Bay-Tek Spin-N-Win! User manual

1

2
FACTORY CONTACT INFORMATION
BAY TEK GAMES INC.
Pulaski Industrial Park
1077 East. Glenbrook Drive
Pulaski, WI 54162 USA
PARTS
P: 920.822.3951 X 1101
F: 920.822.1496
E: [e-mail]
MON - FRI
8 AM - 5 PM C.S.T.
SERVICE
P: 920.822.3951 X 1102
F: 920.822.1496
E: [e-mail]
SALES
P: 920.822.3951
F: 920.822.8936
E: [e-mail]
All games are proudly manufactured at our factory in Pulaski, Wisconsin, USA
JOIN OUR SERVICE FIRST NETWORK!
This free service is intended to keep you up to date on the latest game
information, early notication of parts specials, pertinent technical bulle-
tins, updates on retro t parts, software upgrades, and much more.
Log on to: www.baytekgames.com/parts
then click on the Parts N’ Service tab, or scan the QR code below with
your Smartphone to jump straight to this game’s parts page!
Scan here!

3
TABLE OF CONTENTS
FACTORY CONTACT INFORMATION .................................. 2
WELCOME TO: SPIN-N-WIN ......................................... 4
SPECIFICATIONS.................................................. 5
SAFETY PRECAUTIONS ............................................ 5
HOW TO PLAY .................................................... 6
SET UP GUIDE ..................................................7-16
DIP SWITCH SETTINGS ........................................... 17
MAIN MENU FUNCTIONS ........................................18-26
TICKET PATTERNS .............................................27-28
MAINBOARD PINOUT ............................................. 29
MAINBOARD PINOUT GUIDE ....................................... 30
HOW TO: ACCESS DISPLAY ........................................ 31
HOW TO: REPLACE STOP BUTTON.................................. 31
HOW TO: ACCESS LIGHT BULB WIRING .............................. 31
CIRCUIT BOARD LAYOUT .......................................... 32
TICKET DISPENSERS, HANDLE SWITCH & COIN WIRING DIAGRAM ...... 33
UPPER SECTION POWER SUPPLY WIRING DIAGRAM .................. 34
LOWER SECTION POWER SUPPLY WIRING DIAGRAM.................. 35
LED WIRING DIAGRAM ............................................ 36
LED BULB WIRING DIAGRAM....................................... 37
DIAGNOSTICS .................................................38-39
DECAL DIAGRAM................................................. 40
TROUBLE SHOOTING GUIDE.....................................41-45
PARTS LIST ..................................................... 46
PARTS PICTURES ................................................ 47
MAINTENANCE LOG .............................................. 48
TECHNICAL SUPPORT ............................................ 49
WARRANTY ..................................................... 50

4
WELCOME TO: Spin-N-Win
Congratulations on your purchase!
With it’s bright and colorful vertical presence, Spin-N-Win is sure to grab the attention
of your customers! Having to hit STOP at just the right time with have them spinning
again and again!
Please take a moment to read through this manual and be sure to contact our factory if
you have any questions, or would like some more information.
Thank you for your purchase! Your business is important to us and we hope you enjoy
this game as much as we do!
Your Friends at Bay Tek Games
GAME INSPECTION
Inspect the game for any damaged, loose, or missing parts.
If damage is found, please contact your freight carrier rst.
Then, contact Bay Tek Games’ Service Department at 920.822.3951
or e-mail them at [email protected] for further assistance.

5
GAME SPECIFICATIONS
SAFETY PRECAUTIONS
WEIGHT
NET WEIGHT 485 LBS.
SHIP WEIGHT 540 LBS.
DIMENSIONS
WIDTH 73”
DEPTH 71”
HEIGHT 137”
OPERATING TEMPERATURE
FAHRENHEIT 80-100
CELSIUS 26.7-37.8
POWER REQUIREMENTS
INPUT VOLTAGE
RANGE
100 to 120
VAC /220 to 240 VAC
INPUT FREQUENCY
RANGE 50 HZ / 60 HZ
MAX OPERATING
CURRENT
6.0 AMPS @ 115 VAC
3.5 AMPS @ 230 VAC
DANGER
DO NOT perform repairs or maintenance on this game with the power ON.
Unplug the unit from the wall outlet or shut off the power strip located inside the cabinet.
!!
NOTICE
Modications to the mechanical, electrical and structural components of this game
may void its compliance certications.
!!
WARNING
Use of ammable subtances can cause sever burns or serious injury.
Always use NON-FLAMMABLE solvents for cleaning. DO NOT use gasoline kerosene or thinners.
!!
CAUTION
Lifting heavy objects can cause back, neck or other injuries. Be sure adequate lifting and moving
devices are available when unloading, unpacking and moving this game.
!!
ATTENTION
Be sure the electrical power matches the game requirements. See the serial number located on the
back of the game cabinet. Always plug into a grounded circuit. If the supply cord is damaged, it must
be replaced by an approved cord or assembly provided by the manufacturer.
A shielded power cable must be used for the game to retain EU/EMC compliance.
!!
IN CASE OF EMERGENCY
UNPLUG THE POWER CORD.
The power cord must be accessible at all times in case of an emergency.
!!
This appliance is suitable for INDOOR, DRY locations only.

6
HOW TO PLAY
Pull the handle to start game play.
Time your play and press the button to stop lights
on the highest ticket values.
Win tickets based on the value of the space where
you stopped the the light!

