AXIOMTEK IPC960-525 Series User manual

IPC960-525 series
IPC962-525 series
IPC964-525 series
Industrial Computers
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate
information. Axiomtek Co., Ltd. assumes no responsibility for any infringements of
patents or any third party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the
accuracy, completeness or usefulness of any information in this document. Axiomtek
does not make any commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any
time without notice.
No part of this document may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written permission of Axiomtek Co., Ltd.
Copyright 2020 Axiomtek Co., Ltd.
All Rights Reserved
November 2020, Version A2
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The IPC960-525/IPC962-525/IPC964-525 Series does not come equipped
with an operating system. An operating system must be loaded first before
installing any software into the computer.
2. Be sure to ground yourself to prevent static charge when installing the
internal components. Use a grounding wrist strap and place all electronic
components in any static-shielded devices. Most electronic components are
sensitive to static electrical charge.
3. Disconnect the power cord from the IPC960-525/IPC962-525/IPC964-525
Series before making any installation. Be sure both the system and the
external devices are turned OFF. Sudden surge of power could ruin
sensitive components. Make sure the IPC960-525/IPC962-525/IPC964-525
Series is properly grounded.
4. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
5. Turn OFF the system power before cleaning. Clean the system using a cloth
only. Do not spray any liquid cleaner directly onto the screen.
6. Do not leave this equipment in an uncontrolled environment where the
storage temperature is below -20℃or above 80℃. It may damage the
equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance
is a must, only a trained technician is allowed to do so. Integrated circuits on
computer boards are sensitive to static electricity. To avoid damaging chips
from electrostatic discharge, observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted
portion of the system unit chassis for a few seconds. This will help to
discharge any static electricity on your body.
When handling boards and components, wear a grounding wrist strap,
available from most electronic component stores.

iv
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against the ingress of water: none
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with
air or with oxygen or nitrous oxide.
4. Mode of operation: Continuous
5. Type of protection against electric shock: Class I equipment
General Cleaning Tips
You may need the following precautions before you begin to clean the computer.
When you clean any single part or component for the computer, please read and
understand the details below fully.
When you need to clean the device, please rub it with a piece of dry cloth.
1. Be cautious of the tiny removable components when you use a vacuum cleaner
to absorb the dirt on the floor.
2. Turn the system off before you start to clean up the component or computer.
3. Never drop the components inside the computer or get circuit board damp or
wet.
4. Be cautious of all kinds of cleaning solvents or chemicals when you use it for
the sake of cleaning. Some individuals may be allergic to the ingredients.
5. Try not to put any food, drink or cigarette around the computer.

v
Cleaning Tools:
Although many companies have created products to help improve the process of
cleaning your computer and peripherals users can also use household items to
clean their computers and peripherals. Below is a listing of items you may need or
want to use while cleaning your computer or computer peripherals.
Keep in mind that some components in your computer may require designated
products for cleaning. If this is the case it will be mentioned in the cleaning
instructions.
Cloth: A piece of cloth is the best tool to use when rubbing up a component.
Although paper towels or tissues can be used on most hardware as well, we
still recommend you to rub it with a piece of cloth.
Water or rubbing alcohol: You may moisten a piece of cloth a bit with some
water or rubbing alcohol and rub it on the computer. Unknown solvents may
be harmful to the plastics parts.
Vacuum cleaner: Vacuuming the dust, dirt, hair, cigarette particles, and other
particles out of a computer can be one of the best methods of cleaning a
computer. Over time these items can restrict the airflow in a computer and
cause circuitry to corrode.
Cotton swabs: Cotton swabs moistened with rubbing alcohol or water are
excellent tools for wiping hard to reach areas in your keyboard, mouse, and
other locations.
Foam swabs: Whenever possible it is better to use lint free swabs such as
foam swabs.
Note: It is strongly recommended that you should shut down the system before you
start to clean any single components.
Note: Please check the temperature of system surface before maintenance.
Please follow the steps below:
1.Close all application programs;
2.Close operating software;
3.Turn off power switch;
4.Remove all device;
5.Pull out the power cable.

