Securitron®M32 | M62 | M82
Magnalocks
Installation & Operating Instructions
Product Components
A Magnalock
B Sex Bolt
C Roll Pins (2x)
D Strike Plate
E Funnel Bushing
F Roll Pin
Bushings (2x)
G 5/16-18 Screw
H Rubber Washers
I Magnalock
Installation
Template
Recommended Tools
• Power Drill
• Hammer
• Wire Strippers/
Cutter
• 1/8", 3/8", 1/2"
Drill Bits
• Center Punch
• Crimp Wire
Connectors
• Masking Tape
• Crimp Tool
• 3/16" Hex Key
(Allen Wrench)
• Fish Tape or
Lead Wire
• Multimeter
• 1/2" Open end or
Crescent Wrench
Introduction
The Securitron Magnalock®family is state of the art in electromagnetic
locking, and includes operational electrical characteristics and
mounting configuration options addressed in this document.
The BondSTAT “B” Magnalock Series, Bond Sensor, monitors the magnetic
field. An internal sensor activates a single pole double throw (SPDT)
dry-contact relay connection designed for interface with access control
and/or alarm systems, which reports the status of the Magnalock.
The DPS “D” Magnalock Series, Door Position Sensor, is activated by a
special magnetic strike armature assembly. This isolated SPDT reed switch,
with an internal resettable protection device, is designed to interface
with an access control and/or alarm system to monitor door status.
Diagram 1 Product
Components
A
C
D
E F G H
I
B
Specifications
M32 M62 M82
Holding Force 600 lbs [272 kg] 1200 lbs [544 kg] 1800 lbs [816 kg]
Length 8" [203 mm] 8" [203 mm] 12" [305 mm]
Height 1.88" [48 mm] 3" [76 mm] 3" [76 mm]
Depth 1.6" [41 mm] 1.75" [44 mm] 1.75" [44 mm]
Current at 12 VDC 300 mA 250 mA 350 mA
Current at 24 VDC 150 mA 150 mA 200 mA
Capacitance at 12 VDC 6.8 mF 44 mF 44 mF
Capacitance at 24 VDC 6.8 mF 11 mF 11 mF
Dual Voltage 12/24 Volts DC
BondSTAT Rating (voltage) 30 VDC (Maximum) ~ Current 1 Amp (Maximum)
DPS Rating (voltage) 30 VDC (Maximum) ~ Current 125 mA (Maximum)
Instructions NOTE: See installati on instruc tions for full inf ormation and t roubleshoot ing.
1. The relat ionship between th e two magnet
mounting hole s is critical. DO NOT let
your marking or dr illing wander.
2. DO NOT over drill the diamet er of the 3/8" [9.5 mm]
magnet mount ing holes or the blind nuts wil l
not seat. It is best to us e a center punch to
create indent ations for all drill locat ions.
3. Make sure the blind nut s are collapsed.
4. DO NOT over tighten the magn et mounting
screws. Use pr ovided LOCTITE on sc rew threads.
5. Be care not to scrape th e magnet cable
when pushing it bac k into the frame.
6. The two rubb er washers stack one on top of th e
other and mount in bet ween the strike and t he
door around the cent er strike mounting scre w.
DO NOT place the washer s on the roll pins.
7. Whe n inserting the sex bo lt from the outside of
the door, DO NOT insert i t fully until you have
start ed the mating screw from t he other side.
This insures th at the sex bolt will go in straig ht.
8. DO NOT over tighten the st rike
mounting scre w into the sex bolt.
9. Make sure the str ike plate floats and pi vots around
the center mounti ng screw. This compensate s
for door misalig nment. If the strike is mo unted
rigidly, the Mag nalock will NOT hold.
10. Use of roll pin plastic bush ings is recommended for
metal door s. It the plastic bushing s are not used, drill
3/8" [9.5 mm] diameter holes for the str ike roll pins.
Securitron® M32 Series Magnalock (Standard Mount)
Installation Template
Patent pe nding and/or p atent ww w.assaab loydss.co m/patents Copyrig ht © 2020, Hanche tt Entr y Systems ,
Inc., an A SSA ABLOY Grou p company. All r ights re served. Reproduc tion in who le or in par t without t he
expres s writte n permissi on of Hanche tt Entr y Systems , Inc. is pro hibited. 5 00-10850_7
WARNING DO NOT DRILL into
magnet or st rike for any reaso n.
