Amazone Cayros Series User manual

Operating manual
az
Cayros
Cayros
Cayros
Cayros
Cayros
Cayros
M
XM
XMS
XS
XS-Pro
Cayros
Cayros
Cayros
Cayros
Cayros
M V
XM V
XMS V
XS V
XS-Pro V
Mounted reversible plough
MG5698
BAG0172.7
02.20
Printed in Germany
Read and observe this
operating manual before using
the implement for the first time!
Keep it in a safe place for future
use!
en

2
Cayros BAG0172.7
02.20
READING THE
INSTRUCTION
manual and to adhere to it should not appear to
be inconvenient and superfluous as it is not
enough to hear from others and to realise that a
implement is good, to buy it and to believe that
now everything would work by itself. The person
concerned would not only harm himself but also
make the mistake of blaming the implement for
the reason of a possible failure instead of himself.
In order to ensure a good success one should go
into the mind of a thing or make himself familiar
with every part of the implement and to get
acquainted with its handling. Only this way, you
would be satisfied both with the implement as
also with yourself. To achieve this is the purpose
of this instruction manual.
Leipzig-Plagwitz 1872.

Identification data
Cayros
BAG0172.7 02.20
3
Identification data
Implement ID No.
Type:
Cayros
Permissible system pressure (bar):
Year of manufacture:
Factory:
Basic weight (kg):
Permissible total weight (kg):
Maximum load (kg):
Manufacturer's address
AMAZONE Technology Kft.
Úttörö u. 43
H - 9200
Tel.:
Fax:
Mosonmagyaróvár
+ 36 (06) 20/469 6360
+ 36 (06) 696/576-662
Spare part orders
Spare parts lists are freely accessible in the spare parts portal at
www.amazone.de.
Please send orders to your AMAZONE dealer.
Formalities of the operating manual
Document number:
MG5698
Compilation date:
02.20

Copyright AMAZONEN-WERKE H. DREYER GmbH & Co. KG, 2020
All rights reserved.
Reprinting, even of sections, only possible with the approval of
AMAZONEN-WERKE H. DREYER GmbH & Co. KG.

Foreword
4
Cayros BAG0172.7
02.20
Foreword
Dear Customer,
You have chosen one of the quality products from the wide product
range of AMAZONEN-WERKE, H. DREYER GmbH & Co. KG. We
thank you for your trust in our products
On receiving the implement, check to see if it has been damaged
during transport or if parts are missing. Using the delivery note, check
that the implement has been delivered in full, including any special
equipment ordered. Damage can only be rectified if problems are
signalled immediately.
Before initial operation, read and observe this operating manual, and
particularly the safety information. Only after careful reading will you
be able to benefit from the full scope of your newly purchased
implement.
Please ensure that all the implement operators have read this
operating manual before they put the implement into operation.
Should you have any questions or problems, please consult this
operating manual or contact your local service partner.
Regular maintenance and timely replacement of worn or damaged
parts increases the lifespan of your implement.
User evaluation
Dear Reader
We update our operating manuals regularly. Your suggestions for
improvement help us to create ever more user-friendly operating
manuals.
AMAZONEN-WERKE
H. DREYER GmbH & Co. KG
Postfach 51
D-49202
Tel.:
E-mail:
Hasbergen, Germany
+ 49 (0) 5405 50 1-0
[e-mail]

