DEIMOS BT KIT UL
QUICK REFERENCE GUIDE
Read and follow all instructions and safety procedures.•
Never let play on or walk in the automatic gate area.•
Keep all gate controls out of the reach of children.•
Stand clear of a moving gate and never cross the path of a•
moving gate.
All wiring should only be done by a qualied technician.•
Always make adjustments and connections with supply power•
turned “off”.
This document does not supersede the full instruction manual•
included with each product.
BFT U.S., Inc. 6100 Broken Sound Pkwy., N.W. Suite 14 Boca Raton, FL 33487, U.S.A.
T US: 1 877-995-8155, T: [phone], F: [phone], www.bft-usa.com, [email protected]

DEIMOS BT Kit Components ...................................... 3•
Technical specications ...................................... 3•
Spare parts ...................................... 4•
Accessories and replacement parts ...................................... 4•
Anchoring plate installation ...................................... 5•
Operator and rack installation ...................................... 6 - 7•
Wiring instructions ...................................... 8 - 10•
Battery backup installation ...................................... 11•
Control board quick programming ...................................... 12 - 13•
Menu ow chart ...................................... 14 - 15•
Wiring diagram ...................................... 16•
Troubleshooting ...................................... 17•
Notes ...................................... 18 - 19•
2 Technical Support: 1-877-995-8155
TABLE OF CONTENTS

Technical Support: 1-877-995-8155 3
THE DEIMOS BT KITS CONTAIN THE FOLLOWING COMPONENTS
A B CDE
F G H I J
Components Deimos BT KIT UL
(Ref. # R925228 00003)
A. ANCHORING HOOK 4
B. HEIGHT ADJUSTMENT PLATE 2
C. POSITIONING TEMPLATE PLATE 1
D. M10 NUT 16
E. M10 WASHER 4
F. TRANSMITTER - MITTO 2 1
G. PHOTOCELLS - FL 130B 1
H. MANUAL RELEASE KEY - CLS 1
I. LEFT AND RIGHT LIMIT SWITCH BRACKETS 1
J. OPERATOR - DEIMOS BT 1
Technical Specications:
Power supply: 120 V ac ± 10% - 60 Hz
Working torque: 14.75 lb ft
Pinion pitch: 0.157” (14 teeth)
Gate travel speed 7.9 ”/s
Limit switches Incorporated (electromechanical)
Manual operation: Release key
Cycles per day: 100
Gate length: up to 75’
Gate weight: up to1100 lbs

DEIMOS BT SPARE PARTS, ACCESSORIES AND REPLACEMENT PARTS
4 Technical Support: 1-877-995-8155
REPLACEMENT PARTS
ITEM REF. #
•OPERATOR-DEIMOSBT P925186 00002
•CONTROLBOARD-QSCDUL D111754 00001
•TRANSMITTER-MITTO2 D111750
•PHOTOCELLS-FL130B P111043 00001
•MANUALRELEASEKEY-CLS D610180
•ANCHORINGSYSTEMFORDEIMOSBT N999359
OPTIONAL ACCESSORIES
ITEM REF. #
•DIGITALKEYPAD(external)-SELETTOE P121013
•DIGITALKEYPAD(ush)-SELETTO P121012
•INTERFACEFORSELETTO-SCS1 P111376
•STEELREINFORCEDPLASTICRACK(3’3”)-CP D221073
•STEELADJUSTABLERACK(3’3”)-CVZ D571053
•18TEETHPINION(10.5”/sgatespeed) I098425
•PERSONALISEDKEYRELEASEDKNOB-MSC N999158
•RECEIVERANTENNA-AEL433 D113632
•24VdcBATTERYBACKUP P125002
1 D222262
2 D221651
5 I098401
12 I098404
12 I098501
13 I098404
13 I098425
13 I098501
14 I098404
15 I098404
16 I098434
17 I098434
18 I098512
18 I098434
19 I098434
20 I098434
21 I098434
22 I098434
23 I098434
24 I098434
25 I098434
26 I098434
27 I098417
28 I098416
29 D221904
32 D511286
34 I098417
36 I098404
36 I098417
37 I098417
40 I098416
44 I098416
45 I101102
46 I101102
47 I101102
48 I101102
49 I101102
50 I101102
51 I101102
52 I101103
58 D110941 00002
59 D221520
62 D221827
64 D221463
65 D511272
66 I098401
66 I101109
66 N999359
68 D111754 00001
69 D221826
72 D511318
73 D141382
74 D141379
75 D511184
76 I101102
77 I098417
78 I098417
79 D802089
80 D221464
81 I098401
81 I101109
81 N999359
82 I098401
82 I101109
82 N999359
91 I101111
125 I098416
134 I098416
135 I098416
136 N999359
136 N999359
136 N999359
136 N999359
136 N999359
136 N999359
137 I098435
141 I098401
141 I098421
142 I098401
142 I098421
143 I098401
143 I098421
144 I098401
144 I098421
145 I098401
145 I098421
146 I098401
146 I098421
147 I098401
147 I098421