DO NOT photo copy te mplate.
(Dimensions wil l change)
CUT ALONG THIS LINE
Magnet
Strike Plate
CUT ALONG THIS LINE
FOLD ALONG THIS LINE
.4"
[10.2 mm]
.4"
[10.2 mm]
6.25"
[158.8mm]
7.2"
[182.9mm]
2.25"
[57.2 mm]
.813"
[20.7 mm]
.812"
[20.7 mm]
2.25"
[57.2 mm] .875"
[22.2 mm]
.6"
[15.2 mm]
.6"
[15.2 mm]
2 X Screw Monting Holes:
· Blind nuts used: 3/8" [9.15mm] DIA.
· No blind nuts used: 3/16" [4.18mm] DIA.
Position edge of magnet 1/2" [12.7mm] from frame corner
to provide drilling clearance
3/8" [9.5mm] DIA. wire way hole
2 X 1/2" [12.7mm]
1" [25.4mm]
Deep into Door
3/8" [9.5mm] DIA. Through Door
1/2" [12/7m m] DIA. from other
side for sex bolt
Vertical Mount: Move strike holes 1/10 " [2.5 mm] further from fold line.
Offset Strike: Move strike holes 1/4" [6.4 mm] towards fold line
Header
Door

2 of 8
Perform a
Pre-Installation Survey
NOTE: Additional brackets may be needed for proper
installation. Specialized brackets are available through
Securitron and its many product distributors.
1 PERFORM an initial on-site survey to determine a
method of mounting and to review the installation
plan, taking the following into consideration:
• Physical strength of mounting areas should
be strong enough to meet or exceed the
holding force of the required Magnalock.
• Placement of the Magnalock wiring and
protection from potential damage due to
intruders or vandal’s external attack.
• Accessibility for prevention of
potential safety hazards.
Diagram 2 Typical Magnalock Installation
on an Out-Swinging Door
Diagram 3 Typical Magnalock Installation
on an In-Swinging Door
DOOR
FRAME
DOOR
Sex Bolt and
Strike
Mounting
Screw
Rubber
Washers
Blind Nuts
Magnalock
Mounting
Screws
Flat Washers
Dress Plugs
UHB
Bracket
SFB Bracket
Strike Plate
DOOR
FRAME
DOOR
Strike Plate
Bracket
Mounting
Hardware
Magnalock
Blind Nuts and
Mounting
Screw
Sex Bolt
Z Bracket or
ZA Bracket
(dress cover is
not shown)
Strike Mounting
Hardware and
T-Nut

3 of 8
DOOR
FRAME
TOP OF
DOOR FRAME
DOOR
1
A – C/D Drill holes
3
2
Attach the Template and
Mark the Drill Holes
1 SELECT a mounting location for the
Magnalock and strike assembly.
NOTE: The edge of the template should be about 1" [25.4 mm]
from the latch side of the door to allow proper access
at the mounting locations for drilling and tool access.
2 ATTACH the template to the door and
frame (as shown in Diagram 4).
• IF Installing a strike plate horizontally,
THEN ENSURE the top edge of the strike
will be approximately 1/8" [3.2 mm]
below the door frame stop.
• IF the strike and magnet are to be mounted
VERTICALLY, THEN INCREASE the clearance
between the strike and frame to 3/16" [4.8 mm].
3 WHEN the template is attached, THEN MARK the
location of all holes to be drilled using a center punch.
Drill Holes for the Lock
Body and Strike Plate
1 DRILL Holes #1 and #3 (see Diagram 5) with
3/8" [9.5 mm] diameter without bushings OR
1/2" [12.7 mm] diameter with bushings,
and 1" deep into door.
2 DRILL Hole #2 (see Diagram 5) with 3/8" [9.5 mm]
diameter thru the door, and 1/2" [12.7 mm]
diameter from other side for sex bolt.
3 DRILL holes per template, in door frame, 3/8" [9.5 mm]
diameter for the installation of the lock body blind
nuts. OR 3/16" [5 mm] diameter without blind nuts.
NOTES: Use a pilot hole, then drill to final size for
an accurate hole diameter and placement.
4 INSTALL the Blind Nuts (see Diagram 6).
5 INSERT the assembled blind nut and installation
tool into a 3/8" [9.5 mm] mounting hole.