Table of Contents
Cayros
BAG0172.7 02.20
5
1Implement description.................................................................................7
1.1 Rating plate..............................................................................................................................7
1.2 Proper use................................................................................................................................7
2Safety first ....................................................................................................8
2.1 Safety instructions....................................................................................................................8
2.2 Safety and accident prevention regulations.............................................................................9
2.3 Warning symbols and other labels on the implement............................................................11
2.3.1 Positions of warning symbols and other labels......................................................................12
3Model overview / Technical data .............................................................. 16
3.1 Overview of the equipment versions......................................................................................16
3.2 Technical data........................................................................................................................18
3.2.1 Ploughs with mechanical cutting width adjustment................................................................18
3.2.2 Ploughs with infinitely variable hydraulic cutting width adjustment........................................19
4Preparations on the tractor and plough...................................................20
4.1 Calculating the actual values for the total tractor weight, tractor axle loads and load
capacities, as well as the minimum ballast ............................................................................20
4.1.1 Data required for the calculation............................................................................................21
4.1.2 Calculation of the required minimum front ballast GV min of the tractor to ensure safe steering22
4.1.3 Calculation of the actual tractor front axle load TV act .............................................................22
4.1.4 Calculation of the actual total weight of the tractor/ implement combination.........................22
4.1.5 Calculation of the actual tractor rear axle load TH act..............................................................22
4.1.6 Tyre carrying capacity............................................................................................................22
4.1.7 Table ......................................................................................................................................23
4.2 Preparation on the tractor ......................................................................................................24
4.3 Preparation on the plough......................................................................................................25
5Mounting and dismounting the plough....................................................26
5.1 Mounting the plough ..............................................................................................................27
5.2 Dismounting the plough .........................................................................................................27
5.3 Hydraulic connections............................................................................................................28
5.3.1 Coupling the hydraulic hose lines ..........................................................................................29
5.3.2 Uncoupling the hydraulic hose lines ......................................................................................29
6Turning the plough ....................................................................................30
6.1 Turning with double-acting automatic cylinder.......................................................................31
6.2 Turning with double-acting automatic cylinder in conjunction with hydraulic beam pivoting.32
7Adjusting the plough .................................................................................33
7.1 Mechanical cutting width adjustment .....................................................................................34
7.2 Infinitely variable hydraulic cutting width adjustment.............................................................35
7.3 Front furrow width - Rough adjustment of the plough on the tractor .....................................36
7.4 Working depth adjustment .....................................................................................................37
7.5 Pitch adjustment ....................................................................................................................38
7.6 Pulling point setting................................................................................................................39
7.7 Precise front furrow adjustment .............................................................................................40
7.8 Disc coulter adjustment..........................................................................................................41
7.8.1 Disc coulter adjustment for standard .....................................................................................41
7.8.2 Disc coulter adjustment for Vario...........................................................................................42
7.8.3 Disc coulter adjustment for automatic stone release.............................................................43
7.9 Fertiliser skimmer...................................................................................................................44
7.10 Swivel arm for supporting a packer .......................................................................................45
8Road transport ...........................................................................................46
8.1 Rear transport pendulum support wheel................................................................................47

Table of Contents
6
Cayros BAG0172.7
02.20
8.2 Lighting - Warning equipment for road transport .................................................................. 48
9Overload safety device ............................................................................. 49
9.1 List of shear bolts .................................................................................................................. 49
9.2 Shear bolt .............................................................................................................................. 49
9.3 SEMI-automatic..................................................................................................................... 50
9.4 Automatic hydraulic stone release ........................................................................................ 51
9.4.1 Hydraulic stone release with central pressure setting........................................................... 52
9.4.2 Hydraulic stone release with decentralised pressure setting................................................ 53
10 Cleaning, maintenance and repair........................................................... 54
10.1 Cleaning ................................................................................................................................ 56
10.2 Storage / overwintering ......................................................................................................... 57
10.3 Maintenance schedule – overview........................................................................................ 58
10.4 Checking the condition of the shares and wear parts ........................................................... 59
10.5 Checking the shear bolts....................................................................................................... 59
10.6 Checking the support wheel.................................................................................................. 60
10.6.1 Check bearing clearance on wheel hubs .............................................................................. 60
10.7 Hydraulic system ................................................................................................................... 61
10.7.1 Labelling hydraulic hose lines ............................................................................................... 62
10.7.2 Maintenance intervals ........................................................................................................... 63
10.7.3 Inspection criteria for hydraulic hose lines ............................................................................ 63
10.7.4 Installation and removal of hydraulic hose lines ................................................................... 64
10.7.5 Installation of hose valve chests with O-ring and union nut.................................................. 64
10.8 Screw tightening torques....................................................................................................... 65
11 Malfunctions and their correction............................................................ 66