Technical Support: 1-877-995-8155 5
ANCHORING PLATE INSTALLATION
Inspect all components of the gate to insure proper manual operation and smooth sliding.•
Gate must slide freely and smoothly throughout its travel.•
Make sure that mechanical stops preventing the gate from slipping off the upper guide when manually op-•
erated are present and sound enough.
The gate track must be horizontal and straight. Non straight track will not allow proper operation of pinion•
and rack.
STEP 1
CAUTION: Never install the rack prior to installation of the operator,
installing the rack before the operator will not allow proper mesh of
pinion and rack.
The operator has to be installed at the opening post edge.
Dig a hole for the concrete pad.•
Using provided nuts• (D), bolt the anchoring hooks (A) to the posi-
tioning template plate (C). The template plate must be positioned
all the way down to the thread of the hooks.
Measurements for the positioning of the template plate are shown•
in Fig. 1. It is required at this stage to take into consideration the
thickness of the rack as it is important to position the template
plate so that rack-template plate distance is 0.9” (rack not in-
stalled yet at the moment). For CP rack T measure is 1.57”, for
CVZrackTmeasureis1.45”.
Position the template plate in the hole, make sure it is level. The template plate must have the pinion en-•
gravingnexttothegate.Incasetheholecanbeexecutedunderthetrack,itissuggestedtoweldtwosteel
bars across the anchoring hooks and the track of the gate as shown in Fig. 2, so that if the track sags, the
concrete pad will sag too, keeping the play between pinion and rack constant over time.
Remember that cable conduits have to pass through the hole in•
the template plate. Pour concrete.
NOTE:ifaconcretepadisalreadyexisting,theinstallationcanbe
carried out simply drilling holes in the concrete pad using the tem-
plate plate as reference and anchoring the operator using chemical
anchors and threaded bars instead of anchoring hooks (chemical
anchors, threaded bars and nuts not provided).
Rack: CP -> T = 1.57”
 CVZ ->T=1.45”
Min 3.9”
0.9”T
FIG. 1
FIG. 2

OPERATOR AND RACK INSTALLATION
6 Technical Support: 1-877-995-8155
STEP 2
Position provided nuts• (D) and height adjustment plates (B) on
the anchoring hooks (A) at least 1” higher than the template
plate (C) (Fig. 3).
This clearance is very important, in case the V-tracks sags, hav-
ing no clearance prevents any future adjustment, the pinion will
bear part of the weight of the gate, leading to wear of the rack
and pinion teeth and possible damage to pinion shaft and bear-
ings.
Level height adjustment plates using the 4 lower nuts• (D).
Remove the cover of the operator• (A) and place it on the two
height adjustment plates. Slide it into its nal operating position
(pinion close to the gate).
Use provided nuts• (D) to secure the operator.
Disengage the gate by turning the release knob clock-wise until•
a “click” is heard.
CP – STEEL REINFORCED PLASTIC RACK
Start with gate in closed position.
1.
Put one end of rack section on the sprocket. Make it level and2.
mark on the gate the center of the slot (Fig. 4).
Manually slide the gate so that the mark on the gate is reach-
3.
able. Drill a hole on the gate and connect the rack to the gate us-
ing a self tapping screw (not provided). Make sure that the screw
is centered in the slot for future adjustment.
Put the rack on the pinion and slide the gate so that the other4.
end of the rack section is on the pinion, mark the center of the
slot on the gate (Fig. 5).
Manually slide the gate, drill a hole on the mark and connect the5.
second end of the rack to the gate using a self tapping screw
(not provided).
The rst section of the rack is positioned, use a third screw to6.
secure the section (at least 3 screws for section have to be used).
Repeat steps from 2 to 6 to position other sections of the rack
7.
until proper length is reached.
It is suggested to use an additional section of the rack clamped
8.
on the section which is already connected to the gate and on the
section to be connected to grant proper teeth pitch between dif-
ferent section (Fig. 6).
If needed, cut the last section to meet gate length.9.
Note: rack length must be longer than actual travel of the gate
to accommodate limit switch brackets (I)(1’6”approx.oneach
side).
FIG. 4
FIG. 6
FIG. 4
Mark and bolt
FIG. 5
Mark and bolt
FIG. 3
Min 1”

