Arris Ruckus Q410 User manual

Ruckus Q410 LTE
Access Point
Quick Setup Guide
Introduction
This Quick Setup Guide provides step-by-step instructions
on how to set up your Ruckus Q410 LTE Access Point
(Q410). After completing the steps described in this
guide, you will be able to place Q410 at your site and
provide LTE wireless network access to users.
Before You Begin
Before deploying Ruckus Wireless products, please check
for the latest information and release documentation at
http://support.ruckuswireless.com/documents
Software License and Limited Warranty are available at
http://support.ruckuswireless.com/warranty
Package Contents
A complete Q410 eld installation package includes all of
the items listed below (see Figure 1 for illustrations):
•Q410 (A)
•M3 Shoulder Screw (B)
•Q410 Bracket (C)
•Locking Tab (D)
•R510 Band (E)
•R610 Band (F)
•R720 Band (G)
•M3 Flat Head Screw (H)
•Unit Removal Pin (J)
•Drywall Anchors (K)
•No 8. screws (L)
•Ethernet CAT 5 RJ-45 cable
•Ruckus End User Agreement/Limited Warranty
Statement
•Regulatory Statement
•This Quick Setup Guide
FIGURE 1 Q410 and associated hardware
Mounting Instructions
Q410 can be mounted to a ceiling tile T-bar, to a at
surface, to a pole using cable ties, or to a Junction box.
Mounting Q410 AP to a T-bar
Perform the following steps to mount Q410 to a ceiling
tile T-bar.
1. Attach the two shoulder screws (B in Figure 1)
provided using a 2 mm hex wrench or bit to Q410 (A
in Figure 1). It is recommended to tighten the screws
to 7 in-lbs (see Figure 2).
FIGURE 2 Attaching the shoulder screws (B)
2. Insert two locking tabs (D in Figure 1) into the two
channels on Q410 Bracket (C in Figure 1) as shown in
Figure 3. The two tabs should line up with position 2.
FIGURE 3 Align the arrow on the tab with the position
printed depending on the AP being linked
3. Position the larger hole of the keyhole on Q410
bracket through shoulder screws on Q410, then slide
the bracket away from the Ethernet ports until the
screws are in narrow parts of the keyholes (see Figure
4). Q410 locks in place on the bracket.
Copyright © 2018 ARRIS Enterprises LLC. All rights reserved. Page 1 of 4
Published December 2018, Part Number 800-71629-001 Rev D

FIGURE 4 Attaching the bracket to Q410
4. Clip Q410 and bracket assembly onto the T-bar. Slide
the last locking tab in so that it locks in place around
the T-bar into position 2 (see Figure 5).
FIGURE 5 Attaching the bracket to the T-bar
Aligning Q410 to R510, R610, or R720
Perform the following steps to align Q410 to R510, R610,
or R720.
1. Attach two tabs as shown in Figure 3. The two tabs
should lock in position 1 for R610 and R720 or
position 2 for R510.
2. Attach the bracket to Q410 (see Figure 4).
3. Attach the corresponding band (E, F, or G in Figure 1)
to Q410 using two M3 at head screws (H in Figure 1)
(see Figure 6). It is recommended to tighten the
screws to 7 in-lbs.
4. Clip Q410, band, and bracket assembly onto the T-
bar. Slide the locking tab so that it locks in place
around the T-bar in position 1 for the R610 and R720
or position 2 for the R510 (see Figure 5).
5. Install R510, R610, or R720 to the T-bar as per their
respective installation instructions.
6. Slide Q410 and the other unit together until the band
contacts the face on both sides (see Figure 6).
FIGURE 6 Aligning Q410 to other APs
Mounting Q410 to a Flat Surface
Perform the following steps to mount Q410 to a at
surface.
1. If you are mounting Q410 on a at surface, then you
will also need an electric drill with a 4.75 mm (3/16")
drill bit, and the four No. 8 zinc plated drywall screws
(L in Figure 1) and plastic wall anchors (K in Figure 1)
included with the kit.
2. Remove the three tabs (D in Figure 1) and set them
aside or store them in the original box.
3. Use the secure mounting bracket as a template to
mark the locations for four drill holes on the
mounting surface. There are four screw holes
available on the secure mounting bracket.
4. Line up the bracket and attach to surface with the
drywall screws provided. Make sure the bracket is
oriented as shown in Figure 7.
FIGURE 7 Mounting the bracket to a surface
5. Attach the two shoulder screws (B in Figure 1)
provided using a 2 mm hex wrench or bit to Q410 (A
in Figure 1) as shown in Figure 2. It is recommended
to tighten the screws to 7 in-lbs.
6. Line up the screws with keyholes and slide Q410
away from the LED Indicators. Q410 locks in place on
the bracket (see Figure 8)
FIGURE 8 Attaching Q410 to the Bracket
Mounting Q410 to a Pole using Cable Ties
Perform the following steps to mount Q410 to a Pole
using Cable Ties.
If you are mounting Q410 on a pipe or pole, then feed
two customer-provided cable ties through the slots
on the secure mounting bracket (see Figure 9).
Copyright © 2018 ARRIS Enterprises LLC. All rights reserved. Page 2 of 4
Published December 2018, Part Number 800-71629-001 Rev D