Implement description
Cayros
BAG0172.7 02.20
7
1 Implement description
1.1 Rating plate
When making enquiries or orders, please state the construction year,
implement no., and plough type.
These numbers are embossed in the nameplate on the mounted
body.
All points in this manual concerning your safety have been
ascribed this sign! Please pass all safety instructions or the
manual to all other users.
1.2 Proper use
The implement has been designed only for conventional use in
agricultural work (intended use).
Intended use also includes compliance with the conditions for
operation, maintenance, and repairs prescribed by the manufacturer.
Unauthorised changes to the implement exclude manufacturer from
liability and warranty for resultant damage.
The technical equipment of the implement corresponds to the explicit
wishes of the customer. The customer acknowledges that the
implement may not be intended for use on public roads and may not
have the safety equipment required for road traffic. AMAZONE
Technology Kft. points out that the vehicle owner as well as the
vehicle driver are responsible for ensuring that the implement has the
required safety equipment for use on public roads and complies with
the applicable national laws and regulations.
DANGER
A speed of 25 km/h may not be exceeded!

Table of Contents
8
Cayros BAG0172.7
02.20
2 Safety first
2.1 Safety instructions
It is imperative that the following instructions be observed:
1. When uncoupling plough from tractor, ensure that the stand
support is properly clamped!
2. Road transport with transport swing support wheel:
When transporting on public roads, road traffic regulations must
be observed! On transport journeys with transport swing support
wheel, the tractor's toplink must be dismounted.
Furthermore, when driving with the transport swing support
wheel, the rear plough must be locked using the transport
locking mechanism (located at the front on the headstock)!
3. For plough types M850, M950, M1020 of a 4-furrow design and
above, XM850, XM950, XM1050, XMS850
, XMS950, XMS1050,
XS850, XS950, XS1050, XS1150, XSPro 850, XSPro 950,
XSPro 1050 and XSPro 1150 of a 5-furrow design and above
(shear pin, SEMI or automatic stone release), a transport swing
support wheel must be used for all transport journeys
→Service life of plough reversing mechanism!
RISK OF ACCIDENT!
4. To avoid damage to the transport wheel caused by the disc
coulters when pushing back in transport position, these disc
coulters must be moved up to the stop (near coulter shaft)!
5. For all plough types of 4-furrow design and above, a mounting
axle of Cat. II/36 or III/36 (= pin diameter Ø36 mm or ball
diameter Ø64 mm) is always prescribed.
Pin diameter Ø28 mm or ball diameter
Ø56 mm is prohibited ! RISK OF ACCIDENT!

Safety first
Cayros
BAG0172.7 02.20
9
2.2 Safety and accident prevention regulations
1. Operators shall wear close-fitting clothing. Solid footwear must
be worn.
2. Special care is to be ta
ken when handling any sharp and pointed
tools and components - Risk of injury!
3. Before initial operation, please familiarize yourself with all
equipment and operating elements as well as their function -
both on the tractor and on the plough!
It is too late to do this during working operation.
4. Use only stipulated parts for mounting the plough!
5. The mounting category (pin diameter, ball diameter) for three-
point linkage must be compatible for tractor and plough!
6. Special care must be taken when mounting or dismounting the
implement onto or from the tractor!
7. Prior to connecting and disconnecting implement to the three-
point suspension, place operating equipment in such a position
as to prevent unintentional lifting or lowering!
8. When actuating the external controls for three-point linkage, do
not step between tractor and plough!
9. When working between the tractor and the implement, ensure
that the vehicle is secured by the parking brake and/or wheel
chocks to prevent it from rolling away!
10. Before starting vehicle, check its road and operating safety!
11. Stickers concerning safety warnings must be kept clean and
legible! If damaged, they must be replaced.
12. Couple the implement according to the instructions. Handling,
steering and braking are all influenced by implement, and ballast
weight. Therefore ensure that the steering and brakes are not
impaired.
13. The respective road traffic regulations must be observed at all
times when using public roads.
14. When implement is in transport position, always ensure that
there is sufficient lateral locking of the tractor's three-point
linkage!
15. Packer arms must be swivelled in and locked before road
transport!
16. Observe the authorised axle loads, drawbar loads and total
weights!
17. Check surrounding vicinity (children!) before driving off!
18. When driving in curves, take account of the wide sweep and/or
centrifugal mass of the implement!
19. Do not leave the driver's platform while tractor is in motion!
20. Riding on the implement during work or road transport is not
permissible.
21. Before leaving the tractor, lower the implement to the ground,
switch off the engine, and remove the ignition key!
22. Before each transport journey, check the implement for any
damage, material fatigue, as well as for safe functioning of
relevant safety parts for road transport.