OPERATOR AND RACK INSTALLATION
Technical Support: 1-877-995-8155 7
Lower the operator using nuts so that the play between rack10.
and pinion is between 1 and 2 mm (1/16”) throughout the whole
length of the gate (Fig. 7).
Check that the gate runs smoothly throughout its whole length.11.
Check that the play between rack and pinion is optimal through-
out the whole length of the gate.
Check that the mesh of pinion and rack is correct (Fig. 8), the12.
rack teeth must engage the pinion teeth throughout their full
thickness. If not, adjust the position of the operator by sliding it
in required direction.
If needed, position of the rack can be adjusted for each section13.
changing the position of the screws in the slots.
CVZ–GALVANIZEDSTEELADJUSTABLERACK
Install provided bolts, rack nuts and washers on each section of the
rack.
Take care to tighten bolt and nuts at the center of each slot for pos-
sible future adjustment.
Proceed then the same way as CP rack for installation. Instead of
bolting the rack on the gate, rack nuts have to be welded on the gate
(Fig. 9).
In order to be able to rotate the rack, simply loosen the rack bolts.
Note: rack length must be longer than actual travel of the gate
to accommodate limit switch brackets (I)(1’6”approx.oneach
side).
STEP 3
Position the limit switch brackets• (I) so that the operator will stop
at the desired position (the operator stops when the limit switch
spring is pushed by the limit switch bracket) (Fig. 10). Limit
switch brackets are generally positioned at he two ends of the
rack.
Inertia will drive the gate a little further. At least 1” between the•
gate and the positive stop has to be granted (Fig. 11). Not provid-
ingthisclearancewillresultinpossiblejammingofthegearbox.
A power operated sliding gate must never hit gate positive stops.
If no positive stops are present they have to be installed on both•
sides.
FIG. 7
1/16”
FIG. 8
NO !! OK
FIG. 9
Welding
Rack spacer nut
Rack
Washer
Bolt
FIG. 10
FIG. 11
Min. 1”

CONNECTING THE POWER:
Connect the• line wire of the 120 volt power source to ter-
minal 34 of the Deimos BT control board.
Connect the• neutral wire of the 120 volt power source to
terminal 33 of the Deimos BT control board.
Connect the• ground wire of the 120 volt power source to
ground terminal on the motor basement. No spade con-
nector is needed, stripped wire is ne.
Wires not supplied
CONNECTING THE ANTENNA (OPTIONAL):
Connect the antenna cable to Deimos BT circuit board.•
Strip cable and connect the core wire to terminal 10 and
the shield wire to terminal 11.
CONNECTING THE PHOTOEYE (THROUGH BEAM):
Connect• #1 & #2 of the photoeye receiver to the terminal
13 & 12 of the Deimos BT control board.
Connect• #3 & #5 of the photoeye receiver to the terminal
21 & 24 of the Deimos BT control board.
Remove jumper wire on terminals 21-24.
Wires not supplied.
Connect• #1 & #2 of the photocell transmitter to the termi-
nal 13 & 12 of the Deimos BT control board.
Wires not supplied.
WIRING INSTRUCTIONS
8 Technical Support: 1-877-995-8155
neutral (white)
line (black)
ground (green)
core
shield

