Assa Abloy KESO KEK i-handle S Operator's manual

KESO KEK i-handle S
Documentation
1Important Notes 3
2Introduction 4
3Product description 4
4Requirements 6
5Article No. Definition 11
6Overview of fittings 12
7Technical data 14
8Operations 20
9Warning and Status Messages 21
10 Emergency power / emergency opening 23
11 Programming 24
12 Settings 25
13 Programming Home Version 28
14 Installation 29
15 Maintenance information 32
16 Troubleshooting 32
17 Product services 32
Ausgabedatum: 18.02.2011
Version: 018
ASSA ABLOY,
the global leader in
door opening solutions

KESO KEK i-handle S
KESO AG Subject to change without notice Page 3 from 34 pages
1Important Notes
KESO AG accepts no claims under warranty and no liability in cases where unauthorised
modifications, or improper installation in contradiction to our assembly instructions is
performed or brought about.
1.1 Conditions for use
This documentation was written for users with good mechanical and mechatronic
knowledge. The explanations in this manual also assume that you are familiar with using
Windows®. Important note: KESO partners must have completed training for the
products in question.
1.2 Important notes on this documentation
This documentation is part of the KESO KEK i-handle S product. It contains important notices on
commissioning and handling. For this reason, you should familiarise yourself with the content
and, in particular, observe the notes on safe installation, handling and operations. Make sure
that this is complied with when passing on this product to third parties. For this reason, you
should keep this documentation in a safe place for future reference!
This documentation is based on information that was correct at time of printing. KESO AG
accepts no liability for the correctness and completeness of the content of this documentation.
The figures or graphics shown may differ from the supplied components.
We reserve the right to make changes to reflect technical advancements. The
manual is not covered by our "Update Service".
1.3 Waste disposal
Articles listed in this documentation must not be disposed of as normal household
waste. It is the consumer’s responsibility to dispose of the product at a collection point
for recycling of electrical and electronic waste. Separate disposal of this waste helps to
optimise the recycling of all materials suitable for the recycling process, and to reduce health
and environmental risks. For more information on the correct disposal of this product, please
contact your dealer.

KESO KEK i-handle S
KESO AG Subject to change without notice Page 4 from 34 pages
2Introduction
The requirement for security, control and high levels of flexibility has increased considerably.
This applies in particular to doors with many or frequently changing users such as: interior
access doors, archives, senior residences, server rooms etc… An extension of the mechatronic
systems is necessary to fulfill these requirements.
3Product description
The KESO i-handle S (security) door fitting solution is a mechatronic door set for easy
installation in indoor areas. It is compatible with the entire KEK range and requires
corresponding KEK identification media. Doors fitted with
this system can be opened from the outside assuming the
user presents an authorised access medium (keycard, tag or
KEKcombi key). The handle on the outside engages electro-
mechanically. Without authorisation, the external handle
remains disengaged. Doors can be opened from the inside
without access media at all times. The robust and attractive
fitting, including handle, is typically used for rooms with a
high level of trust, such as office and living accommodation
and archives, and mainly with composite doors.
Authorisation is managed using the KESO Management
Software and transferred to the electronics by means of the
KESO KEK Programmer PPG (V2 with KAPI BUS) or KESO KEK
Programmer USB. This provides a variety of options for
configuring access. The door can be programmed to stay
unlocked during office hours, for instance, or for user groups
who are restricted to a specific time slot. The fitting is
available with cylinder perforation and an additional
mechanical or mechatronic cylinder is fitted for emergency
locking. The reader module supports emergency battery
power at any time, even if the batteries are flat.
3.1 Short description/functional description
The KESO KEK i-handle S is a mechatronic door fitting with an integrated reader for interior use.
The KESO i-handle S is independent of lock and cylinder and can thus be fitted to any popular
door type. The electronics and batteries are located in the protected interior space below the
internal shield. The reader unit and the programming and emergency opening interface (KAPI)
are located above the handle on the external shield. The reader module is activated via a sensor
on the external reader unit and the access medium is read. Door release or blocking is indicated
by means of an optical signal and an acoustic signal. After access has been granted, the external
handle is power engaged and the handle can be actuated. The release time for actuating the
handle is set to 5 seconds by default. However, the configurable actuation time is between 5
and 30 seconds.
KESO i-handle S escutcheons and handles are made of stainless steel (Inox).