7
SET UP GUIDE
Safely lift the marquee off the top of the console.
Set the marquee off to the side for the time being.
With assistance, carefully lift the playeld off the
support beams and lean against a sturdy support
for the time being.
TOOLS NEEDED FOR SET UP:
• 9/16” wrench or socket and impact
• Snips
• Step ladder
• 3 strong people

8
SET UP GUIDE
Use the key taped to the top of the console to
open the cash box door and remove the hardware
kit inside.
Remove the two longest bolts from the hardware
kit along with two lock washers and two regular
washers. Put the 9/16” socket onto the impact or
have your wrench readily available.

9
SET UP GUIDE
Carefully lift the marquee piece up and set into
place on top of the playeld.
The marquee piece will slide in behind the wood
piece attached to the back of the playeld.
Secure the marquee to the playeld using the two
long bolts and washers.

10
SET UP GUIDE
Open the left side door on the back of the
playeld.
Locate cables CE6921, CE6938 and CE6942 -
these will be hanging down from the inside top of
the playeld.
Route all three cables up and out the hole on the
back of the playeld.

11
SET UP GUIDE
Plug in cables CE6921, CE6938 and CE6942
(that were ran up from the playeld) into their
corresponding match that are fed out the back of
the marquee.
Route excess cables back down into the hole on
the back of the playeld. If desired, use the wire
loom located inside the cash box and wrap around
the cables to cover and protect them.
Close the back door on the playeld, ONLY LOCK
THE BOTTOM LOCK!

12
SET UP GUIDE
Push the handle all the way down until it “clicks”
and stays in the down position.
*This next step of lifting the playeld/marquee up
and top of the console will require three people.
With one person on each of the sides and a
spotter in the front, safely and carefully lift the
playeld/marquee on top of the console.

13
SET UP GUIDE
Once in place, use the six remaining bolts, lock
washers and regular washers from the hardware
kit to secure the playeld to the support beams.
Three bolts will go in each support beam.

14
SET UP GUIDE
Unlock the bottom lock on the left side rear door
of the playeld - if needed, use a step ladder to
reach.
Down inside the playeld, nd the gray ribbon
cable (CE6924) that is bundled up. Use the snips
to free the cable.
Route the cable down the oval cut out at the
bottom of the playeld. The cable should fall down
inside the console.
Remove the back door from the bottom
console.

15
SET UP GUIDE
In addition to the gray ribbon cable, locate cables
CE6901, CE6909 and CE6937. Route these
cables down the same oval cut out as the ribbon
cable. These will fall inside the console.
Plug in cables CE6901, CE6909 and CE6937 into
their corresponding match that are already inside
the console.

16
SET UP GUIDE
Route the ribbon cable (CE6924) to the front of the
console and over the circuit board platform.
From the front of the console, plug in the ribbon
cable to its housing located at the top right corner
of the platform.
Route the power cable to a standard outlet and
plug in.
Close, replace and lock all doors.
You are now ready to Spin-N-Win!

17
DIP SWITCH SETTINGS
The dip switch bank is located on the mainboard,
inside the right side, front door of the game.
*factory default settings are highlighted below
SWITCH DESCRIPTION ON OFF
1 X
2 NEW JERSEY PROGRAMMING X
3 X
4 X

18
MAIN MENU FUNCTIONS
MENU DESCRIPTION
N1 Credits Per Play
N2 Game Volume
N3 Attract Volume
N4 Attract Timing
N5 Ticket Pattern
N6 Mercy Tickets
N7 1/2 Ticket Dispense
N8 Fixed Ticket Payout
N9 Stored Tickets/Credits
N10 No Pull Timeout
N11 No Play Timeout
N12 Score Display
N13 Jackpot Window
N14 LED Brightness
N15 Tickets/Points
N16 Operation
N17 Call Attendant
N18 Jackpot Bell
N19 Statistics
N20 Clear Statistics
N21 Switch Test
N22 Light Test
N23 Reset Factory Defaults

19
N1- COINS/CREDITS PER PLAY
N2- GAME VOLUME
N3- ATTRACT VOLUME
012345678
Scroll through the N1 menu with the “MENU” button.
Make your selection with the “SELECT” button.
The factory settings are highlighted below.
0 1 2 3 4 5 6 7 8 9 10
0 1 2 3 4 5 6 7 8 9 10
Scroll through the N2 menu with the “MENU” button.
Make your selection with the “SELECT” button.
The factory settings are highlighted below.
Scroll through the N3 menu with the “MENU” button.
Make your selection with the “SELECT” button.
The factory settings are highlighted below.

20
N4- ATTRACT TIMING
N5- TICKET PATTERN
N6- MERCY TICKETS
OFF 30
SEC.
1
MIN.
5
MINS.
10
MINS.
15
MINS.
1 2 3 4 5 CUSTOM
Scroll through the N4 menu with the “MENU” button.
Make your selection with the “SELECT” button.
The factory settings are highlighted below.
This setting determines how often the attract loop audio is played.
Scroll through the N5 menu with the “MENU” button.
Make your selection with the “SELECT” button.
The factory settings are highlighted below.
SEE PAGES 27-28 FOR TICKET PATTERNS
Scroll through the N6 menu with the “MENU” button.
Make your selection with the “SELECT” button.
The factory settings are highlighted below.
ADJUSTABLE IN INCREMENTS OF 1
0
(OFF) TO 10 0
DEFAULT
