Aseptico AEU-25 Manual

Endo
DTC
DIGITAL TORQUE CONTROL
DUAL VOLTAGE
TM
OPERATION and MAINTENANCE
INSTRUCTION MANUAL
AEU-25 Electronic Endodontic System

TABLE OF CONTENTS:
Introduction . . . . . . . . . . . . . . . . . . . . . . . . .1
Package Contents . . . . . . . . . . . . . . . . . . . .1
Setting Up the Unit . . . . . . . . . . . . . . . . . . .2
Quick Start Operation . . . . . . . . . . . . . . . . .4
Advanced Operation & unctions . . . . . . . .6
HANDPIECE RATIO SELECTOR . . . . . . . .6
SPEED (RPM) SELECTOR . . . . . . . . . . . .6
TORQUE SELECTOR . . . . . . . . . . . . . . . . .6
ORWARD/REVERSE SELECTOR . . . . . .6
MAXIMUM TORQUE BUTTON . . . . . . . . . .6
CALIBRATION AND SYSTEM SETUP . . . .7
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
System Setup Menu
PRESET MEMORY LOCK . . . . . . . . . . . . .7
RECALL ACTORY SETUP . . . . . . . . . . . .7
AUTO STOP REVERSE . . . . . . . . . . . . . . .7
REVERSE BEEPER . . . . . . . . . . . . . . . . . .8
TORQUE WARNING TONE . . . . . . . . . . . .8
ACCESSORY WARNING TONE . . . . . . . . .8
SLEEP MODE . . . . . . . . . . . . . . . . . . . . . .8
Intro to Programming Preset Buttons . . . . .9
Sterilization & Maintenance . . . . . . . . . . . .14
Troubleshooting . . . . . . . . . . . . . . . . . . . . .16
Warranty . . . . . . . . . . . . . . . . . . .Back Cover
Console Size: 3.5” x 5” x 7”
(9 cm x 13 cm x 18 cm)
Console Weight: 3.55 lbs (1.6 kg)
Power Source: Dual Voltage
115V or 230V AC
Power Consumption
Maximum: 100 W (approx.)
Sleep Mode: 6 W
SPECIFICATIONS:
To prevent injury to people and damage to
property, please heed relevant warnings and
remarks. They are marked as follows:
WARNING: Serious injury or death may
result if ignored.
CAUTION: Damage to property or the
environment may result if
ignored.
NOTE: Important additional
information and hints.
MEDICAL ELECTRICAL EQUIPMENT
WITH RESPECT TO ELECTRIC
SHOCK, IRE AND MECHANICAL
HAZARDS ONLY IN ACCORDANCE
WITH UL 2601-1 and CAN/CSA C22.2
No. 601.1
41EJ
P.O. Box 1548
Woodinville, WA 98072
[phone] • [phone]
www.aseptico.com • [email protected]

1
Your new Aseptico Endo DTC®is one of the most advanced
units available to the dental profession. This system features
advanced digital torque control technology with auto-stop
reverse to help prevent file breakage in the canal, five
programmable memory buttons with an onboard file library, an
integrated calibration system, and the versatility of an
autoclavable 30,000 RPM brushless micro motor. These
features combine to make the perfect rotary file system for
endodontic and other dental procedures.
Congratulations!
This system is engineered to provide many years of reliable
service. Please read the instructions provided in this manual to
receive the best and longest service from your Aseptico
equipment.
Separate manuals may be provided to cover the operation and
maintenance of handpieces or other accessories for your unit.
PACKAGE CONTENTS
Electronic Control Console
Remote Power Cord
AE-4B-30 Autoclavable 30K Brushless Micro Motor
Autoclavable Motor Holder
AE-7P oot Switch (971-S)

SETTING UP THE UNIT:
1. Unpack the console and check
that the Voltage Selector is set
to the proper voltage. Use 115v
for 110-120v 60Hz voltages, and
the 230v for 220-250v 50Hz
voltages. To change the Voltage
Selector, see page 15.
2. Attach the power cord to
the back of the Console and plug
into a grounded electrical outlet.
3. Connect the AE-4B-30 motor to
the receptacle on the lower front
panel of the console.
4. Attach the “E” Type handpiece to
the motor. See igure 2.
5. Attach the supplied AE-7P On/Off
oot Switch to the connector on
the back of the unit marked “ oot
Switch”.
2
POWER
CORD
CONSOLE
MOTOR
OOT SWITCH
“E” TYPE
HANDPIECE
MOTOR
MOTOR HOLDER
Do not attempt to operate the Endo DTC®
while configured in the 115V mode with a
230V power source. This could damage
the electrical components and will void
the warranty.
CAUTION
Figure 1
Figure 2

