Assa Abloy ML52RA User manual

Electro-mechanical Lock Model ML52RA
ASSA ABLOY SENSE
USER OPERATION
Up to 60 cards can be added to the lock. These cards can be assigned to the lock as either user cards,
Janitor Cards or Master Cards.
A. PRIVATE MODE
In Private Mode the lock is set to work with the same user cards(s). These cards needs to be previously
registered to this specific lock. In Private Mode up to 5 Master Cards and 55 User Cards can be added.
1: To open the lock, simply present your registered User Card and open the door. If the handle isn’t turned,
the lock will automatically re-lock after 4 seconds.
2: To close, simply turn the handle into locked position and the lock will automatically lock.
B. PUBLIC MODE
In Public Mode the lock is set to work with any Compatible Card that is presented to the lock. This will tem-
porarily register this card to the lock. Upon opening the lock with this card, the lock will remove this as the
Registered Card, and any other Compatible Card can now operate the lock. In Public Mode up to 5 Master
Cards and 50 Janitor Cards can be added.
1: To close, turn the handle into locked position and present a Compatible Card. This will lock the lock.
Other cards cannot now operate the lock.
2: To open, present your Registered Card to the lock. Any other card can now operate the lock.
MASTER CARD OPERATION
The Master Cards can open the lock in both modes. In Public Mode, opening with the Master Card, will also
erase any Registered Card from the lock and leave the lock in open position.
JANITOR CARD OPERATION
The Janitor Cards can open the lock in Public Mode. Different to the Master Card, the Janitor Card will not
erase the registered User Card. When opening with the Janitor Card the lock will automatically re-lock.
FACTORY RESET
Insert a needle or clip through the hole on the back and press for 2 seconds. This will restore the lock into
Factory Mode, see lock setup for different options on how to reprogram the lock into desired configuration.
In Factory Modes the quick setup options are also available.
LOW BATTERY
When the battery level drops below 10%, 3 red flashes will occur after opening the lock. Please change
batteries at this point.
EXTERNAL POWER SUPPLY
Use external 5-pin USB power if the battery is dead and the lock does not respond at all
(Use with smartphone/laptop charger).
PROGRAMMING CARDS
The following cards are used when programming the locks
1
2
3
4
C
Add / Remove User Cards
1
2
3
4
C
Add / Remove Master Card Add /
1
2
3
4
C
Remove Janitor Card
1
2
3
4
C
Switch between Private and Public Mode
1
2
3
4
CCopying Card

BASIC SETUP
When the lock is in Factory Mode (on delivery and after factory reset) and the battery is entered the
following options on how to deploy the lock is available.
A: QUICK SETUP OF MASTERCARD AND USER CARDS FOR USE IN PRIVATE MODE
First present a Compatible Card which will become a new Master Card. Then within 5 seconds present a
second card which will be registered as the first User Card. Continue to present cards within 5 seconds after
the previous registration to add additional User Cards. Then wait 5 seconds and the lock will go into Private
Mode. Further programming is then done by using the Programming Cards.
The sequence below describes an example of how to add one Master Card (1) and two User Cards (2 and 3). Up to
50 User Cards can be registered to each lock.
Enter batteries 1
2
3
(Within five seconds)
1
2
3
(Within five seconds)
1
2
3
(Wait five seconds)
B: QUICK SETUP OF MASTERCARD FOR USE IN PUBLIC MODE
Present first Compatible Card which will become the Master Card. Then wait 5 seconds and the lock will go
into Public Mode. Further programming is then done by using the Programming Cards.
The sequence below describes an example of how to add one Master Card (1) for use in Public Mode.
Enter batteries: 1
2
3
(wait five seconds)
C: USING THE COPYING CARD
STEP 1: Read the setup of a programmed lock and record it to the Copying Card
1
2
3
4
C
1
2
3
4
C(During reading) (After reading completed)
Ex: Present a Copying Card followed by the Master Card and present the Copying Card again for reading the setup
of the lock.
NOTE1: No information of registered User Cards will be read into the Copying Card. User Cards always have
to be registred individually to the locks.
NOTE 2: The card needs to be cleared before beginning this procedure, see special commando 34.
On delivery, the card is cleared.
STEP 2A: Programming locks with the Copying Card into Public Mode
A lock in factory mode will read the setup on the Copying Card. This can be repeated for as many lock as
required.
The sequence below describes an example on how to use the Copying Card to set up lock in Public Mode.
Enter batteries:
1
2
3
4
C(During programming) (After complete programming)
Further programming on this lock is now done with the programming cards. See Lock Programming.
STEP 2B: Programming locks with the Copying Card into Private Mode
A lock in Factory Mode will read the setup on the Copying Card. After that the setup it’s possible to present
Compatible Cards to register them as User Cards. This can be repeated for as many lock as required.
The sequence below describes an example on how to use the Copying Card to set up the lock in Private Mode.
In this case 2 User Cards are also registered.
Enter batteries:
1
2
3
4
C(During programming) (Within five seconds)
1
2
3
(Within five seconds)
1
2
3
(Continue to present cards or wait 5 seconds
to end programming)
Further programming on this lock is now done with the programming cards. See Lock Programming.
Electro-mechanical Lock Model ML52RA
ASSA ABLOY SENSE

