eBOX625-312-FL
Embedded System
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, or any liability arising from such uses.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update any information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted in
any forms or by any means, electronic, mechanical, photocopying, recording, among others,
without prior written permissions of Axiomtek Co., Ltd.
Copyright 2019 Axiomtek Co., Ltd.
All Rights Reserved
Jan 2019, Version A1
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The eBOX625-312-FL does not come equipped with an operating system. An operating
system must be loaded first before installing any software into the computer.
2. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
3. Disconnect the power cord from the eBOX625-312-FL before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the eBOX625-312-FL is properly grounded.
4. Make sure the voltage of the power source is correct before connecting the equipment to
the power outlet.
5. Turn OFF the system power before cleaning. Clean the system using a cloth only. Do not
spray any liquid cleaner directly onto the screen.
6. Do not leave this equipment in an uncontrolled environment where the storage
temperature is below -40℃or above 80℃. It may damage the equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static electricity
on your body.
When handling boards and components, wear a wrist-grounding strap, available from
most electronic component stores.
8. Note!! Caution with touch! eBOX625-312-FL will be hot when it's on.

iv
Classification
1. Degree of production against electric shock : not classified
2. Degree of protection against the ingress of water : IP40
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with air
or with oxygen or nitrous oxide.
4. Mode of operation : Continuous

v
General Cleaning Tips
You may need the following precautions before you begin to clean the computer. When you
clean any single part or component for the computer, please read and understand the details
below fully.
When you need to clean the device, please rub it with a piece of dry cloth.
1. Be cautious of the tiny removable components when you use a vacuum cleaner to
absorb the dirt on the floor.
2. Turn the system off before you start to clean up the component or computer.
3. Never drop the components inside the computer or get circuit board damp or wet.
4. Be cautious of all kinds of cleaning solvents or chemicals when you use it for the sake of
cleaning. Some individuals may be allergic to the ingredients.
5. Try not to put any food, drink or cigarette around the computer.
Cleaning Tools:
Although many companies have created products to help improve the process of cleaning
your computer and peripherals users can also use household items to clean their computers
and peripherals. Below is a listing of items you may need or want to use while cleaning your
computer or computer peripherals.
Keep in mind that some components in your computer may only be able to be cleaned using a
product designed for cleaning that component, if this is the case it will be mentioned in the
cleaning.
Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although
paper towels or tissues can be used on most hardware as well, we still recommend you
to rub it with a piece of cloth.
Water or rubbing alcohol: You may moisten a piece of cloth a bit with some water or
rubbing alcohol and rub it on the computer. Unknown solvents may be harmful to the
plastics parts.
Vacuum cleaner: Absorb the dust, dirt, hair, cigarette particles, and other particles out of
a computer can be one of the best methods of cleaning a computer. Over time these
items can restrict the airflow in a computer and cause circuitry to corrode.
Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are excellent tools
for wiping hard to reach areas in your keyboard, mouse, and other locations.
Foam swabs: Whenever possible it is better to use lint free swabs such as foam swabs.
NOTE: We strongly recommended that you should shut down the system before you
start to clean any single components.
Please follow the steps below:
1. Close all application programs
2. Close operating software
3. Turn off power switch
4. Remove all device
5. Pull out power cable

vi
Scrap Computer Recycling
If the computer equipment’s needs the maintenance or are beyond repair, we strongly
recommended that you should inform your Axiomtek distributor as soon as possible for the
suitable solution. For the computers that are no longer useful or no longer working well, please
contact your Axiomtek distributor for recycling and we will make the proper arrangement.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
IBM, PC/AT, VGA, HDMI are trademarks of International Business Machines Corporation.
Intel®, Pentium®and Celeron®are registered trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBasic are trademarks of Microsoft Corporation.
Windows 10, Windows 8.1, Windows XPE, Windows WinCE embedded, Linux, MS-DOS,
Microsoft C and
Other brand names and trademarks are the properties and registered brands of their
respective owners.

