GOT-5571TL-621
5.7 VGATFT Fanless
Touch Panel Computer
User’s Manual

ii
Disclaimers
This manual has been carefullychecked and believedto contain
accurate information. AXIOMTEK Co., Ltd. assumes no responsibility
for anyinfringements ofpatents or anythird partys rights, and any
liabilityarising fromsuch use.
AXIOMTEK does notwarrant or assume anylegal liabilityor
responsibilityfor the accuracy,completeness or usefulness ofany
information in this document. AXIOMTEK does not make any
commitment to update the information in this manual.
AXIOMTEK reserves theright to change or revise thisdocument
and/or product at anytime without notice.
No part ofthis document maybe reproduced, stored ina retrieval
system, or transmitted, in anyformor byanymeans, electronic,
mechanical, photocopying, recording, or otherwise, without the prior
writtenpermission ofAXIOMTEK Co., Ltd.
Copyright 2009 AXIOMTEK Co., Ltd.
All Rights Reserved
April 2009, Version A1
Printed in Taiwan

iii
SafetyApprovals
uCE Marking
uFCC Class A
uFCC Compliance
This equipment has been tested in compliance with the limitsfor a
Class Adigital device, pursuant to Part 15 oftheFCC Rules. These
limits are meant to provide reasonableprotection against harmful
interference in a residential installation. Ifnotinstalled and used in
accordance with proper instructions, this equipment might generate or
radiateradio frequency energy andcause harmful interference to radio
communications. However,there is no guarantee that interference will
not occur in a particular installation. Ifthis equipment does cause
harmful interference to radio or television reception, which canbe
determined byturning the equipment offand on,theuser is
encouraged to tryto correctthe interference byone or more ofthe
following methods:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect theequipment to another outlet ofa circuit that
doesn t connect with the receiver.
4. Consult the dealer or an experienced radio/TV technician for
help.
Shieldedinterface cables must be used in order to complywith the
emission limits.

iv
SafetyPrecautions
Before getting started, please read the followingimportant safety
precautions.
1. The GOT-5571TL-621 does not come equippedwith an
operating system. An operatingsystemmust be loadedfirst
before installing anysoftware into the computer.
2. Be sure to groundyourself to prevent static charge when
installing the internal components. Use a grounding wrist
strap andplace all electronic components in any
static-shielded devices. Most electronic components are
sensitive to static electricalcharge.
3. Disconnect the power cord fromthe GOT-5571TL-621 before
anyinstallation.Be sure both the systemand external
devices are turned OFF. A suddensurge ofpower could ruin
sensitive components that the GOT-5571TL-621 must be
properlygrounded.
4. The brightness ofthe flat panel displaywill be getting weaker
as a resultoffrequent usage. However, the operating period
varies depending on the application environment.
5. Turn OFF the systempower before cleaning. Clean the
systemusing a cloth only.Do not sprayanyliquid cleaner
directlyonto the screen. The GOT-5571TL-621 maycome
with or w/o a touch screen. Although the touch screen is
chemical resistant, it is recommended that you spraythe
liquid cleaner onaclothfirst before wipingthescreen.Incase
yoursystemcomes withoutthetouch screen, youmust follow
the same procedure andnot sprayanycleaner on the flat
panel directly.
6. Avoidusing sharpobjects to operate the touch screen.
Scratches onthetouchscreen maycause malfunction or
internal failureto the touch screen.
7. The flat paneldisplayis notsusceptible to shockor vibration.
When assemblingthe GOT-5571TL-621, make sure it is
securelyinstalled.
8. Do notopenthesystem sbackcover. Ifopeningthecover for
maintenance is a must, onlya trained technician is allowed to
do so. Integratedcircuits on computer boards aresensitive to
static electricity. To avoid damaging chips fromelectrostatic
discharge, observe the followingprecautions:

v
lBefore handling a board or integrated circuit, touch an
unpainted portion ofthe systemunit chassis for a few
seconds. This will help to discharge anystatic electricity
on your body.
lWhen handling boards and components, wear a
wrist-grounding strap, available frommost electronic
component stores.
TrademarksAcknowledgments
AXIOMTEK is a trademarkofAXIOMTEK Co., Ltd.
IBM, PC/AT, PS/2, VGAaretrademarks ofInternational
Business Machines Corporation.
Intel®and Pentium®are registeredtrademarks ofIntel Corporation.
MS-DOS, Microsoft C and QuickBASIC are trademarks ofMicrosoft
Corporation.
VIA is a trademarkofVIA Technologies, Inc.
SSTis a trademarkofSilicon Storage Technology, Inc.
UMC is a trademarkofUnited Microelectronics Corporation.
Other brand names and trademarks are the properties and registered
brands oftheir respective owners.

