Amazone Cirrus-Control Reference guide

MG832 DB2022-1 GB 03.03
Brief instruction on board computer
Cirrus-Control
for packer coulter sowing combinations Cirrus 8000 and Cirrus 9000
Keypad layout
Automatic at the headlands*
Beginning
of the field
- Blower fan on
- Star wheel downwards
- Track marker downwards
- Track marker downwards
(for automatic operation)
- Implement downwards.
End of
the field
- Star wheel upwards
- Track marker upwards
- Track marker upwards
- Implement upwards until pre-set limit
- Blower fan off.
Track marker and tramline automatic
Change between track marker automatic and
manual operation
F
Automatic operation
Changing of track marker and shifting on
tramline counter when pressing
keys or .
Manual operation
Manual actuation of track. Tramlines cannot
be shifted on.
F
Automatic operation
The "+" sign appears in the display as long as all
functions have been completed. During this time
no other key may be pressed.
Track marker left hand side
upwards
Track marker right hand side
upwards
Track marker left hand side
downwards
Track marker right hand side
downwards
F
Automatic operation
Prior to operation once pre select track
marker by pressing key.
Display:
= Track marker in operating position
= Track marker which will be started to
operate at the next beginning of the field.
F
Manual operation*
By pressing the keys bring track marker in
operatiing and transport position.
Star wheel
upwards
Star wheel
downwards
Track marker
upwards
Track marker
downwards
Implement
upwards
Implement
downwards
Disc elements shallower or levelling tines
shallower (depending on execution)
Disc element deeper orlevelling tines deeper
(depending on execution)
Reduce harrow pressure Increase harrow pressure
Seed placement shallower Seed placement deeper
Seed rate
- increase in 10%-steps (+10%)
- move to set value (100%)
- reduce in 10%-steps (-10%).
*Faster than 2 km/h operational speed (Diode "operation" lights up) briefly press keys.
Slower than 2 km/h operational speed press keys until the function(s) has(have been) executed

AMAZONEN-Werke
H. Dreyer GmbH & Co. KG
e-mail: [e-mail] http://www.amazone.de
Calibrating,
without starting a new job
Folding implement in and out
Press key T1 to select „Menu“.
Press key and . [Fig. 1] appears.
With the stopped machine press key T1 to select “Choice”
Press key until [Fig. 7] appears.
Job Menu T1 Menu T1
Seed rate K/m2 T2 Folding Folding in T2
Desired value: T3 Folding out T3
150,0 kg/ha Proceed T4 Proceed T4
Fig. 1 Fig. 7
Enter desired value, e.g.: 150,0 kg/ha. Press key
Press keys and .
Implement Menu T1
Gearbox- T2
Press key until machine is entirely lifted.
Press key = fold down implement or
Press key = fold in implement.
position: Calibr. T3
50 Proceed T4 Setting the seed placement depth
Fig. 2
Enter any wanted gearbox setting value, e.g.: 50.
Press key and .
Implement Menu T1
Calibration T2
1/40 ha Calibr. T3
34,120 Proceed T4
Fig. 3
Fig. 8
Press key to calibrate
Calibration return T1
T2
T3
calibrate 1/40 ha, weigh,
Enter weight (kg),
Press “Enter” T4
Fig. 4
For grain calibrate at least until the signal sounds
(1/40ha). For fine seeds (e.g. rape) calibrate until in line 2
the value 0,1ha (1/10ha) is shown.
Calibration T1
0,0250 ha T2
12,365 kg T3
Lift packer coulters by pressing key and reset depth
limiting pin (Fig. 8/2) in the setting segment.
The deeper the depth setting pins are set and the higher
the figures on the contact space towards the stops (Fig.
8/1) are the deeper the placement depth of the seed will
get.
Never forget to secure the depth setting pins with clip
pins.
After setting, briefly start the implement and press key
until the stop rests on the depth setting pin.
13,0 kg proceed T4
Fig. 5
Weigh collected seed (e.g.13,0 kg) and enter.
Press key and .
Implement Menu T1
Calibration T2
1/40 ha Calibr. T3
0 kg Proceed T4
Fig. 6
The gearbox setting lever moves to the calculated scale
position. Recheck by pressing key and repeat the
calibration test from Fig. 3 until the displayed seed rate,
e.g. 12,365 kg (see Fig. 5, line 3) coincides with the
weighed seed rate.
After coincidence press key and
