BLK BOX GOLIATH 21-0726 User manual

OWNERS MANUAL & QUICK START GUIDE
GOLIATH SMITH MACHINE ATTACHMENT
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
PRODUCT SPECIFICATION
PRODUCT WEIGHT
MAX USER WEIGHT
MAX TRAINING WEIGHT
DIMENSIONS
-77kg
150kg
200kg
1805mm x 224mm x 2215mm
-
-
-
21-0726
#MADEINBELFAST

WARNING
SPIRIT LEVEL
TOOLS REQUIRED
17MM SPANNER X2 STEP LADDER
PARTS & ATTACHMENTS
No. Name SKU QTY
1 UPRIGHT LHS 21-0795 1
2 UPRIGHT RHS 21-0796 1
3 SMITH MACHINE BAR 21-0937 1
4 CHROME SHAFT 32-0048 2
5 RUBBER STOPPER 16-0282 2
6 SAFETY STOP 21-0800 2
7 SHAFT BRACKET 21-0812 2
8 M10X90 BOLT 10-0008 8
9 M10 WASHER 10-0019 16
10 M10 NYLOCK NUT 10-0024 8
1
2
3
4
6
7
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
PLEASE BE AWARE OF THIS SYMBOL AS AN INDICATION TO CHECK THAT A PART IS LEVEL
OR PLUMB.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL.
#MADEINBELFAST
5
9
8
10

ASSEMBLY
1
REMOVE TOP CROSSMEMBER ON BOTH SIDES.
#MADEINBELFAST

2
BOLT 1QTY LHS UPRIGHT (21-0795) AND 1 QTY RHS UPRIGHT (21-0796) TO THE MIDDLE OF THE
BOTTOM CROSSMEMBER. ATTACH USING BOLT ASSEMBLIES AS SHOWN BELOW. ENSURE TO
KEEP BOLTS LOOSE TO ALLOW PLACEMENT LATER.
NOTE: ENSURE PEGS ARE FACING INWARDS.
#MADEINBELFAST
10.0008
10.0019 x2
10.0024

3
INSERT 2QTY CHROME SHAFT INTO HOLES.
#MADEINBELFAST

4
SLIDE ON 2QTY RUBBER STOPPER (16-0282), 2QTY SAFETY STOP (21-0800) AND SLIDE 1 QTY
SMITH MACHINE BAR (21-0937) ONTO 2 QTY CHROME SHAFT (32-0048).
#MADEINBELFAST

5
BOLT 1QTY SHAFT BRACKET (21-0812) TO UPRIGHTS (21-0795 & 21-0796) WITH BOLT ASSEMBLY AS
SHOWN TIGHTEN TO 30Nm.
TIGHTEN GRUB SCREW ON COLLAR HOLDING CHROME SHAFT USING AN ALLEN KEY.
#MADEINBELFAST
10.0008
10.0019 x2
10.0024

6
REPLACE 2QTY CROSSMEMBERS AND TIGHTEN TO 30Nm.
#MADEINBELFAST

7
STRAIGHTEN BOTH UPRIGHTS AND BOLT TO TOP CROSSMEMBER USING BOLT ASSEMBLY SHOWN
BELOW.
TIGHTEN ALL BOLTS TO 30Nm.
#MADEINBELFAST
10.0008
10.0019 x2
10.0024
