Bennett 3700 Series User manual

120001 Rev K 1-19-18
Bennett 1218 E. Pontaluna Road, Spring Lake, MI 49456
USA 800-235-7618 Outside USA 231-798-1310 [e-mail] www.bennettpump.com
Includes Instructions For:
All 3700 Electronic Commercial Dispensers
All 3800 Electronic Retail Dispensers
Remote Dispensers
and
Self-Contained Pumps
For new manuals, FAX to:
BENNETT MARKETING
SERVICES
[phone]
or visit our web page at:
http://www.bennettpump.com
Bennett Pump Company
Commercial and Retail Dispensers
3700/3800 Series Spec. 100 (2nd Generation)
Electronic Commercial & Retail Installation Manual
Only Trained Personnel May Work on This Equipment
READ THIS MANUAL
This manual has important information for safe installation and
operation of this equipment. Read and understand this manual
before applying power. Keep this manual and tell all service
personnel to read this. If instructions are not followed then
bodily injury, death or damage to the equipment may occur.

2120001 Rev K 1-19-18
NOTICE
Not all equipment covered in this manual is listed by Underwriters Laboratories. Only those
products that bear the Listing Mark of Underwriters Laboratories are listed.
IMPORTANT
Examine the shipment immediately upon arrival to make certain there has been no damage or loss in
transit. Bennett Pump Company, as shipper, is not liable for the hazards of transportation. Please
make damage claims directly to the truck line.
Table of Contents
Safety Instructions........................................................................................................................................................................3
Introduction for the 3000 Series Electronic Commercial and Retail Dispensers ...................................................................4
Determining the Model Number....................................................................................................................................................8
Product Specifications..................................................................................................................................................................9
Dispenser Identification Number Summary (DIN) .........................................................................................................................10
Unloading, Unpacking and Inspecting a New Dispenser...............................................................................................................12
Lifting a New Dispenser and Placing it on the Island ....................................................................................................................13
Alternative Method for Lifting the Dispenser - High Hose..............................................................................................................14
Anchoring the Dispenser to the Island ..........................................................................................................................................14
Determining the Number of Product Supply Pipes Needed...........................................................................................................15
Mechanical and Plumbing Notes ..................................................................................................................................................15
Pipe Lines and Under Ground Containment Sumps .....................................................................................................................16
Above Ground Tank Installation with Self Contained Pumps ........................................................................................................17
Electrical Field Wiring - General Information.................................................................................................................................18
Purging Product Lines for Remote Dispensers .............................................................................................................................20
Purging Product Lines for Self Contained Systems.......................................................................................................................20
Piping Notes for Self Contained Systems .....................................................................................................................................21
Wiring the 3700 Series Dispenser (Commercial)......................................................................................................................22
Determine the Number of Wires Needed ..............................................................................................................................23
Pulling the Field Wires..........................................................................................................................................................25
Installing the Wire Separator ................................................................................................................................................25
Proper Equipment Grounding ...............................................................................................................................................25
AC Power Installation ...........................................................................................................................................................26
Connecting Pump Motor Power for Remote Dispensers .......................................................................................................26
Installing RC Networks .........................................................................................................................................................27
Connecting Suction Pump Motor Power for Suction Pump Systems .....................................................................................27
Connecting the Communication Wiring.................................................................................................................................28
Connecting Field Wiring to the Mechanical Interface Board ..................................................................................................29
Pulse Output Field Wiring Table ...........................................................................................................................................30
Setting the Jumpers on the Pulse Output Board ...................................................................................................................31
CPU Board Jumper Configuration ........................................................................................................................................32
CPU Board Jumper Configuration - Diagram ........................................................................................................................33
Dispenser Startup and Checklist...................................................................................................................................................35
Potting Instructions.......................................................................................................................................................................37
How to Mechanically Calibrate the SB-100 Meter (M-Cal Option).................................................................................................38
How to Electronically Calibrate the SB-100 Meter (E-Cal).............................................................................................................39
Wiring the 3800 Series Dispenser (Retail) ................................................................................................................................41
Determining the Number of Wires Needed ...........................................................................................................................42
Pulling the Field Wires..........................................................................................................................................................44
Installing the Wire Separator ................................................................................................................................................44
Proper Equipment Grounding ...............................................................................................................................................44
AC Power Installation ...........................................................................................................................................................45
Connecting Pump Motor Power for Remote Dispensers .......................................................................................................45
Installing RC Networks .........................................................................................................................................................46
Connecting Suction Pump Motor Power for Suction Pump Systems .....................................................................................46
Connecting Communication Wiring.......................................................................................................................................47
Connecting Field Wires to the Mechanical Interface Board ...................................................................................................48
Pulse Output Field Wiring Table ...........................................................................................................................................49
Setting the Jumpers on the Pulse Output Board ...................................................................................................................50
Dispenser Startup and Checklist...................................................................................................................................................51
Potting Instructions.......................................................................................................................................................................53
How to Mechanically Calibrate the SB-100 Meter (M-Cal Option).................................................................................................54
How to Electronically Calibrate the SB-100 Meter (E-Cal).............................................................................................................55
Footprint Dimensions and Wiring Diagrams ............................................................................................................................57
Audit Form ...................................................................................................................................................................................83
PCI SSC - Legal Terms and Conditions........................................................................................................................................85
Bennett Limited Warranty for Products Installed in the United States - 3000 Retail & Commercial................................................86
Bennett International Limited Warranty for Dispensers and Pumps ..............................................................................................87