KESO KEK i-handle S
KESO AG Subject to change without notice Page 5 from 34 pages
3.2 System benefits with KESO KEK i-handle S
•Fast and easy assembly
•Easy retrofitting as independent of lock
•Convenient operations
•Can be combined with mechanical and mechatronic cylinders
•Variable door width, spindle set can be replaced on site with very little effort
•All security-relevant, electronic units are located within the secure interior area
•Compatible with the entire KEK range
•Contactless entry using RFID access devices (keycard, tag, or KEK combi key)
•Extremely service-friendly
•Distinguishes between up to 8,000 access media
•Managed by KESO Management Software
•User-controllable function for keeping door unlocked (office function)
•Person-specific, time-limited access
•Scheduling for public holidays
•Adjustable optical and acoustic signals
•Adjustable timing for the opening signal
•Emergency power supply, emergency opening
•Available in all popular gap sizes and door thicknesses
•Available as blind version or with round cylinder profile, Europrofile and Euro-Swiss profile

KESO KEK i-handle S
KESO AG Subject to change without notice Page 6 from 34 pages
4Requirements
4.1 Hardware/software requirements
Management and programming of authorization by means of KESO Management Software
(KESO K4 Software Version 4.0.40 or newer). Offline authorization transfer KESO KEK
Programmer PPG V2 or KESO KEK Programmer USB.
No special requirements exist for the Home version. Programming of authorization is effected
by means of master/ programmer/ and user keys or cards.
4.2 Battery requirements
The KESO KEK i-handle S is fully battery-operated. Note the signals in case of low battery power.
In cold weather, or if fitted in cold rooms, please check the battery power several times per year.
The electronically stored data is not lost when you replace the battery. However, please note
that the time must be reset for the PC Time Version if the system is without power for 90 sec.
For more details refer to the maintenance information, item 15.3
Important note:
Do not touch electronic components while changing the battery. (Static discharge can
damage or even destroy electronic components)
Observe correct polarity when inserting batteries. (Inserting the batteries incorrectly
can damage or even destroy electronic components)
Do not use rechargeable batteries as they do not have sufficient capacity to match the
power requirements.
As old batteries can leak, it is advisable to check the battery status at regular intervals.
KESO AG is not liable for consequential damage caused by defective batteries. (we do
not give any guarantee on batteries)
Batteries must be disposed of responsibly, see item 1.3
.
Frequent programming impacts the battery life

KESO KEK i-handle S
KESO AG Subject to change without notice Page 7 from 34 pages
4.3 Door requirements
The door thickness must be at least 38 mm and may be at most 110 mm.
Important facts:
The KESO KEK i-handle S is modular. The distance between the internal and external shield is
defined by the spindle set. The spindle set can be replaced at any time. See item 5
4.3.1 Use with emergency exit doors
The system can be used with emergency exit doors under certain conditions.
Door leaf thickness
38 mm to 110 mm
Outside
Assembly base to
mortise lock
min. 5mm
Inside
Assembly base to
mortise lock
min. 6mm