NOTE• : on BFT control boards safety contacts are always N.C., multiple safety devices connected to the same
contact have to be connected in series.
Command contacts are always N.O., multiple command devices connected to the same contact have to be
connected in parallel.
CAUTION: All command and safety contacts are dry contacts, giving tension to these contacts will damage
the board.
In case more than one photobeam is required, photoeyes have to be connected in series (NC contact). Fol-•
low the diagram (install receivers to avoid cross talking):
CONNECTING THE SAFETY LOOPS:
Safety loops detectors have to be connected as photoeyes, as they use the same PHOT contact (21 – 24).•
Every device connected to PHOT contact, including the safety loops, has to be a N.C. contact and will be con-
nected in series.
CONNECTING OTHER ACCESSORIES:
AccessoriessuchastelephoneentrysystemsandfreeexitloopswillbeconnectedtotheOPENcontact(21•
– 26). Every device connected to OPEN contact has to be a N.O. contact and will be connected in parallel.
AccessoriessuchasSingleButtonControlorexternalreceivercontactwillbeconnectedtotheSTARTcon-•
tact (21 – 22).
The START command operates the gate as below:
OPEN/STOP/CLOSE in sequence (3 step logic ON)
OPEN/STOP/CLOSE/STOP in sequence (3 step logic OFF)
For further details on programming the control board, refer to “Finalizing the installation” chapter at page 12.
NOTE: START-CLOSE logic has to be set to OFF for the Single Button Control to work correctly.
For further details on programming the control board, refer to “Finalizing the installation” chapter at page 12.
WIRING INSTRUCTIONS
Technical Support: 1-877-995-8155 9

CHECKING MOTOR DIRECTION:
The operator can be installed on the left side or on the right side of the drive way (depending on the sliding
gate). In order to have right direction of movement of the gate, proceed with following steps:
Turn power off and disengage the operator.•
Put the gate halfway open.•
Re-engage the operator and turn power on.•
Give a START command (a momentary jumper of terminals 21 – 22) or program a remote (see page 12 for•
details).
If the gate is closing:
Turn the power off.•
Reverse the connection of the motor and the limit switches:•
swap terminals 1 and 2
swap terminals 6 and 7
If the gate is opening:
No further steps are required and the operator is ready to be programmed.
WIRING INSTRUCTIONS
10 Technical Support: 1-877-995-8155
BLUE (-)
RED (+)
BLACK (COM)
RED (SWC)
BROWN (SWO)
RED (+)
BLUE (-)
BLACK (COM)
BROWN (SWC)
RED (SWO)

Turn the power off.•
Place batteries• (a) on the battery support base as shown
in Fig. 12. Cut a hole in the black rubber cap (b) to allow
wires in.
Run battery wire (++ red and -- black) into the provided•
black sheath. Disconnect wire on terminal 4 on the Dei-
mos BT control board and run it through the hole. Run
through the hole provided wires (marked 55, 33, ++ and
--).
Keep SBS charger• (c) loose to facilitate wiring operation. Connect wire labeled ++ to #1 on the SBS charger,
wire labeled -- to #2 on the SBS charger, wire labeled 33 to #3 on the SBS charger and to #3 on the Deimos
BT board (this wire sill share #3 on the DEIMOS BT board with transformer wire, to facilitate wiring use
provided ferrule), connect wire originally connected to #4 on the Deimos BT board to #4 on the SBS charger,
wire labeled 55 on #5 on the SBS charger and on #4 on the Deimos BT board.
Connect remaining red wire with spades at both•
ends (battery jumper in wiring diagram) to free
negative and positive pole on the batteries.
Secure the SBS charger below the board by using•
provided screw.
Connections are also reported on wiring diagram•
below:
Check that 24 Vdc polarity is respected with photocells and ac-•
cessory power supply:
When in battery mode #13 is + (positive), #12 is – (negative).
On BFT photocells #1 is + (positive), #2 is – (negative):•
Check other accessories polarity according to the manufactur-•
er’s installation manual.
BATTERY BACKUP INSTALLATION
Technical Support: 1-877-995-8155 11
55
33
55
33
_ _
++
SBS
Battery jumper
2
1
5
4
3
2
1
13
12
(-)
(-)
(-)
(+)
(+)
(+)
(a)
(b)
(c)
FIG. 12