LOCK PROGRAMMING
1: USER CARDS (ONLY IN PRIVATE MODE)
1A: Add 1 User Card
1
2
3
4
C
(Wait 5 seconds or touch Master Card)
Ex: Present Programming Card 1 followed by a Master Card. Then present a Compatible Card to register this as a new
User Card.
1B: Delete 1 User Card
1
2
3
4
C
(Wait 5 seconds or touch Master Card)
Ex: Present Programming Card 1 followed by a Master Card. Then present a registered User Card to remove this from
the lock.
1 C: Add Multiple Cards
1
2
3
4
C
(Within five seconds) (Within five seconds)
(Continue to present cards or wait 5 seconds to end programming)
Ex: Present Programming Card 1 followed by a Master Card. Then present multiple registered User Cards to remove
them from the lock.
1D: Delete Multiple Cards
1
2
3
4
C
(Within five seconds) (Within five seconds)
(Continue to present cards or wait 5 seconds to end programming)
Ex: Present Programming Card 1 followed by a Master Card. Then present multiple registered User Cards to remove
them from the lock.
1E: Delete all cards
1
2
3
4
C
1
2
3
4
C
Ex: Present Programming Card 1 followed by a Master Card. Then present Programming Card 1 again to remove all
User Cards from the lock.
2: MASTER CARDS
2A: Add 1 Master Card
1
2
3
4
C
(Wait 5 seconds or touch Master Card)
Ex: Present Programming Card 2 followed by a Master Card. Then present a Compatible Card to register this as a new
Master Card.
2B: Delete 1 Master Card. Any Master Card can delete any other Master Card that is registered to the lock.
A Master Card cannot delete itself thus securing that always one Master Card remains registered.
1
2
3
4
C
((Wait 5 seconds or touch master card)
Ex: Present Programming Card 1 followed by a Master Card. Then present another registered Master Card to remove
this from the lock.
2C: Add multiple Master Cards
1
2
3
4
C
((Within five seconds) (Within five seconds) (Continue to present cards
or wait 5 seconds to end programming)
Ex: Present Programming Card 2 followed by a Master Card. Then present multiple Compatible Cards to register these
as new Master Cards.
2D: Delete multiple Master Cards. Any Master Card can delete any other Master Cards that is registered to
the lock. A Master Card cannot delete itself thus securing that always one Master Card remains registered.
1
2
3
4
C
(Within five seconds) (Within five seconds) (Continue to present cards
or wait 5 seconds to end programming)
Ex: Present programming card 2 followed by a Master Card. Then present multiple other registered Master Cards to
remove them from the lock.
ASSA ABLOY SENSE
Electro-mechanical Lock Model ML52RA