3
CONSOLE LCD DISPLAY
MOTOR RECEPTACLE
USE/VOLTAGE
SELECTOR PANEL
POWER SWITCH
POWER CORD
RECEPTACLE
OOT SWITCH
RECEPTACLE
Figure 3 - Console Front
Figure 4 - Console Back
Handpiece Ratio
Selector
Speed Selector
Calibration/
System Setup:
• PRESET MEMORY LOCK
• RECALL ACTORY SETUP
• AUTO STOP REVERSE
• REVERSE BEEPER
• TORQUE WARNING TONE
• ACCESSORY WARNING TONE
• SLEEP MODE
Preset Buttons
Torque Selector
Forward/Reverse
Maximum Torque
Selector
* See page 6 for ADVANCED OPERATION AND FUNCTIONS

4
QUICK START OPERATION
After the unit has been set up, you are ready
for quick start operation as follows:
1. Turn the Power Switch on the rear panel of
the console from the 'O ' (0) to the
'ON' ( –) position.
The Console LCD Display will light and the
Startup Screen (shown below) will be
displayed for a few seconds. The Startup
Screen displays the software version
onboard your Endo DTC®.
ASEPTICO AEU-25
Software Rev. ASP05
2. Insert an endodontic rotary file into the
handpiece.
3. Use the Calibration function to calibrate the
Endo DTC®. See Caution at right.
Press and release the “CAL” button. The
unit will run for a few seconds, measuring
the handpiece for an accurate display of
speed and torque values.
4. Select the Preset Button corresponding to
the endodontic rotary file series you are
using.
By default, the Endo DTC®preset buttons
are set for the file series shown in Chart 1.
Pressing the Preset Button repeatedly will
cycle through the individual files listed
below each series name.
5. Press the foot pedal to activate motor and
begin operation.
When using the optional AE-7D Dual Foot
Control:
The black (right side) pedal controls the
on/off operation of the handpiece (exactly
like the standard AE-7P foot pedal).
The blue (left side) pedal provides a hands-
free way to operate the preset buttons:
• To step to the next individual file of an
entire file series on the active preset
button: Press and release the blue pedal.
• To step to the next preset button: Press
and hold the blue pedal for 1/2 sec. (until
you hear a double beep), then release
the blue pedal.
6. After 20 minutes of inactivity, the Endo
DTC®will go into Sleep Mode to conserve
power. To exit Sleep Mode and resume
operation, press the oot Pedal.

5
Chart 1 - Endo DTC®Default Presets
Preset Button 1 Default ile Series:
DENTSPLY Tulsa Dental Specialties VORTEX®04 Taper iles
ile #1: VORTEX 04, .35 through .50 taper
ile #2: VORTEX 04, .25 and .30 taper
ile #3: VORTEX 04, .15 and .20 taper
Preset Button 2 Default ile Series:
DENTSPLY Tulsa Dental Specialties VORTEX®06 Taper iles
ile #1: VORTEX 06, .35 through .50 taper
ile #2: VORTEX 06, .25 and .30 taper
ile #3: VORTEX 06, .15 and .20 taper
Preset Button 3 Default ile Series:
DENTSPLY Tulsa Dental Specialties GT®Series 20, 30, 40 iles
ile #1: GT Accessory 90, 70, 50, 35/.12 taper
ile #2: GT Yellow 20 Series, .10 and .08 taper
ile #3: GT Yellow 20 Series, .06 and .04 taper
ile #4: GT Blue 30 Series, .10 and .08 taper
ile #5: GT Blue 30 Series, .06 and .04 taper
ile #6: GT Black 40 Series, .10 and .08 taper
ile #7: GT Black 40 Series, .06 and .04 taper
Preset Button 4 Default ile Series:
DENTSPLY Tulsa Dental Specialties ProTaper®Universal iles
ile #1: ProTaper Universal S1 & SX
ile #2: ProTaper Universal S2 & 1
ile #3: ProTaper Universal 2, 3, 4, 5
ile #4: ProTaper Universal Retreatment D1 & D2
ile #5: ProTaper Universal Retreatment D3
Preset Button 5 Default ile Series:
DENTSPLY Tulsa Dental Specialties GT®Series X™(3) iles
ile #1: GT-X 20 Series .04 Taper & .06 Taper
ile #2: GT-X 30 Series .04 Taper & .06 Taper
GT-X 40 Series .04 Taper & .06 Taper
ile #3: GT-X 30 Series .08 Taper
GT-X 40 Series .08 Taper
During Calibration, the
handpiece will operate,
rotating through a
preprogrammed speed
range. Before
calibrating, be sure a
file or bit is secured in
the handpiece with the
collet closed.
CAUTION