3120001 Rev K 1-19-18
DANGER: Fire, explosion, injury or
death will occur if fuel filters are changed by
untrained personnel. Make sure only trained
personnel change filters.
CAUTION: Do not drill holes in fuel
dispensers. Holes can cause failure of the
electronic equipment. The warranty will become
void. Use only adhesive backed sign mounting
brackets.
WARNING: When anchoring the
dispenser, always level the dispenser with shims
before bolting to the island. DO NOT shim just
the middle of the dispenser and bolt down.
WARNING: Make sure this equipment is
correctly grounded. Failure to do will cause
injury or damage equipment or improper
operation. Improper grounding voids the
warranty.
WARNING: You must have training in the
operation and programming of this dispenser
before using it. READ THE OPERATORS
MANUAL.
WARNING: The emergency shut-off valve
(also called the fire valve, shear valve or impact
valve) must be closed when service or
maintenance is performed on this equipment.
WARNING: Electronic components are
static sensitive. Use proper static precautions
(static straps) before working on the equipment.
WARNING: To prevent electric shock,
keep the electrical parts of the dispenser dry.
WARNING: You must have training in the
installation, service or maintenance of this
equipment (dispenser, pump, console, control
box or submerged pump) before working on it.
Maintenance repairs must be done by
authorized personnel only. Warranty work may
only be performed by Bennett certified
technicians.
DANGER: Disconnect all power to this
equipment and associated submerged pump(s)
during installation, service or any maintenance,
i.e., changing filters.
DANGER: Gasoline is flammable.
NO SMOKING OR OPEN FLAME.
DANGER: To prevent injury to you from
vehicles and onlookers, always place a barrier
around this equipment before performing service
or maintenance.
WARNING ADVERTISSEMENT ADVERTENCIA
For the safe installation of this equipment, read and understand all warning and cautions. Look for these
warnings:
“DANGER” means: If you do not follow the instructions, severe injury or death will occur.
“WARNING” means: If you do not follow the instructions, severe injury or death can occur.
“CAUTION” means: If you do not follow the instructions, damage can occur to the
equipment.
READ AND UNDERSTAND ALL WARNING LABELS ATTACHED TO THE DISPENSER
Safety Instructions
IMPORTANT:All trained and licensed technicians must work in accordance to all requirements,
standards, and guidelines specified by the suppliers Environmental Standards® Health, Safety,
Security & Environment (HSSE) policies. Note: Bennett Pump highly recommends all technicians
observe HSSE policies defined by the supplier. Bennett Pump does not impose any restrictions or
additional requirements contained in Environmental Standards® Health, Safety, Security & Envi-
ronment (HSSE) policies.

4120001 Rev K 1-19-18
Standard Features
Simplified electronic computer.
Stand-alone or Interfaced to Control Device.
RS485 interface.
Exclusive eCalTM (Electronic Calibration).
Magnet activated electronic totals display.
Programmable unit of measure for US
gallons, liters, or imperial gallons.
Operates from 115/230Vac, 60/50Hz, or 380
Vac, 50Hz.
Suction pump models feature 1-HP
continuous duty motor(s).
Back lighted 1-inch LCD displays.
Satellite Outlet Connection for remotes
Singles, 1-Product Twins, or 2-Product
Twins.
Construction
Low Hose Cabinet Design.
High Hose Cabinet Design.
Front or side mount nozzle boots.
Long-life cabinet using galvanneal
components and powder coated panels.
Black end panels & top.
Black electronics door - hinged, swing down.
Red lower doors (optional colors available) -
hinged, swing out.
Heavy duty hose hook (optional internal hose
retractor available for low hose models).
Computer
Simplified. single board design electronics.
Includes CPU, power supply, display, eCal,
RS485 connection, electromechanical analog
totalizer, push-button programming switches,
wiring terminal strip.
LED Backlighting board for the LCD display.
Optical pulser.
Designed for temperature extremes—no
heaters or cooling fans required.
Long life, highly visible back lighted LCD
display, 1” (2.54cm) numerals.
Battery Backup for last sale recall during
power outage (required for resale of fuel).
Simple 2-command protocol via RS485
interface to fleet management systems
supplies pump status, pulses, volume sale &
volume totals.
Field wiring goes directly to terminal strip on
Computer (for new installations pull 72” of
wire above grade level).
Transaction display of: 999.999 for gallons,
9999.99 for liters.
Electronic hose totals of:
99999999.999 for gallons (8.3).
999999999.99 for liters (9.2).
Electromechanical totalizer 9999999
Built-in diagnostics with error codes.
Hydraulics
Precision Bennett SB100 Meter, 4-piston,
positive displacement design.
Type 75 or type 75-HD Bennett sliding vane
pumping unit with integral vortex air
eliminator.
SB100 meter is electronically calibrated
(eCal). Mechanically calibrated meter is
optional.
All remote units include built-in inlet check
valves to keep the hydraulics full and prevent
meter/pulser count-up when the submersible
pump pressurizes the system.
Remote units use replaceable paper filter
cartridge.
Suction pumps use a reusable strainer.
All units feature 1” hose outlets
Suction units include 1-1/2” ground joint
union and riser pipe. Union & riser pipe not
supplied for remote units.
Options
E85 alcohol blend compatibility option.
Programmable dual channel, dual hose
Pulse Output Board to interface to fleet
management systems & tank monitoring
system if RS485 is not used.
2-Stage prepay/preset electric solenoid valve
for 1-product, 1-hose or 2-product, 2-hose
suction pumps. (valve is standard on all other
models).
Internal spin-on filter & adapter for remote
models.
For high hose models: balance vapor coax
hose outlet & internal vapor return piping.
Sub pump relay 3-phase contactor.
Intercom speaker for high hose models.
Stainless steel lower doors and/or end
panels.
Stainless “All Panels” Option (lower doors,
end panels, cover for electronics
compartment).
“Super Stainless” Option is “All Panels”
option plus electronics door and grade panel
holder.
Custom lower door colors and/or graphics.
Mechanical calibration dial for SB100 meter.
Hose clamp for 5/8”, 3/4”, or 1” I.D. hose.
Explosion proof junction box for lower
hydraulic area.
380 Volt 3-Phase Motors.
Pressure regulating valve for suction pumps
with aboveground tank installation.
Internal hose retractor (low hose models).
Strainer in lieu of filter w/ or w/o cloth sack.
Hoses, nozzles, swivels.
Companion Satellites (GoPump style in low
or high hose cabinets or economy LPS style).
Satellite pipe kit installed in remote master.
For information on flow rates and
model configurations see our
Price Lists.
ULTM listed.
Certified for resale applications. The
N.T.E.P. Certificate of Conformance
is available upon request.
Specifications in this document are
subject to change without notice.
Bennett dispensers may dispense
“Av-Gas”, but cannot dispense Jet
Fuel to fuel jet aircraft.
Electronic 3000 Series SPEC. 100
Commercial Series Models (Volume Only) - Standard Flow
Units have been tested and found
to comply with the limits for a Class
A computing device in accordance
with Subpart J of Part 15 of FCC
Rules regarding radio frequency
interference.