ASSA ABLOY SENSE
2E: Delete all Master Cards except the one used for this programming
1
2
3
4
C
1
2
3
4
C
Ex: Present Programming Card 2 followed by a Master Card to keep. Then present Programming Card 2 again to
remove all Master Cards from the lock except the Master Card used for this programming.
3: JANITOR CARDS (ONLY IN PUBLIC MODE)
3A: Add Janitor Card
1
2
3
4
C
(Wait 5 seconds or touch Master Card)
Ex: Present Programming Card 3 followed by a Master Card. Then present a Compatible Card to register this as a
new Janitor Card.
3B: Delete Janitor Card
1
2
3
4
C
(Wait 5 seconds or touch master card)
Ex: Present programming card 3 followed by a master card. Then present a registered janitor card to remove this
from the lock.
3C: : Add multiple Janitor Cards
1
2
3
4
C
(Within five seconds) (Within five seconds) (Continue to present
cards or wait 5 seconds to end programming)
Ex: Present Programming Card 3 followed by a Master Card. Then present multiple Compatible Cards to register these
as new Janitor Cards.
3D: Delete multiple Janitor Cards
1
2
3
4
C
(Within five seconds) (Within five seconds) (Continue to present
cards or wait 5 seconds to end programming)
Ex: Present Programming Card 3 followed by a Master Card. Then present multiple registered Janitor Cards to remove
them from the lock.
3E: Delete all Janitor Cards
1
2
3
4
C
1
2
3
4
C
Ex: Present programming card 3 followed by a Master Card. Then present Programming Card 3 again to remove all
Janitor Cards from the lock.
4: SWITCH BETWEEN PRIVATE AND PUBLIC MODE
4A: Switch to Public Mode
1
2
3
4
C
4B: Switch to Private Mode
1
2
3
4
C
NOTE 1: This programming toggles between Private and Public Mode. The LED indicates which mode the lock is
being set to.
NOTE 2: If switching to Public Mode all registered User Cards are deleted. If switching to Private Mode, all Janitor
Cards are deleted. Lock will remain unlocked until first User Card is added.
Electro-mechanical Lock Model ML52RA

ASSA ABLOY SENSE
Electro-mechanical Lock Model ML52RA
OTHER PROGRAMMING
12 OCH 13: ALLOW/DISALLOW TO LOCK MORE THAN ONE LOCK WITH THE SAME CARD (PUBLIC MODE)
Double locking means that a card can lock more than 1 lock in public mode. If disallowed, a card that is registered to one
lock, cannot close another lock before it has opened the first lock. As default double locking is allowed. The function of disal-
low cards to lock more than one lock is NOT available with Mifare DESfire-cards.
12: Allow double locking (default setting)
1
2
3
4
C
1
2
3
4
C
13: Disallow double locking
1
2
3
4
C
1
2
3
4
C
NOTE 1: If lock is set to disallow double locking it is not possible to use Cards with locked sectors, as this setup requires
that the lock can write to the card.
21 AND 23: TURN SOUND ON AND OFF
21: Turn sound on
1
2
3
4
C
1
2
3
4
C
23: Turn sound off (default setting)
1
2
3
4
C
1
2
3
4
C
34: RESET USER CARDS THAT IS LOCKED
In case the Master Card is used to open a lock in Public Mode with double locking disallowed, this will unregister the card
from the lock, but the card will be locked. This card can now no longer be used unless it’s cleared of its registration. To do
this, use the following procedure.
34: Reset User Cards for use in public mode
1
2
3
4
C
1
2
3
4
C
1
2
3
(Within five seconds)
1
2
3
(Within five seconds)
1
2
3(Continue to present cards for reset or
wait five seconds to end reset procedure)
Ex: Present programming card 3 followed programming card 4 .Then present any locked user cards to reset them.

ASSA ABLOY Opening Solutions Sweden
P.O. Box 371
SE-631 05 Eskilstuna
Sweden
Phone [phone]
Fax [phone]
Customer support:
Phone intl. [phone]
Phone nat. 0771-640 640
Fax [phone]
e-mail: [e-mail]
www.assaabloyopeningsolutions.se
We reserve the right to correct any printing errors and update the information after printing.M4177.1912
ASSA ABLOY SENSE
Electro-mechanical Lock Model ML52RA
UPDATE LOCK WITH COPYING CARD
In the case you want to do a quick update of the lock settings for a larger number of locks, the copying card can be used. You
first need to update 1 lock to the desired settings and then follow the steps below.
NOTE: No information of registered User Cards will be read onto the Copying Card. When using the Copying Card to update
the lock no User Cards will be removed or added. For adding/removing User Cards, see lock programming, section 1.
STEP 1: Clear the Copy Card
This is necessary in order to get step 3 to work properly.
1
2
3
4
C
1
2
3
4
C(During clearing of card) (Card cleared)
Ex: On any lock, present the switch card followed by the Copying Card to clear it from any data.
STEP 2: Read the setup of an updated lock and record it to the Copying Card (same as in section C)
1
2
3
4
C
1
2
3
4
C(During reading) (Complete reading)
Ex: Present a Copying Card followed by the Master Card and present the Copying Card again for reading the setup of the lock.
STEP 3: Update the setup of a programmed lock (repeat for all locks that needs to be updated)
NOTE: For security reasons, this requires that at least one Master Card that is registered on the lock that is to be updated, is
also copied onto the Copying Card.
1
2
3
4
C(During update) (Update complete)
Ex: Present a Copying Card to update the lock settings.