FIGURE 9 Mounting slots for mounting the bracket to a
pole or pipe
Mounting Q410 to a Junction Box
Perform the following steps to mount Q410 to a Junction
Box.
1. If you are mounting to a junction box, insert two
customer-provided screws through the slots (see
Figure 10) and secure the bracket to the junction box.
FIGURE 10 Attaching the bracket to a junction box
2. Attach Q410 as shown in Figure 8.
Removing Bracket from a T-Bar
Perform the following steps to remove bracket from a T-
Bar.
1. Move the ceiling tiles out of the way.
2. Lift the lever arm of the locking tab and slide the tab
away from the T-bar to release Q410 bracket
assembly from the T-bar (refer Figure 11).
FIGURE 11 Removing the bracket from the T-bar
Q410 and bracket assembly comes away from the T-
bar.
Removing Q410 from the Bracket
Perform the following step to remove Q410 from the
bracket.
Insert the unit removal pin (J in Figure 1) into the hole
on the side of the bracket (see Figure 12) to unlock
the mounting bracket from Q410 enclosure, then
slide Q410 toward the LED Indicator lights and then
pull Q410 away until it detaches from the bracket.
FIGURE 12 Removing the bracket from Q410
Making the Connections
Be sure to use a Cat 5e or better Ethernet cable with non-
booted connectors (see Figure 13). If using PoE+, attach
one end of the Ethernet cable to an 802.3at Type 2-
certied switch or PoE+ injector (sold separately). Attach
the other end of the Ethernet cable to the PoE+ IN port
on Q410 as shown in Figure 14. If using an AC/DC
adapter, connect it to the 48V DC power port in Figure 14
and to an electrical outlet.
If connecting to other APs, connect the enclosed short
Ethernet CAT 5 RJ-45 cable from the PoE OUT port of
Q410 to the PoE in port of the other AP.
NOTE: PoE OUT complies with IEEE 802.3af Power-
over-Ethernet standard. For best performance, it is
recommended to have a separate power source and
PoE cable for Wi-Fi APs with power requirements that
exceed this standard.
Copyright © 2018 ARRIS Enterprises LLC. All rights reserved. Page 3 of 4
Published December 2018, Part Number 800-71629-001 Rev D

NOTE: Alternative/Optional power sources, PoE+ and
AC/DC adapter, can be ordered separately from
Ruckus. The details are as follows:
1. PoE+: P/N 902-0180-US00
(It includes KIT, SPARE, Integrated Power over
Ethernet (PoE) Injector (10/100/1000 Mbps), w/US
Power Cord, 1 Unit)
2. AC/DC adapter: P/N 902-1170-US00
(It includes KIT, SPARE, Modular AC/DC Power
adapter, 48V - 36W, w/US Power Cord, 1 Unit)
FIGURE 13 Non-booted Ethernet Connector
FIGURE 14 Port Locations
Checking the LED Lights
LED lights verify the installation of APs. Once connected,
the AP will power on and automatically connect to the
Ruckus Cloud over the Internet to congure itself. You will
see some activity and after 5-10 minutes all lights should
turn solid Green or solid Amber (LTE LED).
If any light is o or ashing, see the following table to
help you troubleshoot an issue:
Light Troubleshooting Action
PWR Check Power, Ethernet connections and PoE
(802.3at Type-2 (PoE+) Certied) switch.
EMS Check Internet connection and network/
rewall settings.
EPC Check Internet connection and network/
rewall settings.
SYNC Ensure at least one AP in the network is
near an unobstructed window for a good
GPS signal.
LTE For additional guidance, use the Ruckus
cloud or contact Customer Care.
For More Information
The AP is now operational and can be further managed
by the Ruckus Cloud service. For more information, refer
to the appropriate Ruckus Wireless Cloud documentation
or visit http://support.ruckuswireless.com
© 2018 ARRIS Enterprises LLC. All rights reserved.
ARRIS, the ARRIS logo, Ruckus, Ruckus Wireless, the Ruckus logo, and
the Big Dog design are trademarks of ARRIS International plc and/or
its aliates. All other trademarks are the property of their respective
owners.
Copyright © 2018 ARRIS Enterprises LLC. All rights reserved. Page 4 of 4