6
1. HANDPIECE RATIO SELECTOR:
Sets the Handpiece Ratio Indicator on the
Console LCD Display to read accurately for
different handpiece ratios.
Multiple handpieces with different ratios are
often required to obtain the various speed
ranges used in dental procedures.
The available handpiece ratios and speed &
torque ranges for each are shown in Chart 2
below.
Chart 2 - Ratio, Speed and, Torque
Push the Handpiece Ratio Selector up or down
arrows until the displayed handpiece ratio
matches the handpiece ratio you are using.
Ratio settings are held in memory even after
unit is turned off.
Auto Stop Reverse (ASR) is not available with
Increaser handpieces.
2. SPEED (RPM) SELECTOR:
Controls the speed of the motor and
handpiece.
Push the Speed Up arrow to increase speed
and the Speed Down arrow to decrease speed.
The Speed (RPM) Indicator on the Console
LCD Display shows actual RPM. or display
accuracy, the displayed handpiece ratio must
exactly match the ratio of the handpiece being
used. Speed settings are held in memory even
after unit is turned off.
3. TORQUE SELECTOR:
Allows the user to adjust exact torque limits
in Gram•Centimeter increments. Push the
Torque Selector up/down arrows until the
desired torque level is indicated on the
Console LCD Display. By adjusting the
torque control to reduced limits for each
instrument size and operating the handpiece
at a constant RPM, the risk of instrument
breakage is greatly reduced.
Torque settings are held in memory even
after unit is turned off.
or most endodontic root canal applications,
the included 1/8 reduction contra-angle
handpiece is normally used. Proper contra-
angle maintenance, including cleaning and
lubrication are essential to minimize torque
losses when using the torque reduction
settings.
4. FORWARD/REVERSE SELECTOR
(FWD/REV):
Determines the rotation of the motor and
handpiece. A red LED light above this button
will indicate the reverse rotation during
operation. When the Reverse Beeper (BPR)
feature is active, an audible beeper (and the
red LED light) will indicate the reverse
rotation.
5. MAXIMUM TORQUE BUTTON (MAX):
Press and release to override the Endo DTC®
Torque Control feature.
With MAX Torque acti ated:
The LED above the Max. Torque Button will
display a steady red light, the Torque
Indicator will display "MAX", and the motor
will operate at full torque. When the Max
function is enabled, the Auto Stop Reverse
(ASR) and torque warning tone features are
automatically disabled.
With MAX Torque disabled:
When the motor reaches the programmed
maximum torque level, the LED above the
Max. Torque Button will blink green. This is
the normal setting for endodontic procedures.
ADVANCED OPERATION AND FUNCTIONS
Aseptico Handpiece Speed Torque
Model No. Ratio Range (RPM) Range (g•cm)
AHP-71 5/1 1,500 - 150,000 2-15 (No ASR)
AHP-63 1/1 300 - 30,000 4 - 125
AHP-66 1/4 75 - 7,500 15 - 500
AHP-88/88MP 1/8 40 - 3,750 30 - 1,000
AHP-62/62M 1/16 20 - 1,800 60 - 2,000
AHP-61 1/64 5 - 460 400 - 7,000
Note: Speed and torque ranges are accurate when
handpieces are used with the supplied 30K motor.

7
RECALL FACTORY SETUP
1=no, 2=yes, 3=esc
Recalling the actory Setup allows you to reset
your Endo DTC®to factory specifications.
NOTE: Any customized presets will be lost if
you Recall actory Setup.
• To keep your customized settings, press 1.
• To return the Endo DTC®preset buttons to
the factory settings (as shown in Chart 1 on
page 5), press 2.
•CONFIRM RECALL will appear. Select 2 to
confirm recall or select 1 to reject changes.
• To exit the System Setup Menu and save
changes, press 3.
AUTO STOP REVERSE
1=on, 2=off, 3=esc
When the Auto Stop Reverse (ASR) feature is
enabled, rotation of the handpiece will
automatically stop and reverse when the
selected torque limit is reached. Do not release
the foot pedal when this occurs; keep the foot
pedal activated and the Endo DTC®will
automatically alternate between forward and
reverse rotation in an attempt to free the
instrument.
The Auto Stop Reverse setting is saved when
programming Preset Buttons.
• To enable the Auto Stop Reverse feature,
press 1.
This setting is highly reco ended for
endodontic procedures.
• To disable the Auto Stop Reverse feature,
press 2.
Disabling auto stop reverse is not
reco ended for endodontic procedures, as
file separation may occur.
• To exit the System Setup Menu without
changes, press 3. SAVE CHANGES
selection will appear. Select 1 to save
changes and exit or select 2 to reject all
changes and exit.
6. CALIBRATION AND
SYSTEM SETUP BUTTON:
Calibration (CAL):
Press and release the "CAL" button to activate
the Integrated Calibration System. The AEU-25
will automatically run the handpiece and
system through a self test.
Use the Calibration function in the following
circumstances:
• At the beginning of each day
• After changing handpieces
(especially when changing handpiece type)
• After changing files or burs (optional)
System Setup Menu:
Press and hold the "CAL" button until you hear
a double beep to enter the System Setup Menu.
After entering the System Setup Menu, the
following setup options will be displayed on the
Console LCD Display.
PRESET MEMORY LOC
1=on, 2=off, 3=esc
By default, the Preset Memory Lock is activated
to prevent the user from inadvertently entering
the ile Library during a procedure.
To customize the Preset Buttons with other ile
Library Settings or User Defined Presets, the
Preset Memory Lock must be disabled.
To protect any customized presets, re-enable
the Preset Memory Lock after programming the
Preset Buttons.
This is a system-wide setting and is not saved
on a Preset Button when programming.
• To enable the Preset Memory Lock,
press 1.
• To disable the Preset Memory Lock,
press 2.
• To exit the System Setup Menu without
changes, press 3.