vi
Tableof Contents
Disclaimers....................................................................................ii
SafetyApprovals..........................................................................iii
SafetyPrecautions.......................................................................iv
CHAPTER 1 INTRODUCTION..........................................................1
1.1 General Description.....................................................1
1.2 Specifications..............................................................2
1.2.1 Main CPU board..........................................................2
1.2.2 I/O System...................................................................2
1.2.3 SystemSpecification...................................................3
1.3 Dimensions..................................................................3
1.4 I/O Outlets...................................................................5
1.5 Package list.................................................................6
CHAPTER 2 HARDWARE INTALLATION.........................................7
2.1 CompactFlash Card Installation..................................8
2.2 PC/104 Installation......................................................9
2.3 Serial Port Interface...................................................10
2.4 Ethernet.....................................................................12
2.5 MountingWay:Panel mount.....................................12
2.6 Wireless LAN Card Installation..................................14
CHAPTER 3 PHOENIX-AWARD BIOS UTILITY.............................16
3.1 EnteringSetup...........................................................16
3.2 Control Keys..............................................................17
3.3 Getting Help...............................................................17
3.4 The MainMenu..........................................................18
3.5 Standard CMOS SetupMenu....................................19
3.6 Advanced BIOS Features..........................................22
3.7 Advanced ChipsetFeatures......................................25
3.8 Integrated Peripherals...............................................27
3.9 Power Management Setup........................................32
3.10 PnP/PCI ConfigurationSetup....................................34
3.11 PC HealthStatus.......................................................36
3.12 LoadOptimized Defaults...........................................37
3.13 Set Supervisor/User Password.................................38
3.14 Save & Exit Setup.....................................................39
3.15 Exit Without Saving...................................................40
CHAPTER 4 DRIVER INSTALLATION............................................42
4.1 System.......................................................................42
4.2 Touch Screen............................................................43

vii
4.2.1 Specification..............................................................43
4.2.2 Driver Installation - Windows XP...............................44
Appendix..........................................................................................47

viii
MEMO

GOT-5571TL-621 User sManual
Introduction 1
CHAPTER 1
INTRODUCTION
This chapter contains the general informationandthedetail
specifications oftheGOT-5571TL-621. Chapter 1includes the
following sections:
nGeneral Description
nSystem Specification
nDimensions
nI/O Outlets
nPackage List
1.1 General Description
The GOT-5571TL-621 is a5.7”fanless TFT VGAtouchpanelcomputer.
It is equippedwith CISC-based lowpower consumptionprocessor,
AMD LX800.
Bysupporting theoptionofexternalbatteryset,theGOT-5571TL-621
can continuesystemoperation ifa main power shortage ever happens.
In addition, thePC/104andMini-PCI slotsarereservedfor expansion
availability.
The GOT-5571TL-621 supportsCompactFlash card and is thebest
choice for applications of factoryautomation, machinerymaker,
building automation and semi-conductor.

GOT-5571TL-621 User sManual
Introduction 2
1.2 Specifications
1.2.1 Main CPU board
nCPU: AMDLX800 500MHz
nSystem Chipset: AMD LX + CS5536AD
nBIOS: Phoenix-Award 4Mbit with RPL/PXEEthernetBoot
ROM,Smartviewand customer CMOSbackup.
nSystemMemory: One 200-pin DDR SODIMM
Maximumup to1GB
1.2.2 I/O System
nStandard I/O:
−2 x serialports (1x RS-232, 1 x RS-232/422/485)
−2 x USBPorts 2.0compliant
nEthernet:
−Equippedwith1 x RJ-45for 10/100base-T
nAudio:
−RealtekAC 97 codec audio (Line-out)
nExpansion:
−Equippedwith1 x Mini-PCI &1 x PC/104
nCompact Flash Socket:
−One Compact Flash Type II Socket

GOT-5571TL-621 User sManual
Introduction 3
1.2.3System Specification
n5.7 VGATFTLCD
nDisk drive housing:
−1 x Compact Flash Type II Socket
nDC 24V power input
nHeatdispensingdesign
nNet weight:
−2.0kg
nDimension (main bodysize):
−208.5x 167.3x 66.5 mm
nOperating temperature:
−0°Cto 45°C;Relative umidity:50%
nRelative humidity:
−10%to85% @40°C, non-condensing
nAltitude:
−10,000 ft.(3,000 meters)
nVibration (operating):
−5 to500 Hz,2G random
nShock (operating):
−10 Gpeakacceleration (11 msec. duration)
1.3 Dimensions
The following diagramsshowthedimensions and outlines of
GOT-5571TL-621.

GOT-5571TL-621 User sManual
Introduction 4
Note: The unit oflength is millimeter.