vi
Scrap Computer Recycling
Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in
case computers require maintenance or repair; or for recycling in case computers are out of
order or no longer in use.
Trademark Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Pentium®are registered trademarks of Intel Corporation.
Windows 10, Windows 10 IoT Enterprise, Windows 7, are trademarks of Microsoft
Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

vii
Table of Contents
Safety Precautions................................................................................................iii
Classification......................................................................................................... iv
General Cleaning Tips .......................................................................................... iv
Scrap Computer Recycling.................................................................................. vi
SECTION 1 INTRODUCTION.........................................................................1
1.1 General Description...........................................................................1
1.2 System Specifications....................................................................... 2
1.2.1 Main CPU Board...............................................................................................2
1.2.2 I/O System ........................................................................................................3
1.3 Dimensions ........................................................................................8
1.4 I/O Outlets.........................................................................................10
1.5 Packing List...................................................................................... 16
1.6 M/B Block Diagram ..........................................................................17
1.7 Jumper Settings............................................................................... 18
1.7.1 Restore BIOS Optimal Defaults (JP2)..........................................................18
1.7.2 DELAY Function SW (JP10&JP11)...............................................................18
1.8 Connectors....................................................................................... 19
1.8.1 MINI Card Slot (CN4)......................................................................................20
1.8.2 LAN+USB3.0 (CN9, CN10).............................................................................21
1.8.3 VGA Connector (CN3) ..................................................................................22
1.8.4 USB 2.0 Connector (CN13)...........................................................................23
1.8.5 Audio Connector (CN1).................................................................................23
1.8.6 DC-in Phoenix Power Connector (CN12).....................................................23
1.8.7 HDMI Connector (CN2)..................................................................................24
1.8.8 COM Port Connector (COM1 ) ......................................................................24
1.8.9 M.2 2280 Key M NVMe SSD (CN8)................................................................25
1.8.10 M.2 3050 Key B (CN5)....................................................................................26
1.8.11 SATA Power Connector (SCN2)...................................................................27
1.8.12 SATA Connector (SATA1~SATA2) ..............................................................27
1.8.13 Power On/OFF Button (SW2)........................................................................27
1.8.14 AT/ATX Switch (SSW1) .................................................................................28
1.8.15 Remote Power Switch Connector (PWRBT1).............................................28
1.8.16 Flexible IO - COM I/O Card Connector (AX93511)......................................28
1.8.17 Flexible IO –Isolated COM x4 I/O Card (AX93516).....................................29
1.8.18 Flexible IO –Isolated COM & DIO I/O Card (AX93512)...............................30
1.8.19 Flexible IO- USB3.0x2 & COMx2(RS232/422/485) & LAN(AX93519) .........32
1.8.20 Riser Card- PCIe x16 Gen3 & 1 PCIe x4 Gen 3(AX96205)..........................34
1.8.21 Riser Card- PCIe x16 Gen3 & 1 PCI(AX96206)............................................36
1.8.22 Riser Card- 2 PCI (AX96207).........................................................................38
1.8.23 Riser Card- PCIe x16 Gen3 & 3 PCIe x4 Gen 3 (AX96410).........................40
1.8.24 Riser Card- PCIe x16 Gen3 & 1 PCIe x4 Gen 3 & 2 PCI (AX96411)...........42
SECTION 2 HARDWARE INSTALLATION .................................................45
2.1 Installing the Processor ..................................................................45
2.2 Procedure of Installation................................................................46
2.3 Installing the Memory Module......................................................... 47
2.4 Installing the Hard Disk Drive ......................................................... 48
2.5 Installing the expansion box kit...................................................... 50