8
REVERSE BEEPER
1=on, 2=off, 3=esc
When the Reverse Beeper (BPR) feature is active,
an audible beep will sound when the handpiece is
rotating in the reverse direction. This is a system-
wide setting and is not saved on a Preset Button
when programming.
• To enable the Reverse Beeper feature, press 1.
• To disable the Reverse Beeper feature, press 2.
• To exit the System Setup Menu without changes,
press 3. SAVE CHANGES selection will appear.
Select 1 to save changes and exit or select 2 to
reject all changes and exit.
TORQUE WARNING TONE
1=on, 2=off, 3=esc
When the Torque Warning feature is active, a
chirping warning noise will be audible when the
torque level reaches approximately 75% of the
selected torque limit. This is a system-wide setting
and is not saved on a Preset Button when
programming.
• To enable the Torque Warning Tone,
press 1.
• To disable the Torque Warning Tone,
press 2.
• To exit the System Setup Menu without changes,
press 3. SAVE CHANGES selection will appear.
Select 1 to save changes and exit or select 2 to
reject all changes and exit.
ACCESSORY WARNING TONE
1=off, 2=on, 3=esc
When the Accessory Warning feature is active, a
warning tone will be audible when a GT Accessory
file or ITR Emulation Accessory file is in use. This is
a system-wide setting and is not saved on a Preset
Button when programming.
• To disable the Accessory Warning, press 1.
• To enable the Accessory Warning press 2.
• To exit the System Setup, press 3.
SAVE CHANGES selection will appear.
Select 1 to save changes and exit or select
2 to reject all changes and exit.
SLEEP MODE
1=on, 2=off, 3=esc
After 20 minutes of inactivity, the Endo DTC®
will enter Sleep Mode to conserve power. In
Sleep Mode, the lighted Console LCD display
will turn off and the green LEDs above the
CAL, WD/REV, and MAX buttons will blink
once every second.
To resume normal operation when the Endo
DTC®is in Sleep Mode, press any button on
the console or press the foot control.
This is a system-wide setting and is not saved
on a Preset Button when programming.
• To enable the Sleep Mode, press 1.
• To disable the Sleep Mode, press 2.
• To exit the System Setup, press 3. SAVE
CHANGES selection will appear. Select 1 to
save changes and exit or select 2 to reject
all changes and exit.
7. POWER SWITCH:
Controls power on/off to console. On the
switch, the on position is represented by a
‘1’ and the off position is represented by a
‘0’. When the AEU-25 is turned on and not
in Sleep Mode (see System Setup Menu
page 6), the Console LCD Display will light.
SYSTEM SETUP MENU - CONTINUED:

9
2. If a Single ile was programmed on the
preset button, the words "Single ile
Preset" and the ile Name will be
displayed, as shown in the example
below.
Preset Type
SINGLE FILE PRESET
PROTAPER SX & S1
ile Name
3. If a User Defined Preset was programmed
on the preset button, the words "User
Defined Preset" and the Handpiece Ratio,
Speed in RPM, and Torque in
Gram•Centimeters, will be displayed, as
shown in the example below.
Preset Type
USER DEFINED PRESET
1/8 AG 300 240
Ratio Speed Torque
4. or all programming modes:
When in the Endo DTC®is in operation
(with the foot pedal pressed), the
Operation Screen will be displayed. The
Operation Screen will show the
Handpiece Ratio, Speed (in RPM), Torque
(in Gram•Centimeters), Reverse Beeper
(if enabled), and Auto Stop Reverse (if
enabled).
Ratio Speed Torque
1/8 AG 300 240
BPR ASR RPM g-cm
{Reverse Beeper} {Auto Stop Reverse}
By default, the Preset Buttons are programmed
to recall the file series shown in Chart 1 on
page 5.
The Preset Buttons are also used to navigate
the various menus in the System Setup and
ile Library.
The Preset Buttons can be customized to suit
individual preferences. There are three ways to
program a preset button.
The Preset Buttons can be programmed with:
1. An Entire ile Series from the ile Library
2. A Single ile from the ile Library
3. A User Defined Preset
When recalling a preset button, three different
displays will appear depending on how the
preset button was programmed:
1. If an Entire ile Series was programmed
on the preset button (as is the case for
the factory default setup), the ile Series
and ile Name will be displayed, as
shown in the example below.
ile Series
GT ACC & 20s YELLOW
GT ACC 90, 70, 50, 35/12
ile Name #1
Pressing the same preset button again will
step to the next file in the file series, as
shown below.
ile Series
GT ACC & 20s YELLOW
GT YEL 20/10 & 20/08
ile Name #2
8. INTRODUCTION TO PROGRAMMING PRESET BUTTONS:

10
7. The display will show:
1/8 AG (AHP-88)
1=next, 2=ok, 3=esc
Press Button #1 repeatedly to cycle
through the available handpiece ratios.
When the displayed handpiece ratio
matches the handpiece ratio you are
using with this ile Series, press Button
#2.
8. The Preset Button is now set with the
selected file series.
For Exa ple 1:
The display will now show:
PROTAPER UNIVERSAL
PROTAPER SX & S1
Pressing the Preset Button repeatedly will
cycle through the individual files in the
selected series.
9. When you have completed the
customization of the desired preset buttons,
re-enable the Preset Memory Lock to avoid
inadvertently entering the ile Library during
a procedure. or instructions, read about
the System Setup Menu beginning
on page 6.
1. Disable the Preset Memory Lock.
or instructions, read about the System
Setup Menu beginning on page 6.
2. Press and hold the desired Preset Button
for 1 second (until you hear a double
beep).
3. The display will show:
ACCESS FILE LIBRARY?
1=yes, 2=no, 3=esc
Press Button #1 to access file library.
4. The display will show:
GT ACC & 20s YELLOW
1=next, 2=ok, 3=esc
Press Button #1 repeatedly until the
desired file series is shown on the
display. See the Chart 3 on page 11 for a
list of available file series.
Exa ple 1:
To go to the Protaper®Universal series,
press preset button #1 three times.
The display will then show:
PROTAPER UNIVERSAL
1=next, 2=ok, 3=esc
5. Press Button #2 to select the displayed
file series.
6. The display will show:
LOAD ENTIRE SERIES?
1=yes, 2=no, 3=esc
Press Button #1 to load the entire series.
9. PROGRAMMING A PRESET BUTTON WITH AN ENTIRE FILE SERIES:

11
Chart 3 - Endo DTC®File Library Settings
GT®Acc. & 20 Series YELLOW ile Size Speed (RPM) Torque (g-cm) GT ACC 90, 70, 50, 35/12 500 700 GT YEL 20/10 & 20/08 300 312 GT YEL 20/06 & 20/04 300 174
GT®Acc. & 30 Series BLUE ile Size Speed (RPM) Torque (g-cm) GT ACC 90, 70, 50, 35/12 500 700 GT BLU 30/10 & 30/08 300 347 GT BLU 30/06 & 30/04 300 208
GT®Acc. & 40 Series BLAC ile Size Speed (RPM) Torque (g-cm) GT ACC 90, 70, 50, 35/12 500 700 GT BLK 40/10 & 40/08 300 405 GT BLK 40/06 & 40/04 300 230
PROTAPER®UNIVERSAL ile Size Speed (RPM) Torque (g-cm) PROTAPER S1 & SX 300 520 PROTAPER S2 & 1 300 150 PROTAPER 2, 3, 4, 5 300 312 PROTAPER D1 & D2 500 312 PROTAPER D3 500 150
PROTAPER®UNIVERSAL I ile Size Speed (RPM) Torque (g-cm) PROTAPER S1 & SX 300 520 PROTAPER S2 & 1 300 150 PROTAPER 2, 3, 4, 5 300 312
PROTAPER®RETREAT ile Size Speed (RPM) Torque (g-cm) PROTAPER D1 500 312 PROTAPER D2 500 312 PROTAPER D3 500 150
GT®/PROFILE .04 ile Size Speed (RPM) Torque (g-cm) GT ACC 90, 70, 50, 35/12 500 700 GT 20/10 & GT 20/08 300 312 GT 20/06 & P 35/04 300 132 P 30/04 & P 25/04 300 104 P 20/04 300 75
GT®Series XTM (4) ile Size Speed (RPM) Torque (g-cm) SERIES X 20/04 & 20/06 300 175 SERIES X 30/04 & 30/06 300 210 SERIES X 40/04 & 40/06 300 210 SERIES X 30/08 & 40/08 300 350
GT®Series XTM (3) ile Size Speed (RPM) Torque (g-cm) GT-X 20/04 & 20/06 300 175 GT-X 30&40 /04 & /06 300 210 GT-X 30/08 & 40/08 300 350
VORTEX®04 Taper ile Size Speed (RPM) Torque (g-cm) VORTEX 04/35 Thru 04/50 500 132 VORTEX 04/25 & 04/30 500 104 VORTEX 04/15 & 04/20 500 75
VORTEX®06 Taper ile Size Speed (RPM) Torque (g-cm) VORTEX 06/35 Thru 06/50 500 368 VORTEX 06/25 & 06/30 500 290 VORTEX 06/15 & 06/20 500 195
GT®Series 20, 30, 40 ile Size Speed (RPM) Torque (g-cm) GT ACC 90, 70, 50, 35/12 500 700 GT YEL 20/10 & 20/08 300 312 GT YEL 20/06 & 20/04 300 174 GT BLU 30/10 & 30/08 300 347 GT BLU 30/06 & 30/04 300 208 GT BLK 40/10 & 40/08 300 405 GT BLK 40/06 & 40/04 300 230
** PROFILE®S29®06 TAPER
ile Size Speed (RPM) Torque (g-cm) P S29 06 SIZE 7 & 6 300 368 P S29 06 SIZE 5 & 4 300 290 P S29 06 SIZE 3 & 2 300 195
PROFILE®S29®04 TAPER ile Size Speed (RPM) Torque (g-cm) P S29 04 SIZE 7 & 6 300 132 P S29 04 SIZE 5 & 4 300 104 P S29 04 SIZE 3 & 2 300 75
**
** S29 represents SERIES 29® *** Lexicon Gates and Pro-Post Drills are not compatible with 1/16
reduction handpieces, which have a maximum speed of 1800 RPM.
***
***
PROFILE®ISO 04 TAPER ile Size Speed (RPM) Torque (g-cm) P ISO 40/04 & 35/04 300 132 P ISO 30/04 & 25/04 300 104 P ISO 20/04 & 15/04 300 75
PROFILE®OS ile Size Speed (RPM) Torque (g-cm) P OS SIZE 6 & 5 300 510 P OS SIZE 4 & 3 300 400 P OS SIZE 2 & 1 300 256
LEXICON®GATESV 1.20 ile Size Speed (RPM) Torque (g-cm) LEXICON GATES #6 3000 1000 LEXICON GATES #5 3000 750 LEXICON GATES #4 3000 700 LEXICON GATES #3 3000 400 LEXICON GATES #2 3000 240 LEXICON GATES #1 3000 150I
ITRTM EMULATION SERIES
ile Size Speed (RPM) Torque (g-cm) ACC 500 1000 MAX 300 625 CORONAL 300 250 MID 300 150 APICAL 300 70
PRO-POST®DRILLS ile Size Speed (RPM) Torque (g-cm) PRO-POST DRILLS 2000 1000
* Before programming presets, disable Preset Memory Lock - found
in System Setup menu. Hold down desired Preset Button until you hear a double beep. After programming presets, re-enable Preset Memory Lock.
PROFILE®ISO 06 TAPER ile Size Speed (RPM) Torque (g-cm) P ISO 40/06 & 35/06 300 368 P ISO 30/06 & 25/06 300 290 P ISO 20/06 & 15/06 300 195

12
Exa ple 2:
To go to the 2, 3, 4, and 5 files in
the Protaper®Universal series, press
Button #1 twice. The display will show the
following:
PROTAPER F2 F3 F4 F5
1=next, 2=ok, 3=esc
8. Press Button #2 to select the displayed files.
9. The display will show:
1/8 AG (AHP-88)
1=next, 2=ok, 3=esc
a. If you are using the 1/8 AG handpiece
with this file series, press Button #2 and
go on to Step 10.
b. If you are using a handpiece other than
the 1/8 AG handpiece, press Button #1
and choose the correct handpiece. or
instructions, refer to i and ii on page 10.
10. The Preset Button is now set with the
selected single file settings.
For Exa ple 2 above:
The display will now show:
SINGLE FILE PRESET
PROTAPER F2 F3 F4 F5
11. When you have completed the
programming of the desired preset buttons,
re-enable the Preset Memory Lock to avoid
inadvertently entering the ile Library
during a procedure. or instructions, read
about the System Setup Menu beginning
on page 6.
1. Disable the Preset Memory Lock.
or instructions, read about the System
Setup Menu beginning on page 6.
2. Press and hold the desired Preset Button for
1 second (until you hear a double beep).
3. The display will show:
ACCESS FILE LIBRARY?
1=yes, 2=no, 3=esc
Press Button #1 to access the ile Library.
4. The display will show:
GT ACC & 20s YELLOW
1=next, 2=ok, 3=esc
Press Button #1 repeatedly until the desired
file series is shown on the display. See
Chart 3 on page 11 for a list of available file
series.
Exa ple 2:
To go to the Protaper®Universal series,
press preset button #1 three times.
The display will then show:
PROTAPER UNIVERSAL
1=next, 2=ok, 3=esc
5. Press Button #2 to select the displayed file
series.
6. The display will show:
LOAD ENTIRE SERIES?
1=yes, 2=no, 3=esc
Press Button #2. Do not load entire series.
7. Press Button #1 repeatedly until the desired
file is shown on the display.
See Chart 3 on page 11 for a list of available
files in each file series.
10. PROGRAMMING A PRESET BUTTON WITH A SINGLE FILE

