BLK BOX WEIGHTS TREE User manual

OWNERS MANUAL & QUICK START GUIDE
WEIGHTS TREE
NOTE : PLEASE READ ALL THE INSTRUCTIONS
CAREFULLY BEFORE ASSEMBLING THIS PRODUCT.
BLK BOX
PRODUCT SPECIFICATION
PRODUCT WEIGHT
MAX LOAD
DIMENSIONS
SAFE WORKING ZONE
-
982mm x 1466mm x 800mm
-
-
1082mm x 2700mm x 2400mm
#MADEINBELFAST
36kg
21-0215-0A
-
500kg

WARNING
TOOLS REQUIRED PARTS & ATTACHMENTS
No. Name SKU QTY
1 WEIGHT TREE CM 21-0254-0A 1
2 WEIGHT TREE
SUPPORT
21-0252-0A 2
3 WEIGHT TREE
UPRIGHT
21-0253-0A 1
4 M10X80 SLEEVE
ANCHOR
10-0031 4
5 M10X90 BOLT 10-0008 6
6 M10 FLAT WASHER 10-0019 16
7 M10 NYLOCK NUT 10-0024 6
4
SERIOUS OR FATAL INJURIES MAY OCCUR FROM INCORRECTLY ASSEMBLED EQUIPMENT. ALWAYS ENSURE
BOLTS ARE TIGHTENED CORRECTLY AND ALL PARTS ARE LEVEL AND PLUMB. TO FURTHER REDUCE RISK OF
INJURIES OR DEATH PLEASE USE OUR SUGGESTED TOOLS AND PERSONAL PROTECTIVE EQUIPMENT (PPE).
WE SUGGEST THAT A MINIMUM OF THREE PEOPLE ARE INVOLVED IN THE ASSEMBLY OF THIS PRODUCT.
EACH PERSON SHOULD BE EQUIPPED WITH SAFETY GLASSES, STEEL TOE CAP BOOTS AND EAR PLUGS.
THIS SYMBOL IS AN INDICATION OF THE RECOMMENDED TORQUE EACH
BOLT SHOULD BE TIGHTENED TO. THIS VALUE WILL BE DEPENDENT ON
THE BOLT TYPE. PLEASE HAND TIGHTEN ALL BOLTS UNTIL YOU SEE THIS SYMBOL.
1
2
3
5
6
7
#MADEINBELFAST
10MM MASONRY
DRILL BIT
17MM SPANNER X2
HAMMER
HAMMER DRILL
VACUUM
xx
Nm

x
4
x
2
ASSEMBLY
1
BOLT 1 QTY WEIGHT TREE CM (21-0254-0A) BETWEEN 2QTY WEIGHT TREE SUPPORTS
(21-0252-0A) AND BOLT 1QTY WEIGHT TREE UPRIGHT(21-0253-0A) TO THE CENTRE OF
THE WEIGHT TREE CM (21-0254-0A). ATTACH ALL BOLTS ASSEMBLES AS SHOWN.
ENSURE ALL BOLTS ARE FACING INWARDS.
#MADEINBELFAST
10.0008
10.0019 x2
10.0024
10.0008
10.0019 x2
10.0024

30
Nm
x
4
x4
2
TIGHTEN ALL BOLTS WITHIN THE CIRCLE TO SPECIFIED TORQUE. DRILL AND SECURE
HOLES ON WEIGHT TREE SUPPORTS (21-0252-0A)AS SHOWN IN GUIDE.
#MADEINBELFAST
10.0031
10.0019

1:1 SCALE FASTENERS
FOR TERMS AND CONDITIONS VISIT OUR WEBSITE AT
www.blkboxfitness.com/pages/terms-conditions
GET IN TOUCH
TEL: [phone]
EMAIL: [e-mail]
DISCOVER MORE AT:
www.blkboxfitness.com
M10x90 BOLT
10-0008
NYLOCK NUT
10-0024
M10 FLAT WASHER
10-0019
#MADEINBELFAST
M10x80 SLEEVE ANCHOR
10-0031

#MADEINBELFAST
