SERVICE MANUAL

2
FACTORY CONTACT INFORMATION
All games are proudly manufactured at our factory in Pulaski, Wisconsin, USA
SALES
Phone: [phone]
Fax: [phone]
Email: [e-mail]
PARTS
Phone: [phone] Ext 1101
Fax: [phone]
Email: [e-mail]
SERVICE
Phone: [phone] Ext 1102
Fax: [phone]
Email: [e-mail]
Open Monday - Friday
8 AM - 5PM C.S.T.
BAY TEK ENTERTAINMENT
Pulaski Industrial Park
1077 East Glenbrook Drive
Pulaski, WI 54162 USA
SIGN UP TO RECEIVE OUR E-MAILS!
Stay up to date on the latest game information, new products launches, early notification of
parts specials, updates of retro fit parts, software upgrades, best practices and more!
Visit baytekent.com and enter your email to sign up!
You can also register your new game at baytekent.com/register

3
TABLE OF CONTENTS
FACTORY CONTACT INFORMATION ……..…………………………. 2
TABLE OF CONTENTS...……………………………………………….. 3
WELCOME TO Connect 4 Hoops …..…………………………………. 4
GAME SPECIFICATIONS ……………………………………………… 5
SAFETY PRECAUTIONS ……………………………………………… 5
GAME SET UP ………………………………………………………. 6 - 19
HOW TO PLAY ……………………..…………………………………… 20
GAME PLAY THEORY OF OPERATION ….……………………… 20
MAIN MENU FUNCTIONS ……………………………………………. 21
VOLUME & ATTRACT ………………………………………….. 22
GAME SETTINGS ……………………………...………………… 23
PAYOUT SETTINGS …………………….………………………. 24
TICKET PATTERNS ……………………………………………… 25
STATISTICS …………………………………………….………… 25
DIAGNOSTICS ………………………………………………….. 26
CARD SWIPE INSTALLATION ……………………………………….. 27
CIRCUIT BOARD LAYOUT …………………………………………… 28
WIRING DIAGRAMS ……………………………………………… 29 - 37
DIAGNOSTICS ……………………………………………………. 38 - 43
HOOPS NOT SCORING …………………………...………………….. 44
POWER SUPPLY DIAGNOSTICS …………………………………… 45
BILL ACCEPTOR DIAGNOSTICS …………………………………… 46
I/O AUX BOARD PINOUT …………….……………………………… 46
HOW TO ADJUST PROJECTOR ……………...……………………. 47
HOW TO CHANGE SOFTWARE ……………………………………. 47
HOW TO ACCESS REAR CONTROL BOARD ……………...……. 48
HOW TO ACCESS BALL GATE MOTOR & SENSOR ……………. 48
AVAILABLE BLANKING PLATES …………………………………….. 47
DIPSWITCH SETTINGS ………………………………………………. 49
BALL GATE EXPLODED VIEW ………………………………… 50 - 51
PARTS LIST …………………...…………………………………… 52 - 53
PARTS PICTURES ………………………………….………...…… 54 - 56
DECAL DIAGRAM ……………………………………………………… 57
MAINTENANCE LOG ………………………………………………….. 58
TECHNICAL SUPPORT ……………………………………………….. 59
WARRANTY …………………………………………………………….. 59
SHIPPING CHECKLIST ……………………………………………….. 60
S
Manual 10/10/2022 - Software Version: 1.3.7

4
WELCOME TO CONNECT 4 HOOPS HD
Licensed by:
GAME INSPECTION
Please inspect the game for any damaged, loose, or missing parts.
If damage is found, please contact your freight carrier first.
Then, contact Bay Tek Entertainments’ Service Department at
[phone] Ext. 1102
Or email us at [e-mail] for further assistance.

5
SAFETY PRECAUTIONS
GAME SPECIFICATIONS
WEIGHT
NET WEIGHT 1900lbs. 862 kg
SHIP WEIGHT 2140 lbs. 971 kg
GAME DIMENSIONS
WIDTH 78" 198 cm
DEPTH 150" 381 cm
HEIGHT 138" 351 cm
SHIPPING DIMENSIONS
CONSOLE SECTION 86”x 46”x 87” 800 lbs. class 125
MIDDLE SECTION 80”x 48”x 78” 500 lbs. class 250
LOWER BACK SECTION 80”x 36”x 87” 600 lbs. class 125
UPPER BACK SECTION 80”x 36”x 68” 240 lbs. class 250
POWER REQUIREMENTS
INPUT VOLTAGE
RANGE
100 to 120
VAC 220 to 240
VAC
INPUT FREQUENCY
RANGE 60 Hz 50 Hz
MAX OPERATING CURRENT
3.3 AMPS @ 115VAC / 1.9 AMPS @ 230VAC
OPERATING TEMPERATURE
FAHRENHEIT 45 - 80 F
CELSIUS 7.2 - 26.7 C