5120001 Rev K 1-19-18
Standard Features
Simplified electronic computer.
Stand-alone or Interfaced to Control Device.
RS485 interface or current loop or dual pulse
output (i.e. 4-pulse output channels).
Exclusive eCalTM (Electronic Calibration).
Magnet activated electronic totals display.
Programmable unit of measure for US
gallons, liters, or imperial gallons.
Operates from 115/230Vac, 60/50Hz, or 380
Vac, 50Hz.
Suction pump models feature 1-HP
continuous duty motor(s).
Back lighted 1-inch LCD displays.
Satellite Outlet Connection for remotes
Singles, 1-Product Twins, 2-Product Twins.
Construction
Low Hose Cabinet Design.
High Hose Cabinet Design.
Front or side mount nozzle boots.
Long-life cabinet using galvanneal
components and powder coated panels.
Black end panels & top.
Black electronics door - hinged, swing down.
Optional color lower doors - hinged, swing
out.
Heavy duty hose hook (optional internal hose
retractor available for low hose models).
Computer
Simplified single board design electronics.
Includes CPU, power, display, eCal, RS485
or current loop connection, electromechanical
analog totalizer, push-button programming
switches, wiring terminal strip.
LED Backlighting board for the LCD display.
Optical pulser.
Designed for temperature extremes—no
heaters or cooling fans required.
Long life, highly visible back lit LCD display,
1” (2.54cm) numerals for money & volume;
1/2” (1.27cm) numerals for price-per-volume.
Battery Backup for last sale recall during
power outage (required for resale of fuel).
Simple 2-command protocol via RS485
interface to fleet management systems
supplies pump status, pulses, volume sale &
volume totals.
Current loop Bennett fuel protocol interface.
Field wiring goes directly to terminal strip on
Computer (for new installations pull 72” of
wire above grade level).
Built-in diagnostics with error codes.
Transaction display of: 999.999 for gallons,
9999.99 for liters and 6-digits for money with
programmable decimal point.
Electronic hose totals of:
99999999.999 for gallons (8.3)
999999999.99 for liters (9.2)
Electromechanical totalizer 9999999.
Hydraulics
Precision Bennett SB100 Meter, 4-piston,
positive displacement design.
Type 75 or type 75-HD Bennett sliding vane
pumping unit with integral vortex air
eliminator.
SB100 meter is electronically calibrated
(eCal). Mechanically calibrated meter is
optional.
All remote units include built-in inlet check
valves to keep the hydraulics full and prevent
meter/pulser count-up when the submersible
pump pressurizes the system.
Remote units use replaceable paper filter.
Suction pumps use a reusable strainer.
All units feature 1” hose outlets; .
Suction units include 1-1/2” ground joint
union and riser pipe. Union & riser pipe not
supplied for remote units.
Options
Debit/Credit card reader (single display per
side models only).
E85 alcohol blend compatibility option.
Programmable Dual Pulse Output Board to
interface to fleet management systems &
tank monitoring system if RS485 is not used.
2-Stage prepay/preset electric solenoid valve
for 1-product, 1-hose or 2-product, 2-hose
suction pumps. (valve is standard on all other
models).
Internal spin-on filter & adapter for remote
models.
For high hose models: balance vapor coax
hose outlet & internal vapor return piping.
Sub pump relay 3-phase contactor.
Intercom speaker for high hose models.
Stainless steel lower doors and/or end
panels.
Stainless “All Panels” Option (lower doors,
end panels, cover for electronics
compartment.
“Super Stainless” Option is “All Panels”
option plus electronics door and grade panel
holder).
Custom lower door colors and/or graphics.
Mechanical calibration dial for SB100 meter.
Hose clamp for 5/8”, 3/4”, or 1” I.D. hose.
Explosion proof junction box for lower
hydraulic area.
380 Volt 3-Phase Motors.
Local Preset (attendant preset)
Pressure regulating valve for suction pumps
with aboveground tank installation.
Internal hose retractor.
Strainer in lieu of filter w/ or w/o cloth sack.
Hoses, nozzles, swivels.
Companion Satellites (GoPump style in low
or high hose cabinets or economy LPS style).
Satellite pipe kit installed in remote master.
Satellite in use light for remote master.
For information on flow rates and
model configurations see our
Price Lists.
ULTM listed.
Certified for resale applications. The
N.T.E.P. Certificate of Conformance
is available upon request.
Specifications in this document are
subject to change without notice.
Bennett dispensers may dispense
“Av-Gas”, but cannot dispense Jet
Fuel to fuel jet aircraft.
Units have been tested and found
to comply with the limits for a Class
A computing device in accordance
with Subpart J of Part 15 of FCC
Rules regarding radio frequency
interference.
Electronic 3000 Series SPEC. 100
Retail Series Models (Money & Volume) - Standard Flow