NAVIGATING THROUGH THE MENUS:
The “• OK” button is used for: switching on the display, conrming changes to the programming, entering the
menus.
The “• +” button is used for: scrolling up the menus (go up in the menus as shown at page 14), increasing
values.
The “• -” button is used for: scrolling down the menus (go down in the menus as shown at page 14), decreas-
ing values.
The “• +” and “-” buttons pushed at the same time are used for: getting back one level in the menus, discard-
ingchangestoprogramming,exitingfromtheprogrammingmode(turningoffthedisplay).
FINALIZINGTHEINSTALLATION:
• Turnthepowerofftothecontrolboard.
• Connectanyexternalcontroldeviceaccordingtowiringdiagramonpage16.
• Turnonpowertocontrolboard.CheckredpowerlightonDeimosBTcontrolboard.
ADDING TRASMITTERS TO THE RECEIVER
Turn on the display (by pressing twice the “1. OK” button).
Scroll down (“2. -“ button) to “Radio” menu and press “OK”.
The display will show “3. Add Start”. Press “OK”.
The display will show “4. Hidden button”. Press the hidden button of the transmit-
ter you want to store as shown in Fig. 13.
The display will show “5. Desired button”. Press the button you want to activate
the gate with as shown in Fig. 14.
The display will show “6. Add Start”, repeat the procedure from step # 3 to install
other transmitters.
Switch off the display by pressing “7. +” and “-” buttons at the same time twice.
CONTROL BOARD QUICK PROGRAMMING
12 Technical Support: 1-877-995-8155
+ BUTTON
- BUTTON
OK BUTTON
FIG. 13
FIG. 14
Technical Support: 877-995-8155 13
CONTROL BOARD QUICK PROGRAMMING
NAVIGATING THROUGH THE MENUS:
• The “OK” button is used for: switching on the display, conrming changes to the
programming, entering the menus.
• The “+” button is used for: scrolling up the menus (go up in the menus as shown on page
15), increasing values.
• The “-” button is used for: scrolling down the menus (go down in the menus as shown on
page 15), decreasing values.
• The “+” and “-” buttons pushed at the same time are used for: getting back one level in the
menus, discarding changes to programming, exiting from the programming mode (turning
off the display).
FINALIZING THE INSTALLATION:
• Turn off power to the control board.
• Connect any external control device according to wiring diagram on page 17.
• Turn on power to control board. Check red power light on Libra
control board.
ADDING TRANSMITTERS TO THE RECEIVER
1. Turn on the display (by pressing twice the “OK” button).
2. Scroll down(“-”button) to “RADIO” menu and press “OK”.
3. The display will show “ADD START”. Press “OK”
4. The display will show “HIDDEN BUTTON”. Press the two front buttons
of the transmitter at the same time as shown on Fig. A.
Note: Older models will have the hidden button on the back side of the
transmitter as shown on Fig. C.
5. The display will show “DESIRED BUTTON”. Press the button you want
to activate the gate with as shown on Fig. B.
6. The display will show “ADD START” . Repeat the programming
procedure from step #3 to install other transmitters.
7. Switch off the display by pressing “+” and “-” buttons at the
same time twice.
Fig. A
Fig. B
Fig. C
NAVIGATING THROUGH THE MENUS:
• The “OK” button is used for: switching on the display, conrming changes to the programming, entering the
menus.
• The “+” button is used for: scrolling up the menus (go up in the menus as shown on page 15), increasing values.
• The “-” button is used for: scrolling down the menus (go down in the menus as shown on page 15), decreasing
values.
• The “+” and “-” buttons pushed at the same time are used for: getting back one level in the menus, discarding
changes to programming, exiting from the programming mode (turning off the display).
FINALIZING THE INSTALLATION:
• Turn off power to the control board.
• Connect any external control device according to wiring diagram on page 16.
• Turn on power to control board. Check red power light on Libra control board.
ADDING TRANSMITTERS TO THE RECEIVER
1. Turn on the display (by pressing twice the “OK” button).
2. Scroll down(“-”button) to “RADIO” menu and press “OK”.
3. The display will show “ADD START”. Press “OK”
4. The display will show “HIDDEN BUTTON”. Press the two front buttons
of the transmitter at the same time as shown on Fig. A.
Note: Older models will have the hidden button on the back side of the
transmitter as shown on Fig. C.
5. The display will show “DESIRED BUTTON”. Press the button you want
to activate the gate with as shown on Fig. B.
6. The display will show “ADD START” . Repeat the programming
procedure from step #3 to install other transmitters.
7. Switch off the display by pressing “+” and “-” buttons at the
same time twice.
Fig. A
Fig. B
Fig. C