viii
2.6 Installing the Fan Module................................................................ 53
2.6.1 Installing Internal Fan Module......................................................................53
2.6.2 Installing external Fan Module.....................................................................55
2.7 Installing PCI or PCIe Card.............................................................. 56
2.7.1 Installing PCI or PCIe card............................................................................56
2.7.2 The height limitation of an add-on card ......................................................59
2.7.3 The length limitation of an add-on card ......................................................60
2.7.4 Inatalling T4 graphics card w/T4 fan module..............................................62
2.8 Installing the Mini Card Module ...................................................... 68
2.9 Installing the 5G Wireless Module ..................................................69
2.10 Installing the NVMe SSD Module .................................................... 72
2.11 Mounting........................................................................................... 74
SECTION 3 AMI BIOS UTILITY...................................................................79
3.1 Starting............................................................................................. 79
3.2 Navigation Keys............................................................................... 80
3.3 Main Menu ........................................................................................81
3.4 Advanced Menu ............................................................................... 82
3.5 Chipset Menu ................................................................................... 97
3.6 Security Menu ................................................................................ 102
3.7 Boot Menu ...................................................................................... 103
3.8 Save & Exit Menu........................................................................... 104
APPENDIX A WATCHDOG TIMER ...........................................................107
A.1 About Watchdog Timer.................................................................. 107
A.2 How to Use Watchdog Timer......................................................... 107
APPENDIX B CONFIGURING SATA FOR RAID.......................................111

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
1
SECTION 1
INTRODUCTION
This chapter contains general information and detailed specifications of the IPC960-
525/IPC962-525/IPC964-525 Series. Chapter 1 includes the following sections:
General Description
System Specifications
Dimensions
I/O Outlets
Jumper Settings
Connectors
Package List
1.1 General Description
The IPC960-525 ,IPC962-525 and IPC964-525 are fanless systems with an optional
fan module that can support LGA1151 socket for Intel®9th/8th generation CoreTM
i7/i5/i3 processors. The IPC960-525/IPC962-525/IPC964-525 is also built with a
rugged design that makes the system suitable for the most endurable operation.
For operation systems, the IPC960-525/IPC962-525/IPC964-525 series not only supports
Windows®10 and Ubuntu, but also supports embedded OS.
The IPC960-525/IPC962-525/IPC964-525 Series supports two hard-drive bays to
make it easy for customers to install and maintain the system.
Embedded O.S. supported

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
2
1.2 System Specifications
1.2.1 Main CPU Board
CPU
Socket LGA1151 for 9th / 8th Generation Intel®CoreTM i7/i5/i3 processors, up to
65W
Below is a list of supported CPUs.
Generation
Proc No
WATT
Core
Thread
Base frequency
Coffee Lake-S refresh
i9-9900
65
8
16
3.1 GHz
Coffee Lake-S refresh
i5-9600
65
6
6
3.1 GHz
Coffee Lake-S refresh
i5-9500F
65
6
6
3.0 GHz
Coffee Lake-S refresh
i5-9500E
65
6
6
3.0 GHz
Coffee Lake-S refresh
i5-9500
65
6
6
3.0 GHz
Coffee Lake-S refresh
i5-9400F
65
6
6
2.9 GHz
Coffee Lake-S refresh
i5-9400
65
6
6
2.9 GHz
Coffee Lake-S refresh
i3-9100F
65
4
4
3.6 GHz
Coffee Lake-S refresh
i3-9100
65
4
4
3.6 GHz
Coffee Lake-S refresh
i3-9320
62
4
4
3.7 GHz
Coffee Lake-S refresh
i3-9300
62
4
4
3.7 GHz
Coffee Lake-S refresh
G4950
54
2
2
3.3 GHz
Coffee Lake-S refresh
G4930
54
2
2
3.2 GHz
Coffee Lake-S refresh
i7-9700TE
35
8
8
1.8 GHz
Coffee Lake-S refresh
i7-9700T
35
8
8
2.0 GHz
Coffee Lake-S refresh
i5-9600T
35
6
6
2.3 GHz
Coffee Lake-S refresh
i5-9500TE
35
6
6
2.2 GHz
Coffee Lake-S refresh
i5-9500T
35
6
6
2.2 GHz
Coffee Lake-S refresh
i5-9400T
35
6
6
1.8 GHz
Coffee Lake-S refresh
i3-9300T
35
4
4
3.2 GHz
Coffee Lake-S refresh
i3-9100TE
35
4
4
2.2 GHz
Coffee Lake-S refresh
i3-9100T
35
4
4
3.1 GHz
Coffee Lake-S refresh
G4930T
35
2
2
3.0 GHz
Coffee Lake-S
i7-8700
65
6
12
3.2 GHz
Coffee Lake-S
i5-8600
65
6
6
3.1 GHz
Coffee Lake-S
i5-8500
65
6
6
3.0 GHz
Coffee Lake-S
i5-8400
65
6
6
2.8 GHz
Coffee Lake-S
i3-8100
65
4
4
3.6 GHz
Coffee Lake-S
i3-8300
62
4
4
3.7 GHz
Coffee Lake-S
G5400
58
2
4
3.7 GHz
Coffee Lake-S
G4900
54
2
2
3.1 GHz