Table of Contents
10
Cayros BAG0172.7
02.20
23. If using subsoilers, the subsoiler(s) must be dismounted on the
release side and removed to ensure the stability of the plough.
24. Make sure that no people or animals are within the working and
swivelling range of the plough. The implement operator is
responsible for people and animals in work area.
25. All hydraulically controlled folding parts have shear and crush
zones!
26. The implement must only be parked on level, firm, and
horizontal ground.
RISK OF OVERTURNING!
27. The turning cylinder of implements with single-acting turning
cylinder must be hydraulically locked using stop tap.
28. Put the stand supports in the correct position and fasten
securely when mounting or dismounting the plough!
29. Maintenance, repair, and adjustment work shall only be carried
out when the implement has been lowered to the ground.
30. For spare parts or accessories, use only original parts! Do not
make any "independent" changes to the implement.
31. When carrying out electrical welding work on the tractor and
mounted implement, disconnect the cable on the generator
(alternator) and battery!
32. The hydraulic system is under pressure!
33. When connecting the hydraulic hoses to the tractor's hydraulic
system, ensure that the hydraulics are depressurised on both
the tractor side and the implement side!
34. Label coupling sleeves and plugs to exclude operating errors!
When the connections are inverted, the inverse function is
performed (e.g. lifting / lowering)
Risk of accident!
35. Check hydraulic hose lines regularly and replace if damaged or
worn! The replacement lines must meet the technical
requirements of the implement manufacturer.
36. Fluids (hydraulic oil) escaping under high pressure can
penetrate the skin and cause serious injuries! In the event of
injury, seek medical advice immediately. Risk of infection!
37. Lower the implement on the ground before working on the
hydraulic system. Depressurise system and switch off engine.
38. Check the nuts and bolts regularly for tight fit and retighten if
necessary!
39. For maintenance work - e.g.: the replacement of wearing parts –
that is performed when the implement is raised, always secure
with suitable support mechanisms!
40. Replacement parts must at least meet the technical
requirements stipulated by the implement manufacturer! This is
guaranteed by using original replacement parts.

Safety first
Cayros
BAG0172.7 02.20
11
2.3 Warning symbols and other labels on the implement
Always keep all the warning symbols of the implement clean and in a
legible state. Replace illegible warning symbols. You can obtain the
warning symbols from your dealer using the order number (e.g.
MD 075).
Warning symbols – structure
Warning pictograms indicate danger areas on the implement and
warn of residual dangers. Permanent or unexpected dangers exist in
these areas.
A warning symbol consists of two fields:
Field 1
is a symbol describing the danger, surrounded by triangular safety
symbol.
Field 2
is a symbol showing how to avoid the danger.
Warning symbols – explanation
The column Order number and explanation provides an explanation
of the neighbouring warning symbol. The description of the warning
symbols is always the same and specifies, in the following order:
1. A description of the danger.
For example: risk of cutting
2. The consequence of non-compliance with the risk avoidance
instructions.
For example: causes serious injuries to fingers or hands.
3. Risk avoidance instructions.
For example: only touch implement parts when they have come
to a complete standstill.

Table of Contents
12
Cayros BAG0172.7
02.20
2.3.1 Positions of warning symbols and other labels
Warning symbols
The following diagrams show the arrangement of the warning symbols on the implement.

