 54
10040 Leinì (TO)
ITALY
Warranty
The material contained in this
document is provided “as is,” and is
subject to being changed, without
notice, in future editions. Further, to
the maximum extent permitted by
applicable law, Agilent disclaims all
warranties, either express or implied,
with regard to this manual and any
information contained herein,
including but not limited to the
implied warranties of merchantability
and fitness for a particular purpose.
Agilent shall not be liable for errors
or for incidental or consequential
damages in connection with the
furnishing, use, or performance of
this document or of any information
contained herein. Should Agilent and
the user have a separate written
agreement with warranty terms
covering the material in this
document that conflict with these
terms, the warranty terms in the
separate agreement shall control.
Technology Licenses
The hardware and/or software
described in this document are
furnished under a license and may be
used or copied only in accordance
with the terms of such license.
Restricted Rights Legend
If software is for use in the
performance of a U.S. Government
prime contract or subcontract,
Software is delivered and licensed as
“Commercial computer software” as
defined in DFAR 252.227-7014 (June
1995), or as a “commercial item” as
defined in FAR 2.101(a) or as
“Restricted computer software” as
defined in FAR 52.227-19 (June 1987)
or any equivalent agency regulation or
contract clause. Use, duplication or
disclosure of Software is subject to
Agilent Technologies’ standard
commercial license terms, and non-
DOD Departments and Agencies of the
U.S. Government will receive no
greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June
1987). U.S. Government users will
receive no greater than Limited Rights
as defined in FAR 52.227-14 (June
1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Trademarks
Windows and MS Windows are U.S.
registered trademarks of Microsoft
Corporation.
Safety Notices
CAUTION
A CAUTION notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in damage to the product
or loss of important data. Do not
proceed beyond a CAUTION notice
until the indicated conditions are fully
understood and met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or the
like that, if not correctly performed
or adhered to, could result in
personal injury or death. Do not
proceed beyond a WARNING notice
until the indicated conditions are
fully understood and met.
VacIon Plus 500 pumps User Manual / 87-900-104-01 (F)

VacIon Plus 500
VacIon Plus 500
VacIon Plus 500 pumps User Manual / 87-900-104-01 (F) 3/92

VacIon Plus 500
4/92 VacIon Plus 500 pumps User Manual / 87-900-104-01 (F)

Contents
Contents
1Procedura per l’installazione 9
Informazioni Generali 10
Preparazione per l’installazione 11
Installazione 13
Uso15
Procedure di uso 16
Manutenzione 18
Smaltimento 18
2Anleitung zur Installation 19
Allgemeine Hinweise 20
Vor der Installation 21
Installation 23
Gebrauch 25
Bedienungsschritte 26
Wartung 28
Entsorgung 28
3Procédure pour l’installation 29
Indications Generales 30
Préparation de l'installation 31
VacIon Plus 500 pumps User Manual / 87-900-104-01 (F) 5/92

Contents
Installation 33
Utilisation 35
Procédure d’utilisation 36
Maintenance 38
Mise au rebut 38
4Installation Procedure 39
General Information 40
Preparation for Installation 41
Installation 43
Use 45
Operating Procedure 46
Maintenance 48
Disposal 48
5Technical Information 49
Vacion Plus Pump Replacement Parts and Accessories 50
Description of the VacIon Pump 51
Technical Specification 53
Vaclon Plus 500 Starcell 55
Vaclon Plus 500 Diode 57
Vaclon Plus 500 Noble Diode58
Outline Drawing 60
Stray Magnetic Field 61
6/92 VacIon Plus 500 pumps User Manual / 87-900-104-01 (F)

Contents
VacIon Plus Pump Installation 65
Typical Installation 68
Inlet Flange Connection 69
Control Unit Connection 72
Safety Interlock 73
Heater Installation 73
Heater Replacement 75
Bakeout Operation 75
Operating Procedure 77
Maintenance 78
Exchange of the High Voltage Feedthrough 80
Pump Troubleshooting 83
Vaclon Plus Pump Replacement Parts and Accessories 84
Vacion Plus Pump Controllers 85
VacIon Plus 500 pumps User Manual / 87-900-104-01 (F) 7/92

Contents
8/92 VacIon Plus 500 pumps User Manual / 87-900-104-01 (F)

VacIon Plus 500 pumps User Manual
1
Procedura per l’installazione
Informazioni Generali 10
Preparazione per l’installazione 11
Installazione 13
Uso 15
Procedure di uso 16
Manutenzione 18
Smaltimento 18
Traduzione delle istruzioni originali
9/92

1Procedura per l’installazione
Informazioni Generali
Informazioni Generali
Questa apparecchiatura è destinata ad uso professionale.
L'utilizzatore deve leggere attentamente il presente manuale di
istruzioni ed ogni altra informazione addizionale fornita dalla Agilent
prima dell'utilizzo dell'apparecchiatura. La Agilent si ritiene sollevata
da eventuali responsabilità dovute all'inosservanza totale o parziale
delle istruzioni, ad uso improprio da parte di personale non
addestrato, ad interventi non autorizzati o ad uso contrario alle
normative nazionali specifiche.
Le pompe della serie VacIon Plus sono pompe ioniche utilizzate
comunemente per applicazioni di ultra alto vuoto, grazie alla loro
pulizia, capacità di pompare qualsiasi tipo di gas, e del loro
funzionamento senza vibrazioni e necessità di manutenzione.
Nei paragrafi seguenti sono riportate tutte le informazioni necessarie
a garantire la sicurezza dell'operatore durante l'utilizzo
dell'apparecchiatura. Informazioni dettagliate sono fornite
nell'appendice “Technical Information”.
Questo manuale utilizza le seguenti convenzioni:
AVVERTENZA!
I messaggi di avvertenza attirano l'attenzione dell'operatore su una procedura
o una pratica specifica che, se non eseguita in modo corretto, potrebbe
provocare gravi lesioni personali.
ATTENZIONE! I messaggi di attenzione sono visualizzati prima di procedure che, se non
osservate, potrebbero causare danni all'apparecchiatura.
NOTA Le note contengono informazioni importanti estrapolate dal testo.
10/92 VacIon Plus 500 pumps User Manual / 87-900-104-01 (F)