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
3
Coffee Lake-S
G4920
54
2
2
3.2 GHz
Coffee Lake-S
i7-8700T
35
6
12
2.4 GHz
Coffee Lake-S
i5-8600T
35
6
6
2.3 GHz
Coffee Lake-S
i5-8500T
35
6
6
2.1 GHz
Coffee Lake-S
i5-8400T
35
6
6
1.7 GHz
Coffee Lake-S
i3-8100T
35
4
4
3.1 GHz
Coffee Lake-S
i3-8300T
35
4
4
3.2 GHz
Coffee Lake-S
G5400T
35
2
4
3.1 GHz
Coffee Lake-S
G4900T
35
2
2
2.9 GHz
System Chipset
Intel®H310 chipset (IPC960-525-H310-DC-FL/IPC962-525-H310-DC-FL)
Intel®Q370 chipset (IPC960-525-Q370--DC-FL/IPC962-525-Q370-DC-FL-/IPC964-
525-Q370-DC-FL)
BIOS
AMI BIOS, with Smart View and Customer CMOS Backup.
System Memory
Two DDR4-2666/2400 un-buffered SO-DIMM max. up to 64GB
System Certification
CE/FCC
Features
Compact front IO design
Supports PCIe/PCI expansion slots
DC to DC power supply support 24VDC (uMin=19V/uMax=30V)
Supports two 2.5" HDD bays (7/9.5mm height)
Supports RAID 0,1 (for Q370 PCH)
Supports TPM2.0
Supports optional 5G mobile module (for Q370 PCH) or WLAN module & antennas
Supports optional fan module (for IPC962 and IPC964)
1.2.2 I/O System
Standard I/O Interface -- Front
One ATX power on/off switch w/LED
One ATX/AT mode switch
One 2-pin connector output for remote power on/off switch
DC to DC power supply, which supports 24VDC (uMin=19V/uMax=30V) with
phoenix power plug
Four USB 3.1 Gen.2 ports (for Q370 PCH) or
Four USB3.1 Gen.1 ports (for H310 PCH)

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
4
Two USB 2.0 ports
Note: IPC960-525 series support a internal USB2.0 with 180D type A connector for
license key, up to 30mm)
One HDD/SSD access LED
Three user’s LEDs
Two G.E. LAN ports (i211AT & I219LM)
Extension system I/O module:
AX93511 4 x RS-232/422/485 module (default RS-232) or
AX93512 2 x RS-232/422/485 w/ isolated 1.5KVDC protection and
8-in/8-out isolated 1.5KVDC DIO or
AX93516 4 x RS232/422/485 w/isolated 2KVDC module
AX93519 2 x RS232/422/485 + 1 G.E. LAN (i211AT) + 2 USB.3.1 (1 USB3.1
Gen.2 signal & 1 USB 2.0 signal) (for Q370 PCH) or
AX93519 2 x RS232/422/485 + 1 G.E. LAN (i211AT) + 2 USB.3.1 (2 USB 2.0
signal) (for H310 PCH)
Note: The RS-485 auto flow control only supports below formats to communicate data:
8 data bits + 1 stop bit
8 data bits + 1 parity bit + 1 stop bit
8 data bits + 1 parity bit + 2 stop bits
8 data bits + 2 stop bits
7 data bits + 1 parity bit (even or odd) + 2 stop bits
One VGA supports resolution up to 1920 x 1200 @60Hz
One HDMI 1.4b supports resolution up to 4096 x 2160@24MHz
1 x Audio (Line-out)
Expansion Interface
IPC962-525-H310 / IPC962-525-Q370
Mini card slot
1 x on board full-size PCI Express Mini Card slot with USB interface (for H310 PCH)
or
1 x on board full-size PCI Express Mini Card slot with USB/PCIe interface (for Q370
PCH)
PCIe/PCI slot
1 x AX96205: 1 PCIe x16 + 1 PCIe x4 or
1 x AX96206: 1 PCIe x16 + 1 PCI or
1 x AX96207: 2 PCI
IPC964-525-Q370
Mini Card slot
1 x on board full-size PCI Express Mini Card slot with USB/PCIe interface
PCIe/PCI slot