Safety first
Cayros
BAG0172.7 02.20
13
Order number and explanation
Warning symbols
MD 078
Risk of crushing of fingers/hand by
accessible, moving parts of the implement!
This hazard can cause the most severe injuries
with loss of body parts.
Never reach into the hazardous area while the
engine of the tractor with connected universal
joint shaft/hydraulics/electronic system is
running.
MD 079
Risk of materials or foreign objects being
flung away by or out of the implement!
These dangers can cause extremely serious and
potentially fatal injuries.
•Keep a sufficient safety distance from the
implement as long as the tractor engine is
running.
•Ensure that all other persons also keep a
sufficient safety distance from the danger
area of the implement as long as the tractor
engine is running.
MD 095
Read and follow the operating manual and safety
information before starting up the implement!

Table of Contents
14
Cayros BAG0172.7
02.20
MD 096
Danger from escaping high-pressure
hydraulic fluid due to leaking hydraulic hose
lines.
This danger may cause serious injuries, perhaps
even resulting in death, if escaping high-
pressure
hydraulic fluid passes through the skin and into
the body.
•Never attempt to plug leaks in hydraulic
hose lines using your hand or fingers.
•Read and observe the information in the
operating manual before carrying out
maintenance work on the hydraulic hose
lines.
•If you are injured by hydraulic fluid, contact
a doctor immediately.
MD 097
Risk of crushing and contusions between the
rear of the tractor and the implement when
coupling and uncoupling the implement!
These dangers can cause extremely serious and
potentially fatal injuries.
•It is forbidden to actuate the three-point
hydraulic system of the tractor as long as
persons are standing between the rear of
the tractor and the implement.
•Actuate the operator controls for the
tractor's three-point hydraulic system:
οOnly from the intended workstation
alongside the tractor.
οOnly when you are outside the danger
area between the tractor and the
implement.
MD 102
Dangerous situations for the operator due to
unintentional starting / rolling of the
implement during all work on the implement,
e.g. insta
llation, adjustment, troubleshooting,
cleaning or maintenance.
The potential dangers can inflict severe and
potentially fatal injuries on all parts of the body.
•Secure the tractor and the implement
against unintentional start-up and rolling
before any intervention in the implement.
•Depending on the type of intervention, read
and understand the information in the
relevant sections of this operating manual.

Safety first
Cayros
BAG0172.7 02.20
15
MD 114
This pictogram indicates a lubrication point.
MD 199
The maximum operating pressure of the
hydraulic system is 210 bar.
MD240
Remove the upper link from the mounting body
for transport and secure the implement.
MD241
The coupling point of the upper link on the
implement side must be located at the front in
the slot of the support frame.

Table of Contents
16
Cayros BAG0172.7
02.20
3 Model overview / Technical data
3.1 Overview of the equipment versions
MODEL MXM XMS XS XSPro
Medium
series for
universal use
Medium
weight model
series,
universal use
Medium
weight
premium
class,
specially for
maize straw,
up to 105 cm
For large tractors
Tractor - Hp Class to 120 to 140 to 175 to 260 to 380
Number of shares
3 shares

   
4 shares

   
5 shares
  
6 shares


Cutting width, mechanical
(standard)

Cutting width, hydraulic
(Vario)

Overload safety:
•
Shear pin

•SEMI-automatic
(semi-automatic with spiral spring)