SETTING THE FORCE
Turn on the display (by pressing twice the “1. OK” button).
Scroll down (“2. -“ button) to “Autoset” menu.
The autoset feature will automatically let the control board learn torques required to correctly operate the gate.
WARNING: Once “OK” button is pressed the gate will start to move, obstruction detection is disabled
during Autoset. Be sure that no obstacle is within the working range of the gate while Autoset is being
performed.
NOTE: the Autoset must be launched from a fully closed position. Autoset run from a different position may lead
to improper control board setting.
Press “3. OK”.Thegatewillopenandcloseautomatically.Twocycleswillbeexecuted.
At the end of the second cycle the display will show “4. OK” (Autoset successful) press “OK” (if “KO” is dis-
played, the autoset failed, usually the cause of it, is a much too heavy gate).
Turn off the display.5.
COMMON SETTINGS
Parameters:
TCA: Timer to close (sec).
Normal opening speed time: Working time (sec) at full speed during opening, after this time motor will
proceed at slow down speed).
Normal closing speed time: Working time (sec) at full speed during closing, after this time motor will
proceed at slow down speed).
Slow speed: Slow down speed: 0 (25% of full speed)
WARNING! afterchangingtheaboveparameters(exceptTCA)anAutosetisrequired.
Logics:
TCA: Auto close enabled (ON)
3 step: 3 step logic (ON)
Ibl open: Commands during opening ignored (ON).
Photoc. Open: Photocells will be ignored while the gate is opening (ON)
1 mot on: Single gate installation (ON)
Dual gate installation (OFF)
WARNING! the automation will not function properly if logic “1 mot on” is not set correctly.
CONTROL BOARD QUICK PROGRAMMING
Technical Support: 1-877-995-8155 13

MENU FLOW CHART
14 Technical Support: 1-877-995-8155
TCA (timer to close) [sec.]
(default10sec.,min3sec.,max60sec.)
Opening torque [%]
(default80%,min1%,max99%)
Closing torque [%]
(default80%.min1%,max99%)
Opening torque slow-down [%]
(default50%,min1%,max99%)
Closing torque slow-down [%]
(default50%,min1%,max99%)
Normal opening speed time [sec.]
(default15sec.,min1sec.,max120sec.)
Normal closing speed time [sec.]
(default15sec.,min1sec.,max120sec.)
SIow-down speed
(deault 0,minslowdown0,maxslowdown3)
Zone(serialconnection–requiresSCS1card)
(default0,min0,max127)
TCA (automatic closing)
Default: OFF, Enabled: ON, Disabled: OFF
3 STEP (3 step/4 step)
Default: OFF, 3 step: ON, 4 step: OFF
IBL OPEN (commands ignored on opening)
Default: OFF, Enabled: ON, Disabled: OFF
PHOTOC. OPEN (photobeam ignored on opening)
Default: OFF, Enabled: ON, Disabled: OFF
TEST PHOT (photobeam test, OFF suggested)
Default: OFF, Enabled: ON, Disabled: OFF
PRE ALARM (strobe active 3 sec. before gate movement)
Default: OFF, Enabled: ON, Disabled: OFF
HOLD TO RUN (dead man activation, continuous contact)
Default: OFF, Single op. install.: ON, Dual op. inst.: OFF
START-CLOSE (terminal 16 as CLOSE)
Default: OFF, Term. 16: CLOSE: ON, Term. 16 START: OFF
FIXED CODE (xed/rollingcodereceiver)
Default:ON,Fixedcode:ON,Rollingcode:OFF
RADIO PROG. (radio learn)
Default: ON, Enabled: ON, Disabled: OFF
LOOP (loop connection between boards – requires SCS1)
Default: OFF, Enabled: ON, Disabled: OFF
MASTER (board as “master board” – requires SCS1 card)
Default: OFF, Master board: ON, Slave board: OFF
Warning: the logic MASTER has no relation to single/dual operator installation, it is used only if serial connection with multiple boards is required.