vii
Table of Contents
Disclaimers.............................................................................................................ii
Safety Precautions................................................................................................iii
Classification......................................................................................................... iv
General Cleaning Tips ........................................................................................... v
Scrap Computer Recycling................................................................................... vi
CHAPTER 1 INTRODUCTION................................................................................1
1.1 General Description...........................................................................1
1.2. System Specification......................................................................... 2
1.2.1 CPU...................................................................................................................2
1.2.2 I/O System........................................................................................................2
1.2.3 System specifications.....................................................................................4
1.2.4 Driver CD Content............................................................................................4
1.3 Dimensions ........................................................................................5
1.3.1 System Dimension...........................................................................................5
1.3.2 Wall mount Bracket Dimension......................................................................6
1.3.3Din-rail mount Bracket Dimension.................................................................7
1.3.4VESA mount Bracket Dimension....................................................................8
1.4 I/O Outlets ..........................................................................................9
1.5 Packing List...................................................................................... 11
1.6Model List......................................................................................... 11
CHAPTER 2 HARDWARE INSTALLATION.......................................................13
2.1Installing of the Memory module .................................................... 13
2.2Installing of the PCI Express Mini Card ......................................... 15
2.3Installing of the 2.5"SATA Device...................................................17
CHAPTER 3 JUMPER SETTING & CONNECTOR...........................................19
3.1 CAPA312 layout................................................................................19
3.2 Jumper Setting Summary................................................................21
3.2.1 Restore BIOS Optimal Defaults (JP3) ..........................................................21
3.2.2 COM3 Data/Power Selection (JP4)...............................................................22
3.2.3AT/ATX Quick Switch (SSW1).......................................................................22
3.3 Connectors.......................................................................................23
3.3.1VGA Connector (CN23).................................................................................24
3.3.2COM Serial Port Connector (CN17, CN18, CN4) ........................................24
3.3.3USB 2.0 Port (CN7).........................................................................................25
3.3.4SATA Connector (CN15)................................................................................25
3.3.5HDMI Connector (CN19)................................................................................26
3.3.6USB 3.0 Ports (CN20 and CN21)...................................................................27
3.3.7Ethernet Ports (LAN1 and LAN2)..................................................................28
3.3.8Full-size PCI-Express Mini Card Connector (SCN1)...................................29
3.3.9SIM Card Socket (SCN2)................................................................................30
3.3.10 Full-size PCI-Express Mini Card or mSATA Connector (SCN3)................31
3.3.11 Power and HDD LED Indicator .....................................................................32
3.3.12 System Power Switch ...................................................................................32

viii
3.3.13AC to DC Jack Power In Connector.............................................................32
CHAPTER 4 BIOS SETUP UTILITY ....................................................................33
4.1 Starting............................................................................................. 33
4.2 Navigation Keys...............................................................................33
4.3 Main Menu........................................................................................34
4.4 Advanced Menu................................................................................35
4.5 Chipset Menu ...................................................................................49
4.6 Security Menu .................................................................................. 52
4.7 Boot Menu ........................................................................................53
4.8 Save & Exit Menu............................................................................. 54
APPENDIX A WATCHDOG TIMER..............................................................57
A.1 About Watchdog Timer.................................................................... 57
A.2 How to Use Watchdog Timer .......................................................... 57
APPENDIX B BIOS FLASH UTILITY...................................................................59

eBOX625-312-FL User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
This chapter contains general information and detailed specifications of the eBOX625-312-FL.
The Chapter 1 includes the following sections:
General Description
System Specification
Dimensions
I/O Outlets
Packing List
Model List
1.1 General Description
The eBOX625-312-FL is an embedded system equipped with Intel®Celeron®N3350/N4200
SoC onboard which features fan-less design with full feature I/O supported for more
connectivity. The system also supports 204-pin DDR3L-1866 SO-DIMM slot for up to 8GB of
memory. In addition, for enhanced security, the eBOX627-312-FL supports TPM 1.2. It also
supports Axiomtek's exclusive AXView Industrial IoT software for smart device monitoring and
management. It is well-suited for multimedia applications, security surveillance and smart
factory automation.
Features
1. Intel®Celeron N3350/N4200 SoC onboard
2. Maximum to 8GB DDR3L-1866 memory
3. VGA/HDMI for dual display
4. Supports 4 USB 3.0 & 2 USB 2.0 ports
5. Supports 2 RS-232/422/485 and 1 RS-232
6. Supports dual 10/100/1000Mbps Ethernet ports
7. One 2.5” SATA HDD/SSD drive bay (Max. up 9.5 mm height)
8. Two Full-Size Mini PCI Express Mini Card. Support 1 w/mSATA.
9. One SIM slot
10. AXView 2.0 and TPM 1.2 supported
11. Wide temperature: -20°C~65°C supported (with W.T. SSD & Memory at non-turbo mode)
12. 12VDC screw type power input.

eBOX625-312-FL User’s Manual
Introduction
2
Reliable and Stable Design
The eBOX625-312-FL adopts the advanced cooling system and supporting wide
operating temperature with fan-less design, which makes it especially suitable in harsh
environments, best for industrial automation, digital signage and gaming application.
Flexible Connectivity
It comes with rich I/O interfaces including one RS-232 ports, two RS-232/422/485 ports,
four USB 3.0 ports, two USB 2.0 ports, two GbE LAN ports.
Embedded O.S. Supported
The eBOX625-312-FL supports Windows®10 IoT,Linux and AXView 2.0.
Various Storage
Supported In terms of storage, the eBOX625-312-FL supports one 2.5" SATA
storage drive bay and one mSATA device.
1.2. System Specification
1.2.1 CPU
CPU
Intel® Celeron®processor N3350 Dual Core, up to 2.4 GHz with turbo boost.
Intel® Pentium®processor N4200 Quad Core, up to 2.5 GHz with turbo boost.
Chipset
SoC integrated
System Memory
One 204-pin DDR3L-1866 SO-DIMM socket, up to 8 GB at the maximum.

