CLOUD 9™1182
LIFT COFFEE TABLE
DESIGN MATTHEW WEATHERLY
LET’S GET STARTED.
INSTRUCTION MANUAL

Congratulations on the purchase of your Cloud 9 Lift Coee Table 1182 from BDI. Your
coee table has been designed to provide a lifetime of enjoyment. This manual will
provide you with assembly instructions and other helpful information to ensure that you
get the most out of your product. Please save it for future reference.
Your Cloud 9 Lift Coee Table has been engineered for simple assembly. Please follow
these directions carefully to prevent any damage.
Should you need further assistance, contact BDI at [e-mail].
ENJOY!

BDIUSA.COM | 3NEED ASSISTANCE? [e-mail]
PART # C2
DESCRIPTION Top Assembly
QUANTITY 1
PART # C1
DESCRIPTION Leg Frame
QUANTITY 2
HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS
Unpack and identify the parts listed below. The assembly workspace should be a non-marring
surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at
[e-mail].
Do not use power tools for the assembly of this product.
For all other concerns, please contact your BDI retailer.
PART # T1
DESCRIPTION Hex Wrench
QUANTITY 1
PART # H2
DESCRIPTION Rubber Leveler
QUANTITY 4
PART # H1
DESCRIPTION M6 x 10mm Screw
QUANTITY 8

4 | BDIUSA.COM CLOUD 9 1182
NOTE: Do not remove the straps that are keeping
the tabletop in its closed position.
Orient the table as shown. Attach the (C1) Leg
Frames with countersunk holes facing away
from the metal box. Secure the (C1) Leg Frames
using (H1) Screws and (T1) Hex Wrench.
PART/DESCRIPTION QTY
T1-HEX WRENCH 1
H1-SCREW 8
C1
C1
C2
H1
H1H1
H1
H1
C1
DO NOT
remove these straps
Counter-sink this side
STEP 1. ATTACH LEGS TO TOP ASSEMBLYASSEMBLY

BDIUSA.COM | 5NEED ASSISTANCE? [e-mail]
ASSEMBLY
STEP 2. REMOVE STRAPS
2 PERSON TASK
With help from another person, carefully flip the table onto its base.
Remove both of the straps.
Straps facing
away from sofa
NOTICE! Objects placed in the indicated areas will interfere with the closing of the lift mechanism.
Maximum height of objects in the center storage compartment should not exceed 2 1/2" | 64mm.
FINE TUNING
Do not place
objects in
lift mechanism
area