6
CONNECT 4 HOOPS GAME SETUP
SECTION BREAKDOWN
UPPER BACK SECTION
LOWER BACK SECTION
MIDDLE SECTION
FRONT CONSOLE SECTION
TOP MARQUEE SECTION
TOP SIDE BOARD

7
Open the left (red) ticket door on the front console.
Pull out drawer slide and open the coin box.
Remove the hardware kit.
This hardware will be used to assemble the game.
CONNECT 4 HOOPS GAME SETUP
Place the Upper Back Section down flat on floor in
approximate position of final game location.
The game will arrive on 4 pallets. Please inspect the pallets for shipping damage and report
immediately to the freight company if any damage found.
Unbox the pallets and remove parts attached, referring to the Shipping Checklist on the back of
manual to verify all parts are present.
Tools Needed:
1 step ladders (12-15 foot) # 2 Phillips screwdriver bit 2 of 9/16” Wrenches
4 people # 1 Phillips screwdriver bit 7/16” Wrench
# 3 Phillips screwdriver bit # 2 Square head screwdriver bit 1” Crescent Wrench
Important:
Portions of this game are heavy, bulky and large. Assembly requires 4 people to lift heavy
components, and ladders that are tall and strong enough to position components to the top of the
game.
Place the Lower Back Section down flat on floor and push
up against the top section.
The top edge of both sections should be even and flush.
Note: Game keys are located in small cardboard box on front
console.

8
Locate the 2 of A5ME10012 middle back connector plates.
CONNECT 4 HOOPS GAME SETUP
Warning: Use 4 people to lift the top of game upward and
stand the assembled back sections upright onto the leg
leveler feet.
Install the plates on both sides of the cabinet
with 16 of the black ¼-20 X 1 Phillips head
bolts using a # 3 Phillips Head bit.
(8 per side)
Carefully slide the upright back of game into final game
position. We recommend to leave a 1-2 foot gap between
the game and the wall behind it if possible.
Place the Middle Section (Reference page 8) in position
close to the back section to connect cables before sliding into
final position.
On the left side - uncoil the USB cable - push this through the
middle cabinet section and through the front cabinet when the
time comes and plug into the motherboard.
Plug in the yellow connectors, and both pink connectors.
On the right side - connect the orange connectors.
Game standing height is 137” , but ceiling height
should be 141” to accommodate this to tip upward.
A5BOPH312

9
CONNECT 4 HOOPS GAME SETUP
Locate 2 of the A5ME10010 bottom side connector plates.
Install the plates on both sides of the cabinet with the black
¼-20 X 1 Phillips head bolts using a # 3 Phillips Head bit.
(10 per side)
Note: If the holes do not line up - adjust the leg leveler feet on the cabinet
using 1” Crescent Wrench.
Place the front Console Section in position close to the middle section to
install uprights and connect top marquee.
Locate the AAME10000-2 Back Left Pole
Line up the back left pole and test fit on the outside
of the cabinet. It will have the white plastic toward
the outside and rear of the cabinet.
Welded T-nuts to the outside of cabinet.
Once the correct pole is selected, feed the 2 cables
down into the hole in the left corner of the cabinet.
Slide pole down into the hole and line up the holes
in the cabinet with the pole.
Hand thread 2 of 3/8-16 X 1 1/2“ bolt with 3/8”
washer to get both started, then tighten both using
a 9/16” wrench.
A5BOPH312
A5SCHH010
Feed the 2 cables from the pole down and connect the
ground cable and the non-colored connectors at the bottom of cabinet.
A5WAFL050

10
CONNECT 4 HOOPS GAME SETUP
Locate the AAME10000-1 Back Right Pole
Feed the 2 cables down into the hole in the right corner of
the cabinet. Slide pole down into the hole and line up the
holes in the cabinet with the pole.
The white plastic must be toward the outside of the cabinet.
Locate the AAME10000-4 Front Left Pole This left pole will have the HDMI cable inside.
Feed the 4 cables down into the hole on the left corner
of the cabinet. Ensure to route the male side of HDMI
cable into the hole first to ensure the correct end of
pole is being used.
Slide pole down into the hole and line up the bolt holes
in the cabinet with the pole.
Open the front left ticket door, slide out ticket tray a bit, and connect the 4
cables to the cables near door hinge.
Clip cables into wire holder above ticket tray so they do not interfere with
ticket tray sliding in and out.
Excess cable can now be pulled up into pole and will end up in the top
marquee sign.
Hand thread 2 of 3/8-16 X 1 1/2“ bolt with 3/8”
washer to get both started,
then tighten both using a
9/16” wrench.
Hand thread 2 of 3/8-16 X 1 1/2“ bolt with 3/8”
washer to get both started, then tighten both using
a 9/16” wrench.
Feed the 2 cables from the pole down
and connect the ground cable and the
non-colored connectors.
A5SCHH010 A5WAFL050
A5SCHH010 A5WAFL050

