BLK BOX 21-0549-0A User manual

OWNERS MANUAL & QUICK START GUIDE
BINARY RACK
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
21-0549-0A
#MADEINBELFAST
628mm x 1450mm x 2212mm
2128mm x 2950mm x 3076mm
65kg
PRODUCT SPECIFICATION
PRODUCT WEIGHT
MAX USER WEIGHT
MAX USER
MAX TRAINING WEIGHT
DIMENSIONS
SAFE WORKING ZONE
-125kg
200kg
-
-
-
-
1
-
All manuals and user guides at all-guides.com

SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
PLEASE BE AWARE OF THIS SYMBOL AS AN INDICATION TO CHECK THAT A PART IS LEVEL
OR PLUMB.
WARNING
SPIRIT LEVEL
10MM MASONRY
DRILL BIT
TOOLS REQUIRED
2x 30MM SPANNER
2x 17MM SPANNER
1x 13MM SPANNER
HAMMER
HAMMER DRILL VACUUM STEP LADDER
#MADEINBELFAST
TAPE MEASURE
All manuals and user guides at all-guides.com

PARTS & ATTACHMENTS
#MADEINBELFAST
1
2
3
4
3
6
7
8
9
10
11
12
13
14
16
15
All manuals and user guides at all-guides.com

ASSEMBLY
1
PLACE THE WM STRINGER (20-0350-0A) IN A VERTICAL POSITION AGAINST THE WALL ,
PERPENDICULAR TO THE FLOOR.
MARK THE LOCATION OF THE INDICATOR ON THE WALL, USING THE POINT IN THE CENTRE
AS A GUIDE.
#MADEINBELFAST
All manuals and user guides at all-guides.com

#MADEINBELFAST
2
MOVE THE STRINGER 1200MM LEFT/RIGHT AND REPEAT STEP 1.
1200 MM
All manuals and user guides at all-guides.com

3
MARK OUT THE REST OF THE HOLES USING THE GUIDE BELOW.
#MADEINBELFAST
All manuals and user guides at all-guides.com

#MADEINBELFAST
4
CHECK THAT THE STRINGERS ARE LEVEL AND ALIGN WITH THE HOLES THAT HAVE BEEN
MARKED OUT. DRILL 10MM HOLES, 90MM DEEP. VACUUM OUT THE DUST
All manuals and user guides at all-guides.com

5
BOLT 4QTY HINGE BRACKET (21-0552-0B) TO 2QTY WM STRINGER WITH BOLTS
ASSEMBLY AS SHOWN.
#MADEINBELFAST
10-0031 x 2
10-0019 x 2
10-0019 x 2
10-0024 x 2
30
Nm
All manuals and user guides at all-guides.com

#MADEINBELFAST
6
SECURE STRINGERS TO THE WALL USING 16QTY M10 SLEEVE ANCHOR BOLTS (10-0031)
AND THE PREDRILLED HOLES.
30
Nm
All manuals and user guides at all-guides.com

7
BOLT 4QTY FOLDING RACK BOX CM (21-0551-0A) TO 2QTY UPRIGHT (21-0557-0A).
#MADEINBELFAST
10-0134 x 2
10-0023 x 2
10-0023 x 2
10-0028 x 2
10-0134 x 2
10-0023 x 2
10-0023 x 2
10-0028 x 2
All manuals and user guides at all-guides.com

#MADEINBELFAST
ENSURE THE LOGO ON UPRIGHTS ARE FACING OUTWARDS AND ALL BOLTS FACING INWARDS.
10-0134 x 2
10-0023 x 2
10-0023 x 2
10-0028 x 2
All manuals and user guides at all-guides.com

8
BOLT 4QTY BOX CM (21-0551-0A) TO 4QTY HINGE BRACKETS (21-0552-0A).
#MADEINBELFAST
10-0067 x 1
10-0019 x 1
10-0019 x 1
10-0024 x 1
All manuals and user guides at all-guides.com

#MADEINBELFAST
9
ATTACH 1QTY PULL UP BAR (21-0553-0B) WITH 2QTY UPRIGHTS USING 2QTY HITCH PINS
(16-0004)
All manuals and user guides at all-guides.com

10
LOCK UPRIGHTS IN FORWARD FACING POSITION USING 4QTY MAGNETIC LOCATING PINS
(10-0160)
#MADEINBELFAST
All manuals and user guides at all-guides.com

#MADEINBELFAST
11
TO FOLD, TAKE OUT 4QTY MAGNETIC PINS AND REMOVE THE PULL UP BAR. FOLD
UPRIGHTS INTO WALL. LOCK IN THE UPRIGHTS WITH THE 4QTY MAGNETIC PINS AND
ATTACH THE PULL UP CROSSMEMBER TO ONE OF THE BOX CM.
All manuals and user guides at all-guides.com

#MADEINBELFAST
All manuals and user guides at all-guides.com

#MADEINBELFAST
All manuals and user guides at all-guides.com

#MADEINBELFAST
1:1 SCALE FASTENERS
M20 x 100 HEX HEAD BOLT
10-0134
M10 x 100 HEX HEAD BOLT
10-0067
M10 x 30 HEX HEAD BOLT
10-0001
M10 SLEEVE ANCHOR BOLT
10-0031
All manuals and user guides at all-guides.com

FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT
www.blkboxfitness.com/pages/terms-conditions
GET IN TOUCH
TEL: [phone]
EMAIL: [e-mail]
DISCOVER MORE AT:
www.blkboxfitness.com
#MADEINBELFAST
M20 WASHER
10-0023
M20 NYLOC NUT
10-0028
M10 WASHER
10-0019
M10 NYLOC NUT
10-0024
All manuals and user guides at all-guides.com

#MADEINBELFAST
THIS IS A BLANK PAGE
