Assa Abloy Yale nexTouch NTB610 Technical specifications

1
P/N 80-9150-0080-010 (11-19)
Retrofitting or modifying this product may impact fire rating, safety features and warranty.
Consult with code specifications to ensure compliance with all codes and ratings.
™
nexTouch
Touchscreen and Push Button Access Cylindrical Lock
Installation and Programming Instructions
3/32"
AA
AA
AA
AA
Optional
Optional

2
P/N 80-9150-0080-010 (11-19)
?Determining Handing
Left Hand “LH”, Hinges Left.
Open Inward.
Left Hand Reverse "LHR", Hinges Left.
Open Outward.
Right Hand "RH", Hinges Right.
Open Inward.
Right Hand Reverse "RHR", Hinges Right.
Open Outward.
The hand of a door is determined from the secure side of the door. The
term "secure" means the side from which you initially unlock and enter.

3
P/N 80-9150-0080-010 (11-19)
Preparing Door
!
Drill holes 1/2 way thru
door then complete from
other side to prevent
splitting.
DPS Option
Wood Door:
3/8" Dia. x Thru to
Hole in Door Face
*Metal Door:
3/4" Dia. Thru to
Hole in Door Face
*Metal Door Installations
Supplied plastic collar MUST be
installed for DPS to function properly.
80-8150-0032-010
Rev C
™
nexTouch
Cylindrical Lock
BEVELED EDGE
DOOR ONLY
HIGH EDGE
LOW EDGE
1" Dia.(25mm)
Thru Door
HIGH EDGE Fold Line
2-3/4" Beveled Backset
2-3/8" Square Backset
Fold Line
2-3/8" Square Backset
Fold Line
5/32" Dia x 1/8" Deep
(4mm x 3mm)
2 Locations
Both sides of door
2-3/4" (70mm)
Between Centers
2-1/8" Dia
(54mm)
Thru Door
3-1/2"
(89mm)
Between
Centers
3"
3"
CAUTION:
If printed from website
Print 1:1 Scale
Measure both 3" lines to check scale
SQUARE EDGE
DOOR ONLY
5/32" Dia x 1/8" Deep
(4mm x 3mm)
2 Locations
Both sides of door
HIGH EDGE Fold Line
2-3/8" Beveled Backset
LOW EDGE Fold Line
2-3/8" Beveled Backset
LOW EDGE Fold Line
2-3/4" Beveled Backset
WHEN IN TOP
POSITION ONLY
5/16" Dia
(8mm)
Thru Door
5/16" Dia
(8mm)
Thru Door
1" Dia.(25mm)
Thru Door
WHEN IN TOP
POSITION ONLY
3-1/2"
(89mm)
Between
Centers
Horizontal
Center Line
Vertical
Center Line
CUT
CUT
CUT CUT
CUT
CUT
Product Support Tel 800-810-WIRE (9473) • www.yalelocks.com
nexTouch™ is a trademark of Yale Security Inc., an ASSA ABLOY Group company.
Copyright © 2017, Yale Security Inc., an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Yale Security Inc., an ASSA ABLOY Group company is prohibited.
Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company.
An ASSA ABLOY Group brand
3/4" (19mm) Dia.
Metal Frame
3/8" (9.5mm) Dia.
Wood Frame
™
nexTouch Cylindrical Locks
NTB610
NTB620
NTB630
NTB640
Cylinder Override - Push Button
Cylinder Override - Cap Touch
No Cylinder Override - Push Button
No Cylinder Override - Cap Touch
3/4" (19mm) Dia.
Metal Frame
3/8" (9.5mm) Dia.
Wood Frame
1
!

4
P/N 80-9150-0080-010 (11-19)
2Preparing Frame
DoorFrame
1" Dia. x
1/2" Deep
Frame DPS Option
Wood Frame:
3/8" Dia. x 1"
*Metal Frame:
3/4" Dia. x 1"
See Instruction
A7983B
Inside
of Door
Frame
3-1/2"
7-16 / 8-32 x 1" UNCWS
x2
*Metal Frame Installations
Supplied plastic collar MUST be
installed for DPS to function properly.
!