6 HOLD the install nut using a 1/2" [13 mm]
box-end wrench and, at the same time,
COLLAPSE the blind nut using a 3/16" [5 mm]
hex wrench to turn the socket cap screw.
NOTE: The collapsing tool is reusable for
several blind nut installations.
7 REMOVE the collapsing tool when finished.
NOTE: Once installed, the blind nuts leave a
threaded insert that will accept the machine
screws provided in the hardware pack.
8 VERIFY that the blind nut is properly collapsed.
Diagram 4 Attaching the Template
Diagram 5 Drill Holes
BLIND NUT
INSTALL NUT
SOCKET CAP SCREW
HEX (ALLEN) WRENCH
TURN
WRENCH HOLD
FLAT WASHERS (X2)
STAR WASHER
Blind Nut
AFTER Collapse
Blind Nut
BEFORE Collapse
Diagram 6 Blind Nut

4 of 8
Install the Strike Plate
1 Using a hammer, TAP the roll pins into the
strike plate until seated. Protect face of strike
to prevent damage. (see Diagram 9).
2 INSERT the 5/16-18 bolt through the funnel
bushing and strike plate (see Diagram 10).
3 APPLY thread lock to the 5/16-18
bolt threads (see Diagram 12).
4 INSTALL 2 or 3 rubber washers on the 5/16-18 bolt.
5 INSTALL the roll pin bushings into
the door (see Diagram 11).
6 From the outside of the door, gently
TAP the sex bolt into place.
NOTE: The strike plate is secured to the
door via the supplied sex bolt.
7 INSTALL the strike by aligning it with the sex
bolt and roll pin bushing and then tightening
the center screw (see Diagram 12).
NOTE: The center screw should not be
over tightened; strike should float.
DOOR
FRAME
TOP OF
DOOR FRAME
DOOR
Roll Pin Bushings
Blind Nuts
Sex Bolt Hole
DOOR
THREAD
LOCK
Funnel Bushing
Washers
5/16-18 Bolt
STRIKE PLATE
Diagram 9 Seating the Roll Pins
Diagram 11 Install the
Bushings in the Door
Diagram 12 Tap Sex Bolt into door (outside).
Align sex bolt with roll pin bushing.
Diagram 10 Install the Bolt through funnel in Strike Plate

5 of 8
Alignment Tolerances
MODEL X-Coordinate
Alignment (+/–)
Y-Coordinate
Alignment (+/–)
M32 B/D 9/32" 1/8"
M62 B/D 5/16" 1/8"
M82 B/D 9/16" 1/8"
DOOR
FRAME
TOP OF
DOOR FRAME
DOOR
Finishing Caps
Maglock
Diagram 13 Secure Maglock
body and add finishing caps
Diagram 14 Maglock and Strike Plate Alignment
X
Y
0
0
(–)
(–)
(+)
(–) (+)
(+)
(–)
(+)
Magnalock
Strike Plate
Install the Magnalock
1 PULL the lock wire into frame and to desired location.
2 APPLY thread lock to mounting screws.
3 MOUNT lock body to frame using
supplied hardware (see Diagram 13).
4 INSERT the tamper finish caps into the
mounting screw holes (see Diagram 13).
5 ENSURE the Magnalock and strike plate are
in proper alignment (see Diagram 14).
NOTE: When installing the Magnalock and strike plate,
each should be in proper alignment to the other
(see Diagram 14). This is considered critical for the
operation of both the BondSTAT and DPS. However, there
are alignment tolerances, see table in Diagram 14, for each
model of Magnalock, but these should be viewed as the
extreme— the installation desire is always total alignment.
CAUTION The Magnalock and strike plate must
be in proper alignment or the BondSTAT and
DPS functions will not operate correctly

6 of 8
SERIES “B” BONDSTAT
Magnalock
RED
WHITE
GREEN
ORANGE
BLACK
DC
Power Supply
Access
Control Device
120
VAC Input
12/24
VDC
Output
NC
C
NO
REF.
LOCK
STATUS
+
–
NO
C
NC
RED
YELLOW
BLUE
BROWN
BLACK
DC
Power Supply
Access
Control Device
SERIES “D” DPS
Magnalock
120
VAC Input
12/24
VDC
Output
NC
C
NO
REF.