•hydraulical decentralised

•hydraulical central


Model overview / Technical data
Cayros
BAG0172.7 02.20
17
Equipment versions for mounted reversible plough
Additional equipment:
•Disc coulter: For clean furrow clearing
•Landside coulter: More inexpensive version instead of the disc
coulter; mounted on the plough head
•Fertiliser skimmer: Universal use, from ploughing up grassland
to maize straw
Can be mounted on each element
•Skimmer: Used especially for shallow work when ploughing up
grassland
Mounted like the fertiliser skimmer
•Special skimmer: For optimal work with extreme harvest
residues, with large underbeam clearance
Mounted like the fertiliser skimmer
•Skimmer guide plate: To incorporate the fertiliser
Mounted on the plough body
•Deflector plate: Enables crop residues to slide off more easily
•Subsoiler: Mounted on the plough head
•Double support wheel
•Pendulum support wheel rear
•Transport swing wheel
•Scraper
•Lighting
•Packer extension arm: Can be mounted on the adjustment
slide block for any plough type, the packer is used for clod
breaking or seedbed preparation
•Hydraulic pulling point adjustment: Recommended when the
pulling point is frequently adjusted
•Hydraulic beam pivoting: Recommended for 5-furrow ploughs
and above
•Hydraulic track width adjustment: Recommended when the
track width is frequently adjusted
For the list below, the following applies:
* The specified maximum HP (kW) values correspond to the max.
permissible tractor power.
** Weight excluding additional equipment (weight depends on
beam height and plough body)

Table of Contents
18
Cayros BAG0172.7
02.20
3.2 Technical data
3.2.1 Ploughs with mechanical cutting width adjustment
kW/HP*
Share
Type
Cayros
Interbody
clearance.
(cm)
Cutting width
Underbe
am
clearand
e (cm)
Clear span
(mm)
max. HP
range
(PS)-
Weights (kg) **
2 3 4 5 6
M 850 S 85
32/36/40/44
78 1150 - 1700 88 (120) 675 890 1105 ––
M 950 95
36/40/44/48
78 950 - 1500 88 (120) 575 730 890 ––
M 950 S 95
36/40/44/48
78 1150 - 1700 88 (120) 680 895 1110 ––
M 1020 102
36/40/44/48
78 950 - 1500 88 (120) 580 735 895 ––
M 1020 S 102
36/40/44/48
78 1150 -1700 88 (120) 685 900 ––
XM 850 85
32/36/40/44
78/82 1050 - 1650 103 (140) –860 1005 ––
XM 850 S 85
32/36/40/44
78 1250 - 1850 103 (140) –1025 1225 ––
XM 950 95
36/40/44/48
78/82 1050 - 1650 103 (140) –865 1010 ––
XM 950 S 95
36/40/44/48
78 1250 - 1850 103 (140) –1030 1230 ––
XM 1050 105
36
1)/40/44/48
78/82 1050 - 1650 103 (140) –870 1015 ––
XM 1050 S 105
36/40/44/48
78 1250 - 1850 103 (140) –1035 1235 ––
XMS 850 85
32/36/40/44
78/82 1050 - 1650 147 (200) –975 1150 1345 –
XMS 850 S 85
32/36/40/44
78/82 1250 - 1850 147 (200) –1140 1370 1620 –
XMS 950 95
36/40/44/48
78/82 1050 - 1650 147 (200) –980 1160 1360 –
XMS 950 S 95
36/40/44/48
78/82 1250 - 1850 147 (200) –1145 1380 1635 –
XMS 1050 105
36
1)/40/44/48
78/82 1050 - 1650 147 (200) –985 1170 1375 –
XMS 1050 S 105
36/40/44/48
78/82 1250 - 1850 147 (200) –1150 1390 ––
XS 950 95
36/40/44/48
82/90 1050 - 1850 191 (260) ––1310 15301745
XS 950 S 95
36/40/44/48
82 1250 - 2050 191 (260) ––1565 1845 2115
XS 1050 105
36
1)/40/44/48
82/90 1050 - 1850 191 (260) ––1325 1550 1765
XS 1050 S 105
36/40/44/48
82 1250 - 2050 191 (260) ––1580 1865 2130
XS 1150 115
40/44/48
82/90 1050 - 1850 191 (260) ––1340 1570 –
XS pro 950 95
36/40/44/48
82/90 1050 - 1850 279 (380) ––1360 1590 1818
XS pro 950 S 95
36/40/44/48
82 1250 - 2050 279 (380) ––1615 1905 2185
XS pro 1050 105
36/40/44/48
82/90 1050 - 1850 279 (380) ––1375 1610 1835
XS pro 1050 S 105
36/40/44/48
82 1250 - 2050 279 (380) ––1630 1925 2200
XS pro 1150 115
40/44/48
82/90 1050 - 1850 279 (380) ––1390 1630 –