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
5
1 x AX96410: 1 PCIex16 + 3 PCIex4 or
1 x AX96411: 1 PCIex16 + 1 PCIex4 + 2PCI
Note: The maximum power rating for expansion slots at 60 ℃ cannot exceed
the following value:
The maximum loading of +3.3V+5V+12V<150W
Note: 12V maximum loading is 12A(144W).
Note: The system power rating may thus be changed base on differing combinations of
attached devices.
Drive Capacity
Supports two 2.5”HDD driver bays (SSD/HDD 7 or 9.5mm height)
Note: Since Gen. 2 SSD with JMicron controller has a compatibility issue with
Intel H310 PCH, it is strongly recommended to use Gen. 3 SSD on the
IPC962 Series.
Power Input
24VDC (uMin=19V/uMax=30V) with phoenix power plug
Note: Please fix the system power input in 24Vdc when plugging an add-on card.
Operating Temperature
Generation
Proc No
WATT
Core
Thread
Operating
Temperature
Remark
Base
frequency
Coffee Lake-S
refresh
i9-9900
65
8
16
-10℃-50℃
*
3.1 GHz
Coffee Lake-S
refresh
i5-9600
65
6
6
-10℃-50℃
*
3.1 GHz
Coffee Lake-S
refresh
i5-9500F
65
6
6
-10℃-50℃
*
3.0 GHz
Coffee Lake-S
refresh
i5-9500E
65
6
6
-10℃-50℃
*
3.0 GHz
Coffee Lake-S
refresh
i5-9500
65
6
6
-10℃-50℃
*
3.0 GHz
Coffee Lake-S
refresh
i5-9400F
65
6
6
-10℃-50℃
*
2.9 GHz
Coffee Lake-S
refresh
i5-9400
65
6
6
-10℃-50℃
*
2.9 GHz
Coffee Lake-S
refresh
i3-9100F
65
4
4
-10℃-50℃
3.6 GHz
Coffee Lake-S
refresh
i3-9100
65
4
4
-10℃-50℃
3.6 GHz
Coffee Lake-S
refresh
i3-9320
62
4
4
-10℃-50℃
3.7 GHz