LOCK
STATUS
+
–
NO
C
NC
RED
WHITE
GREEN
ORANGE
YELLOW
BLUE
BROWN
BLACK
DC
Power Supply
Access
Control Device
SERIES “BD” DPS
Magnalock
120
VAC Input
12/24
VDC
Output
NC
C
NO
REF.
LOCK
STATUS
REF.
DOOR
STATUS
+
–
NO
C
C
NC
NO
NC
Wiring
WARNING: A shock hazard may occur if the
Magnalock is operated from a DC power supply that
is connected to earth ground or not isolated.
CAUTION: The Magnalock must be operated from
DC power supply of appropriate capacity and voltage.
The DC output of the power supply must not be
connected to earth ground but must be isolated,
or possible damage to the product could result.
Reference Diagrams 15-18 for wiring by model.
NOTE: In order to confirm that the DC outputs of a power
supply are isolated, it can be checked with an ohmmeter
between earth ground and +V, and then between earth
and 0V (negative). There should not be continuity.
Diagram 15 Typical Magnalock Connections
Diagram 16 Connections for BondSTAT “B” Version (5 wires)
Diagram 17 Connections for DPS “D” Version (5 wires)
Diagram 18 Connections for “BD” Version (8 wires)
DC
Power Supply Access
Control Device
RED
BLACK
Standard Version
2-wire Magnalock
120
VAC Input
12/24
VDC
Output
NC
C
NO
+
–
BondSTAT “B” Version
• GREEN and WHITE wires supply electrical
connection when the lock is ON and SECURE.
• ORANGE and WHITE wires supply electrical
connection when the lock OFF or UNSECURE.
DPS “D” Version
• BLUE and YELLOW wires supply electrical
connection when the door condition is CLOSED.
• BROWN and YELLOW wires supply electrical
connection when the door condition is OPEN.

7 of 8
BondStat
Double Door Status
When two Magnalocks are used for double
door installation, the BondSTAT contacts should
be wired in series for proper reporting.
CONNECT the GREEN wire of one lock to the
WHITE wire of the other (see Diagram 19).
DPS Double Door Status
When two Magnalocks are used for double
door installation, the DPS contacts should
be wired in series for proper reporting.
CONNECT the BLUE wire of one lock to the
YELLOW wire of the other (see Diagram 20).
Determining Wire Gauge
The Magnalock requires adequate voltage and
current for proper operation. Resistance is
created by the length and gauge (size) of the
wire being used. An accurate estimated distance
from the power supply to the opening is crucial.
For superior operation the correct size gauge
wire must be used—the devices used operate
optimally with the least amount of resistance
on the source. Using the correct gauge wires
protects against large voltage and current (load)
losses. The gauge is determined by the wire
distance, voltage and current of all devices.
1 CALCULATE total current for either a 12 VDC system
or a 24 VDC system as required. Use Tables 1 or 2.
2 Using the value obtained in Step 1, DETERMINE the
proper wire gauge and length using Tables 3 or 4.
Table 1 12 VDC System Current Used
Device Amps (12 VDC) Progressive Totals
Securitron M62 Magnalock .25 .25
Securitron DK-26 Access .16 .41
Securitron XMS Motion .05 .46
Securitron EEB2 Timer .025 .485
Total Current (Rounded Up) .6 A
Table 2 24 VDC System Current Used
Device Amps (12 VDC) Progressive Totals
Securitron M82 Magnalock .2 .2
Securitron TSB Touch Bar .025 .225
Securitron DK-11 Access .07 .295
Securitron XDT-24 Delay .05 .345
Securitron MK Bypass/Reset .02 .365
Total Current (Rounded Up) .4 A
Table 3 12 VDC Wire Gauge and Length
Current Gauge
1 A 20 18 16 14 14 12 10 10 8
.8 A 22 18 18 16 14 12 10 10 8
.6 A 22 20 18 18 16 14 14 12 10
.4 A 22 22 20 18 18 16 14 14 12
.3 A 24 22 22 20 18 18 16 14 14
.2 A 24 22 22 22 20 18 18 16 14
Distance 50’
[15m]
100’
[30m]
150’
[46m]
200’
[61m]
300’
[91m]
400’
[122m]
500’
[152m]
750’
[229m]
1000’
[305m]
Table 4 24 VDC Wire Gauge and Length
Current Gauge
1 A 22 20 20 18 16 14 14 12 10
.8 A 22 22 20 18 18 16 14 14 12
.6 A 24 22 22 20 18 18 16 14 14
.4 A 24 22 22 22 20 18 18 16 14
.3 A 24 24 22 22 22 20 20 18 16
.2 A 24 24 24 22 22 22 20 20 18
Distance 50’
[15m]
100’
[30m]
150’
[46m]
200’
[61m]
300’
[91m]
400’
[122m]
500’
[152m]
750’
[229m]
1000’
[305m]
Diagram 19 Connections
Diagram 20 DPS Connections
BondSTAT
Magnalock
WHITE
WHITE
GREEN
GREEN BondSTAT
Magnalock
DPS
Magnalock
YELLOW
YELLOW
BLUE
BLUE DPS
Magnalock
Wire for Emergency Release
• Magnalocks are often wired into a system for quick release in case of emergency.