KESO KEK i-handle S
KESO AG Subject to change without notice Page 8 from 34 pages
4.4 Mortise lock requirements
The KESO KEK i-handle S can be used with most, commercially available door and mortise locks.
Use only mortise locks by established lock manufacturers to guarantee standardised drilling
patterns for KESO KEK i-handle S.
IMPORTANT:
Use only locks with transmission function in conjunction with locking cylinders.
(Emergency opening)
IMPORTANT:
Do not use locks with split follower.
IMPORTANT:
For locks with a backset of less than 35mm you must use special handles (not included
in the KESO range).
Important facts:
Use self-locking panic locks. This enhances security.
Ensure that the spring function of the handle nut is adequate.
Worn handle nut springs can lead to problems.
8 mm
Maximum rotation movement 35°

KESO KEK i-handle S
KESO AG Subject to change without notice Page 9 from 34 pages
4.5 Handle requirements
It is possible to deploy “third-party handles”. These handles are then retained by a special
spring-loaded spindle. If the handle lock is active, the handle freewheels and is thus not
engaged.
IMPORTANT:
The handle itself is held by a spring. This means that the maximum weight of the
individual handle cannot exceed 157 grams.
IMPORTANT:
The handle itself is held by a spring. For this reason the maximum projection of the
handle is not permitted to exceed 140mm.
4.6 Locking cylinder requirements
The KESO KEK i-handle S is designed for use with Euro profile cylinders, Euro-Swiss cylinders and
Swiss round cylinders. The KESO KEK i-handle S can also be used without a locking cylinder.
Please refer to the definition of article number (see item 5) for more details.
The cylinder projection from the assembly base is 21 mm on the interior and 11 mm on
the exterior
For door thicknesses, see also spindle set below item 7.6
Türstärke
21
11
A B
External shield 11 mm Internal shield 21 mm

KESO KEK i-handle S
KESO AG Subject to change without notice Page 10 from 34 pages
4.7 Fitting tool requirements
•Assembly instructions included in packaging
•Drilling template included in packaging
•Drill
•Drill tips 16mm and 25mm
•Various slotted and Phillips screwdrivers
•Multimetre to check the battery
•Set of Allen keys
•Set of torx screwdrivers
•Tweezers

KESO KEK i-handle S
KESO AG Subject to change without notice Page 11 from 34 pages
5Article No. Definition
5.1 KESO KEK i-handle S
EG.711 _ _ _ _ I_ _ _ 8 0 _ _ _ 1
Handle set Cylinder cut-out fitting Colour fitting Hole spacing distance Door leaf thickness Spindle Electronics version Moisture protection
Designs
Sena, Inox SI
Vector, Inox VI
Xara, Inox XI
Zafira, Inox ZI
EU Profile 01
Euroswiss 04
CH Profile 07
Blind (internal, external) 10
Surface Inox I
Hole spacing distance blind 00
Hole spacing distance 72mm 72
Hole spacing distance 74mm 74
Hole spacing distance 78mm 78
Hole spacing distance 88mm 88
Hole spacing distance 92mm 92
Hole spacing distance 94mm 94
Door leaf thickness 38 – 43mm 1
Door leaf thickness 44 – 49mm 2
Door leaf thickness 50 – 55mm 3
Door leaf thickness 56 – 61mm 4
Door leaf thickness 62 – 67mm 5
Door leaf thickness 68 – 74mm 6
Door leaf thickness 80– 86mm 8
Door leaf thickness 104–110mm 7
Spindle 8 mm 80
Home Battery OHB
PC Battery OPB
PC Time Battery PTB
Without moisture protection 1

KESO KEK i-handle S
KESO AG Subject to change without notice Page 12 from 34 pages
6Overview of fittings
Please check scope of delivery before your start fitting. (lock and cylinder not included in scope
of delivery)
Item Description Article SM Number
7.2 Handle set hole component Model Sena G.380/SI
7.3 Handle set hole component Model Vector G.308/VI
7.4 Handle set hole component Model Xara G.380/XI
7.5 Handle set hole component Model Zafira G.380/ZI
7.6 Spindle set and 3 pcs. screws G.381/../80
7.7 Reader module with connecting cable K.027/01
7.8 Batteries (set of 3) V.000/21/20
7.9 Internal and external shield, stainless steel
without reader module
G.713/….
7.10 Basic module with electronics EK.028/…
8. Mortise lock (not included) ----
7.6
8
7.2
7.3
7.4
7.5
7.6
7.6
7.6
7.10
7.7
7.7
7.8 7.9
7.9
7.2
7.3
7.4
7.5
7.2
7.3
7.4
7.5

