Step 7
Felix 2 Drawer Bedstead
If you need help or have damaged or missing parts, call the Customer Helpline: 01992 450333
Assembly Instructions - Please keep for future reference
Important - Please read these instructions fully before starting assembly
Dimensions Double
Issue 1 - 24.04.12
Width x Depth x Height
145cm x 228cm x 92cm
Dimensions King
Width x Depth x Height
160cm x 235cm x 92cm
Dimensions Super King
Width x Depth x Height
189cm x 235cm x 92cm
697/1236
697/1195
697/1205
697/1243
697/1212
697/1250
Safety and Care Advice
Important–Please read these instructions fullybefore starting assembly
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals away
from the work area, small parts if
swallowed could cause choking.
• Make sure you have enough
space to layout the parts before
starting.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Assembly requires 2 people.
• Do not fully tighten bolts until
the whole bed is assembled.
• Do not overtighten the nuts to
avoid causing damage to the
threads.
• We do not
recommend the
use of power
drill/drivers for
inserting bolts,
and screws as this could damage
the unit. Only use hand screw-
drivers and Allen keys.
• Dispose of all packaging
carefully and responsibly.
.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
stunrostlobesooloneraereht
. .tinusihtno
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
1
Components If you have damaged or missing components,
call the Customer Helpline: 01992 450333
2
1 Right side rail
2 Left side rail 3 Headboard
4 Footboard
Please check you have all the parts listed below
5 Center Support Bar
8Slats
x 26 (double)
x 28 (king/super king)
106 Support Legs x 2 7 Support Legs x 4 End slat caps
13 Metal drawer support x 2
Central slat caps
9
Feet x 4
12
11 Castor x 10
14 Drawer side panel x 4
18 Drawer outer front x 2
15 Drawer back panel x 2
16 Drawer bottom panel x 2
17 Drawer inner front x 2
x 26 (double)
x 28 (king/super king)
x 13 (double)
x 14 (king/super king)
Components - Fittings
3
Please check you have all the fittings listed below
Tools required
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
A
Ø5/16 25mm Bolt x 8
M3 35mm Wood screw x 44
5mm Allen key x 1 (supplied) 4mm Allen key x 1 (supplied)
B
Ø5/16 45mm Bolt x 6
C
D
M4 45mm Wood Screw x 8
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Phillips screwdriver
G
Ø1/4 15mm Bolt x 8
M4 25mm Screw x 16
E
M3.5 10mm Wood Screw x 40
F
Assembly Instructions
4
Step 1
Step 2
Attaching feet
a: Attach 2 x wooden feet
to the underside of
the headboard using
screws as shown.
12
3
C
6
B
Repeat on the underside
of the footboard .
b: Align the long support
leg x 2
Please note: The long
support leg has a
plastic foot adjuster
which is used to adjust
the height of the long
support leg.
with the
pre-drilled holes on the
centre rail . Insert
screw and tighten
using allen key.
12
4
3
4
C
12
6
5
6
6
5
C
B
B
Assembly Instructions
5
Step 3
Attaching side rails
a: Loosely fit bolts (A) to
headboard before
hooking the side rails
and
b: Securely tighten bolts
Do not over tighten.
2
Repeat this step for
footboard
(A) once side rails
and have been
attached.
1
4
2
1
3
2
A
A
3
A
A
A
A
3
4
3
4
1
2
1
2
A
A
Assembly Instructions
Step 4
a: Align the long support
legs
pre-drilled holes on the
centre rail . Insert
bolt and tighten
using allen key.
B
Step 5
a: Insert 1/4 x 15mm
screw into each side rail.
bracket and clamp using
M4 allen key.
7
7
13
7
13
B
B
x 2 with the
13
1
1
G
G
6
2
Assembly Instructions
Step 6
7
a: Insert the local centre
rail in brackets on
headboard and
footboard.
Step 7
a: Insert slat into
b: Insert single plastic
cap onto ends of slat
Repeat for all 14 pairs
of slat.
Attaching Slats
both sides of double
plastic cap .
9
8
5
3
10
8
8
4
1
3
5
2
5
3
8
8
9
9
8
10
10
L BRACKET
BRACKET
Assembly Instructions
Step 8
8
15
17
18
16
11
11
16
14
17
c:
D
F
F
16
b:
D
D
D
18
E
E
15
14
14
17
a:
D
E
D
D
D
D
d: Align outer front
panel to inner front
panel and secure
using screw .
a: Align side panel
to back panel and
front panel . Secure
using screw .
b: Align bottom panel
and secure using screw
Repeat steps to assemble
second drawer.
c: Attach 5 x castor
to drawer’s bottom panel
using screw .
d:
Assembly Instructions
Step 9
Repeat to fit each drawer.
Assembly is now complete.
IMPORTANT:Now with the
bed in its final position
please check and fully
tighten all fixings and bolts.
9