6120001 Rev K 1-19-18
Hydraulics
Rotary meter rated at 70gpm maximum.
Built-in inlet check valves to keep the
hydraulics full and prevent meter/pulser count
-up when the submersible pump pressurizes
the system.
1-1/2” 2-Stage prepay/preset electric
solenoid valve.
Dual spin-on filters
1-1/4” elbow hose outlet(s) with 1-1/4” x 1”
reducer bushing.
Note: Union & riser pipe not supplied for
remote units.
Self-Contained unit available (up to 40gph)
Options
Programmable dual channel, dual hose
Pulse Output Board to interface to fleet
management systems & tank monitoring
system if RS485 is not used.
Sub pump relay 3-phase contactor.
Intercom speaker for high hose models.
Explosion proof junction box for lower
hydraulic area.
Stainless steel lower doors and/or end
panels.
Stainless “All Panels” Option (lower doors,
end panels, cover for electronics
compartment).
“Super Stainless” Option is “All Panels”
option plus electronics door and grade panel
holder.
Custom lower door colors and/or graphics.
Hoses, nozzles, swivels.
Satellite-in-use light(s) for remote master.
Satellite pipe kit installed in remote master.
Companion Satellites (Full size Big Fueler
styling in low or high hose models. Singles
or Duals, One or two sided. Note: a dual
can be one or two sided.).
Companion Satellites (LPS Economy low
hose models in single or dual style. Note:
Duals are two sided only.).
For further details about satellite models, see
our Product Cut Sheet for Satellites.
Standard Features
Simplified electronic computer.
Stand-alone or Interfaced to Control Device.
RS485 interface.
Exclusive eCalTM (Electronic Calibration).
Magnet activated electronic totals display.
Programmable unit of measure for US
gallons, liters, or imperial gallons.
Operates from 115/230Vac, 60/50Hz, or 380
Vac, 50Hz.
Back lighted LCD displays.
Satellite Outlet Connection.
Remote dispensers only.
Single Master, dual master, master/satellite
combination, & master-master/satellite-
satellite dual combination.
Field configurable for single point or
simultaneous master & satellite fueling.
Construction
Low Hose Cabinet Design.
High Hose Cabinet Design
Front or side mount nozzle boots.
Heavy duty lift-to-start nozzle boots
accommodate high speed truck stop nozzles.
Long-life cabinet construction using
galvanneal components and powder coated
panels.
Black end panels & top.
Black electronics door - hinged, swing down.
Green lower doors (optional colors available)
- hinged, swing out.
Heavy duty hose hook for low hose models.
Computer
Simplified single board design electronics.
Includes CPU, power supply, display, eCal,
RS485 connection, electromechanical analog
totalizer, push-button programming switches,
wiring terminal strip.
LED Backlighting board for the LCD display.
Magnetic drive, tamper-proof pulser.
Designed for temperature extremes—no
heaters or cooling fans required.
Long life, highly visible back lighted LCD
display, 1” (2.54cm) numerals.
Battery Backup for last sale recall during
power outage (required for resale of fuel).
Simple 2-command protocol via RS485
interface to fleet management systems
supplies pump status, pulses, volume sale
and volume totals.
Field wiring goes directly to terminal strip on
Computer (for new installations pull 72” of
wire above grade level).
Computer (cont’d)
Transaction display of: 999.999 for gallons,
9999.99 for liters.
Electronic hose totals of:
99999999.999 for gallons (8.3)
999999999.99 for liters (9.2)
Electromechanical totalizer 9999999.
Built-in diagnostics with error codes.
For information on flow rates and
model configurations see our
Price Lists.
ULTM listed.
Certified for resale applications. The
N.T.E.P. Certificate of Conformance
is available upon request.
Specifications in this document are
subject to change without notice.
Bennett dispensers may dispense
“Av-Gas”, but cannot dispense Jet
Fuel to fuel jet aircraft.
Units have been tested and found
to comply with the limits for a Class
A computing device in accordance
with Subpart J of Part 15 of FCC
Rules regarding radio frequency
Electronic 3000 Series SPEC. 100
Commercial Big Fueler Series Models (Volume Only) - High Flow