KESO KEK i-handle S
KESO AG Subject to change without notice Page 13 from 34 pages
6.1.1 Dimensions
5
19.5
Depending
on handle
type
ab 110
ab 110
De
p
endin
g
on handle
type
23
11

KESO KEK i-handle S
KESO AG Subject to change without notice Page 14 from 34 pages
7Technical data
7.1 KESO KEK i-handle S
Article No.: EG.711/…
Application type: Stand alone
Material shield/handle: Stainless steel
Surface shield/handle: Satin Inox (others on request)
Arbour: 8 mm
Material reader module: Polycarbonate RAL 9005
Electronics: Electronics on interior of fitting, reader module in
black plastic housing on exterior of fitting
Power supply: 3 alkali manganese cells
Type LR03 (AAA), 1.5 Volt
Battery life: approx. 40,000 actuations at roomt temperature
or approx. 2 years in standby mode (without actuation)
Dimensions external shield: 281x40.5x11mm (LxWxH)
Dimensions internal shield: 281x40.5x21mm (LxWxH)
Protection type: IP30
Operating temperature: -10° C to +60° C
Storage temperature electronics: -40 to +80° C (without batteries)
Storage temperature batteries: -40 to +50° C
Air humidity: 10 - 95 % (non-condensing)
Climate : Interior rooms, not suitable for highly corrosive
atmosphere (chlorine, ammonia etc..).
ATEX: Not suitable for potentially-explosive atmospheres
.
Standards: EN 61000-4-2 / EN 61000-4-3
EN 50364 / EN 50357
ETSI EN 300 330-1 / ETSI EN 301 489-3
Labels: CE
Reader method: contactless (RFID)
Reaction time: 0.5 sec. until handle engages
Data storage: EEPROM / all data stored in non-volatile memory
Signalling: LED red, green; acoustic signal can be enabled/disabled
Programming interface: Interior side: serial
Exterior side: KAPI (KESO Advanced Programming
Interface) and KESO KEK Programmer PPG V2
Emergency power: via KAPI and KESO KEK Programmer PPG V2

KESO KEK i-handle S
KESO AG Subject to change without notice Page 15 from 34 pages
7.1.1 Home Version
Programming: With programming/deteting key/cards
User keys: Up to 256 per KESO KEK i-handle S
Programming keys: Up to 32 per KESO KEK i-handle S
Deletion keys: unrestricted
7.1.2 PC Version (until end of 2010)
Event logging: 500 events (Last in First out) with
door designation, person, action
Management: via KESO Management Software (see item 4)
Programming: via KESO Management Software (see item 4)
KESO KEK Programmer PPG V2 (KAPI)
User keys: 8,000 per KESO KEK i-handle S
7.1.3 PC Time Version
Event logging: 500 events (Last in First out) with date, time,
door designation, person, action
Time slots: Firmware until 3.1.99:
16 (24 hours plus 15 freely programmable)
From Firmware 4…. onwards:
24 (24 hours plus 23 freely programmable)
comprising 4 time blocks
Clock precision: +/- 3 seconds/ day
Clock resolution: 1 second
Clock power reserve: ~ 90 seconds
Special days: 3 time blocks, such as works holidays,
holidays, public holidays
Operating modes: Always open in time slot
User-controlled always open function (office function)
Management: via KESO Management Software (see item 4)
Programming: via KESO Management Software (see item 4)
KESO KEK Programmer PPG V2 (KAPI)
User keys: 8,000 per KESO KEK i-handle S