MENU FLOW CHART
Technical Support: 1-877-995-815 5 15
AUTOSET
It automatically sets the motor torque (Motor 1 torque, Motor 2 torque, Motor 1 slow
down torque, Motor 2 slow down torque).
Note: If slow down is disabled or not reached slow down torque will not be set. After
slow down adjustment Autoset has to be carried out gain.
WARNING!: obstruction detection is disabled during Autoset. Be sure that no
obstacle is within the working range of the gate while Autoset is being performed.
ADD START
(Program a button of a remote to activate the gate)
ADD 2CH
(No effect)
READ
(Check if a remote is in the memory of the re-
ceiver and display button #)
EX:
02 t1 (remote #2, button #1)
ko (remote not in the memory)
ERASE 64
WARNING!
Removes all remotes devices
from the receiver memory.
COD RX
Displays the receiver code (required only if cloning
remotes is needed)

WIRING DIAGRAM
16 Technical Support: 1-877-995-8155
MOTOR CONNECTION
TRANSFORMER SECONDARY
TRANSFORMER PRIMARY
STROBE LIGHT CONNECTION
ANTENNA CONNECTION
UL ALARM: the contact closes after 2 consecutive obstruction detections with no limit switch activation.
Can be reset by opening the stop contact or switching off the power supply.
PHOTOBEAM TEST: it requires different wiring to be used , please refer to instruction manual.
PHOTOBEAM: it stops the gate when opened, when closed back continues opening (if gate opening) or reverses
(if gate closing).
SAFETY EDGE: it stops, reverses and halts the gate when engaged. Further command needed to move the gate.
OPEN: itopensthegatewhenclosed(eg.freeexitlooportelephone entry contact).
NEUTRAL (WHITE)
LINE (BLACK)
PARTIAL OPENING: it open the gate 3’.
START/CLOSE: it opens-closes-stops (START) or always closes (CLOSE) the gate depending on the logic setting
(default is START).
STOP & RESET: it stops the gate and UL ALARM when opened.
COMMON
COMMON
(-) 24 Vac POWER SUPPLY TO ACCESSORIES
(+)
(-) 24 Vac FAIL SAFE POWER SUPPLY:
it requires different wiring to be used , please refer to
instruction manual.
(+)
BLACK
LIMIT SWITCH CONNECTIONRED
BROWN
1
5
13
9
17
23
31
2
6
14
10
18
24
32
3
7
15
21
11
19
25
33
4
8
16
22
12
20
26
34
M
BLUE
RED
COM
FAULT
N.C.
N.O.
N.C.
N.C.
N.C.
N.C.
N.O.
N.O.
N.O.
SWO
PED
START
PHOT
OPEN
ANTENNA
SHIELD
24 Vac/dc
(180mAmax)
24 Vac/dc Vsafe
(180mAmax)
UL ALARM
N.O.
SWC
COM
COM
STOP
BAR
24Vdc/25Wmax
120 Vac power input
WARNING!: when the UL ALARM is active (#14-15 open) the board does not respond to any command. To make the board opera-
tional again, reset the board (open and close STOP terminal #21-23 or turn the power off and back on).

