Installing the DDR Module
Step 1 Make sure system power is off and unplug the power cord.
Step 2 Turn the tBOX300-510-FL upside down, loosen the cover
screws and lift the bracket as shown.
Step 3 Loosen the screws as shown below to remove the
cover and put the thermal pad on the slot.
Step 4 Install the DDR module with caution and put the
thermal pad on the DDR module again. Then screw the
DDR cover to finish the installation.
tBOX300-510-FL Quick Installation Guide
9416N300000E 1
© Copyright 2018 Axiomtek Co., Ltd.
Ver ion A1 December 2018
Printed in Taiwan
Packing List

System Unit x 1

SATA Drive Key x 4

Quick Installation Guide x 1

Wall Mount Bracket x 2

DVD x 1 (for drivers)

DRAM Thermal Pad x 4
Screw Pack x 1 
HDD Mylar x 8

Foot Pad x 4
Note: Please contact your local distributor if any of the above-mentioned
items is missing or damaged. DO NOT apply power to the board if any
component is damaged.
Dimensions
tBOX300-510-FL Embedded System
All manuals and user guides at all-guides.com

2 9416N300000E
© Copyright 2018 Axiomtek Co., Ltd.
Ver ion A1 December 2018
Printed in Taiwan
I/O Outlets
The following figures show the I/O outlets on the front panels of the
tBOX300-510-FL series.
▼
▼▼
▼Front View
Installing the HDD/SSD
Step 1 Attach a Mylar on the HDD/SSD and screw the HDD/SSD
on the tray.
Step 2 Insert the tray into the SATA drive to finish the installation.
9416N300000E 3
© Copyright 2018 Axiomtek Co., Ltd.
Ver ion A1 December 2018
Printed in Taiwan
Installing the Value-added module
Step 1 Unscrew the rear side screws (x2) and then remove the
value-added module slot cover.
Step 2 Insert the value-added module (VAM) as shown below.
Make sure the module is on the track and slide the
module fully into the slot.
Step 3 Secure the module by fastening the screws to finish the
installation.