KESO KEK i-handle S
KESO AG Subject to change without notice Page 16 from 34 pages
7.2 Handle set type SENA
Article No.: G.380/SI
Incl. mounting set (without shield)
Hole component: 2 pcs. for 8mm arbour
Dimensions: 130 x 60mm
Material: Inox
7.2.1 Dimensions
7.3 Handle set type VECTOR
Article No.: G0.380/VI
Incl. mounting set (without shield)
Hole component: 2 pcs. for 8mm arbour
Dimensions: 120 x 60mm
Material: Inox
7.3.1 Dimensions

KESO KEK i-handle S
KESO AG Subject to change without notice Page 17 from 34 pages
7.4 Handle set type XARA
Article No.: G.380/XI
Incl. mounting set (without shield)
Hole component: 2 pcs. for 8mm arbour
Dimensions: 130 x 56mm
Material: Inox
7.4.1 Dimensions
7.5 Handle set type ZAFIRA
Article No.: G.380/ZI
Incl. mounting set (without shield)
Hole component: 2 pcs. for 8mm arbour
Dimensions: 140 x 55mm
Material: Inox
7.5.1 Dimensions

KESO KEK i-handle S
KESO AG Subject to change without notice Page 18 from 34 pages
7.6 Spindle set and screws
Spindle with stopper ring: 8 mm arbour
Screws: 2 pcs. M5 round headed screws
1 pc. M5 countersunk screw
Article No.: G.381/38/80
Door leaf thickness: 38-43 mm
Article No.: G.381/44/80
Door leaf thickness: 44-49 mm
Article No.: G.381/50/80
Door leaf thickness: 50-55 mm
Article No.: G.381/56/80
Door leaf thickness: 56-61 mm
Article No.: G.381/62/80
Door leaf thickness: 62-67 mm
Article No.: G.381/68/80
Door leaf thickness: 68-74 mm
Article No.: G.381/80/80
Door leaf thickness: 80-86 mm
Article No.: G.381/104/80
Door leaf thickness: 104-110 mm
7.6.1 Sketch of spindle
Len
g
th de
p
ends on door
leaf thickness

KESO KEK i-handle S
KESO AG Subject to change without notice Page 19 from 34 pages
7.7 Reader module with connecting cable
Article No.: K.027/01
Material: Polycarbonate RAL 9005
Dimensions: approx. 160 mm length
approx. 5 mm diameter
7.8 Battery
Article No.: V.000/21/20
Set: 3 pc. Alkali manganese cells
Type: LR03 (AAA) 1.5 V
7.9 Internal and external shield without electronics
Material: Stainless steel
Dimensions external shield: 281 x 40.5 x 11mm
Dimensions internal shield: 281 x 40.5 x 21mm
7.9.1 Matrix for Article Numbers
IMPORTANT: Articles not available from stock; delivery period approx.
3-4 weeks
Distance Blind Euroswiss
CH
Round cylinder Europrofile
Blind G.713/000/10
72 G.713/072/01
74 G.713/074/04 G.713/074/07
78 G.713/078/04 G.713/078/07
88 G.713/088/01
92 G.713/092/01
94 G.713/094/04 G.713/094/07

KESO KEK i-handle S
KESO AG Subject to change without notice Page 20 from 34 pages
7.9.2 Dimensions
Internal shield
External shield
7.10 Basic module with electronics
Article No. Home Version: EK.028.OHB.2
Article No. PC Version: EK.028.OPB.2
Article No. PC - Time Version: EK.028.PTB.2
Note: Depending on system
8Operations
The sensor element in the reader is located above the external handle. A contactless
reader is integrated into the security fitting.
The reader is highly energy-efficient. This results in a long battery life. In standby operations
the reader enters "sleep mode". You can wake the reader by moving the medium (key, tag, card)
quickly in the direction of the reader field. Ideally you should keep your finger between the medium
and the reader to accelerate the read operation.
11