5
P/N 80-9150-0080-010 (11-19)
3Preparing Inside Escutcheon
!Do not take apart the
outside assembly.
3
2
1

6
P/N 80-9150-0080-010 (11-19)
Curved edge of latchbolt
faces direction door closes.
!
Installing Latchbolt
Inside of Door
7-16 / 8-32 x 1" UNCWS
x2
Removing Battery Cover
4
5
2-3/8" Latchbolt for thin doors sold separately.
See Installation Options.

7
P/N 80-9150-0080-010 (11-19)
Installing Outside Assembly
Inside of Door
Inside of Door
1
2
View from Outside of Door
"T" Tabs
Retractor Pocket
Mounting Flange
Two moving "T" tabs
must be fully captured
in retractor pocket.
Mounting Flanges
must be in Mounting
Flange Pockets.
!
Mounting Flange Pocket
Mounting
Flange
Mounting Flange Pocket
6Thin door gaskets sold separately.
See Installation Options.
Optional DPS

8
P/N 80-9150-0080-010 (11-19)
7
10-32 x 2-1/2" PFHMS
Do Not
Overtighten Screws
!
Installing Inside Support Assembly
Inside of Door
x2
Optional DPS

9
P/N 80-9150-0080-010 (11-19)
Attaching Cables
Optional
DPS
Connection
Motor
Connection
Touchpad
Connection
8

10
P/N 80-9150-0080-010 (11-19)
9Installing Inside Escutcheon
Testing Inside Lever Operation
Avoid pinching
cables
!
Thin door gaskets sold separately.
See Installation Options.

11
P/N 80-9150-0080-010 (11-19)
Optional Network or Yale
Accentra Key module must be
installed BEFORE batteries. See
Installation Options.
!
"Welcome to Yale."
™
Congratulations, you've installed the Yale nexTouch Lock!
Continue on next page to customize your product.
Installing Batteries & Cover
10

Privacy DPS Switch
Metal Frame/Door Installations
Supplied plastic collars MUST be
installed for DPS to function properly.
Inside of Door
Door Position Switch Option
enables Privacy feature
Installation Options
Outside Gasket Inside Gasket2-3/8" Latchbolt
Adjusting for 1-3/8" Door (if necessary)
Network or Yale Accentra Key Module
Order 1-3/8" Thin Door Kit: 14-4761-0106
!
12
P/N 80-9150-0080-010 (11-19)

Programming Instructions
OR
Master PIN Code must be created before any further programming.
Max User Codes = 500
Lock Activation
Interior Escutcheon
Privacy
Button
Speaker
Low Battery
Indicator
Exterior Escutcheon
9Volt Battery
Override Terminal
Lockout Mode
Indicator
Unlock
Indicator
13
P/N 80-9150-0080-010 (11-19)

Creating Master PIN Code
1Creating a Master PIN Code must be performed upon installation or after resetting
the lock to factory default. Programming and use of lock is not possible until this
step has been successfully completed.
Enter 4-8 digit
Master PIN Code.
Press
Press
"Register Master
Code. Press the gear
key to continue."
"Enter a 4-8 digit
PIN code. Press the
gear key to continue."
"Registered."
"Completed."
14
P/N 80-9150-0080-010 (11-19)

Creating User PIN Codes
2
Enter Master
PIN code
Press
Press
Press
"Press 1 to
register a code."
"Register User code.
Press the gear key
to continue." Press
Press
"Register User code.
Press the gear key
to continue."
"PIN code registration.
Enter a 4-8 digit PIN code.
Press the gear key
to continue."
"Menu Mode,
enter number."
Master PIN code must be created first.
*Max User Codes = 500
15
P/N 80-9150-0080-010 (11-19)

16
P/N 80-9150-0080-010 (11-19)
Creating User PIN Codes con't
2
Press
Adding more User Codes:
Enter 4-8 digit PIN code
Press
To end programming:
Press
"Registered.
Press the check key to
complete. Press the gear
key to continue."
Enter 4-8 digit PIN code
followed by
"Completed."
"Registered.
Press the check key to
complete. Press the gear
key to continue."