11
CONNECT 4 HOOPS GAME SETUP
Locate the AAME10000-3 Front Right Pole. This right pole will have the AC power cord
inside.
Feed the 3 cables down into the hole on the right corner of the cabinet.
Ensure to route the male side of power cable into the hole first to
ensure the correct end of pole is being used.
Slide pole down into the hole and line up the bolt holes in the
cabinet with the pole.
The game will now look like this:
The front console with poles is separated from the rear 2
sections.
Close and lock both ticket doors and remove keys.
The front console with poles will be laid down on it’s front to
install the top marquee.
Once the front marquee is attached, the front console will be
tilted back up in place and will be unstable until attached to
the rear sections.
It is very important to have 4 people ready to hold in
position until it is secured!
Hand thread 2 of 3/8-16 X 1 1/2“ bolt with 3/8”
washer to get both started, then tighten both using
a 9/16” wrench.
Open the front right ticket door, slide out ticket tray a bit,
and connect the 3 cables to the cables near door hinge.
Clip cables into wire holder above ticket tray so they do not
interfere with ticket tray sliding in and out.
Excess cable can now be pulled up into pole and will end
up in the top marquee sign.
A5SCHH010 A5WAFL050

12
CONNECT 4 HOOPS GAME SETUP
Tilt the front console down and lay on it’s face.
Place the top large marquee in position as shown:
Place the smaller marquee in position
onto the 2 previously installed bolts in
the large marquee.
Hand thread the 2 remaining 1/4-20 X 1 1/2” bolts with 1/4”
lock washers into the 2 lower holes in the large marquee to get
started, then tighten all 4 bolts using a 7/16” wrench.
Plug in the 2 connectors, it does not matter which connector plugs into
which socket.
Place marquee on it’s face and position close to the
poles coming from the front console.
Position large marquee in front of game and hand
thread 2 of 1/4-20 X 1 1/2” bolts with 1/4” lock washers
into the 2 upper holes. Leave about 1/2” of bolt so that
the smaller marquee can be placed over the heads of
the bolts.
A5BOHH060 A5WASI020
A5BOHH060 A5WASI020

13
CONNECT 4 HOOPS GAME SETUP
Using 4 people - raise the front poles of the front console
and position on top of the top marquee.
Slide the top marquee into the front poles.
The front console will be at an angle as shown.
The 2 front poles will slide into the white
plastic mounting guides.
Secure top marquee to the front poles using
4 of 3/8-16 X 4 bolts - reach inside plexi
side to tighten with 3/8” washers and 3/8-16
nylon nuts using a 9/16” wrench.
Game will now
look like this.
On the right side of marquee - connect the AC power cord and
white connectors. Feed excess cable length into the marquee
itself.
On the left side of marquee - connect the blue colored
connectors together, and plug the brown colored connectors
together. Feed excess cable length into the marquee itself.
This one connector and coiled wire will be left unplugged for
now.
Secure the left and right plexi to the top marquee
with 8 of 4 X 1/2”small black screws using a #1
Phillips screwdriver.
A5BOHH096
A5NUNY070
A5NUNY070
A5WALO010
A5SCPH030

14
CONNECT 4 HOOPS GAME SETUP
Warning! At this time, the front console with top marquee is ready to be stood upright.
The assembly will be unstable until attached to the rear sections.
It is very important to have 4 people ready to hold in position until it is secured!
Lift the marquee and stand the front console upright and position
close to the rest of game to connect cables before sliding into
final position.
On the left side - connect the 4 connectors: USB cables, green, and gold
connectors.
On the right side - connect the white colored connectors.
Locate the 2 remaining A5ME10010 bottom side connector plates.
Note: If the holes do not line up - adjust the leg leveler feet on the cabinet.
Install the plates on both sides of the cabinet with the black
¼-20 X 1 Phillips head bolts using a # 3 Phillips Head bit.
(10 per side)
A5BOPH312

15
CONNECT 4 HOOPS GAME SETUP
Locate the 4 roof side boards.
Match the left back board to the left front
board - There will be an “L” carved into the
back of the wood to be used.
Locate a A5ME10011 top side connector plate.
Install the plate with 8 of the black ¼-20 X 1 Phillips head
bolts using a # 3 Phillips Head bit.
*** Repeat this process for the top right roof side. ***
Flip the assembled roof side upside-down so that the decal is
facing down. Place metal rail on long straight edge of the
wood and match up pilot holes with the metal bracket.
Ensure the “L” is positioned to the inside of the wood as
shown.
Locate both A5ME10013 long roof metal side rails.
Install the rail with 11 of the black 10 X 5/8” screws using a
# 2 Square Head bit.
*** Repeat this process for the top right roof side. ***
A5BOPH312
A5SCPH150