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
6
Coffee Lake-S
refresh
i3-9300
62
4
4
-10℃-50℃
3.7 GHz
Coffee Lake-S
refresh
G4950
54
2
2
-10℃-50℃
3.3 GHz
Coffee Lake-S
refresh
G4930
54
2
2
-10℃-50℃
3.2 GHz
Coffee Lake-S
refresh
i7-9700TE
35
8
8
-10℃-60℃
*
1.8 GHz
Coffee Lake-S
refresh
i7-9700T
35
8
8
-10℃-60℃
*
2.0 GHz
Coffee Lake-S
refresh
i5-9600T
35
6
6
-10℃-60℃
*
2.3 GHz
Coffee Lake-S
refresh
i5-9500TE
35
6
6
-10℃-60℃
*
2.2 GHz
Coffee Lake-S
refresh
i5-9500T
35
6
6
-10℃-60℃
*
2.2 GHz
Coffee Lake-S
refresh
i5-9400T
35
6
6
-10℃-60℃
*
1.8 GHz
Coffee Lake-S
refresh
i3-9300T
35
4
4
-10℃-60℃
3.2 GHz
Coffee Lake-S
refresh
i3-9100TE
35
4
4
-10℃-60℃
2.2 GHz
Coffee Lake-S
refresh
i3-9100T
35
4
4
-10℃-60℃
3.1 GHz
Coffee Lake-S
refresh
G4930T
35
2
2
-10℃-60℃
3.0 GHz
Coffee Lake-S
i7-8700
65
6
12
-10℃-50℃
*
3.2 GHz
Coffee Lake-S
i5-8600
65
6
6
-10℃-50℃
3.1 GHz
Coffee Lake-S
i5-8500
65
6
6
-10℃-50℃
*
3.0 GHz
Coffee Lake-S
i5-8400
65
6
6
-10℃-50℃
*
2.8 GHz
Coffee Lake-S
i3-8100
65
4
4
-10℃-50℃
3.6 GHz
Coffee Lake-S
i3-8300
62
4
4
-10℃-50℃
3.7 GHz
Coffee Lake-S
G5400
58
2
4
-10℃-50℃
3.7 GHz
Coffee Lake-S
G4900
54
2
2
-10℃-50℃
3.1 GHz
Coffee Lake-S
G4920
54
2
2
-10℃-50℃
3.2 GHz
Coffee Lake-S
i7-8700T
35
6
12
-10℃-60℃
*
2.4 GHz
Coffee Lake-S
i5-8600T
35
6
6
-10℃-60℃
2.3 GHz
Coffee Lake-S
i5-8500T
35
6
6
-10℃-60℃
2.1 GHz
Coffee Lake-S
i5-8400T
35
6
6
-10℃-60℃
1.7 GHz
Coffee Lake-S
i3-8100T
35
4
4
-10℃-60℃
3.1 GHz
Coffee Lake-S
i3-8300T
35
4
4
-10℃-60℃
3.2 GHz

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
7
Coffee Lake-S
G5400T
35
2
4
-10℃-60℃
3.1 GHz
Coffee Lake-S
G4900T
35
2
2
-10℃-60℃
2.9 GHz
* The IPC system may cause CPU frequency hopping when operating in an extremely high
temperature environment, and thermal throttling may occur when the system remains in
full loading conditions.
Note: The performance of the system might be adversely affected when operating
at a temperature above the system’s limitation or with an unrecommended
processor.
Note: If the operating temperature is above 35 ° C, it is recommended to use a wide
temperature SSD on the device.
Storage Temperature
-20℃~ 80℃
Humidity
10% ~ 90% (Non-condensing)
Dimensions
IPC960-525
83.5 mm (3.28") (W) x 192 mm (7.54") (H) x 230 mm (9.04") (D)
IPC962-525
147.5 mm (5.81") (W) x 192 mm (7.56") (H) x 230 mm (9.04") (D)
IPC964-525
188.1 mm (7.39") (W) x 192 mm (7.54") (H) x 230 mm (9.04") (D)
Note: All specifications and images are subject to change without notice.

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
8
1.3 Dimensions
The following diagrams show you dimensions and outlines of the IPC960-525/IPC962-
525/IPC964-525 Series.
IPC960-525
IPC962-525

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
9
IPC964-525

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
10
1.4 I/O Outlets
The following figures show locations of the IPC900 series I/O outlets
IPC960-525 Front Panel
Mark
Description
1
1 x HDD/SSD access LED
3 x User's LED
2
1 x 4-pin terminal block
3
1 x RS-232/422/485 (default RS-232)
4
2 x LAN

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
11
5
1 x VGA
6
1 x HDMI
7
1 x Switch for power on/off w/LED
8
Extension system I/O module
9
1 x Line out
10
1 x Remote switch
11
2 x USB2.0
12
4 x USB 3.1
13
1 x AT/ATX switch (default ATX)
14
1 x Terminal ground

IPC960/IPC962/IPC964-525 Series User’s Manual
Introduction
12
IPC962-525 Front Panel
Mark
Description
1
1 x HDD/SSD access LED
3 x User's LED
2
1 x 4-pin terminal block
3
1 x RS-232/422/485 (default RS-232)
4
2 x LAN
5
1 x VGA
6
1 x HDMI