TROUBLESHOOTING
FAULT DIAGNOSTIC CAUSE FIX
The LED on the board is OFF Power or transformer connection is loose. Check power and transformer connections.
Mainfuse(nextto120Vacinput)isblown. Replace fuse.
Bad control board. Replace control board.
OPERATOR DOES NOT RUN
remote or single button
control (terminal 21-22) not
working. No relay clicking
audible.
STOP STOP contact is open (21 – 23). Check STOP contact connections.
PHOT PHOT contact is open (21 – 24). Check PHOT connections or obstructions
on photobeam. Check proper functioning of
connected devices.
Display blank and STRT displayed when
hitting the button
UL ALARM activated (contact 14 - 15
closed).
Reset the board (open and close STOP
contact (21-23) or turn the power off and
back on.
Logic “Test Phot” set to ON and photobeam
wired traditionally (4 wires for the receiver)
or photobeam not present.
Set “Test Phot” logic to OFF.
STRT not displayed when hitting the button Remote not programmed. Program remote (see remote program-
ming at page 12).
Remote battery out of charge (LED off on
the remote when pressing button).
Replace battery.
Motor fuse blown. Replace fuse.
Bad control board. Replace control board.
OPERATOR DOES NOT RUN
Relay clicking audible.
STRT displayed when giving the command Gearboxjammed. Disengage the operator. Move it manu-
ally. Re-engage the operator. Check limit
switch brackets adjustment to avoid further
jamming.
Bad control board. Replace control board.
Bad motor. Replace motor.
GATE OPENS BUT DOESN’T
CLOSE
OPEN OPEN contact (21-26) continuously closed
(ex.openbuttonstuck).
Open the OPEN contact.
PHOT PHOT contact is open (21 – 24). The gate
opens because photoeye is ignored on
opening in the logic setting.
Check PHOT connections or photoeye
obstructed. Check proper functioning of
connected devices.
GATE STOPS AND REVERSES
AFTER STARTING TO MOVE
AMP or BAR displayed when starting
reversing
Torque setting too low. Increase manually the torque (Motor 1
torque, Motor 2 torque, Motor 1 torque
slow-down, Motor 2 torque slow-down
in parameters section) or run another
Autoset.
Obstruction present. Remove obstructions.
GATE TIMES OUT AND OPENS
INSTEAD OF CLOSING
Motor and limit switch connection revesed. Reverse motor and limit switch connection
(see checking motor direction at page 10).
GATE DOES NOT CLOSE
AUTOMATICALLY
Automatic closing is disabled. Set automatic closing (TCA in logics sec-
tion) to ON.
OPEN OPEN contact (21-26) continuously closed
(ex.openbuttonstuck).
Open the OPEN contact.
PHOT PHOT contact is open (21 – 26). The gate
opens because photoeye is ignored on
opening in the logic setting.
Check PHOT connections or photoeye
obstructed. Check proper functioning of
connected devices.
GATE RUNS TOO SLOW Working time at normal speed is set too
low.
Increase working time at normal speed
(Normal opening and closing speed time
parameters section) to desired value.
GATE DOES NOT SLOW
DOWN
Slow down is disabled. Activate slow down (Slow-down speed in
parameters section).
Working time at normal speed is higher
than the time required to get to the full
opening/closing position.
Decrease working time at normal speed
(Normal opening and closing speed time
parameters section) to desired value.
Technical Support: 1-877-995-8155 17

NOTES
18 Technical Support: 1-877-995-8155

NOTES
Technical Support: 1-877-995-8155 19

DEIMOS BT QUICK REFERENCE GUIDE v 1.2 ENG - Apr/13/2008
DEIMOS BT
UL 325 approved by CSA•
Rack and pinion drive for smooth gate movement•
LCDdisplayprogrammingformaximuminstallationspeedandexibility•
Exhaustivediagnosticmessagesbythedisplay•
Built-in rolling code receiver•
Very compact design, control board and battery back up t in the operator•
Very energy efcient motor at only 70 W (3 amps)•
Autoset feature to quickly and simply adjust torque level on the gate•
Opening width up to 75’•
Adjustable slow down, 3 different slowdown speeds•
Battery backup available, batteries are engaged only when main power is out•
Easy manual release through triangular key•
Inherentobstructiondetectionsystemformaximumsafety•
BFT U.S., Inc. 6100 Broken Sound Pkwy., N.W. Suite 14 Boca Raton, FL 33487, U.S.A.
T US: 1 877-995-8155, T: [phone], F: [phone], www.bft-usa.com, [email protected]
Also available from BFT
Road barriers Hydraulic underground
operators
Hydraulic arm
operators
Electromechanical arm
operators
Accessories
DEIMOS BT QUICK REFERENCE GUIDE v 1.3 ENG - July 2009