16
CONNECT 4 HOOPS GAME SETUP
Bring the left side board up into position and set on top white plastic
on back left pole.
Line up holes in side board with back left pole.
Locate a A5ME10011 top side connector plate.
Install the plate with 8 of the black ¼-20 X 1 Phillips head
bolts using a # 3 Phillips Head bit.
*** Repeat this process for the top right roof side. ***
Using 3 people - the side boards can now be installed on the top of the cabinet.
We recommend 2 people inside the cabinet to hold each side and
one person on a ladder outside the cabinet to insert the bolts.
Hand thread 2 of 3/8-16 X 1 1/2“ bolt with 3/8” washers to get
both started.
Go to the front left pole and
align the holes in the wood to the metal pole.
Hand thread 2 of 3/8-16 X 1 1/2“ bolt with 3/8” washers to get
both started.
All 4 of the bolts on the front poles can now be tighten using a 9/16”
wrench.
A5BOPH312
A5SCHH010
A5WAFL050
A5SCHH010 A5WAFL050

17
CONNECT 4 HOOPS GAME SETUP
Bring a cage to the side of the cabinet and pass it to a
person inside the cabinet to install. There are brackets
and plastic spacers attached to each of the 4 corners.
Locate both AAME10019 Side Metal Cages
These are interchangeable - it does not matter which side goes where.
*** Repeat this process for the other side cage. ***
Locate 3 of WACA10000 Game Roof Boards
Place on top of game in the channel created by “L” brackets.
Ensure the T-nuts are facing upward.
Align holes in wood with holes in metal “L” bracket.
Install each board with 4 of the black ¼-20 X 1 Phillips head bolts using a
# 3 Phillips Head bit.
The bolt is screwed in from under the metal bracket, upward into the wood
and T-nut.
*** Repeat this process for the 2 other roof boards. ***
Snip the wire tie on the coiled cable in front left side of game. Uncoil
the cable along the top left side of game and plug into the
connector at the rear left of cabinet.
Install cage using black # 10 screws using a # 2 Square Head bit.
3 screws in each corner, total of 12 screws per side.
A5BOPH312
A5SCPH152

18
CONNECT 4 HOOPS GAME SETUP
Locate the WACA10091 Clear Acrylic ball guard.
Remove the protective paper from both sides of the Acrylic plexi.
The flat edge bottom of the plexi will fit into the
groove between the white plastic and wood lip.
Slide acrylic plexi into place.
Hand thread 8 of 10-24 X 1 Phillips bolts with
3/16 X 3/4” lock washer and 3/16 X 3/4” fender
washer to get all started, then tighten all using a
#2 Phillips screwdriver bit.
To plug in game:
Remove power cord from small cardboard box. There are 2 options to access line filter socket:
Option #1:
If you have access to the back of the game, remove the 4
bolts using a 7/16” wrench.
Remove back panel.
Reach to the left to plug the power cord into the line filter.
Option #2:
If you do not have access to the back of the game, climb
inside the cabinet and remove the floor panel by removing
the 10 screws using a #2 Square bit.
Climb down under the cabinet to the right and plug the
power cord into the line filter.
Power on game:
Open the front middle door and turn on rocker switch on
the power strip.
Note: The protective pa-
per should be removed by
the time the screws are insert-
A5WASI020 A5WAFE010
A5BOPH210

19
Allow game to boot up and inspect the picture quality. The projector may need to be adjusted.
CONNECT 4 HOOPS GAME SETUP
If the screen picture is out of focus or too small, reach up
into the marquee opening where the projection is emitted.
There are 2 levers on the projector.
One is for focus, the other for zoom.
If the screen picture is off to the side or height is off, the wood box holding the projector will have to
be adjusted. This is not common.
Remove the small front marquee and unlock and open the front door
in the marquee.
Loosen these bolts to adjust the projector up and down.
Loosen these bolts to adjust the projector left and right.
Ensure the USB cable from the rear controller board is plugged into any of the USB slots on the
motherboard.
The game is now set up and ready for play!
Enter menu to adjust settings to your location specific price per play and ticket payout.

20
HOW TO PLAY
Choose a player color and insert your credits;
wait for a partner to join, or shoot a ball to
play solo!
Shoot when it is your turn.
Be the first to align 4 of your basketballs hori-
zontally, vertically, or diagonally to win!
Collect your tickets once you Connect 4!
Upon game start, the ball gate will lower to
allow the balls to flow toward player.
As the ball is thrown into the hoops, sensor
boards located behind white backboard will
see the ball as it enters the target area.
The projector mounted inside the tall front
marquee will display the information on the
white backboard.
When game is over, the ball gate will raise to
prevent further balls being released.
GAME PLAY THEORY OF OPERATION
