AT&T SPIRIT 308 User guide

AT&T
Customer Name
Address
Phone
DOSS Order No.
SPIRIT
®
Communications System Model 308/616
System Planner
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
The information on this form will enable your AT&T Service Technician to install
your new SPIRIT system so that it works exactly as you want. It is important that you
provide the information
prior to installation. In addition to installing the system, the
Service Technician will train you to use it, so you
must have someone present during
installation.
What is the name and phone number of the person who will be present for training when the system is
installed? Name
Phone
How many phone numbers (lines) do you have?
What sound do you hear when you dial your telephone? Touch tones
Rotary clicks
Depends on the line
Do you dial a 1 before the area code when you make long distance calls? Yes
No
Do the people in your business have a need for private telephone conversations, or
one another’s calls without permission? Privacy No privacy
Do you have any lines that should be used only by a specific person or group
manager’s personal line that no one else is allowed to use. Yes
No
attached form.
Unless you specify otherwise, all lines are available when someone lifts the receiver
automatically selects one of the lines, the person hears a dial tone and makes the
button. Do you want any lines to be ineligible, so that people will have to press a
dial tone? Yes
No
If yes, complete Part B of the attached form.
should they be able to join
of people? For example, a
If yes, complete Part A of the
to make a call. The system
call without pressing a line
line button before getting a
The SPIRIT system lets you set your lines to ring immediately, in an abbreviated fashion, with a delay, or not
at all. For example, if you have a secretary who answers your calls, you may want the secretary’s phone to ring
immediately, but yours to ring with a delay (that is, only if it has already rung for 12 seconds at the secretary’s
phone). If you want anything other than immediate ring on any of your phones, complete Part C of the
attached form.
You can restrict some phones to internal calls only or local calls only, if you like. If you want to restrict any of
your phones, complete Part D of the attached form.
The location of your controller must meet the following requirements:
— It should be mounted at least two feet from the floor.
— It should be within five feet of the network interface jacks, that is, where your telephone lines come into
your establishment.
— It should be within five feet of 110V AC outlet not controlled by a switch.
— The area should be well ventilated and free of excess dust.
— The dimensions are:
Controller
8½ " H x 16" W x 3"D
Expansion Unit 6"H x 16"W x 3"D
Where will your controller be located?

SPIRIT® COMMUNICATIONS SYSTEM MODEL 308/616
Please assign each telephone to an intercom extension number. (Use 18-25 only if you have a Model 616). The
person who will be customizing your system should be intercom extension 10.
Intercom
Extension
Number
10
11
12
13
15
16
Telephone User
Name and
Location
17
18
19
A
Line Use Permission
1-No Permission
2-Full Permission
3-Answer Only
B
Automatic Line
Selection
1-Not Eligible
2-Eligible
C
Line Ringing Options
1-No Ring
2-Normal
3-Abbreviated
4-Delayed
D
Outside Service
1-Outward Restricted
2-Unrestricted
3-Toll Restricted
Line
1 2
3 4 5 6 Line
1 2 3 4 5 6 Line 1
2 3 4 5 6
14
20
21
22
23
24
25
LINE 1 LINE 2 LINE 3 LINE 4 LINE 5 LINE 6
A
C
1 — No Permission - Can’t use this line to make 1 — No Ring - Line will never ring.
or receive calls. 2— Normal - Line will begin ringing immediately.
2— Full Permission - Line can be used both to 3— Abbreviated - Line will ring for 12 seconds only.
make and receive calls. 4— Delayed - Line will begin ringing after 12 seconds.
3— Answer Only - Can only receive calls on this line.
D
B
1 — Outward Restricted - User can make intercom
1 — Not eligible -To use this line you must press a calls only.
button. 2— Unrestricted - User is unrestricted.
2— Eligible -This line is eligible for use without 3—Toll Restricted - User can make intercom and
pressing a button. local calls only. 999-350-595
SPIRIT is a registered trademark of AT&T
Issue 1, October 1987