17
P/N 80-9150-0080-010 (11-19)
3Locking & Unlocking Door with
Registered Master or User PIN Code
Enter PIN Code
Press

18
P/N 80-9150-0080-010 (11-19)
Locking Door with Privacy Button
4
Testing Outside Lever Operation

19
P/N 80-9150-0080-010 (11-19)
Resetting Lock to Factory Default
1. Remove inside lever with the
supplied lever removal tool.
2. Remove the battery cover with
supplied hex wrench and then
remove batteries.
3. Remove the 10-32 x 3/4" pan
head screw from the center of the
battery housing.
4. Remove the interior escutcheon
from the door to access the reset
button on back of escutcheon.
Cables may stay connected. (See
illustration at above for location of
the reset button.)
9. Release reset button and wait
approximately 15 seconds.
Speaker will announce "Welcome
to Yale."
5. Reinstall four (4) AA batteries.
7. While continuing to press the
reset button, temporarily remove
one (1) AA battery.
8. Reinstall the battery.
10. Reassemble escutcheon by
reversing steps 1-4.
6. Press the reset button for 3
seconds.
Interior Escutcheon
When lock is reset to factory defaults all user codes (including the Master PIN code*)
are deleted and all programming features are reset to original default settings (see
Factory Settings).
Upon reset, Master PIN Code creation is the only option available and must be
performed prior to any other programming of the lock.
IMPORTANT: The outside assembly remains assembled.
Lever Removal Tool Hex Wrench
Button
Reset

20
P/N 80-9150-0080-010 (11-19)
Definitions
Privacy Mode: With optional Door Position Switch installed, Privacy Mode enabled thru Menu Mode and door
closed, all keypad functions can be disabled with a 3 second press of the Privacy Button. Privacy Mode is
disabled by default. Enable Privacy Mode thru Main Menu selection #3 then #4. With door closed, press and
hold the privacy button until voice prompt indicates Privacy Mode is enabled. Privacy Mode duration ends when
door is opened and voice prompt indicates Privacy Mode is disabled.
Volume Setting Mode: The volume setting for PIN code verification is set to HIGH (1) by default; otherwise it
can be set to Low (2) or Silent (3) for quiet areas. (Main Menu selection #4.)
Wrong Code Entry Limit: After five (5) unsuccessful attempts at entering a valid PIN code, the lock will not
accept a PIN code for the duration of the shut down time. The touchscreen keypad will flash, and a red lock
symbol will be at the bottom of the keypad. The push button keypad will flash and the Yale icon will flash blue
for the shut down period. The keypad will be available after the shut down time is complete.
Low Battery: When battery power is low, the Low Battery Warning indicator is a flashing red battery icon on the
touchscreen keypad and the Yale logo will flash red on the push button keypad. If battery power is completely
lost, use 9Volt battery override. To use 9V battery override apply 9V battery, in either direction, to terminals on
the touchscreen for backup power option. Activate the touchscreen and enter your pin code to unlock door.
Privacy Button to Lock Door: If Automatic Re-lock is disabled, a short 1 second press of this button will lock the
door.
Shut Down Time: Unit will shut down for sixty (60) seconds and not allow operation after wrong code entry
limit (5 attempts) has been met. When unit is in Shut down, keypad will be flashing.
Language Setting Mode: Choose English (1), Spanish (2) or French (3) for lock's voice prompts. (Main Menu
selection #5.)
User PIN Code: The User code operates the lock. Maximum number of user codes is 500.
Automatic Re-lock Time: After a successful unlock, unit will re-lock automatically after 5 seconds or for a
duration selected in Advanced Lock Settings (Main Menu selection #3 then #1).
All Code Lockout Mode: This feature is enabled by the Master code. When enabled, it restricts all user (except
Master) PIN code access. When attempting to enter a code while unit is in Lockout, the RED locked padlock will
appear on the screen. (Main Menu selection #6.)
Network Module Setting: With optional Network Module installed, this setting becomes available (Main Menu
selection #7) and allows the lock to connect with a network controller.
One Touch Locking: When unit is unlocked, activating the touchscreen will lock unit (during Automatic Re-lock
duration or when Automatic Re-lock is disabled). When One-Touch Re-lock is not in use (disabled), any valid
PIN code will re-lock the lock. (Main Menu selection #3 then #3.)
Master PIN Code: The Master PIN code is used for programming and for feature settings. It must be created
prior to programming the lock. The Master code will also unlock/lock the lock.
Tamper Alert: Audible alarm sounds if attempting to forcibly remove outside lock from door.