GOT-5571TL-621 User sManual
Introduction 5
1.4 I/O Outlets
The following figure showsthe I/O locations ofthe GOT-5571TL-621.
1: Power Switch 6: LAN
2: DC power connector 7: USB 2.0x 2
3: COM 2 (RS-232) 8: Line-out
4: COM 1 (RS-232/422/485) 9: CompactFlash card
5: PC/104 slot

GOT-5571TL-621 User sManual
Introduction 6
1.5 Package list
When you receive the GOT-5571TL-621, the bundledpackage should
contain the following items:
1. GOT-5571TL-621 x 1
2. Panel mount kit x 6
3. Driver CD x1
4. Wireless LAN kit x 1 (Optional)
Ifyouhave any demand for theoptionalitemsor any itemsare missing,
please contactAXIOMTEK distributors immediately.
`

GOT-5571TL-621 User sManual
Hardware Installation 7
CHAPTER 2
HARDWARE INTALLATION
The GOT-5571TL-621 provides rich I/O portsand flexible expansions
for you tomeet different demand such as PCMCIA, WLAN module and
so on. The chapter will showyouhowtoinstall thehardware. It
includes:
nCompactFlash Card
nPC/104
nSerial Port
nEthernet
nMountingWay
nWireless LAN Card

GOT-5571TL-621 User sManual
Hardware Installation 8
2.1 CompactFlashCardInstallation
GOT-5571TL-621 offers one CF slot for users to install CompactFlash
card. Please refer to thefollowing instructions and illustration:
Remove the rubber cover at left-side.
Install CompactFlash cardin theGOT-5571TL-621.

GOT-5571TL-621 User sManual
Hardware Installation 9
2.2 PC/104 Installation
The GOT-5571TL-621 offers aconvenient expansion for users to
install PC/104module suchas PCMCIA,WLAN, COM portcard and
so on. Please followthe steps:
1. Unscrewscrews to remove the bracket.
2. Install PC/104 module.

GOT-5571TL-621 User sManual
Hardware Installation 10
PC/104 Bus Pin Assignment
Pin Pin Name Pin Pin Name Pin Pin Name Pin Pin Name
1 IOCHCHK 2 GND 3 SD7 4 RESETDRV
5 SD6 6 +5V 7 SD5 8 IRQ9
9 SD4 10 -5V 11 SD3 12 DRQ2
13 SD2 14 -12V 15 SD1 16 ENDXFR
17 SD0 18 +12V 19 IOCHRDY 20 GND
21 AEN 22 SMEMW23 SA19 24 SMEMR
25 SA18 26 IOW27 SA17 28 IOR
29 SA16 30 DACK3 31 SA15 32 DRQ3
33 SA14 34 DACK1 35 SA13 36 DRQ1
37 SA12 38 REFRESH 39 SA11 40 SYSCLK
41 SA10 42 IRQ7 43 SA9 44 IRQ6
45 SA8 46 IRQ5 47 SA7 48 IRQ4
49 SA6 50 IRQ3 51 SA5 52 DACK2
53 SA4 54 TC 55 SA3 56 SALE
57 SA2 58 +5V 59 SA1 60 OSC
61 SA0 62 GND 63 GND 64 GND
2.3 Serial Port Interface
The GOT-5571TL-621 has twoonboard serial ports, COM1

GOT-5571TL-621 User sManual
Hardware Installation 11
(RS-232/422/485) & COM2(RS-232).
The pin assignments are listed below:
Description
1Data Carrier Detect (DCD)
2Receive Data (RXD)
3Transmit Data (TXD)
4Data Terminal Ready (DTR)
5Ground (GND)
6Data Set Ready (DSR)
7Request to Send (RTS)
8Clear to Send (CTS)
9Ring Indicator (RI)
In addition, COM1can be set for RS-232/422/485 byjumper.The jump
setting is listed as below:
COM1 JP12 JP10 JP11
RS-232 (default) 1-2 3-5, 4-6 3-5, 4-6
RS-422 3-4, 7-8 1-3, 2-4 1-3, 2-4
RS-485 5-6, 7-8 1-3, 2-4 1-3, 2-4
When COM1 set to RS-422or RS-485, the pin assignments are listed
below:
COM2 COM1

GOT-5571TL-621 User sManual
Hardware Installation 12
2.4 Ethernet
The GOT-5571TL-621 provides anNE2000 compatibleEthernet
(RJ-45) interface. For networkconnection, just plugin one cable end of
the GOT-5571TL-621 10/100 Base-T Hub into the standard RJ-45
connector.The pin assignment ofthe RJ-45 is listed below;
Pin Signal
1 TX+ (Data transmission positive
2 TX- (Data transmission negative)
3 Rx+(Data reception positive)
4 RJ45 termination
5 RJ45 termination
6 Rx- (Data reception negative)
7 RJ45 termination
8 RJ45 termination
2.5 Mounting Way: Panel mount
The GOT-5571TL-621 is designedfor panel mount application. To
mount the GOT-5571TL-621, thestandard set of mountingkit
(included in the systempackaging) is needed.
12345678
RJ-45