Model overview / Technical data
Cayros
BAG0172.7 02.20
19
3.2.2 Ploughs with infinitely variable hydraulic cutting width adjustment
kW/PS* Shares
Type
Cayros V
Interbody
clearance.
(cm)
Cutting width
Underbe
am
clearande
(cm)
Clear span
(mm)
max. HP
range (PS)- Weights (kg) **
3456
M 950 V 95 32 - 52 78 950 - 1500 88 (120) 800 975 ––
M 950 VS 95 32 - 52 78 1150 - 1700 88 (120) 965 –––
M 1020 V 102 32 - 52 78 950 - 1500 88 (120) 805 980 ––
M 1020 VS 102 32 - 52 78 1150 - 1700 88 (120) 970 –––
XM 850 V 85 32 - 52 78/82 1050 - 1650 103 [phone] ––
XM 850 VS 85 32 - 52 78 1250 - 1850 103 (140) 1110 1325 ––
XM 950 V 95 32 - 52 78/82 1050 - 1650 103 [phone] ––
XM 950 VS 95 32 - 52 78 1250 - 1850 103 (140) 1115 1330 ––
XM 1050 V 105 32 - 52 78/82 1050 - 1650 103 [phone] ––
XMS 850 V 85 32 - 52 78/82 1050 - 1650 147 [phone] 1515 –
XMS 850 VS 85 32 - 52 78/82 1150 - 1850 147 (200) 1270 1530 1810 –
XMS 950 V 95 32 - 52 78/82 1050 - 1650 147 [phone] 1530 –
XMS 950 VS 95
32 - 52 78/82
1150 - 1850 147 (200) 1280 1540 1825 –
XMS 1050 V 105 32 - 52 78/82 1050 - 1650 147 [phone] 1545 –
XMS 1050 VS 105 32 - 52 78/82 1150 - 1850 147 (200) 1290 1550 ––
XS 950 V 95
32 - 52 82/90
1050 - 1850 191 (260) –1380 1650 1905
XS 950 VS 95
32 - 52 78/82
1150 - 2050 191 (260) –1635 1980 2325
XS 1050 V 105
32 - 52 82/90
1050 - 1850 191 (260) –1390 1665 1925
XS 1050 VS 105
32 - 52 78/82
1150 - 2050 191 (260) –1645 1995 –
XS 1150 V 115 32 - 55 82/90 1050 - 1850 191 (260) –1400 1680 –
XS pro 950 V 95
32 - 52 82/90
1050 - 1850 279 (380) –1740 1940 2190
XS pro 950 VS 95
32 - 52 78/82
1150 - 2050 279 (380) –1890 2295 2695
XS pro 1050 V 105
32 - 52 82/90
1050 - 1850 279 (380) –1755 1960 2215
XS pro 1050 VS 105
32 - 52 78/82
1150 - 2050 279 (380) –1905 2315 –
XS pro 1150 V 115 32 - 55 82/90 1050 - 1850 279 (380) –1770 1980 –

Table of Contents
20
Cayros BAG0172.7
02.20
4 Preparations on the tractor and plough
4.1 Calculating the actual values for the total tractor weight, tractor axle
loads and load capacities, as well as the minimum ballast
The approved total tractor weight specified in the vehicle
documentation must be greater than the sum of the
• empty tractor weight
• ballast weight and
• machine's total weight when attached or supported weight when
hitched.
This note only applies to Germany:
If, having tried all possible alternatives, it is not possible to comply
with the axle loads and/or the approved total weight, then a survey by
an officially recognised motor traffic expert can, with the approval of
the tractor manufacturer, be used as a basis for the responsible
authority to issue an exceptional approval according to § 70 of the
German Regulations Authorising the Use of Vehicles for Road Traffic
and the required approval according to § 29, paragraph 3 of the
German Road Traffic Regulations.