7120001 Rev K 1-19-18
Computer (cont’d)
Transaction display of: 999.999 for gallons,
9999.99 for liters and 6-digits for money with
programmable decimal point.
Electronic hose totals of:
99999999.999 for gallons (8.3)
999999999.99 for liters (9.2)
Electromechanical totalizer 9999999.
Hydraulics
Rotary meter rated at 70gpm maximum.
Built-in inlet check valves to keep the
hydraulics full and prevent meter/pulser count
-up when the submersible pump pressurizes
the system.
1-1/2” 2-Stage prepay/preset electric
solenoid valve.
Dual spin-on filters
1-1/4” elbow hose outlet(s) with 1-1/4” x 1”
reducer bushing.
Note: Union & riser pipe not supplied for
remote units.
Self-Contained unit available (up to 40gph)
Options
Local Preset (Attendant Preset)
Debit/Credit card reader (single display per
side models only).
Programmable Dual Pulse Output Board to
interface to fleet management systems &
tank monitoring system if RS485 is not used.
Sub pump relay 3-phase contactor.
Intercom speaker for high hose models.
Explosion-proof junction box for lower
hydraulic area.
Stainless steel lower doors and/or end
panels.
Stainless “All Panels” Option (lower doors,
end panels, cover for electronics
compartment.
“Super Stainless” Option is “All Panels”
option plus electronics door and grade panel
holder).
Custom lower door colors and/or graphics.
Hoses, nozzles, swivels.
Satellite-in-use light(s) for remote master.
Satellite pipe kit installed in remote master.
Companion Satellites (Full size Big Fueler
styling in low or high hose models. Singles
or duals, one or two sided. Note: a dual can
be one or two sided).
Companion Satellites (LPS Economy low
hose models in single or dual style. Note:
duals are two sided only).
For further details about satellite models, see
our Product Cut Sheet for Satellites.
For information on flow rates and model
configurations see our Price Lists.
Standard Features
Simplified electronic computer.
Stand-alone or Interfaced to Control Device
(e.g. Trendar, VeriFone).
RS485 interface or current loop or dual pulse
output (i.e. 4-pulse output channels).
Exclusive eCalTM (Electronic Calibration).
Magnet activated electronic totals display.
Programmable unit of measure for US
gallons, liters, or imperial gallons.
Operates from 115/230Vac, 60/50Hz, or 380
Vac, 50Hz.
Back lighted 1-inch LCD displays.
Satellite Outlet Connection.
Single Master, dual master, master/satellite
combination, & master-master/satellite-
satellite dual combination.
Field configurable for single point or
simultaneous master & satellite fueling.
Construction
Low Hose Cabinet Design.
High Hose Cabinet Design.
Front or side mount nozzle boots.
Heavy duty lift-to-start nozzle boots
accommodate high speed truck stop nozzles.
Long-life cabinet using galvanneal
components and powder coated panels.
Black end panels & top.
Black electronics door - hinged, swing down.
Optional color lower doors - hinged, swing
out.
Heavy duty hose hook for low hose models.
Computer
Simplified single board design electronics.
Includes CPU, power, display, eCal, RS485
or current loop connection, electromechanical
analog totalizer, push-button programming
switches, wiring terminal strip.
LED Backlighting board for the LCD display.
Magnetic drive, tamper-proof pulser.
Designed for temperature extremes—no
heaters or cooling fans required.
Long life, highly visible back lit LCD display,
1” (2.54cm) numerals for money & volume;
1/2” (1.27cm) numerals for price-per-volume.
Battery Backup for last sale recall during
power outage (required for resale of fuel).
Simple 2-command protocol via RS485
interface to fleet management systems
supplies pump status, pulses, volume sale &
volume totals.
Current loop Bennett fuel protocol interface.
Field wiring goes directly to terminal strip on
Computer (for new installations pull 72” of
wire above grade level).
Built-in diagnostics with error codes.
Certified for resale applications. The
N.T.E.P. Certificate of Conformance
is available upon request.
Specifications in this document are
subject to change without notice.
Units have been tested and found
to comply with the limits for a Class
A computing device in accordance
with Subpart J of Part 15 of FCC
Rules regarding radio frequency
interference.
Electronic 3000 Series SPEC. 100
Retail Big Fueler Series Models (Money & Volume) - High Flow

8120001 Rev K 1-19-18
Determine the model number of the dispenser from the serial plate located on the dispenser. Utilizing
the chart below determine the features of the dispenser to be installed. Understanding the features of
the dispenser to be installed will be helpful in understanding the proper installation of the dispenser.
How a Model for the 3000 Series Dispensers is Made Up.
Pump Model Retail Commercial Electronics Flow Rate # Products # Hoses Motor
See Note 1 See Note 2
3711 X531 Package All 11
3712 X531 All 12
3722 X531 All 22
3724 X531 All 24
See Note 2
3811 X210 Package All 11
3812 X210 All 12
3822 X210 All 22
3824 X210 All 24
Note 1 - Flow Rate -
Standard - *23gpm (Remote) , 15 gpm (Self Contained)
Heavy Duty Suction - 24 gpm
Big Fueler Suction - 35 gpm (nominal with one hose active, 40 gpm total with Master and Satellite in
simultaneous flow ) with 1-1/2” valve.
Big Fueler Remote - 35 gpm (nominal with one hose active, 50 gpm total with Master and Satellite in
simultaneous flow) with 1-1/2” valve.
*Flow rates are “nominal” under ideal test conditions without accounting for system restrictions such as
hanging hardware. Actual flow rates will vary depending on conditions of installation.
Note 2 - Motor -The hydraulic arrangement can be as follows-
Remote
(submerged pump)
Standard/Heavy Duty
Suction with (1 Horse Power) Standard 1 phase 115/230 VAC 50/60 Hz
Suction with (1 Horse Power) Standard 1 phase 115/230 VAC 50/60 Hz with prepay valves
Suction with (1 Horse Power) 3 phase 380 VAC 50 Hz
Suction with (1 Horse Power) 3 phase 380 VAC 50 Hz with prepay valves
Big Fueler
Suction with (2 Horse Power) 1 phase 230 VAC 50/60 Hz with prepay valves
Suction with (2 Horse Power) 3 phase 380 VAC 50/60 Hz with prepay valves
Determining the Model Number

9120001 Rev K 1-19-18
POWER REQUIREMENTS
AC Power Input, Electronic .............................................Universal Input 85-270 Volts A.C. 50/60 Hz.
DC Power Supply Outputs .............................................+5VDC 100mA Max, +12 VDC 100mA Max.
DC Power Supply Outputs ..............................+24 VDC 1.0 Amps Max., +5 VDC Isolated 50mA Max
Nickel-Cadmium Battery Output ........................................................... +10.8 VDC, 40 Milliamp Hours
NOTE: Self-Contained dispenser 1-HP motors are set at the factory for 115V. 2-HP motors can only be
used at 230V and are not interchangeable. (Big Fueler Suction Models)
ENVIRONMENTAL REQUIREMENTS
Operating Temperature Range: .......................................................-40°C to +65°C (-40°F to +149°F)
Humidity: ..................................................................................................................0-95% condensing
DIMENSIONS
3700/3800 Series Low Hose (height x width x depth)...................................*60” H x 30” W x 20” D
3700/3800 Series High Hose (height x width x depth)..................................*88” H x 30” W x 20” D
*Without Valance.
Product Specifications

10 120001 Rev K 1-19-18
Dispenser Identification Number Summary (DIN)
3000 Electronic - Standard Flow