• Manual switching or automatic triggering from a fire alarm system is practical.
• It is the user’s responsibility to correctly hookup the Magnalock according to the instructions.
• Securitron power supplies have terminals for connecting emergency release switches.
• USE a switch or relay to perform break of power.

8 of 8
[e-mail] | assaabloyesh.com
800 626 7590 | 10027 S. 51st Street Phoenix, AZ 85044 USA
Patent pending and/or patent www.assaabloydss.com/patents
Copyright © 2020, Hanchett Entry Systems, Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written
permission of Hanchett Entry Systems, Inc. is prohibited. 500-10420_8
Warranty
For information on warranty coverage and replacement options,
please visit assaabloyesh.com/warranty
Troubleshooting A Magnalock
PROBLEM SOLUTIONS
Lock does not generate
a magnetic field
• CHECK for specified voltage at Magnalock.
• CHECK for specified current draw at Magnalock.
Reduced holding force
• CHECK DC power source is Full-Wave Rectified
(Half-wave Rectifier or AC Power unacceptable).
• CHECK for specified voltage at Magnalock.
• CHECK for specified current draw at Magnalock.
• CHECK strike mounting for proper installation.
• CHECK the Magnalock and strike for obstructions
and that contact surfaces are properly cleaned.
BondSTAT does not
report secure
• CHECK for specified voltage at Magnalock.
• CHECK for specified current draw at Magnalock.
• CHECK strike mounting for proper alignment and
pivoting for proper closure to Magnalock.
• CHECK the Magnalock and strike for obstructions
and that contact surfaces are properly cleaned.
DPS does not report
door status
• CHECK strike mounting for proper alignment.
• CHECK for proper door closure.
• CHECK for proper voltage/current on switch.
• CHECK resettable protection device.
Magnalock does
not release
• ENSURE no voltage is present at Magnalock.
• ENSURE the Magnalock is not drawing current.
• CHECK if the strike is sticky and hard to release.
• CHECK the Magnalock and strike for obstructions
and that contact surfaces are properly cleaned.
Magnalock is dirty or rusty • ENSURE the Magnalock is properly cleaned.
Electronic noise
interference with Access
Control System
• CHECK for voltage from Magnalock to door
frame; there should be no voltage present.
Perform an Inspection
1 CHECK the rubber washers for elasticity and
proper pivoting; TIGHTEN as required.
2 CHECK for the build-up of debris on the Magnalock
and strike armature; CLEAN as required.
3 CHECK for rust on the Magnalock and strike
plate armature; CLEAN as required.
Cleaning the Magnalock
1 CLEAN the Magnalock at the following intervals:
• Once a year for normal maintenance
• Every 6 months when minor rusting occurs
• Every 3 months if rust conditions are severe
2 APPLY rubbing alcohol onto a clean cloth and
thoroughly WIPE DOWN the Magnalock and
strike plate armature (indoor applications).
3 APPLY a silicone-based cleaner/lubricant onto a clean
cloth and thoroughly WIPE DOWN the Magnalock
and strike plate armature (outdoor applications).
NOTE: An example of a silicon-based cleaner/lubricant
is the following: Super Lube®Aerosol with SYNCOLON®
(PTFE) Part Number: 31040 ~ 6oz. / 31110 ~ 11 oz. / 32015
~ 14 oz. Phone: [phone] / Website: super-lube.com
4 USE a plastic dishwashing scrub pad
to aid in the removal of rust.
Magnalock Maintenance