American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS
TPM
TPM 1.2
1.2.2 I/O System
Display
1 x Lockable HDMI (HDMI 1.4b up to 3840 x 2160@30Hz)
1 x VGA (1920 x 1200)
Ethernet
2 x 10/100/1000 Ethernet ports (i211-AT)
USB Ports
2 x USB 2.0
4 x USB 3.0

eBOX625-312-FL User’s Manual
Introduction
3
Serial Ports
1 x RS-232 (9-pin D-Sub male connector)
2 x RS-232-422-485 (9-pin D-Sub male connector)
Audio
1 x Mic-in/Line out
Expansion slots
2 x full-size PCI Express Mini Card Slots (USB + PCI Express signal)
1 x SIM slot
Storage
1 x 2.5" SATA HDD/SSD drive bay
1 x mSATA (enabled in BIOS setting)
Indicator
1 x Green LED as indicator for PWR status
1 x Yellow LED as indicator for HDD active
Switch
1 x ATX PWR switch
1 x ATX/AT Quick switch
Antenna
4 x SMA type connector openings for antenna

eBOX625-312-FL User’s Manual
Introduction
4
1.2.3 System specifications
Watchdog Timer
65536 levels, 1 to 65535 sec.
Power Supply
12VDC/60W AC to DC adapter (optional)
Operation Temperature
Turbo Mode (Default):
-20°C ~ +60°C (-4°F ~ +140°F) (with W.T. SSD/DRAM)
Non-turbo Mode:
-20°C ~ +65°C (-4°F ~ +149°F) (with W.T. SSD/DRAM)
Storage Temperature
-40℃~ 80℃(-40 ºF ~ 176ºF)
Humidity
10% ~ 95% (non-condensation)
Vibration Endurance
IEC 60068-2-27 (with SSD: 50G, half sine, 11 ms duration)
Shock Endurance
IEC 60068-2-64 (with SSD: 3Grms STD, random, 5 to 500 Hz,1 hr/axis)
Weight
1.1 kg (2.43 lb)/1.8 kg (3.97 lb)
Dimensions
200mm (7.87”) (W) x 120mm (4.72”) (D) x 46mm(1.81") (H)
1.2.4 Driver CD Content
Driver
Chipset
Graphic
TXE
Ethernet
Audio
AXVIEW 2.0
Manual
User Manual
Quick Manual
NOTE:All specifications and images are subject to change without notice.

eBOX625-312-FL User’s Manual
Introduction
5
1.3 Dimensions
The following diagrams show you dimensions and outlines of the eBOX625-312-FL.
1.3.1 System Dimension

eBOX625-312-FL User’s Manual
Introduction
6
1.3.2 Wall mount Bracket Dimension

eBOX625-312-FL User’s Manual
Introduction
7
1.3.3 Din-rail mount Bracket Dimension

eBOX625-312-FL User’s Manual
Introduction
8
1.3.4 VESA mount Bracket Dimension

eBOX625-312-FL User’s Manual
Introduction
9
1.4 I/O Outlets
The following figures show you I/O outlets on front view of the eBOX625-312-FL.
Front View
Front View drawing

eBOX625-312-FL User’s Manual
Introduction
10
Rear View
Rear View drawing

eBOX625-312-FL User’s Manual
Introduction
11
1.5 Packing List
The package bundled with your eBOX625-312-FL should contain the following items:
eBOX625-312-FL System Unit x 1
eBOX625-312-FL Quick Manual x 1
DVD/CD x 1 (For Driver and User’s Manual)
Screws Pack x 1
Pre-installed Foot pad x 4
DRAM Thermal Pad x 1
HDMI Cable Locking Clip (optional)
12V/60W power adapter (optional)
Power cord (optional)
If you cannot find this package or any items are missing, please contact Axiomtek distributors
immediately.
1.6 Model List
eBOX625-312-FL-DC-
N3350
Fanless Embedded System with Intel®Celeron®N3350 2.4
GHz,HDMI/VGA, 2 GbE LANs, 6 USB, 3 COM and 12 VDC (w/o
power adapter and power cord)
eBOX625-312-FL-DC-
N4200
Fanless Embedded System with Intel®Celeron®N4200 2.5
GHz,HDMI/VGA, 2 GbE LANs, 6 USB, 3 COM and 12 VDC(w/o
power adapter and power cord)

eBOX625-312-FL User’s Manual
Introduction
12
This page is intentionally left blank.