11 120001 Rev K 1-19-18
Dispenser Identification Number Summary (DIN)
3000 Electronic - High Flow

12 120001 Rev K 1-19-18
Bennett dispensers are bolted to a pallet and then carefully packaged with cardboard/styrofoam liners
and a cardboard exterior carton. The entire package is then securely wrapped with plastic shrink wrap.
Use a fork lift to lift the dispenser while it is still on the pallet.
Before signing the freight delivery receipt, inspect the carton and pallet for any obvious signs of damage
that may have damaged the dispenser. If any damage is found, instruct the delivery driver to make a
notation on the delivery receipt before signing it. If possible, open the carton and inspect the dispenser
before signing the delivery receipt.
Bennett dispensers are shipped Ex-Works. This means that the title to the equipment passes to the
purchaser at the time the equipment is loaded on the truck at our factory. Freight damage claims are
the responsibility of the purchaser. Bennett will assist in preparing any damage claim, by helping
identify and price any parts necessary to make needed repairs.
Carefully remove the plastic shrink-wrap from the carton. Then carefully remove the cardboard
container and any inside liners. DO NOT DISCARD THE PACKAGING. Should the need arise to
repackage the dispenser, the cardboard packaging can be reused. Plastic shrink-wrap can be
purchased at office supply stores or industrial packaging stores.
Examine the exterior panels for any signs of freight damage. If damage is found after signing for
delivery, call the freight carrier immediately and request an inspection. DO NOT DISCARD THE
PACKAGING; the inspector will want to examine it.
Once you are sure that there is no freight damage to the exterior of the dispenser, use the door key
(wire tied to the nozzle hook) to unlock the lower door. Remove the lower door from both sides of the
dispenser. Visually examine the interior of the dispenser for shipping damage. While the dispenser is
extremely sturdy, a dispenser that has been “dropped” can suffer damage internally even while it
appears normal on the exterior.
Read the model/serial plate of the dispenser and check to confirm that the hydraulic configuration
matches the order specified.
Report any non-shipping related problems to Bennett Customer Service by mail, facsimile, telephone or
e-mail at the locations specified below:
Bennett Pump Company
Customer Service Services
1218 East Pontaluna Road
Spring Lake, MI 49456
Telephone from USA 1-800-423-6638
Telephone from outside USA 231-798-1310, Extension 287 or 269
Facsimile: 231-799-6202
Email: [e-mail]
Website: www.bennettpump.com
For new manuals, visit our web page at www.bennettpump.com
Unloading, Unpacking, and Inspecting a New Dispenser

13 120001 Rev K 1-19-18
The dispenser is bolted to a pallet with bolts and nuts. With the lower doors removed and safely stored
away, remove the nuts and bolts that secure the dispenser to the pallet as shown in figure 1 and figure
2.
Thread two lifting straps (900 lbs. Capacity each minimum) through the dispenser as shown in figure 3
and figure 4. Be careful not to allow the straps to go under any of the hydraulic castings such as the
meter outlet, copper tubes or valves. The straps should be lifting only against the front and rear chassis.
Use a forklift or pallet lifting device with the forks spread wider than the pump and gently lift the
dispenser. This lifting method will also work on the high hose dispenser. Place the dispenser gently on
the island using care to line up the base anchor bolt holes with the anchor bolts embedded in the
concrete island.
WARNING: Lift only to the height required to set the dispenser on the island. Keep hands
and feet clear of the dispenser while it is suspended in the air.
Figure 4 - Front View - Using lifting
straps to lift and move the dispenser.
Figure 3 - Side View - Using lifting
straps to lift and move the dispenser.
Notice the forks are spread wider than
the pump.
Figure 1 - Unlock the lower door with the keys
that come with the unit. Swing the door open 90
degrees and lift.
Figure 2 - Remove the door and store in a safe
place until it is ready to be re-installed.
Lifting a New Dispenser and Placing it on the Island

14 120001 Rev K 1-19-18
Lifting the Dispenser from Above - On the high hose models, there are lifting brackets provided in the
upper area of the dispenser. There is a cover that has to be removed to access these brackets. (See
figure 5 and figure 6 below).
Figure 5 - Cover is screwed onto the top of the dispenser
and must be removed to access the lifting brackets. Figure 6 - After the top cover is removed, the lifting brack-
ets can be accessed for lifting the dispenser from above.
The dispenser must be bolted firmly to the concrete island. The dispenser base is provided with anchor
bolt holes (see base drawings in back of this manual for dimensions). Anchor bolts embedded in the
concrete island must be not less than ½” diameter. The threaded ends of the anchor bolts should
project 1-1/2” above the concrete.
On the Low Hose dispenser, 2 anchor bolts required minimum.
On the High Hose dispenser, 4 anchor bolts required minimum in the outer 4 mounting holes.
Refer to the Footprint Drawings in the back of this manual for hole locations.
When anchoring the dispenser, always level the dispenser with shims before bolting to the island. Place
the shims at the location of the anchor bolts so the dispenser frame is not distorted when the anchor
bolts are tightened down.
Lifting a New Dispenser and Placing it on the Island
Alternate Method for High Hose
Anchoring the Dispenser to the Island