13
7. The display will show:
ACCESS FILE LIBRARY?
1=yes, 2=no, 3=esc
Press Button #2. Do not access
the file library.
8. The display will show:
SAVE CURRENT SETTINGS?
1=yes, 2=no, 3=esc
Press Button #1 to record settings on the
Preset Button.
9. The display will resemble the following:
(The handpiece ratio, speed and torque
values will vary according to your settings).
USER DEFINED PRESET
1/8 AG 300 240
The Preset Button is now programmed with
the specified settings.
10. When you have completed the
programming of the desired preset buttons,
re-enable the Preset Memory Lock to avoid
inadvertently entering the ile Library
during a procedure. or instructions, read
about the System Setup Menu beginning
on page 6.
1. Disable the Preset Memory Lock and enable
or disable Auto Stop Reverse and torque
warning tone.
or instructions, read about the System
Setup Menu beginning on page 6.
2. Set the Handpiece Ratio to the correct
setting.
Press the Handpiece Ratio Selector up or
down arrows until the Handpiece Ratio
Indicator matches the ratio of the handpiece
to be used.
3. Set the speed to the desired setting.
Press the Speed Selector up/down arrows
until the desired speed is shown on the
display.
4. Set the torque level to the desired setting.
Press the Torque Selector up/down arrows
until the desired torque is shown on the
display.
To operate the motor at full torque, press the
"MAX" Torque Button. The LED above the
"MAX" Torque Button will display a steady
red light, the Torque Indicator on the display
will read "MAX". Operating at max. torque
will override the Auto Stop Reverse feature.
5. Set Handpiece Rotation to the desired
direction.
Press the orward/Reverse Selector to
change the direction of handpiece rotation.
A red L.E.D. light above the
orward/Reverse Selector indicates reverse
rotation.
6. Press and hold the desired Preset Button for
1 second (until you hear a double beep).
11. PROGRAMMING A PRESET BUTTON WITH A USER DEFINED PRESET

14
STERILIZATION:
WARNING - Sterilize the motor
between each patient use.
WARNING - Use of a sterilization
method or temperatures other than what
are prescribed may damage the motor
or present a risk of cross-contamination
between patients.
CAUTION - Do not soak or submerge
the motor in any liquid.
STERILIZATION PROCEDURE:
Pre-clean
1) Thoroughly brush off any visible signs of
debris from the motor and cord.
2) Thoroughly clean the device with a moist
cloth or towel to remove any remaining signs
of debris.
Sterilize
3) Select one of the three following
sterilization methods (A. B. or C.):
Wrapped Sterilization – Place in an
appropriately sized sterilization pouch and
seal it.
A. Gravity Wrapped:
• Minimum Temperature:
132° C (270° )
• Full Cycle Time: 20 minutes
• Minimum Dry time: 30 minutes
B. Prevacuum Wrapped:
• Preconditioning Pulses: 3
• Minimum Temperature:
132° C (270° )
• Full Cycle Time: 4 minutes
• Minimum Dry time: 40 minutes
Flash Sterilization – or immediate use
only.
C. Gravity Unwrapped:
• Minimum Temperature:
132° C (270° )
• Full Cycle Time: 10 minutes
No dry time is required for flash
sterilization.
MOTOR & CORD ASSEMBLY:
• The entire motor and cord assembly is fully
autoclavable. Before autoclaving the
assembly, remove any handpiece from motor
and install autoclaving plugs into the end of
the motor and motor cord connector as
shown below. The plugs are supplied with the
motor and cord.
• Loosely coil the motor cord when auto-
claving. Avoid sharply bending the cord when
autoclaving.
NOTE: Call Aseptico, Inc. at 1-800-426-
5913 for any questions or clarifications on
this sterilization procedure.
• Always install the autoclaving plugs into motor
and motor connector before autoclaving.
• If the autoclaving plug for the motor becomes
difficult to remove or install, apply silicone grease
or similar lubricant to the O-rings.
Turn black connector ring only
HANDPIECES - Thorough cleaning and
lubrication of handpieces after each use and
before sterilization is very important to ensure
proper operation and service life of the
handpiece. ollow the instructions provided with
the handpiece purchased for complete
maintenance instructions.
CONSOLE MAINTENANCE - The exterior of
the console may be cleaned by wiping with a
soft cloth moistened with mild detergent or
disinfecting solution.
MAINTENANCE & CLEANING:
• Do not attempt to disassemble the motor or motor connector.
• Do not oil or lubricate the motor.
• Do not attach a handpiece to the motor while motor is running.
• Do not bend motor cord sharply.
WARNING
ailure to comply with any of the above instructions may
void your warranty

