Anderson RB600 Troubleshooting guide

This Quick start up guide does not replace in any way or form the
user manual of this unit.The intension of this document is for use
when setting up the machine after delivery to the dealer and before
the machine is transferred to the end user.This document should
be used as achecklist and memory aid for employees already
familiar with the guidelines in the user manual.Failure to operate
the product correctly can result in damage to the product, personal
property, and cause serious injury.This guide should not be
transferred to the owner of the machine.
QUICK START UP
RB600

After receiving your machine you will want to set it up to be ready for any demo
opportunity or sale that may come along.Besides that, you want to be sure that the
machine is in factory condition, free of damage from transport and defective parts due
to the transport from our factory to your dealership.This is aquick guide that will help
you to be up and ready in ashort time.Before using the machine you must grease and
oil all points on the wrapper that require it.
Basics:
Round bale wrapper
•4 or 5ft bale
•1 stretcher (30’’)
•Computer & remote
•Mechanical plastic cut and hold
Note: Before pressure washing the machine be sure to remove the computer
QUICK START GUIDE
RB600
1
2
3
5
6
7
8
9
10
6
4

QUICK START GUIDE
RB600
When the machine is to be delivered to the user there are steps you must follow to be sure they are
comfortable with wrapping their first bale. These steps are also important if you are doing a live demo.
Setup is very important to bale size as this machine is not set to a specific bale at the factory.
1) Know your bale size before you start. Asking can help but an actual measurement of
the bale is sometimes necessary.
2) Be sure that everything is greased (if left for more than 3 months outside without use
the machine needs to be fully greased and oiled.
3) Your remote control is charged and tested operational (see user manual on machine for
functions).
The stretcher pole has 3 positions. Be sure that the position is
not over the height of the bale or under it. (This part is normally
removed for shipping so be sure to install it correctly to wrap
your bales)
Set the cone rollers for 4 or 5 foot
long bale.
Put plastic in the
stretcher. There is only
one way to put the plastic
through. See the diagram
to the left. This is a
sticker found on the
machine as well.

Turn on the computer.
1) Pull the emergency stop button (1), the blue
light (2) will come on.
2) Press the power button on the remote (3),
when the screen is ON push the power button
(3) again
3) Make sure the M.C. LED light (4) on the
receiver’s control panel is ON.
QUICK START GUIDE
RB600
Hook the machine up to atractor to test it.
Attach the machine’s hoses to the tractor as
shown.Be sure that your tractor is adjusted
at aflow rate of 8GPM at 2000 PSI.
Or, if equipped with aHonda power unit,
make sure it is full of gas and oil.
Starting and Aligning the wrapper
1) If equipped with an Honda engine, put the
ignition key in the ON position and press the
start engine button on the remote.
2) Before wrapping you need to align the
wrapper, press the alignment key (5) on the
remote control.
3) When the alignment menu appears on the
remote control screen, press the same key (5)
asecond time, the alignment will start and the
screen should display Alignment in progress (it
can take up to 2minutes).
Receiver
Remote
Emergency control box
1
2
3
4
5
Start Wrapping
1) Make sure the blue button’s light (2) is on,
which means that the alignment is finished.
2) Push the wrap key (6), the wrapper’s table will
make the set number of rotation and
unloading will happen automatically, and will
engage the plastic cutter.
3) If the remote is not charged or missing you can
wrap automatically by pressing the blue
button (2).
6

QUICK START GUIDE
RB600
The RB500 is equipped with amechanical cut and hold system.The mechanical cut and
hold works on arack and pinion system that stretches alarge spring as the table turns.
The trigger for the release of the system is under the table and is activated as the table
dumps.If the plastic isn’t cut or not completely cut you want to make sure the blade is
sharp and free of rust first.Then you can check if the trigger hits the plate at the right
time and adjust it if need be.
Activated too early Activated at the right time
Fine tuning adjustment
Basic adjustment
Activation plate