15 120001 Rev K 1-19-18
Step 1: Determine the type of supply line needed from the model number’s 7th position on the
serial tag. If the model number is 3711SNR (Note the R) the dispenser will require a submerged pump
and pressurized supply line for each product. If the model number is 3711SNS (Note the S) the pump
will require a suction supply line for each product.
Step 2: Determine the number of product pipes required by finding the model number below.
Model Number Product Supply Lines Required
3711 / 3811 Use 1 product line plumbed to position 1.
3712 / 3812 Use 1 product line plumbed to position 1.
3722 / 3822 Use 1 product line plumbed to position 1 and 1 product line plumbed to position 2.
*Refer to base drawings in the back of this manual for product inlet locations.
Pipe Size - The 3000 Series do not come with an inlet pipe or joint. The customer is responsible for the
1 1/2” NPT inlet pipe. These will thread directly into the inlet casting (see figure 7, figure 8 and figure 9).
Determining the Number of Product Supply Pipes Needed
For remote dispensers, a U.L. Listed Emergency Shut Off Valve is required for each product inlet. The
Emergency Shutoff Valve can be referred to as an “Impact Valve”, “Safety Valve”, “Shear Valve”,
“Crash Valve”, or “Fire Valve”. The Emergency Shut Off Valve must be supported by the island frame or
containment sump frame. Follow all instructions contained in the valve’s installation manual and
observe all national, state, NFPA, and local codes.
For self-contained
(suction) pumps, a
vertical check valve is
required under each
of the pump’s ground
joint unions for the product inlet. The vertical check valve ensures that the
pump’s hydraulic system remains full of product, and it is necessary to
maintain the “prime” of the suction line so that liquid product does not drain
back to the tank. Follow all instructions contained in the vertical check
valve’s installation manual and observe all local codes.
Product inlet locations and dimensions are on the footprint foundation
drawings in this manual.
Listed ground joint union must be installed between sheer section of
Emergency Shut Off valve and dispenser inlet. If rigid product inlet pipes
are used, they must be plumbed so no strain is exerted on the dispenser chassis caused by tightening
down the unions.
For dispensers used with companion satellites, follow all federal, state, and local codes regarding
installation of impact valves.
Install an approved emergency shut off valve, designed to close automatically in the event of severe
impact or fire exposure, in the dispenser supply line at the base of the dispenser. The valve will also
permit safe inspection and maintenance. Follow the installation instructions for the valve being
installed (see figure 10).
Mechanical and Plumbing Notes
Figure 8 - SatelliteFigure 7 - Master Big Fueler
Not Included
Figure 9 - Big Fueler Suction
Figure 10 - Shear Valve

16 120001 Rev K 1-19-18
General -
The dispenser must be mounted on a concrete foundation. Do not pour concrete around the product
pipes or electrical conduit. The use of a UL approved containment sump designed for the Bennett
Dispenser Model used is highly recommended. Follow the containment sump manufacture’s installation
instructions for proper installation. If no containment sump is used, fill the sump area with clean sand or
dirt as far up the product pipe as possible once installation is complete. Use water to pack the sand in
place (see figure 11 and figure 12) .
Figure 11 - Example of Remote Figure 12 - Example of Self Contained
NOTE: All piping must be clean of foreign debris, such as: oil, grease and shavings. All
connections must be tight to prevent leaks.
Swing joints or flex pipe must be used at the ends of the horizontal pipe between the dispenser and the
tank (see figure 13). These joints prevent leaks which might develop through ground movement from
settling of the tank, frost heaving of the ground or pump island settling. The joint under the dispenser
also aids proper alignment of the product union or coupling.
Figure 13 - Underground Piping
Pipelines and Underground Containment Sumps
NOTE: Please refer to PEI/RP100 Recommended Practices. The installation must conform to
EPA, NFPA, and State regulations for underground storage tanks.
*Acceptance Varies by State*

17 120001 Rev K 1-19-18
Bennett self contained dispensers can be used with aboveground tank installations if the following
requirements are met:
 An Underwriters (U.L.) Listed Pressure Regulating Valve designed for under-the-pump mounting is
installed for each pumping unit according to the valve manufacturer’s instructions.
 Any additional valves suggested by the Pressure Regulating Valve manufacturer are installed
according to the manufacturer’s recommendations.
 The installation must be installed and used in accordance with Federal, State, Local, and National
Electrical code NFPA #70 and Motor Fuel Dispensing Facilities and Repair Garages code NFPA
30A.
 Follow PEI/RP200 Recommended Practices for Installation of Aboveground Storage Systems.
Above Ground Tank Installation with Self Contained Pumps

18 120001 Rev K 1-19-18
Electrical Wiring Section -
For 3700 go to page 20
For 3800 go to page 38
Find the wiring diagram specific to the dispenser model for the dispenser that is being installed in the
Wiring Diagrams section. Read and follow all directions including supplemental notes contained on the
drawing.
The dispenser’s field wiring connections are in the upper electronics head (electrical enclosure ) of the
dispenser. Or, the dispenser may have been ordered with the optional explosion proof junction box
located in the lower area of the dispenser. Using the door keys shipped with the dispenser, (on side 1)
unlock the two locks on the upper electronics enclosure and open the door to access the wiring terminal
on the CPU/ Control board. If there is a junction box then wire to the terminal strip and flying leads in
the junction box. Refer to the instructions for wiring to the junction box under the “Wiring Diagrams”
section of this manual.
All field wiring must be stranded copper, oil and gas resistant (THHN) color coded, with a 600 volt
insulation rating. See wiring diagrams section for proper wire sizes. Pull 72” extra wire to reach the top
of the dispenser. Do not use wire nuts. The ends of the wires should be clean and free from oxidation.
The wire separator (supplied with the pump) must be installed on the wires as they exit the conduit
located in the electrical enclosure before the wires are terminated in the electronics enclosure. The wire
separator is needed to properly seal the conduit in the last step of installation.
Underground conduit for the field wiring must be 3/4”, rigid metal and continuous. The use of PVC
conduit is not allowed. All conduit between the building and each dispenser should be a separate
conduit run.
For Remote dispensers Bennett requires the installation of RC networks across the coil and contactors
of the sub-pump relays for proper operation of the dispenser. Failure to install the RC networks will void
Bennett’s limited warranty.
Intercom wiring must be in a separate conduit from the dispenser conduit. DO NOT install intercom
wiring in the same conduit as the dispenser wiring or else the Bennett Warranty will be voided and
improper system operation will result.
Dispenser Electronic Power must be on a separate dedicated circuit breaker. Do not put submerged
pump or self-contained pump power on this circuit breaker. Up to two dispenser may be placed on (1)
15 amp circuit breaker. No more than two dispensers per 15 amp breaker. All dispensers at the station
must be on the same phase of power.
All dispenser field wiring between the building and the dispenser for power, neutral and ground wire
conductors must not be spliced, wire nutted or shared with any other equipment. Doing so would void
the Bennett Limited Warranty. All power, neutral and ground conductors shall be run from the dispenser
to the Main Service Panel.
Follow all local, state and federal requirements for installation of vapor seals.
Electrical contractors must pull 72” of wire above the grade level to reach through the
dispenser’s conduit and into the electrical area at the top of the dispenser. Read and follow all
instructions on the wiring diagram and observe all national and local electrical codes.
Electrical Field Wiring
General Information