15
CHANGINGTHE FUSE ORVOLTAGE -
1. Use a small flathead screwdriver to open the
use/Voltage Selector Panel on the back of
the unit.
2. Remove the red useholder from the unit.
3a. Changing the fuse:
Replace the blown fuses on either side
of the useholder.
Replacement uses:
115V: 1.0A/250V slo-blo fuse
230V: 0.5A/250V slo-blo fuse
3b. Changing the voltage:
The proper fuses for the country of use are
sent in the unit. When changing voltage,
replace the fuses with fuses that are rated
for the new voltage.
Turn the useholder until the white lettering
with the proper voltage is right side up.
4. Replace the useholder and close the
use/Voltage Selector Panel.
5. Select a power cord or grounded plug
adapter specific to the country of use.
Turn the power off and unplug the
unit before following the steps below.
WARNING
1.
2.
4.
3b.
Do not attempt to operate the Endo DTC®
while configured in the 115V mode with a
230V power source. This could damage
the electrical components and will void
the warranty.
CAUTION
CHANGING THE VOLTAGE
ollow the corresponding steps.

16
Problem:
Console does not light when
turned on:
Console lights when turned on,
but handpiece does not turn:
Improper display:
Motor slowing down or sluggish:
Correction:
If lights are blinking, press a button or foot switch
to exit Sleep Mode.
Check console to power connection.
Check voltage setting.
Check fuse. If blown, replace with 1.0A/250V
slo-blo fuse for 115 volts, & 0.5A/250V slo-blo
fuse for 230 volts.
Check motor plug connection.
Check foot switch connection.
Depress foot switch.
Check that a file is properly seated in the
handpiece and the latch is closed.
Verify that ratio setting matches handpiece ratio.
Use Calibration function.
Turn power switch off, wait 5 seconds, then turn
back on to reset.
Dirty, under-lubricated handpiece.
Handpiece lubricant is running into motor.
After lubricating and before autoclaving, set
handpiece with head down to let excess lubricant
drain out.
Check voltage setting.
TROUBLESHOOTING:

17
NOTES:
WARNING: This device has been tested and found to comply with the
emissions requirements of EN 55011:1991. These requirements
provide reasonable protection against harmful electromagnetic
interference in a typical medical installation. However, high levels of
radio-frequency (R ) emissions from electrical devices, such as cellular
phones, may disrupt the performance of this device. To mitigate
disruptive electromagnetic interference, position this device away from
R transmitters and other sources of electromagnetic energy.
SYMBOL DEFINITIONS:
Type B
Equipment
Dangerous
Voltage
Attention - Consult
Accompanying
Documents
The UL 2601 Standard Duty Cycle for Intermittent Use is 1 min. on / 5 min. off.
Serial Number

P/N: 420308
Rev. J
ECO 14684
Software Rev. ASP05 Series
03/2019
WARRANTY
Aseptico warrants its products against defects in material or workmanship for a period
of two (2) years, from date of original invoice. Some handpieces are warranted for one
year under the same conditions. Other handpieces and expendable components, such
as air turbines and light bulbs, are covered by shorter warranty periods, or have no
warranty. Aseptico's sole obligation under product warranty is (at its sole option and
discretion) to repair or replace any defective component or product in part or whole.
Aseptico shall be the sole arbiter of such action.
In the event of alleged defect under warranty, the purchaser is to notify Aseptico's
Customer Service Department promptly. Customer Service will provide instructions,
usually directing that the product be returned for service. Shipment to Aseptico and the
cost thereof is always the responsibility of the purchaser.
Accidental misuse, inappropriate installation, or failure to perform directed maintenance
voids the warranty. Deliberately defacing, modifying, or removing the serial number
voids the warranty.
Aseptico does not assume, under this warranty, any risks or liabilities arising from the
clinical use of its products, whether or not such use involves coincidental utilization of
products manufactured by others.
P.O. Box 1548
Woodinville, WA 98072
[phone] • [phone]
www.aseptico.com • [email protected]