19 120001 Rev K 1-19-18
In instances where new dispensers are replacing old dispensers, Bennett recommends that new wiring
be pulled to each dispenser.
If existing wiring is used (not recommended) and does not reach to the dispenser electronic head (top
area) of the dispenser, the wires can be extended only if the connections are soldered, weather proof
and contained in an explosion-proof type junction box. Follow all current national and local electrical
codes for extending wire runs.
The maximum distance from the breaker panel to the dispenser is 500 feet. For self-contained units
increase the motor wire size from 14Ga to 12Ga for runs over 50 feet, increase the motor wire size from
12Ga to 10Ga for runs over 100 feet and increase the motor wire size from 10Ga to 8 Ga for runs over
250 feet.
The power for the motors in 1 h.p. self-contained standard pumps must be located on the opposite
phase from the dispenser electronic power or be connected at 230V. This is necessary to limit the
electronic noise from feeding back into the dispenser’s electronic power. Failure to observe this will
create problems with the operation of the dispenser’s computers. Note: if 230v motor power is used be
sure to set the motor switch located on the motor to the high voltage setting by moving the switch to the
high position. Note: 2 h.p. Big Fueler motors do not have an adjustment switch. They must be wired for
230vac 1 phase, or 380vac 3 phase.
WARNING: DO NOT CROSS PHASE THE DISPENSERS OR DAMAGE WILL OCCUR. When
installing more than one dispenser the remote sub-pump relay control wire from each dispenser must be
on the same phase of power or cross phasing will occur at the sub-pump relay. This means that the
electronic power for all dispensers at the site must be on the same phase.
Electrical Conduits - Make sure that each dispenser has its own electrical underground conduit. Wiring
from multiple dispensers in a single conduit is not allowed. All underground conduit should be rigid metal
and drawn up tight. The use of PVC (plastic) conduit is not allowed and may void the Bennett Warranty.
Make sure that vapor “seal offs” are properly installed on all conduits at and from each dispenser. Make
sure any intercom wiring is not run with dispenser field wiring. A separate (second) conduit must be run
if using an intercom at the dispenser.
Electrical Field Wiring
General Information (Cont’d)

20 120001 Rev K 1-19-18
Once product piping and tanks have been tested for leaks and any leak conditions have been fixed then
the remote dispenser product lines must be purged of all air that may be trapped in the lines. All
electrical connections must be made and verified at this time.
CAUTION! DO NOT USE THE DISPENSER TO PURGE AIR FROM THE PRODUCT LINES.
RUNNING THE METER IN A DRY CONDITION AND AT THE HIGH SPEEDS RESULTING FROM
PRESSURIZED AIR, WILL DAMAGE THE METER AND VOID THE BENNETT LIMITED WARRANTY.
The emergency shutoff valve contains a test port that may be used to bleed off air that may be trapped
in the product lines. Manually close the emergency shutoff valve. Do not leave this process unattended
while purging the air from the product lines. Once liquid fuel product begins to weep from the test port,
retighten the plug in the test port. If more than one dispenser is on a submerged pump product feed
line, start this purging process at the dispenser furthest from the submerged pump and work backwards
toward the submerged pump.
WARNING! Take appropriate measures to contain any product seepage from the test port.
Dispose of any spilled product in proper manner consistent with applicable laws and codes.
Manually open the emergency shutoff valve and lock it into the “on” position according to the instructions
from the valve manufacturer. Use a test prover can or other appropriate approved container to dispense
50 to 100 gallons or 175 to 350 liters through the dispenser. Begin dispensing by only slightly opening
the nozzle to allow any entrapped air in the dispenser to slowly release through the nozzle. This
prevents an over-speed pulser error.
Once the dispenser has dispensed 50 gallons of fuel, the SB100 meter should be tested for calibration.
Refer to the section in this manual for calibration procedures.
Once product piping and tanks have been tested for leaks and any leak conditions have been fixed then
the self contained (suction) dispenser product lines must be purged of all air that may be trapped in the
lines. All electrical connections must be made and verified at this time.
The pumping unit evacuates all the air in the pipe before it gets to the meter. The air is expelled through
the vent at the top of the pumping unit. Nothing but fuel should pass through the meter. The meter will
not turn until fuel enters the pump and pressurizes the system.
WARNING! Take appropriate measures to contain any product seepage from the air elimination
chamber tube. Dispose of any spilled product in proper manner consistent with applicable laws
and codes.
Use a test prover can or other appropriate approved container to dispense 50 gallons or 175 liters
through the dispenser. Begin dispensing by only slightly opening the nozzle to allow any entrapped air
in the dispenser to slowly release through the air eliminator. This prevents over-speeding of the meter.
Once the dispenser has dispensed 150 gallons of fuel, the SB100 meter should be tested for calibration.
Refer to the section in this manual for calibration procedures.
Purging Product Lines for Self Contained Systems
Purging Product Lines for Remote Dispensers
